The RV 10 digital represents the continual enhancement of the IKA RV 10 rotary evaporator line. The  (more)unit comes with an universal heating bath, vertical glassware, state-of-the-art safety features and digital connectivity. The RV 10 digital is a robust and reliable lab companion. Its optimized bath volume allows for fast heat-up times. The condenser unit has special designed glass tubes that utilize the 1600 cm² surface extremely efficient. That’s why the RV 10 digital delivers reliable and reproducible process results that are usually reserved for more costly systems. Additional features such as smooth start, left-right interval or timer function capability support the user in their daily lab work. Another important aspect of the RV 10 digital are the sophisticated safety features. The motorized lift has an automated lift-out function in case of power outage to prevent superheating of the solvent. Safety temperature circuits can be set individually. Dry-run protection, adjustable lower end stop and lock function of bath setting complete the line of safety features. Type of cooling: vertical Cooling surface: 1600 cm² Speed range: 5 – 280 rpm Reversible direction of rotation: yes Lift: Motor Stroke: 140 mm Heating temperature range: room temp – 180°C Set temperature resolution: ±1 K Filling volume max: 4 l Timer: yes Dimensions (WxHxD): 500 x 430 x 440 mm Weight: 32.36 kg

The Buchi R-205 rotavapor is designed for applications associated with solvent evaporation. This rot (more)avapor is extremely suitable for, among other things, the distillation of solvents, for the evaporation of solvents and suspensions and for the (re)crystallization of liquids in the rotating evaporation flask. The distillations can be carried out under vacuum and atmospheric pressure. This increases performance and helps protect products. Speed: 0-250 rpm External dimensions (WxDxH): 450 x 360 x 1000 mm Pressure: 0 – 1400 mbar Temperature range: 20ºC to 180ºC

The radiomatic model 515 is a high performance flow scintillation analyzer for the qualatative and q (more)uantatative monitoring of single and dua labeled radioisotopic samples. It presents a unique combination of state-of-the-art scintillation counting technology and interchangeable beta/gamma/positron emmission detectors.

Dimensions (H x W x D): 1730 x 1020 x 780 mm Internal dimensions (H x W x D): 600 x 995 x 600 mm Dia (more)meter of exhaust duct: 250 mm

Pure water requires a storage system to prevent the degradation of your water quality. Merck Millipo (more)re’s 30 liter polyethylene (PE) storage tank is designed to maintain consistent purity of stored water and provide effective protection against airborne contaminants.

Type of movement: orbital Shaking stroke: 10 mm Permissible shaking weight (incl. attachment): 7.5 k (more)g Permissible ON time: 100 % Speed range: 0 – 500 rpm Speed display: LED line Timer: yes Time setting range: 5 – 50 min Operating mode: timer and continuous operation Dimensions (WxHxD): 360 x 98 x 420 mm Weight: 8.5 kg

Dimensions: 900 x 600 x 800 mm

A Sartorius balance, type GE811 with a weighing range of 810 g and a readability of 0.1 g. dim. (wei (more)ghing platform): 145 x 175 mm.

Safe, reliable and economic laminar flow cabinet for protection of the work item, including ergonomi (more)c practical properties needed in normal work. Particle free working conditions in class ISO5. All materials and surfaces are smooth and resistant to cleaning and disinfection agents. Front screen and side panels are made of shock-resistant laminated safety glass. Electrically operated front screen. Glare-free and shadow-free fluorescent lighting providing illumination on work surface 1500 lux Flow control with digital display Alarm for false flow speed 1/2 speed switch Hour counter UV outlet with switch (lamp not included) Base stand 800 mm Down flow 0,4 m/s ± 20% Dimensions (WxDxH): 1930 x 790 x 1460 mm Internal dimensions (WxDxH): 1840 x 600 x 655 mm

All the outstanding features of the Reax Top’s “little brother” can be found in this model: a rotati (more)onal speed of up to 2,500 rpm and a 5 mm shaking orbit. The electronic speed control and the scaling of the speed display allow precise settings. Applications that require a determined speed are thus shaken more gently. Shear force-sensitive organisms remain particularly protected by the constant speed in the low range. Motion: vibrating Rotation speed range: 0 – 2,500 rpm Operating Mode: automatic or continous Orbit/Stroke: 5 mm

Capacity: 410 g Readability: 1 mg Repeatability: 0.9 mg Linearity: ±2 mg Calibration type: Internal  (more)Dimensions (WxDxH): 194 x 366 x 276 mm Usable heigh of draft shield: 175 mm Weighing platform: 127 x 127 mm Weight: 7.6 kg

110V

Flow rate: Up to 32 l/min Application: Analytical Laboratory LC-MS, Analytical Laboratory LC-MS/MS,  (more)Nebulizers for APCI and ESI, ELSD, Turbo Vaps, Chemical Solvent Evaporation Type of gas prepared: Nitrogen Gas purity: up to 99.5% Inlet pressure classification: 8 barg Intake air quality specifications: ISO8573-1:2001 Class 3.2.1 Dimensions (HxWxD): 700 x 310 x 900 mm Weight: 93 kg Includes 270 L storage tank

Excluding rotor.

Dimensions (HxWxD): 760 x 1525 x 790 mm

Speed control range: 0 – 3000 RPM Max. stirring volume (water): 5 litres Max. length of magnetic sti (more)rring element (bar): 50 mm Stirring liquid viscosity: up to 1170 mPa.s Maximum continuous operation time: 24 hrs Operation in closed laboratory rooms: at ambient temperature from +4°C to +40°C Working plate size: 110 x 110 mm Working surface material: Stainless steel Overall dimensions (WxDxH): 120 x 150 x 65 mm Weight: 0.8 kg

Dimensions (HxWxD): 1980 x 600 x 620 mm

Strong magnetic field Infinitely variable speed from 0 – 1100 rpm Stainless steel housing facilitate (more)s cleaning and sterilization Dimensions (WxHxD): 140 x 75 x 200 mm Plate (LxW): 140 x 120 mm

Abbott Commander Incubator 8 shelves Type 6210/02

Zoom ratio 8.5:1 Focussing range 50 mm Headpiece 45° inclined, interpupillary distance 50 – 76 mm Di (more)stortion free objective, 1X: N.A. 0.084, W.D. 81 mm Widefield eyepiece, high eyepoint, F.N. 24, diopter lock mechanism, build in double cross line Heated stage with transparent stage plate Illumination mode: high contrast, low contrast and oblique illumination Illumination area Ø 40 mm

The power source of the brand Pharmacia type MultiDrive XL is designed for use in combination with e (more)lectrophoresis and isoelectric focusing (IEF). This power source can control and supply the three electrical parameters voltage, current and power. The duration of the run can be controlled by setting values for the following parameters: time, voltage and milliamperes per hour. In addition, the Pharmacia MultiDrive XL contains nine pre-programmed methods. Specifications Voltage: 3500V Current: 400mA Power: 150W Dimensions (WxDxH): 365 x 300 x 160 mm

Capacity: 17 L Max temperature: 100°C Max flow rate: 17 L/min Max pump pressure: 300 mbar Dimensions (more) (DxWxH): 457 x 381 x 456 mm Weight: 13.7 kg

The SECTOR Imager offers high sensitivity and six logs of dynamic range. The SECTOR Imager 2400 read (more)s plates at a rate of approximately 3 ½ minutes per plate. Using MSD DISCOVERY WORKBENCH software, all models provide the capability to interact with a third party external robotic controller. The SECTOR Imager 2400 is compatible with: 96- and 384-well MULTI-ARRAY plates 96-well, 4-, 7-, and 10-spot MULTI-SPOT plates Multiplex analysis for the analysis of biomarkers Electrochemiluminescence for detection Single and multiplex plate formats Highly sensitive imaging detection systems Rapid read times (reads a plate in just over 3 minutes) Workstation or automated operation Simultaneous reading of bar code labels on both short and long sides of microplates Six logs dynamic range No complicated fluidics

The Hei-TORQUE 100 is a overhead stirrer with a wide speed range (10 – 2,000 rpm) and a maximum torq (more)ue of 100 Ncm. With it you can optimally stir viscosities up to 60,000 mPas or volumes up to 50 liters (H2O). The Hei-TORQUE 100 performs every stirring task with minimal noise thanks to the latest engine technology. This overhead stirrer is also very user-friendly in terms of operation and safety. The 2.4 inch display makes it very easy to set the application parameters and control the process (e.g. using the torque trend display). The safety-related start/stop touch-function serves to minimize the risk of unintentional switching on. Suitable for use in fume hoods or as a drive for reactor superstructures, the Hei-TORQUE 100 has a quick-action chuck (quick chuck with safety ring) with a diameter of 10.5 mm, which can be combined with a large number of stirring tools. Rotation speed range: 10 – 2000 rpm Rotation speed indicator: digital Speed control: electronic Maximum torque: 100 Ncm Torque indicator: symbol Overheat protection: automatic cut-out Maximum viscosity: 60000 mPa s Stirring capacity (H2O): 50 l Throught-shaft design: yes Maximum shaft diameter: 10.5 mm Including tripod and a PR 31 Ringed Pitched-Blade Impeller Due to its blade dimensions, the ringed pitched-blade impeller PR 31 is ideal for solutions, emulsions and suspensions in vessels with the following characteristics: Ideal vessel diameter: 83 – 165 mm Ideal ground clearance: 17 – 33 mm Ideal filling level: 83 – 165 mm Ideal volume: 400 – 3500 ml The ringed pitched-blade impeller PR 31 has a total length of 400 mm and is made of stainless steel. Its stirring shaft has a diameter of 8 mm.

Dimensions (WxHxD): 600 x 600 x 580 mm
