Motic MOTICAM S6 6MP Microscope Camera with USB 3.1 Interface

UsedMoticCamerasUnited States

From€683.38excl. VAT

In stock

Can't find what you're looking for?

Sensor Type
sCMOS
Sensor Size
1/3"
Imaging Area
6.09mm (Diagonal)
Capture Resolution Info
1.2MP
Live display mode through USB (pixels)
1280x960, 640x480
All 23 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 23

Brands
Motic
New/Used
Used
Sensor Type
sCMOS
Sensor Size
1/3"
Imaging Area
6.09mm (Diagonal)
Capture Resolution Info
1.2MP
Live display mode through USB (pixels)
1280x960, 640x480
Pixel size
3.75x3.75μm
Scan mode
Progressive
Shutter mode
Rolling Shutter
Data transfer
USB 3.1
Max. frames per second (fps*)
1280x960 @ 120fps, 640x480 @ 240fps
Exposure time
15 μsec to 2 sec
Operating temperature
From -10 to +60 Degrees Celsius non condensing
Sensitivity
2350mV(G) @ 1/30 sec
Support device
TWAIN, SDK and DirectShow Driver
Supported OS
Microsoft Windows 7/8/10, MAC OSX, Linux or higher
Minimum computer requirements
2GHz dualcore - RAM memory 2GB - Video memory min. 512 MB
Lens mount
C-Mount
Software
Motic Images Plus 3.0 for Windows, OSX and Linux
Functions
Still image and video capture, live and still image measurement, image adjustments, white balance, automatic & manual exposure, individual objective calibration system
Power supply
5V (from USB Port)
Package includes
CS ring adaptor, USB 3.1 cable, Motic 4-dot calibration slide, Motic Images Plus 3.0 for Windows/OSX/Linux

Product description

6MP sCMOS microscope camera with USB 3.1, C-mount, and advanced sensor for high-res imaging and video capture.

The Motic MOTICAM S6 is a microscope camera designed for high-resolution imaging and video presentation with a 6MP sCMOS sensor. It features:

  • Sensor size: 1/1.8" with an 8.92mm diagonal imaging area
  • Pixel size: 2.4 x 2.4 μm; rolling shutter with progressive scan mode
  • Maximum live display resolutions: 3072x2048 @ 30fps, and 1536x1024 @ 50fps via USB 3.1
  • Exposure time range: 16 μsec to 2 seconds
  • Operating temperature: -10°C to +60°C, non-condensing environment
  • Sensitivity: 425 mV(G) at 1/30 s exposure
  • Lens mount: standard C-Mount for microscope compatibility
  • Supported operating systems: Windows 7/8/10, Mac OSX, Linux or higher
  • Supplied software: Motic Images Plus 3.0 for image capture, measurement, and adjustment functions
  • Interfaces: TWAIN, SDK, and DirectShow drivers included for extended device support
  • Power supplied via USB port (5V)
  • Package includes CS ring adaptor, USB 3.1 cable, calibration slide, and software

Ideal for presentations, video projection, and high-quality print reporting with advanced sensor technology from the Motic S Series.
