Thermo Fisher Scientific (formerly FEI) Quanta

Name: Thermo Fisher Scientific (formerly FEI) Quanta
Brand: Thermo Fisher Scientific (formerly FEI)
SKU: 68701
Availability: PreOrder

UsedThermo Fisher Scientific (formerly FEI)Electron microscopesNetherlands

Procurable

Not in stock, available to order through our sourcing team

Not in stock, but we can get it for you

We source this model through our supplier network. Request a quote and we'll come back within one hour.

Request a quote
We confirm price and lead time
You approve, we ship to you

Accelerating Voltage: 200 V to 30 kV
Probe Current: Up to 100 nA
Operating Pressure: High-vacuum: 6 × 10⁻⁴ Pa; Low-vacuum: 10 to 130 Pa; ESEM-vacuum: 10 to 4000 Pa
Stage Travel: X = Y = 150 mm; Z = 65 mm; Tilt = -5° to +70°; Rotation = 360° continuous
Compatible Sample Stages: Heating stage up to approximately 1000°C; Kammrath Weiss tensile module
Availability: Procurable
Lead time: Confirmed with your quote

All 23 specifications

Ships to NL
Response within 1 hour
Warranty available. Buy without worry
Support from a scientist

Specifications 23

Brands: Thermo Fisher Scientific (formerly FEI)
New/Used: Used
Accelerating Voltage: 200 V to 30 kV
Probe Current: Up to 100 nA
Operating Pressure: High-vacuum: 6 × 10⁻⁴ Pa; Low-vacuum: 10 to 130 Pa; ESEM-vacuum: 10 to 4000 Pa
Stage Travel: X = Y = 150 mm; Z = 65 mm; Tilt = -5° to +70°; Rotation = 360° continuous
Compatible Sample Stages: Heating stage up to approximately 1000°C; Kammrath Weiss tensile module
Sample Chamber Dimensions: Up to 300 mm wide and 50 mm tall
Resolution at 30 kV in High Vacuum Mode: 1.2 nm (Secondary Electron Imaging)
Resolution at 30 kV in Low Vacuum Mode: 1.5 nm (Secondary Electron Imaging)
Resolution at 30 kV in ESEM Mode: 1.5 nm (Secondary Electron Imaging)
Resolution at 1 kV in High Vacuum Mode: 3.0 nm (Secondary Electron Imaging)

Resolution at 1 kV in Low Vacuum Mode: 3.0 nm (Secondary Electron Imaging)
Resolution at 3 kV in Low Vacuum Mode: 3.0 nm (Secondary Electron Imaging)
Imaging Modes: High Vacuum; Low Vacuum; Environmental SEM (ESEM)
Magnification Range: 7× to 2,000,000×
Field of View: 17 mm at longest working distance; 500 µm with standard, axial, gaseous secondary electron (SE) detector
Digital Image Sizes: 4096 × 3536; 2048 × 1768; 1024 × 884; 512 × 442
Detector Types: Everhart-Thornley Secondary Electron Detector (SED); Low-vacuum SED; Gaseous SED; Solid-state Backscattered Electron Detector (BSED); Gaseous BSED; IR-CCD
Energy Dispersive X-ray Spectroscopy (EDS) Detector: Bruker QUANTAX 400 with XFlash 4010 (10 mm²) Silicon Drift Detector (SDD); Energy Resolution Mn K – 125 eV at over 100,000 counts per second; Detection Beryllium to Americium
System Control Interface: Windows 2000™ based 32-bit graphical user interface
Availability: Procurable
Lead time: Confirmed with your quote

Product description

High-resolution SEM with FEG, multiple vacuum modes, advanced detectors, and versatile sample handling for diverse specimens.

The FEI Quanta 600 is a versatile scanning electron microscope (SEM) designed to deliver high-resolution imaging and analysis across a diverse range of sample types. Equipped with a field emission gun (FEG), this instrument offers exceptional performance in both high-vacuum and low-vacuum environments, accommodating conductive and non-conductive specimens alike.

Key features include:

Multiple imaging modes: High vacuum, low vacuum, and environmental SEM (ESEM) modes enable the examination of various sample conditions, including wet or non-conductive materials.
High-resolution imaging: Achieves resolutions down to 1.2 nm at 30 kV in high vacuum mode, facilitating detailed surface analysis.
Advanced detectors: Equipped with secondary electron detectors (SED), backscattered electron detectors (BSED), and energy-dispersive X-ray spectroscopy (EDS) for comprehensive material characterization.
Versatile sample handling: Features a motorized, five-axis eucentric stage with extensive travel ranges, accommodating large and irregularly shaped specimens.
In situ experimentation: Supports dynamic experiments with options for heating and cooling stages, allowing real-time observation of sample behavior under varying conditions.

This SEM is widely utilized in fields such as materials science, geology, biology, and nanotechnology. Its adaptability makes it a valuable asset in university laboratories, research institutions, and industrial R&D facilities. Introduced in the mid-2000s, the FEI Quanta 600 remains relevant due to its robust design and comprehensive feature set, continuing to support cutting-edge research and development.
