General laboratory equipment

Ohaus 30314839 12 x 1.5/2.0ml Fixed Angle Rotor The Ohaus 30314839 12 x 1.5/2.0ml Fixed Angle Rotor  (more)accommodates a capacity of up to 12 x 1.5 / 2.0 ml. This rotor is designed for use with Ohaus FC5718, FC5718R, and FC5830R series centrifuges. The Ohaus 30314839 Fixed Angle Rotor reaches a maximum speed of 30,000 RPM and a maximum Relative Centrifugal Force of 65,395 x g. INCLUDED: The Ohaus 30314839 12 x 1.5/2.0ml Fixed Angle Rotor includes: - Ohaus 30314839 12 x 1.5/2.0ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314836 30 x 1.5/2.0ml Fixed Angle Rotor The Ohaus Ohaus 30314836 30 x 1.5/2.0ml Fixed Angle  (more)Rotor accommodates a capacity of up to 30 x 1.5 / 2.0 ml. This rotor is designed for use with Ohaus FC5916, FC5916R, FC5718, FC5718R, FC5830R, and FC5720R series centrifuges. The Ohaus 30314836 Fixed Angle Rotor reaches a maximum speed of 20,000 RPM and a maximum Relative Centrifugal Force of 42,032 x g. INCLUDED: The Ohaus 30314836 30 x 1.5/2.0ml Fixed Angle Rotor includes: - Ohaus 30314836 30 x 1.5/2.0ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314833 20 x 10ml Fixed Angle Rotor The Ohaus 30314833 20 x 10ml Fixed Angle Rotor accommodat (more)es a capacity of up to 20 x 10 ml. This rotor is designed for use with Ohaus FC5816, FC5816R, FC5718, FC5718R, FC5916, and FC5916R series centrifuges. The Ohaus 30314833 fixed angle rotor reaches speeds up to 16,000 RPM with a maximum RCF of 28,045 x g. INCLUDED: The Ohaus 30314833 20 x 10ml Fixed Angle Rotor includes: - Ohaus 30314833 20 x 10ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314832 30 x 15ml Fixed Angle Rotor The Ohaus 30314832 30 x 15ml Fixed Angle Rotor accommodat (more)es a capacity of up to 30 x 15 ml. This rotor is designed for use with Ohaus FC5816, FC5816R, FC5718, FC5718R, FC5830R FC5714, and FC5720R series centrifuges. The Ohaus 30314832 Fixed Angle Rotor reaches a maximum speed of 4,500 RPM and a maximum Relative Centrifugal Force of 2,830 x g. INCLUDED: The Ohaus 30314832 30 x 15ml Fixed Angle Rotor includes: - Ohaus 30314832 30 x 15ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314831 6 x 50ml Fixed Angle Rotor The Ohaus 30314831 6 x 50ml Fixed Angle Rotor accommodates (more) a capacity of up to 6 x 50 ml. This rotor is designed for use with Ohaus FC5816, FC5816R, FC5718, FC5718R, FC5916, FC5916R, and FC5830R series centrifuges. The Ohaus 30314831 fixed angle rotor reaches speeds up to 21,000 RPM with a maximum RCF of 41,410 x g. INCLUDED: The Ohaus 30314831 6 x 50ml Fixed Angle Rotor includes: - Ohaus 30314831 6 x 50ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314829 10 x 50ml Fixed Angle Rotor The Ohaus 30314829 10 x 50ml Fixed Angle Rotor accommodat (more)es a capacity of up to 10 x 50ml. This rotor is designed for use with Ohaus , FC5718, FC5718R, FC5816, FC5816R, FC5916, and FC5916R series centrifuges, and reaches speeds up to 10,500 RPM with a maximum RCF of 16,022 x g. INCLUDED: The Ohaus 30314829 10 x 50ml Fixed Angle Rotor includes: - Ohaus 30314829 10 x 50ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314828 4 x 250ml Swing Out Rotor The Ohaus 30314828 4 x 250ml Swing Out Rotor accommodates a (more) capacity of up to 4 x 250ml. This rotor is designed for use with Ohaus FC5816, and FC5816R series centrifuges, and reaches speeds up to 4,500 RPM with a maximum RCF of 3,735 x g. INCLUDED: The Ohaus 30314828 4 x 250ml Swing Out Rotor includes: - Ohaus 30314828 4 x 250ml Swing Out Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314827 4 x 85ml Fixed Angle Rotor The Ohaus 30314827 4 x 85ml Fixed Angle Rotor accommodates (more) a capacity of up to 4 x 85ml. This rotor is designed for use with Ohaus FC5916, FC5916R, FC5816, FC5816R, FC5718, and FC5718R series centrifuges. The Ohaus 30314827 fixed angle rotor reaches speeds up to 20,000 RPM with a maximum RCF of 41,137 x g. INCLUDED: The Ohaus 30314827 4 x 85ml Fixed Angle Rotor includes: - Ohaus 30314827 4 x 85ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314826 6 x 85ml Fixed Angle Rotor The Ohaus 30314826 6 x 85ml Fixed Angle Rotor accommodates (more) a capacity of up to 4 x 85ml. This rotor is designed for use with Ohaus FC5916, FC5916R, FC5816, FC5816R, FC5718, and FC5718R series centrifuges. The Ohaus 30314827 fixed angle rotor reaches speeds up to 13,000 RPM with a maximum RCF of 21,726 x g. INCLUDED: The Ohaus 30314826 6 x 85ml Fixed Angle Rotor includes: - Ohaus 30314826 6 x 85ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314825 6 x 85ml Fixed Angle Rotor The Ohaus 30314825 6 x 85ml Fixed Angle Rotor accommodates (more) a capacity of up to 4 x 85ml. This rotor is designed for use with Ohaus FC5718, and FC5718R series centrifuges, and reaches speeds up to 13,000 RPM with a maximum RCF of 21,726 x g. INCLUDED: The Ohaus 30314825 6 x 85ml Fixed Angle Rotor includes: - Ohaus 30314825 6 x 85ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314824 2 x 3 MTP Swing Out Rotor w/ Buckets The Ohaus 30314824 2 x 3 MTP Swing Out Rotor w/  (more)Buckets accommodates a capacity of up to 2 x 3MTP. This rotor is designed for use with Ohaus FC5816, FC5816R, FC5718, FC5718R, FC5916, FC5916R, FC5714, and FC5720R series centrifuges. The Ohaus 30314824 2 x 3 MTP Swing Out Rotor reaches speeds up to 4,500 RPM with a maximum RCF of 2,716 x g. INCLUDED: The Ohaus 30314824 2 x 3 MTP Swing Out Rotor w/ Buckets includes: - Ohaus 30314824 2 x 3 MTP Swing Out Rotor w/ Buckets - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314822 4 x 145ml Swing Out Rotor The Ohaus 30314822 4 x 145ml Swing Out Rotor accommodates a (more) capacity of up to 4 x 145 ml. This rotor is designed for use with Ohaus FC5718, FC5718R, FC5714, and FC5720R series centrifuges. The Ohaus 30314822 Fixed Angle Rotor reaches a maximum speed of 4,500 RPM and a maximum Relative Centrifugal Force of 3,350 x g. INCLUDED: The Ohaus 30314822 4 x 145ml Swing Out Rotor includes: - Ohaus 30314822 4 x 145ml Swing Out Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314821 6 x 250ml Fixed Angle Rotor The Ohaus 30314821 6 x 250ml Fixed Angle Rotor accommodat (more)es a capacity of up to 6 x 250ml. This rotor is designed for use with Ohaus FC5816, FC5816R, FC5916, and FC5916R series centrifuges, and reaches speeds up to 10,000 RPM with a maximum RCF of 15,650 x g. INCLUDED: The Ohaus 30314821 6 x 250ml Fixed Angle Rotor includes: - Ohaus 30314821 6 x 250ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30314820 4 x 290ml Swing Out Rotor The Ohaus Ohaus 30314820 4 x 290ml Swing Out Rotor accommod (more)ates a capacity of up to 4 x 290 ml. This rotor is designed for use with Ohaus FC5816, FC5816R, and FC5830R, and FC5515R series centrifuges. The Ohaus 30314820 Swing Out Rotor reaches a maximum speed of 4,500 RPM and a maximum Relative Centrifugal Force of 3,780 x g. INCLUDED: The Ohaus 30314820 4 x 290ml Swing Out Rotor includes: - Ohaus 30314820 4 x 290ml Swing Out Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30130878 6 x 50ml Fixed Angle Rotor The Ohaus 30130878 6 x 50ml Fixed Angle Rotor Fixed Angle  (more)Rotor accommodates a capacity of up to 6 x 50 ml. This rotor is designed for use with Ohaus FC5706 series centrifuges. The Ohaus 30130878 Fixed Angle Rotor reaches a maximum speed of 6,000 RPM and a maximum Relative Centrifugal Force of 4,427 X g. INCLUDED: The Ohaus 30130878 6 x 50ml Fixed Angle Rotor includes: - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30130877 12 x 15ml Fixed Angle Rotor The Ohaus 30130877 12 x 15ml Fixed Angle Rotor accommodat (more)es a capacity of up to 12 x 15 ml. This rotor is designed for use with Ohaus FC5706 series centrifuges. The Ohaus 30130877 Fixed Angle Rotor reaches a maximum speed of 6,000 RPM and a maximum Relative Centrifugal Force of 4,427 X g. INCLUDED: The Ohaus 30130877 12 x 15ml Fixed Angle Rotor includes: - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30130873 12 x 5ml Fixed Angle Rotor The Ohaus 30130873 12 x 5ml Fixed Angle Rotor accommodates (more) a capacity of up to 12 x 5 ml. This rotor is designed for use with Ohaus FC5515. and FC5515R series centrifuges. The Ohaus 30130873 Fixed Angle Rotor reaches a maximum speed of 15,500 RPM and a maximum Relative Centrifugal Force of 19,978 x g. INCLUDED: The Ohaus 30130873 12 x 5ml Fixed Angle Rotor includes: - Ohaus 30130873 12 x 5ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 30130872 30 x 1.5/2.0ml Fixed Angle Rotor The Ohaus 30130872 30 x 1.5/2.0ml Fixed Angle Rotor  (more)accommodates a capacity of up to 30 x 1.5 / 2.0 ml. This rotor is designed for use with Ohaus FC5515, and FC5515R series centrifuges. The Ohaus 30130872 Fixed Angle Rotor reaches a maximum speed of 13,500 RPM and a maximum Relative Centrifugal Force of 19,150 x g. INCLUDED: The Ohaus 30130872 30 x 1.5/2.0ml Fixed Angle Rotor includes: - Ohaus 30130872 30 x 1.5/2.0ml Fixed Angle Rotor - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Ohaus 2400-11 Mechnical Scale, 16 kg, 5g Maximum Capacity 16 kg Readability 5g Platform Size 11 in ( (more)279 mm) Features - Without the restrictions of connecting the scale to an outlet, weighing can be conducted in any setting. - The large stable pan will hold oversized samples without tipping, and the weighted base keeps the entire scale extremely steady. - The portable Field Test scale can be easily moved from location to location around your work site with the integrated carrying handle. - Metal base and beam construction with stainless steel pan to ensure durability within varying weighing applicaitons. - Magnetic damping, positive load stops. The Ohaus 2400-11 Mechnical Scale, 16 kg, 5g is a powerful nine position stirrer with a capacity of 250ml per position. With precise speed control, and repeatable performance, the STMP9DG ensures that its user's vital laboratory stirring tasks are accomplished with ease and accuracy. Its analog interface additionally provides simply control for end users. This product is designed for applications including dissolution studies, titrations, media preparation, and synchronized stirring of multiple samples. INCLUDED: The Ohaus 2400-11 Mechnical Scale, 16 kg, 5g includes: - Operator's Guide - Manufacturer's Documentation - 2 Year Manufacturer's Warranty

Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (5x, 10x, 20x) PA Objectiv (more)es APO 5X, 10X, 20X Parfocality Adjustable Optical System Specialized Lenses Design For NUV to Visible NIR Illumination Port for Fiber-Optic Coaxial Illumination Features - Ergonomic Design: The design of the PSM-1000 encourages the optimal amount of usability without sacrificing comfort. - Laser Work: The PSM-1000 is standard equipped for laser work covering the spectrums ranging from 355nm [UV] to 532nm [Green] to 1064nm [IR]. - Focusing Block: Rated for load weights up to 45lbs., image focal planes can be adjusted at 1μm resolutions within the total 50mm stroke. - Adjustable Nosepiece: Forward facing and equipped for four M26 x 1/36" (0.706) type objectives, the PSM-1000's nosepiece is dovetail mounted for moulding to different types of research and usage. The PSM1000 is an OEM-ready instrument for the best images of flat, reflective specimens. Samples from metallurgy and the semiconductor field are treated by ELWD Plan Apochromatic objectives with a stupendous resolution power. The large FOV24 with an erect, true sided image allows fast orientation and manipulation work. INCLUDED: The Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (5x, 10x, 20x) PA includes: - APO 5X, 10X, 20X Parfocality Adjustable Objectives - Adjustable Nosepiece - Widefield WF10X/24mm Eyepiece - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (5x, 10x, 20x) Objectives  (more) APO 5X, 10X, 20X Optical System Specialized Lenses Design For NUV to Visible NIR Illumination Port for Fiber-Optic Coaxial Illumination Features - Ergonomic Design: The design of the PSM-1000 encourages the optimal amount of usability without sacrificing comfort. - Laser Work: The PSM-1000 is standard equipped for laser work covering the spectrums ranging from 355nm [UV] to 532nm [Green] to 1064nm [IR]. - Focusing Block: Rated for load weights up to 45lbs., image focal planes can be adjusted at 1μm resolutions within the total 50mm stroke. - Adjustable Nosepiece: Forward facing and equipped for four M26 x 1/36" (0.706) type objectives, the PSM-1000's nosepiece is dovetail mounted for moulding to different types of research and usage. The PSM1000 is an OEM-ready instrument for the best images of flat, reflective specimens. Samples from metallurgy and the semiconductor field are treated by ELWD Plan Apochromatic objectives with a stupendous resolution power. The large FOV24 with an erect, true sided image allows fast orientation and manipulation work. INCLUDED: The Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (5x, 10x, 20x) includes: - APO 5X, 10X, 20X Objectives - Adjustable Nosepiece - Widefield WF10X/24mm Eyepiece - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (2x, 10x, 20x) PA Objectiv (more)es APO 2X, 10X, 20X Parfocality Adjustable Optical System Specialized Lenses Design For NUV to Visible NIR Illumination Port for Fiber-Optic Coaxial Illumination Features - Ergonomic Design: The design of the PSM-1000 encourages the optimal amount of usability without sacrificing comfort. - Laser Work: The PSM-1000 is standard equipped for laser work covering the spectrums ranging from 355nm [UV] to 532nm [Green] to 1064nm [IR]. - Focusing Block: Rated for load weights up to 45lbs., image focal planes can be adjusted at 1μm resolutions within the total 50mm stroke. - Adjustable Nosepiece: Forward facing and equipped for four M26 x 1/36" (0.706) type objectives, the PSM-1000's nosepiece is dovetail mounted for molding to different types of research and usage. The PSM1000 is an OEM-ready instrument for the best images of flat, reflective specimens. Samples from metallurgy and the semiconductor field are treated by ELWD Plan Apochromatic objectives with a stupendous resolution power. The large FOV24 with an erect, true sided image allows fast orientation and manipulation work. INCLUDED: The Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (2x, 10x, 20x) PA includes: - APO 2X, 10X, 20X Parfocality Adjustable Objectives - Adjustable Nosepiece - Widefield WF10X/24mm Eyepiece - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (2x, 10x, 20x) Objectives  (more) APO 2X, 10X, 20X Optical System Specialized Lenses Design For NUV to Visible NIR Illumination Port for Fiber-Optic Coaxial Illumination Features - Ergonomic Design: The design of the PSM-1000 encourages the optimal amount of usability without sacrificing comfort. - Laser Work: The PSM-1000 is standard equipped for laser work covering the spectrums ranging from 355nm [UV] to 532nm [Green] to 1064nm [IR]. - Focusing Block: Rated for load weights up to 45lbs., image focal planes can be adjusted at 1μm resolutions within the total 50mm stroke. - Adjustable Nosepiece: Forward facing and equipped for four M26 x 1/36" (0.706) type objectives, the PSM-1000's nosepiece is dovetail mounted for moulding to different types of research and usage. The PSM1000 is an OEM-ready instrument for the best images of flat, reflective specimens. Samples from metallurgy and the semiconductor field are treated by ELWD Plan Apochromatic objectives with a stupendous resolution power. The large FOV24 with an erect, true sided image allows fast orientation and manipulation work. INCLUDED: The Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (2x, 10x, 20x) includes: - APO 2X, 10X, 20X Objectives - Adjustable Nosepiece - Widefield WF10X/24mm Eyepiece - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Panthera TEC POL EPI (Trinocular) Features - UC Plan Achromat objectives (strain-free) for FOV (more) 22mm - Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL EPI series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL EPI (Trinocular) includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL EPI (Trinocular) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf typeSensor type-Sensor size-Capture resolution-Live display mode (through Wi-Fi)-Live display mode (through ethernet)-Live display mode (through HDMI)-Inclination25º inclinedTrinocular light splitFixed 50:50Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjective classificationPlan Achromatic objectives & CCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight10.4kgComparison of ModelsSpecificationPanthera TEC POL EPI (Binocular)Panthera TEC POL EPI (Digital)Panthera TEC POL EPI (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeInterpupillary distance48-75mm48-75mm48-75mmEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(4) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera TEC POL EPI (Digital) Features - UC Plan Achromat objectives (strain-free) for FOV 22 (more)mm - Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL EPI series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL EPI (Digital) includes: - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL EPI (Digital) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeBinocular head, Siedentopf type with built-in digital cameraSensor typeCMOSSensor size1/2.5"Capture resolution5MP (2592x1944)Live display mode (through Wi-Fi)1920x1080 (Full HD)Live display mode (through ethernet)1280x720, 1920x1080 (Full HD)Live display mode (through HDMI)1280x720, 1920x1080 (Full HD)Inclination25º inclinedTrinocular light split-Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjective classificationPlan Achromatic objectives & CCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight9.9kgComparison of ModelsSpecificationPanthera TEC POL EPI (Binocular)Panthera TEC POL EPI (Digital)Panthera TEC POL EPI (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeInterpupillary distance48-75mm48-75mm48-75mmEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(3) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera TEC POL EPI (Binocular) Features - UC Plan Achromat objectives (strain-free) for FOV  (more)22mm - Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL EPI series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL EPI (Binocular) includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL EPI (Binocular) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeBinocular head, Siedentopf typeSensor type-Sensor size-Capture resolution-Live display mode (through Wi-Fi)-Live display mode (through ethernet)-Live display mode (through HDMI)-Inclination25º inclinedTrinocular light split-Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjective classificationPlan Achromatic objectives & CCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight10.4kgComparison of ModelsSpecificationPanthera TEC POL EPI (Binocular)Panthera TEC POL EPI (Digital)Panthera TEC POL EPI (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeInterpupillary distance48-75mm48-75mm48-75mmEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(2) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera TEC POL (Trinocular) Features - UC Plan Achromat objectives (strain-free) for FOV 22m (more)m - Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL (Trinocular) includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL (Trinocular) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf typeSensor type-Sensor size-Capture resolution-Live display mode (through Wi-Fi)-Live display mode (through ethernet)-Live display mode (through HDMI)-Inclination25º inclinedTrinocular light splitFixed 50:50Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyRotatable analyzer 360º, Bertrand lens and slot for compensatorsObjective classificationCCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmTravel range X&Y1º increments, 0.1º vernier scaleCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight9.8kgComparison of ModelsSpecificationPanthera TEC POL (Binocular)Panthera TEC POL (Digital)Panthera TEC POL (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmTravel range X&Y1º increments, 0.1º vernier scale1º increments, 0.1º vernier scale1º increments, 0.1º vernier scaleFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(4) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera TEC POL (Digital) Features - UC Plan Achromat objectives (strain-free) for FOV 22mm - (more) Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL (Digital) includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL (Digital) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeBinocular head, Siedentopf type with built-in digital cameraSensor typeCMOSSensor size1/2.5"Capture resolution5MP (2592x1944)Live display mode (through Wi-Fi)1920x1080 (Full HD)Live display mode (through ethernet)1280x720, 1920x1080 (Full HD)Live display mode (through HDMI)1280x720, 1920x1080 (Full HD)Inclination25º inclinedTrinocular light split-Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyRotatable analyzer 360º, Bertrand lens and slot for compensatorsObjective classificationCCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmTravel range X&Y1º increments, 0.1º vernier scaleCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight9.9kgComparison of ModelsSpecificationPanthera TEC POL (Binocular)Panthera TEC POL (Digital)Panthera TEC POL (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmTravel range X&Y1º increments, 0.1º vernier scale1º increments, 0.1º vernier scale1º increments, 0.1º vernier scaleFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(3) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera TEC POL (Binocular) Features - UC Plan Achromat objectives (strain-free) for FOV 22mm (more) - Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL (Binocular) includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL (Binocular) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeBinocular head, Siedentopf typeSensor type-Sensor size-Capture resolution-Live display mode (through Wi-Fi)-Live display mode (through ethernet)-Live display mode (through HDMI)-Inclination25º inclinedTrinocular light split-Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyRotatable analyzer 360º, Bertrand lens and slot for compensatorsObjective classificationCCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmTravel range X&Y1º increments, 0.1º vernier scaleCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight10.4kgComparison of ModelsSpecificationPanthera TEC POL (Binocular)Panthera TEC POL (Digital)Panthera TEC POL (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmTravel range X&Y1º increments, 0.1º vernier scale1º increments, 0.1º vernier scale1º increments, 0.1º vernier scaleFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(2) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera Cloud Features - Built-in Smart CAM digital head 8.0 MP - ImagingOnDevice system (Pan (more)thera App embeded software) - HDMI (1080i - FullHD) - USB 2.0 for external devices (2x) - RJ-45 (1 GB LAN) - Wi-Fi - Unique Cloud Storage Function - 10 GB Internal Memory - Sleep mode (auto on-off function) The Panthera Cloud has been designed to streamline workflow! The Smart CAM digital head and its ImagingOnDevice System allows you to instantly capture what you are viewing with the tip of your finger. Work in FullHD through the HDMI port directly on a screen with the help of a mouse, or work with your Tablet and the Panthera App. Thanks to the QRlink system, you can send your live image to your tablet or smartphone by simply scanning the QR-code on the top of the Tubehead cover. The LAN port offers users the option to work through DigiClass or remote sharing.INCLUDED: The Motic Panthera Cloud includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 100X/1.25/S (WD 0.16mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Immersion Oil (5mL) - Blue Filter - Halogen Bulb - LED Module - HDMI Cable - Wi-Fi USB Dongle - Calibration Slide - Operator's Guide Motic Panthera Cloud SpecificationsObservation tubeBinocular head, Siedentopf type 25°, 360° swivelingOptical systemColour Corrected Infinity Optical System (CCIS®)Sensor TypeCMOSSensor Size1/2.5"Capture Resolution Info8MPCondenserFocusable and centerable Abbe condenser N.A. 0.90/1.25 with slot for contrast slidersDarkfieldOptional slider/turretData transferWi-Fi, HDMI, EthernetDiaphragmIris diaphragmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentFilter holderOn top of the illuminator with fixing capFine focus precision2µmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFocusing stroke25mmIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityInclination25° inclined, 360° swivelingInterpupillary distance48-75mmLive display mode through Ethernet1280x720, 1920x1080 pixels (Full HD)Live display mode through HDMI1920x1080 (Full HD)Live display mode through Wi-Fi1920x1080 (Full HD)NosepieceReversed quintuple, codedObjective classificationCCIS® UC Plan Achromatic (Pb free), DINObjective mounting threadW 4/5"x1/36" (RMS standard)Objectives4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)Other featuresUSB 2.0 for external Devices (x2)Phase contrastOptional slider/turretPolarizationOptional add-onStageCompact mechanical stage with built-in low position rackless coaxial stage control and sample holderStage size185x145mmStand typeUprightStandard contrast techniqueBrightfieldTransmitted illuminationKoehler LED 3W & Quartz halogen 6V/30W with intensity controlTravel range X&Y75x50mmUpper limit stopUpper limit stop preset but adjustableSoftwareImagingOnDevice System (Panthera App embedded)TransformerInternalPower supply110-240V (CE)Dimensions LxWxH282x210x394mmWeight Net8.8kgDownloadsTechnical Specification Download Operator's Manual Download Request a Formal Quote
