Teledyne Lumenera INFINITY 3-3UR Monochrome Microscope Camera with Sony ICX674 CCD Sensor

UsedLumeneraCamerasUnited States

€4,392.56excl. VAT

In stock

Can't find what you're looking for?

Image Sensor
Sony ICX674 CCD monochrome, 2/3″ optical format
Effective Pixels
1936 x 1456, 4.54 μm square pixels
Frame Rate
53 fps at 1936 x 1456, 66 fps (1920 x 1088), 109 fps (640 x 480)
Dynamic Range
65.3 dB (mono)
Digital Output
8 and 14-bit
All 23 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 23

Brands
Lumenera
New/Used
Used
Image Sensor
Sony ICX674 CCD monochrome, 2/3″ optical format
Effective Pixels
1936 x 1456, 4.54 μm square pixels
Frame Rate
53 fps at 1936 x 1456, 66 fps (1920 x 1088), 109 fps (640 x 480)
Dynamic Range
65.3 dB (mono)
Digital Output
8 and 14-bit
Read Noise
6.2 e- (4 taps, 16 tps, 25° ambient, 41° internal)
Dark Current
<1 e-/s (at 22°C ambient, 41°C internal)
Mass
340g
Power Requirement
External 5VDC – 1.2A, power supply (included)
Power Consumption
~ 4 Watts
Operating Temperature
0° C to +50° C
Operating Humidity
5%-95%, Non-condensing
Integration Time
3 µs to 71 min (snapshot); 23 µs to 1.3 s (video)
ROI
Any multiple of 16x16 (quad tap mode)
Exposure Mode
Automatic / Manual
White Balance
Automatic / Manual
Gain
0.8 to 33x (mono)
Interface Connector
USB 3.0 (USB 2.0 supported at lower frame rates)
Dimensions (L x W x H)
2.75 x 3.85 x 1.56 inches
Lens Mount
C-Mount lens adapter
Binning Options
2 x 2, 3 x 3, 4 x 4, 8 x 8

Product description

Monochrome CCD microscope camera, 1936x1456 px, up to 53 fps, USB 3.0, high dynamic range, low noise.

The INFINITY 3-3UR is a scientific monochrome microscope camera featuring the industry-leading Sony EXview HAD II ICX674 CCD sensor with a 2/3″ optical format. Key specifications include:

  • Sensor: Sony ICX674 monochrome CCD, 2/3" optical format
  • Resolution: 1936 x 1456 effective pixels with 4.54 x 4.54 µm square pixels
  • Frame Rate:
  • 53 fps at full resolution (1936 x 1456)
  • 66 fps at 1920 x 1088
  • 109 fps at VGA (640 x 480)
  • Dynamic Range: 65.3 dB (monochrome)
  • Digital Output: Selectable 8-bit or 14-bit pixel data
  • Read Noise: 6.2 electrons (4 taps, 16 tps, 25°C ambient, 41°C internal)
  • Dark Current: <1 electron/s at 22°C ambient and 41°C internal
  • Interface: High-speed USB 3.0 (backward compatible with USB 2.0 at reduced frame rates)
  • Camera Controls:
  • GPI/O for peripheral control and synchronization
  • Region of Interest (ROI) selectable in multiples of 16x16 pixels (quad tap mode)
  • Exposure modes: Automatic and manual
  • Gain adjustment: 0.8 to 33x (mono)
  • White balance: Automatic / manual
  • Integration Time:
  • Snapshot mode: 3 µs to 71 minutes
  • Video mode: 23 µs to 1.3 seconds
  • Binning Options: 2x2, 3x3, 4x4, 8x8
  • Physical Characteristics:
  • Dimensions: 2.75 x 3.85 x 1.56 inches
  • Mass: 340 g
  • Lens Mount: C-Mount adapter
  • Power: External 5V DC power supply included, consumption approximately 4 Watts
  • Operating Conditions:
  • Temperature: 0°C to +50°C
  • Humidity: 5%–95% non-condensing

Included Accessories:

  • AU-280M-CCD INFINITY digital camera for USB 3.0 connectivity
  • User application software DVD (INFINITY Analyze)
  • TWAIN driver
  • Documentation
  • USB 3.0 cable
  • Power supply

This camera is optimized for scientific and industrial imaging applications demanding extreme sensitivity, high resolution, and fast frame rates, including fluorescence and near-infrared (NIR) imaging in low-light conditions.
