Laboratory equipment

Motic BA310 POL Binocular & EPI Illuminator Magnification Range 5x to 50x Optical System Colour  (more)Corrected Infinity (CCIS) Illumination Koehler Quartz 30W Halogen, Epi-illumination Halogen 12V/50W Features - Polarizing microscope - Binocular head - 360 degree rotatable stage - Rotatable polarizer - Rotatable analyzer - Focusable, center able Bertrand lens - WF PL10x/20 eyepiece - CCIS Plan LP Strain-free Objectives - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) The BA310POL is an extremely powerful yet affordable polarization microscope for transmitted light samples. Designed for the examination of birefringent samples from petrography and mineralogy, it can also be used for the synthetic materials industry where repeatable observations can be performed with efficiency and reliability. The BA310POL also works especially well in educational applications of material professions, where affordability and ease-of-use are the key requirements. The BA310 EPI Illuminator is equipped with a Quartz Halogen 12V/50W bulb, ensuring bright and consistent illumination. It includes integrated field and aperture diaphragms, as well as features an external lamp house.INCLUDED: The Motic BA310 POL Binocular & EPI Illuminator includes: - BA310 Epi-Illuminator - 5X, 10X, 20X, 50X(S) Objectives - Dust Cover - Power Cord - Allen Key - Blue Filter - Spare Fuse - Empty Insertion Plate - Power Cord - Manufacturer’s Documentation - 5 Year Manufacturer’s Warranty Motic BA310 POL Binocular & EPI Illuminator SpecificationsObservation tubeBinocular head, Siedentopf typeOptical systemColour Corrected Infinity Optical System (CCIS®)CondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.9/0.13 (strain-free)DiaphragmIris diaphragmDiopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield PL10X/20mm with Diopter AdjustmentFilter holderOn top of the illuminator with fixing capFine focus precision2µmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFocusing stroke17mmIllumination featuresRotatable polarizer 360°Inclination30° inclined, 360° rotatingInterpupillary distance55-75mmNosepieceReversed quadruple, single centerable positionsObjective classificationCCIS Plan LP Strain-freeObjective mounting threadW 4/5"x1/36" (RMS standard)Objectives5X, 10X, 20X, 50X(S)PolarizationSwing in/outStageCircular rotating 360°, lockableStage sizeØ160mmStand typeUprightStandard contrast techniqueBrightfield, polarizingTransmitted illuminationKoehler Quartz halogen 6V/30W, Epi-Illumination halogen 12V/50WTravel range X&Y1° increments, 0,1° vernier scaleUpper limit stopUpper limit stop preset but adjustableTransformerInternalPower supply100-240V (CE)Dimensions LxWxH400x220x452mmWeight Net10.4kg Request a Formal Quote

Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image) Motic’s BA310MET series presents a  (more)powerful microscope line for incident light applications in all material sciences. Industrial quality control of opaque samples can be performed as well as teaching in educational environments of engineering and material professions, where affordability and ease of use are key demands. Extended flexibility is given by the BA310MET-T models with built-in transmitted light for transparent or compound materials. The BA310MET-H includes a more flexible focusing device, dedicated to larger samples with little limitation in size. Motic's LM Plan-Achromatic objectives with Long-Working Distance for incident light provide optimal image contrast for reflective, non-covered specimen. Together with a fully corrected tube lens an intermediate image without colored fringes is created. In all models the Epi-Illuminator offers a powerful 50W Halogen light source. The built-in field diaphragm and aperture diaphragm help to optimize image quality by reducing stray light and thus increasing contrast.INCLUDED: The Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image) includes: - 5X/0.13 (WD 20.3mm) Objective - 10X/0.25 (WD 17.5mm) Objective - 20X/0.40 (WD 8.1mm) Objective - 50X/0.55 (WD 8.4mm) Objective - Widefield N-WF10X/20mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue, Frosted, Green and Yellow Filters - Operator's Guide Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf type, 360° SwivelingInclination30° inclinedTrinocular light split100:0/20:80Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield N-WF10X/20mm with diopter adjustmentIntermediate bodyEpi-illuminator quartz halogen with integrated field and aperture diaphragms and external lamphouseNosepieceReversed quintupleObjective classificationCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)Objective mounting threadW 4/5"x1/36" (RMS standard)Stand typeUprightStageMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage size240x140mmTravel range X&Y75x50mm (3"x2")CondenserFocusable and centerable Abbe condenser N.A. 0.85DiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2μmFocusing stroke30mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capIncident illuminationQuartz halogen 12V/50W with integrated field and aperture diaphragmsTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WIllumination featuresExternal lamp house for Epi-illuminatorTransformerEpi-illuminator external, transmitted internalPower supply100-240V (CE)Dimensions LxWxH508x240x465mmNet weight12.7kgComparison of ModelsSpecificationMotic BA310 MET BinocularMotic BA310 MET TrinocularMotic BA310 MET-H TrinocularMotic BA310 MET-H Trinocular (Erect Image)Motic BA310 MET-T Trinocular (3"x2" Stage)Motic BA310 MET-T Trinocular (6"x4" Stage)Motic BA310 MET-T Trinocular (Erect Image)Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image)Observation TubeBinocular headTrinocular headTrinocular headTrinocular head (Erect Image)Trinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingInterpupillary Distance48-75mm48-75mm55-75mm55-75mm48-75mm48-75mm48-75mm48-75mmObjective ClassificationCCIS® EC Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 11.5mm), 10X/0.3 (WD 6.8mm), 20X/0.40 (WD 11.1mm), 50X/0.55 (WD 8.2mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)StageMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage Size180x140mm180x140mm180x140mm180x140mm240x140mm300x180mm180x140mm240x140mmTravel Range X&Y75x50mm75x50mm100x80mm100x80mm75x50mm150x100mm75x50mm75x50mmIllumination InterchangeabilityQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3W.comparison-table tr td:nth-child(9) { background-color: #fffacd; }DownloadsTechnical Specification Download Operator's Manual Download

Motic BA310 MET-T Trinocular (Erect Image) Motic’s BA310MET series presents a powerful microscope li (more)ne for incident light applications in all material sciences. Industrial quality control of opaque samples can be performed as well as teaching in educational environments of engineering and material professions, where affordability and ease of use are key demands. Extended flexibility is given by the BA310MET-T models with built-in transmitted light for transparent or compound materials. The BA310MET-H includes a more flexible focusing device, dedicated to larger samples with little limitation in size. Motic's LM Plan-Achromatic objectives with Long-Working Distance for incident light provide optimal image contrast for reflective, non-covered specimen. Together with a fully corrected tube lens an intermediate image without colored fringes is created. In all models the Epi-Illuminator offers a powerful 50W Halogen light source. The built-in field diaphragm and aperture diaphragm help to optimize image quality by reducing stray light and thus increasing contrast.INCLUDED: The Motic BA310 MET-T Trinocular (Erect Image) includes: - 5X/0.13 (WD 20.3mm) Objective - 10X/0.25 (WD 17.5mm) Objective - 20X/0.40 (WD 8.1mm) Objective - 50X/0.55 (WD 8.4mm) Objective - Widefield N-WF10X/20mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Operator's Guide Motic BA310 MET-T Trinocular (Erect Image) SpecificationsObservation tubeTrinocular head, Siedentopf type, 360° swivelingOptical systemColour Corrected Infinity Optical System (CCIS®)Diopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield N-WF10X/20mm with diopter adjustmentFine focus precision2µmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFocusing stroke30mmIllumination featuresExternal lamp house for Epi-illuminatorIllumination interchangeabilityQuartz halogen 12V/50W or LED 3WIncident illuminationQuartz halogen 12V/50W with integrated field and aperture diaphragmsInclination30° inclinedInterpupillary distance48-75mmNosepieceReversed quintupleObjective classificationCCIS® EC Plan Achromatic, DINObjective mounting threadW 4/5"x1/36" (RMS standard)Objectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)PolarizationOptional slidersStageMechanical stage, hard coated with built-in low position coaxial stage controlStage size180x140mmStand typeUprightStandard contrast techniqueBrightfieldTravel range X&Y75x50mmUpper limit stopUpper limit stop preset but adjustableTransformerExternalPower supply100-240V (CE)Accessories includedDust cover, power cord, Allen keyDimensions LxWxH508x240x465mmWeight Net12.7kgComparison of ModelsSpecificationMotic BA310 MET BinocularMotic BA310 MET TrinocularMotic BA310 MET-H TrinocularMotic BA310 MET-H Trinocular (Erect Image)Motic BA310 MET-T Trinocular (3"x2" Stage)Motic BA310 MET-T Trinocular (6"x4" Stage)Motic BA310 MET-T Trinocular (Erect Image)Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image)Observation TubeBinocular headTrinocular headTrinocular headTrinocular head (Erect Image)Trinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingInterpupillary Distance48-75mm48-75mm55-75mm55-75mm48-75mm48-75mm48-75mm48-75mmObjective ClassificationCCIS® EC Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 11.5mm), 10X/0.3 (WD 6.8mm), 20X/0.40 (WD 11.1mm), 50X/0.55 (WD 8.2mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)StageMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage Size180x140mm180x140mm180x140mm180x140mm240x140mm300x180mm180x140mm240x140mmTravel Range X&Y75x50mm75x50mm100x80mm100x80mm75x50mm150x100mm75x50mm75x50mmIllumination InterchangeabilityQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3W.comparison-table tr td:nth-child(8) { background-color: #fffacd; }DownloadsTechnical Specification Download Operator's Manual Download

Motic BA310 MET-T Trinocular (Stroke 6”x 4” Stage) Motic’s BA310MET series presents a powerful micro (more)scope line for incident light applications in all material sciences. Industrial quality control of opaque samples can be performed as well as teaching in educational environments of engineering and material professions, where affordability and ease of use are key demands. Extended flexibility is given by the BA310MET-T models with built-in transmitted light for transparent or compound materials. The BA310MET-H includes a more flexible focusing device, dedicated to larger samples with little limitation in size. Motic's LM Plan-Achromatic objectives with Long-Working Distance for incident light provide optimal image contrast for reflective, non-covered specimen. Together with a fully corrected tube lens an intermediate image without colored fringes is created. In all models the Epi-Illuminator offers a powerful 50W Halogen light source. The built-in field diaphragm and aperture diaphragm help to optimize image quality by reducing stray light and thus increasing contrast.INCLUDED: The Motic BA310 MET-T Trinocular (Stroke 6”x 4” Stage) includes: - 5X/0.13 (WD 20.3mm) Objective - 10X/0.25 (WD 17.5mm) Objective - 20X/0.40 (WD 8.1mm) Objective - 50X/0.55 (WD 8.4mm) Objective - Widefield N-WF10X/20mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue, Frosted, Green and Yellow Filters - Operator's Guide Motic BA310 MET-T Trinocular (Stroke 6”x 4” Stage) SpecificationsModelBA310MET-H Trinocular (6"x4")Optical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf type, 360° SwivelingInclination30° inclinedTrinocular light split100:0/20:80Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield N-WF10X/20mm with diopter adjustmentIntermediate bodyEpi-illuminator quartz halogen with integrated field and aperture diaphragms and external lamphouseNosepieceReversed quintupleObjective classificationCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)Objective mounting threadW 4/5"x1/36" (RMS standard)Stand typeUprightStageMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage size300x180mmTravel range X&Y150x100mm (6"x4")CondenserFocusable and centerable Abbe condenser N.A. 0.85DiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2μmFocusing stroke30mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capIncident illuminationQuartz halogen 12V/50W with integrated field and aperture diaphragmsTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WIllumination featuresExternal lamp house for Epi-illuminatorTransformerEpi-illuminator external, transmitted internalPower supply100-240V (CE)Dimensions LxWxH508x240x465mmNet weight12.7kgComparison of ModelsSpecificationMotic BA310 MET BinocularMotic BA310 MET TrinocularMotic BA310 MET-H TrinocularMotic BA310 MET-H Trinocular (Erect Image)Motic BA310 MET-T Trinocular (3"x2" Stage)Motic BA310 MET-T Trinocular (6"x4" Stage)Motic BA310 MET-T Trinocular (Erect Image)Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image)Observation TubeBinocular headTrinocular headTrinocular headTrinocular head (Erect Image)Trinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingInterpupillary Distance48-75mm48-75mm55-75mm55-75mm48-75mm48-75mm48-75mm48-75mmObjective ClassificationCCIS® EC Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 11.5mm), 10X/0.3 (WD 6.8mm), 20X/0.40 (WD 11.1mm), 50X/0.55 (WD 8.2mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)StageMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage Size180x140mm180x140mm180x140mm180x140mm240x140mm300x180mm180x140mm240x140mmTravel Range X&Y75x50mm75x50mm100x80mm100x80mm75x50mm150x100mm75x50mm75x50mmIllumination InterchangeabilityQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3W.comparison-table tr td:nth-child(7) { background-color: #fffacd; }DownloadsTechnical Specification Download Operator's Manual Download

Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) Motic’s BA310MET series presents a powerful micro (more)scope line for incident light applications in all material sciences. Industrial quality control of opaque samples can be performed as well as teaching in educational environments of engineering and material professions, where affordability and ease of use are key demands. Extended flexibility is given by the BA310MET-T models with built-in transmitted light for transparent or compound materials. The BA310MET-H includes a more flexible focusing device, dedicated to larger samples with little limitation in size. Motic's LM Plan-Achromatic objectives with Long-Working Distance for incident light provide optimal image contrast for reflective, non-covered specimen. Together with a fully corrected tube lens an intermediate image without colored fringes is created. In all models the Epi-Illuminator offers a powerful 50W Halogen light source. The built-in field diaphragm and aperture diaphragm help to optimize image quality by reducing stray light and thus increasing contrast.INCLUDED: The Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) includes: - 5X/0.13 (WD 20.3mm) Objective - 10X/0.25 (WD 17.5mm) Objective - 20X/0.40 (WD 8.1mm) Objective - 50X/0.55 (WD 8.4mm) Objective - Widefield N-WF10X/20mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue, Frosted, Green and Yellow Filters - Operator's Guide Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf type, 360° SwivelingInclination30° inclinedTrinocular light split100:0/20:80Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield N-WF10X/20mm with diopter adjustmentIntermediate bodyEpi-illuminator quartz halogen with integrated field and aperture diaphragms and external lamphouseNosepieceReversed quintupleObjective classificationCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)Objective mounting threadW 4/5"x1/36" (RMS standard)Stand typeUprightStageMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage size240x140mmTravel range X&Y75x50mm (3"x2")CondenserFocusable and centerable Abbe condenser N.A. 0.85DiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2μmFocusing stroke30mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capIncident illuminationQuartz halogen 12V/50W with integrated field and aperture diaphragmsTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WIllumination featuresExternal lamp house for Epi-illuminatorTransformerEpi-illuminator external, transmitted internalPower supply100-240V (CE)Dimensions LxWxH508x240x465mmNet weight12.7kgComparison of ModelsSpecificationMotic BA310 MET BinocularMotic BA310 MET TrinocularMotic BA310 MET-H TrinocularMotic BA310 MET-H Trinocular (Erect Image)Motic BA310 MET-T Trinocular (3"x2" Stage)Motic BA310 MET-T Trinocular (6"x4" Stage)Motic BA310 MET-T Trinocular (Erect Image)Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image)Observation TubeBinocular headTrinocular headTrinocular headTrinocular head (Erect Image)Trinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingInterpupillary Distance48-75mm48-75mm55-75mm55-75mm48-75mm48-75mm48-75mm48-75mmObjective ClassificationCCIS® EC Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 11.5mm), 10X/0.3 (WD 6.8mm), 20X/0.40 (WD 11.1mm), 50X/0.55 (WD 8.2mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)StageMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage Size180x140mm180x140mm180x140mm180x140mm240x140mm300x180mm180x140mm240x140mmTravel Range X&Y75x50mm75x50mm100x80mm100x80mm75x50mm150x100mm75x50mm75x50mmIllumination InterchangeabilityQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3W.comparison-table tr td:nth-child(6) { background-color: #fffacd; }DownloadsTechnical Specification Download Operator's Manual Download

Motic BA310 MET-H Trinocular (Erect Image) Motic’s BA310MET series presents a powerful microscope li (more)ne for incident light applications in all material sciences. Industrial quality control of opaque samples can be performed as well as teaching in educational environments of engineering and material professions, where affordability and ease of use are key demands. Extended flexibility is given by the BA310MET-T models with built-in transmitted light for transparent or compound materials. The BA310MET-H includes a more flexible focusing device, dedicated to larger samples with little limitation in size. Motic's LM Plan-Achromatic objectives with Long-Working Distance for incident light provide optimal image contrast for reflective, non-covered specimen. Together with a fully corrected tube lens an intermediate image without colored fringes is created. In all models the Epi-Illuminator offers a powerful 50W Halogen light source. The built-in field diaphragm and aperture diaphragm help to optimize image quality by reducing stray light and thus increasing contrast.INCLUDED: The Motic BA310 MET-H Trinocular (Erect Image) includes: - 5X/0.13 (WD 20.3mm) Objective - 10X/0.25 (WD 17.5mm) Objective - 20X/0.40 (WD 8.1mm) Objective - 50X/0.55 (WD 8.4mm) Objective - Widefield N-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Operator's Guide Motic BA310 MET-H Trinocular (Erect Image) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf typeInclination30° inclinedTrinocular light splitFixed 50:50 erect imageInterpupillary distance55-75mmDiopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield N-WF10X/20mm with diopter adjustmentIntermediate bodyEpi-illuminator quartz halogen with integrated field and aperture diaphragms and external lamphouseNosepieceSide facing quintupleObjective classificationCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)Objective mounting threadW 4/5"x1/36" (RMS standard)Stand typeUpright with pole stand with focusing block and baseStageMechanical stage, hard coated with coaxial stage controlStage size180x140mmTravel range X&Y100x80mmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2μmFocusing stroke30mmIncident illuminationQuartz halogen 12V/50W with integrated field and aperture diaphragmsIllumination interchangeabilityQuartz halogen 12V/50W or LED 3WIllumination featuresExternal lamp house for Epi-illuminatorTransformerExternalPower supply100-240V (CE)Dimensions LxWxH369x485x391mmBase300x300mmNet weight15.7kgComparison of ModelsSpecificationMotic BA310 MET BinocularMotic BA310 MET TrinocularMotic BA310 MET-H TrinocularMotic BA310 MET-H Trinocular (Erect Image)Motic BA310 MET-T Trinocular (3"x2" Stage)Motic BA310 MET-T Trinocular (6"x4" Stage)Motic BA310 MET-T Trinocular (Erect Image)Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image)Observation TubeBinocular headTrinocular headTrinocular headTrinocular head (Erect Image)Trinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingInterpupillary Distance48-75mm48-75mm55-75mm55-75mm48-75mm48-75mm48-75mm48-75mmObjective ClassificationCCIS® EC Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 11.5mm), 10X/0.3 (WD 6.8mm), 20X/0.40 (WD 11.1mm), 50X/0.55 (WD 8.2mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)StageMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage Size180x140mm180x140mm180x140mm180x140mm240x140mm300x180mm180x140mm240x140mmTravel Range X&Y75x50mm75x50mm100x80mm100x80mm75x50mm150x100mm75x50mm75x50mmIllumination InterchangeabilityQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3W.comparison-table tr td:nth-child(5) { background-color: #fffacd; }DownloadsTechnical Specification Download Operator's Manual Download

Motic BA310 MET-H Trinocular Motic’s BA310MET series presents a powerful microscope line for inciden (more)t light applications in all material sciences. Industrial quality control of opaque samples can be performed as well as teaching in educational environments of engineering and material professions, where affordability and ease of use are key demands. Extended flexibility is given by the BA310MET-T models with built-in transmitted light for transparent or compound materials. The BA310MET-H includes a more flexible focusing device, dedicated to larger samples with little limitation in size. Motic's LM Plan-Achromatic objectives with Long-Working Distance for incident light provide optimal image contrast for reflective, non-covered specimen. Together with a fully corrected tube lens an intermediate image without colored fringes is created. In all models the Epi-Illuminator offers a powerful 50W Halogen light source. The built-in field diaphragm and aperture diaphragm help to optimize image quality by reducing stray light and thus increasing contrast.INCLUDED: The Motic BA310 MET-H Trinocular includes: - 5X/0.13 (WD 11.5mm) Objective - 10X/0.3 (WD 6.8mm) Objective - 20X/0.40 (WD 11.1mm) Objective - 50X/0.55 (WD 8.2mm) Objective - Widefield N-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Operator's Guide Motic BA310 MET-H Trinocular SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf typeInclination30° inclinedTrinocular light split100:0/20:80Interpupillary distance55-75mmDiopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield N-WF10X/20mm with diopter adjustmentIntermediate bodyEpi-illuminator quartz halogen with integrated field and aperture diaphragms and external lamphouseNosepieceReversed quintupleObjective classificationCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 11.5mm), 10X/0.3 (WD 6.8mm), 20X/0.40 (WD 11.1mm), 50X/0.55 (WD 8.2mm)Objective mounting threadW 4/5"x1/36" (RMS standard)Stand typeUpright with pole stand with focusing block and baseStageMechanical stage, hard coated with coaxial stage controlStage size180x140mmTravel range X&Y100x80mmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2μmFocusing stroke30mmIncident illuminationQuartz halogen 12V/50W with integrated field and aperture diaphragmsIllumination interchangeabilityQuartz halogen 12V/50W or LED 3WIllumination featuresExternal lamp house for Epi-illuminatorTransformerExternalPower supply100-240V (CE)Dimensions LxWxH369x485x391mmBase300x300mmNet weight15.7kgComparison of ModelsSpecificationMotic BA310 MET BinocularMotic BA310 MET TrinocularMotic BA310 MET-H TrinocularMotic BA310 MET-H Trinocular (Erect Image)Motic BA310 MET-T Trinocular (3"x2" Stage)Motic BA310 MET-T Trinocular (6"x4" Stage)Motic BA310 MET-T Trinocular (Erect Image)Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image)Observation TubeBinocular headTrinocular headTrinocular headTrinocular head (Erect Image)Trinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingInterpupillary Distance48-75mm48-75mm55-75mm55-75mm48-75mm48-75mm48-75mm48-75mmObjective ClassificationCCIS® EC Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 11.5mm), 10X/0.3 (WD 6.8mm), 20X/0.40 (WD 11.1mm), 50X/0.55 (WD 8.2mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)StageMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage Size180x140mm180x140mm180x140mm180x140mm240x140mm300x180mm180x140mm240x140mmTravel Range X&Y75x50mm75x50mm100x80mm100x80mm75x50mm150x100mm75x50mm75x50mmIllumination InterchangeabilityQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3W.comparison-table tr td:nth-child(4) { background-color: #fffacd; }DownloadsTechnical Specification Download Operator's Manual Download

Motic BA310 MET Trinocular Motic’s BA310MET series presents a powerful microscope line for incident  (more)light applications in all material sciences. Industrial quality control of opaque samples can be performed as well as teaching in educational environments of engineering and material professions, where affordability and ease of use are key demands. Extended flexibility is given by the BA310MET-T models with built-in transmitted light for transparent or compound materials. The BA310MET-H includes a more flexible focusing device, dedicated to larger samples with little limitation in size. Motic's LM Plan-Achromatic objectives with Long-Working Distance for incident light provide optimal image contrast for reflective, non-covered specimen. Together with a fully corrected tube lens an intermediate image without colored fringes is created. In all models the Epi-Illuminator offers a powerful 50W Halogen light source. The built-in field diaphragm and aperture diaphragm help to optimize image quality by reducing stray light and thus increasing contrast.INCLUDED: The Motic BA310 MET Trinocular includes: - 5X/0.13 (WD 20.3mm) Objective - 10X/0.25 (WD 17.5mm) Objective - 20X/0.40 (WD 8.1mm) Objective - 50X/0.55 (WD 8.4mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Operator's Guide Motic BA310 MET Trinocular SpecificationsObservation tubeTrinocular head, Siedentopf type, 360° swivelingOptical systemColour Corrected Infinity Optical System (CCIS®)Diopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield N-WF10X/20mm with diopter adjustmentFine focus precision2µmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFocusing stroke30mmIllumination featuresExternal lamp house for Epi-illuminatorIllumination interchangeabilityQuartz halogen 12V/50W or LED 3WIncident illuminationQuartz halogen 12V/50W with integrated field and aperture diaphragmsInclination30° inclinedInterpupillary distance48-75mmNosepieceReversed quintupleObjective classificationCCIS® EC Plan Achromatic, DINObjective mounting threadW 4/5"x1/36" (RMS standard)PolarizationOptional slidersStageMechanical stage, hard coated with built-in low position coaxial stage controlStage size180x140mmStand typeUprightStandard contrast techniqueBrightfieldTravel range X&Y75x50mmUpper limit stopUpper limit stop preset but adjustableTransformerExternalPower supply100-240V (CE)Accessories includedDust cover, power cord, Allen keyDimensions LxWxH508x240x465mmWeight Net12.7kgComparison of ModelsSpecificationMotic BA310 MET BinocularMotic BA310 MET TrinocularMotic BA310 MET-H TrinocularMotic BA310 MET-H Trinocular (Erect Image)Motic BA310 MET-T Trinocular (3"x2" Stage)Motic BA310 MET-T Trinocular (6"x4" Stage)Motic BA310 MET-T Trinocular (Erect Image)Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image)Observation TubeBinocular headTrinocular headTrinocular headTrinocular head (Erect Image)Trinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingInterpupillary Distance48-75mm48-75mm55-75mm55-75mm48-75mm48-75mm48-75mm48-75mmObjective ClassificationCCIS® EC Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 11.5mm), 10X/0.3 (WD 6.8mm), 20X/0.40 (WD 11.1mm), 50X/0.55 (WD 8.2mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)StageMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage Size180x140mm180x140mm180x140mm180x140mm240x140mm300x180mm180x140mm240x140mmTravel Range X&Y75x50mm75x50mm100x80mm100x80mm75x50mm150x100mm75x50mm75x50mmIllumination InterchangeabilityQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3W.comparison-table tr td:nth-child(3) { background-color: #fffacd; }DownloadsTechnical Specification Download Operator's Manual Download

Motic BA310 MET Binocular Motic’s BA310MET series presents a powerful microscope line for incident l (more)ight applications in all material sciences. Industrial quality control of opaque samples can be performed as well as teaching in educational environments of engineering and material professions, where affordability and ease of use are key demands. Extended flexibility is given by the BA310MET-T models with built-in transmitted light for transparent or compound materials. The BA310MET-H includes a more flexible focusing device, dedicated to larger samples with little limitation in size. Motic's LM Plan-Achromatic objectives with Long-Working Distance for incident light provide optimal image contrast for reflective, non-covered specimen. Together with a fully corrected tube lens an intermediate image without colored fringes is created. In all models the Epi-Illuminator offers a powerful 50W Halogen light source. The built-in field diaphragm and aperture diaphragm help to optimize image quality by reducing stray light and thus increasing contrast.INCLUDED: The Motic BA310 MET Binocular includes: - 5X/0.13 (WD 20.3mm) Objective - 10X/0.25 (WD 17.5mm) Objective - 20X/0.40 (WD 8.1mm) Objective - 50X/0.55 (WD 8.4mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Operator's Guide Motic BA310 MET Binocular SpecificationsObservation tubeBinocular head, Siedentopf type, 360° swivelingOptical systemColour Corrected Infinity Optical System (CCIS®)Diopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield N-WF10X/20mm with diopter adjustmentFine focus precision2µmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFocusing stroke30mmIllumination featuresExternal lamp house for Epi-illuminatorIllumination interchangeabilityQuartz halogen 12V/50W or LED 3WIncident illuminationQuartz halogen 12V/50W with integrated field and aperture diaphragmsInclination30° inclinedInterpupillary distance48-75mmNosepieceReversed quintupleObjective classificationCCIS® EC Plan Achromatic, DINObjective mounting threadW 4/5"x1/36" (RMS standard)Objectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)PolarizationOptional slidersStageMechanical stage, hard coated with built-in low position coaxial stage controlStage size180x140mmStand typeUprightStandard contrast techniqueBrightfieldTravel range X&Y75x50mmUpper limit stopUpper limit stop preset but adjustableTransformerExternalPower supply100-240V (CE)Dimensions LxWxH508x240x465mmWeight Net12.5kgComparison of ModelsSpecificationMotic BA310 MET BinocularMotic BA310 MET TrinocularMotic BA310 MET-H TrinocularMotic BA310 MET-H Trinocular (Erect Image)Motic BA310 MET-T Trinocular (3"x2" Stage)Motic BA310 MET-T Trinocular (6"x4" Stage)Motic BA310 MET-T Trinocular (Erect Image)Motic BA310 MET-T Trinocular (Stroke 3”x 2” Stage) (Erect Image)Observation TubeBinocular headTrinocular headTrinocular headTrinocular head (Erect Image)Trinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingTrinocular head, Siedentopf type, 360° SwivelingInterpupillary Distance48-75mm48-75mm55-75mm55-75mm48-75mm48-75mm48-75mm48-75mmObjective ClassificationCCIS® EC Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® LM Plan Achromatic, DINCCIS® EC Plan Achromatic, DINCCIS® LM Plan Achromatic, DINObjectives5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 11.5mm), 10X/0.3 (WD 6.8mm), 20X/0.40 (WD 11.1mm), 50X/0.55 (WD 8.2mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)5X/0.13 (WD 20.3mm), 10X/0.25 (WD 17.5mm), 20X/0.40 (WD 8.1mm), 50X/0.55 (WD 8.4mm)StageMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage control and glass plateMechanical stage, hard coated with built-in low position coaxial stage controlMechanical stage, hard coated with built-in low position coaxial stage control and glass plateStage Size180x140mm180x140mm180x140mm180x140mm240x140mm300x180mm180x140mm240x140mmTravel Range X&Y75x50mm75x50mm100x80mm100x80mm75x50mm150x100mm75x50mm75x50mmIllumination InterchangeabilityQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3WQuartz halogen 12V/50W or LED 3WEpi-illuminator Quartz halogen 12V/50W or LED 3W, transmitted Quartz halogen 6V/30W or LED 3W.comparison-table tr td:nth-child(2) { background-color: #fffacd; }DownloadsTechnical Specification Download Operator's Manual Download

Motic BA310 Digital LED Compound Microscope Magnification Range 4x to 100x Optical System Colour Cor (more)rected Infinity (CCIS) Illumination Koehler 3W LED Features - Binocular head Siedentopf type, 30º inclined with built-in digital camera CMOS 1/2” chip - 3MP - 2048x1536 pixels with USB2.0 output - Widefield high eyepoint eyepieces N-WF10X/20mm with diopter adjustment on both eyepieces, with rubber eyecups - Reversed quintuple revolving nosepiece - CCIS EF-N Plan Achromatic objectives EF-N PL 4X, 10X, 40X S, 100X S Oil - Coaxial coarse and fine focusing system with tension adjustment - Built in low position coaxial mechanical stage (Right-hand control) - Focusable Abbe condenser N.A. 0.90/1.25 with iris diaphragm and slot - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) The new Motic BA310 Digital LED Compund Microscope is designed for the rigors of daily routine work specifically for diverse applications in Hematology and Cytology. The BA310 Digital is a version of the BA310 featuring a built-in 3.0MP sensor. The demands placed on any routine microscope for daily work needing careful focus on every microscope detail. The new BA310 series features a powerful adjustable light source to meet both delicate and detailed lighting requirements for all sample types while the fully featured Koehler illumination helps in highlighting even the weakest stained specimens. New CCIS EF-N Plan Achromat objectives provide optimal image contrast through newly designed multi-layer lens coatings. Click Here to View Product Video INCLUDED: The Motic BA310 Digital LED Compound Microscope includes: - Widefield high eyepoint eyepiece N-WF10X / 20mm with diopter adjustment - Built-in Digital Live Hi-Res Imaging Camera (5MP Resolution USB 2.0) - Reversed quintuple revolving nosepiece - CCIS EC Plan Achromat Objectives 4x, 10x, 40x S, 100x S-oil - Built in low position coaxial mechanical stage (Right-hand control) - Focusable Abbe condenser N.A. 0.9 with iris diaphragm and slot - 45mm blue filter, immersion oil (5mL), power cord, allen hexagonal key, vinyl dust cover - Koehler illumination 3W LED with intensity control - Motic Images Plus 3.0 for PC and MAC - Calibration Slide - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic BA210S Trinocular Microscope with LED Illumination w/o 100x Objective This version of the Moti (more)c BA210S is a biological compound microscope with a trinocular head and ASC PL 4x, 10x, 40x S objectives designed for advanced biology students, teachers, doctors, and lab technicians. Every aspect of these microscopes contributes to making your daily work easier. The ergonomic shape of the stand and the comfortability of the different heads enables fatigue-free viewing for many hours.The BA210S is designed for educational and teaching environments from basic life sciences to medical applications. Contrast methods like Phase Contrast, Polarization, and Darkfield are easily performed by using optional accessories.INCLUDED: The Motic BA210S Trinocular Microscope with LED Illumination w/o 100x Objective includes: - 10x Eye Piece - Objectives: ASC PL 4X, 10X, 40X S - Power Cord - Operator's Guide - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic BA210S Trinocular Microscope with LED Illumination This version of the Motic BA210S is a biolo (more)gical compound microscope with a trinocular head and ASC PL 4x, 10x, 40x S, and 100X S-Oil objectives designed for advanced biology students, teachers, doctors, and lab technicians. Every aspect of these microscopes contributes to making your daily work easier. The ergonomic shape of the stand and the comfortability of the different heads enables fatigue-free viewing for many hours.The BA210S is designed for educational and teaching environments from basic life sciences to medical applications. Contrast methods like Phase Contrast, Polarization, and Darkfield are easily performed by using optional accessories.INCLUDED: The Motic BA210S Trinocular Microscope with LED Illumination includes: - 10x Eye Piece - Objectives: ASC PL 4X, 10X, 40X S, 100X S-Oil - Power Cord - Operator's Guide - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic BA210S Binocular Microscope with LED Illumination w/o 100x Objective This version of the Motic (more) BA210S is a biological compound microscope with a binocular head and ASC PL 4x, 10x, and 40x objectives designed for advanced biology students, teachers, doctors, and lab technicians. Every aspect of these microscopes contributes to making your daily work easier. The ergonomic shape of the stand and the comfortability of the different heads enables fatigue-free viewing for many hours.The BA210S is designed for both educational and teaching environments from basic life sciences to medical applications. Contrast methods like Phase Contrast, Polarization and Dark field are easily performed by using optional accessories.INCLUDED: The Motic BA210S Binocular Microscope with LED Illumination w/o 100x Objective includes: - 10x Eye Piece - Objectives: ASC PL 4X, 10X, 40X S - Power Cord - Operator's Guide - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic BA210S Binocular Microscope with LED Illumination This version of the Motic BA210S is a biolog (more)ical compound microscope with a binocular head and ASC PL 4x, 10x, 40x S, and 100X S-Oil objectives designed for advanced biology students, teachers, doctors, and lab technicians. Every aspect of these microscopes contributes to making your daily work easier. The ergonomic shape of the stand and the comfortability of the different heads enables fatigue-free viewing for many hours.The BA210S is designed for both educational and teaching environments from basic life sciences to medical applications. Contrast methods like Phase Contrast, Polarization and Dark field are easily performed by using optional accessories.INCLUDED: The Motic BA210S Binocular Microscope with LED Illumination includes: - 10x Eye Piece - Objectives: ASC PL 4X, 10X, 40X S, 100X S-Oil - Power Cord - Operator's Guide - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic BA210E LED Trinocular Compound Microscope Magnification Range 4x to 100x Optical System Colour (more) Corrected Infinity (CCIS) Illumination 3W LED Features - Optional intermediate Epi-LED S fluorescence module - Quadruple nosepiece - EC Plan achromatic objectives - Compact rackless stage - Upgradable with phase & pol contrast and simple darkfield - Fixed-Koehler illumination, HAL/LED interchangeability - Coaxial coarse and fine focusing system with tension adjustment - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) Motic’s BA210E is dedicated to give an answer on basic demands from educational and biomedical laboratory work. The upgraded EC Plan Achromatic objectives in our CCIS© Infinity Concept deliver a fully corrected intermediate image for crisp and clear results within a 20mm Field of View. The rackless stage enables a safe x/y scanning even for the unexperienced user. The complete series of EC Plan Achromatic objectives, from 4X to 100X magnification, is achieving an improved image contrast both for human eye and digital cameras through the photo port. Especially in Phase contrast, the optional objectives (positive & negative Phase) show a remarkable performance for a wide range of applications. The N-WF eyepieces start with the standard 10X/20 mm Field of View and provide a diopter adjustment (+/-5dpt) for both eyes, ready for the use of optional reticles. Motic's BA210E is designed for a demanding daily usage. The rackless stage allows a safe evaluation of samples without prominent gear rack. The standard eyepiece tubes feature a 30° viewing angle for maximum comfort, whereas the interpupillary distance of 55-75mm can easily be adjusted, following individual conditions. The trinocular tube option with a 100:0 / 20:80 light split allows the adaption of digital camera systems and the presentation of microscopic images to a larger public. The BA210E is an integral part of Motic’s BA microscope concept. An upgrade with Phase contrast (positive & negative), Darkfield, Polarization and even LED Fluorescence can easily be performed. The BA210E exceeds the limits of a basic upright microscope, allowing to use contrast methods for specific application fields even in teaching environments with limited resources. INCLUDED: The Motic BA210E LED Trinocular Compound Microscope includes: - Trinocular head Siedentopf type 30° inclined 360° rotating (Light Split 100:0/20:80) - Widefield high eyepoint eyepiece N-WF10X/20mm with diopter adjustment - Reversed quadruple revolving nosepiece - CCIS EC Plan Achromat objectives EC PL 4x, 10x, 40x S, 100x S-oil - Built in low position coaxial rackless stage (Right-hand control) - Focusable Abbe condenser N.A. 1.25 with iris diaphragm and slot - 3WLED module - 45mm blue filter, immersion oil (5mL), allen hexagonal key, thumb screw, vinyl dust cover - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic BA210E LED Binocular Compound Microscope w/o 100x Objective Magnification Range 4x to 40x Opti (more)cal System Colour Corrected Infinity (CCIS) Illumination 3W LED Features - Optional intermediate Epi-LED S fluorescence module - Quadruple nosepiece - EC Plan achromatic objectives - Compact rackless stage - Upgradable with phase & pol contrast and simple darkfield - Fixed-Koehler illumination, HAL/LED interchangeability - Coaxial coarse and fine focusing system with tension adjustment - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) Motic’s BA210E is dedicated to give an answer on basic demands from educational and biomedical laboratory work. The upgraded EC Plan Achromatic objectives in our CCIS© Infinity Concept deliver a fully corrected intermediate image for crisp and clear results within a 20mm Field of View. The rackless stage enables a safe x/y scanning even for the unexperienced user. The complete series of EC Plan Achromatic objectives, from 4X to 100X magnification, is achieving an improved image contrast both for human eye and digital cameras through the photo port. Especially in Phase contrast, the optional objectives (positive & negative Phase) show a remarkable performance for a wide range of applications. The N-WF eyepieces start with the standard 10X/20 mm Field of View and provide a diopter adjustment (+/-5dpt) for both eyes, ready for the use of optional reticles. Motic's BA210E is designed for a demanding daily usage. The rackless stage allows a safe evaluation of samples without prominent gear rack. The standard eyepiece tubes feature a 30° viewing angle for maximum comfort, whereas the interpupillary distance of 55-75mm can easily be adjusted, following individual conditions. The trinocular tube option with a 100:0 / 20:80 light split allows the adaption of digital camera systems and the presentation of microscopic images to a larger public. The BA210E is an integral part of Motic’s BA microscope concept. An upgrade with Phase contrast (positive & negative), Darkfield, Polarization and even LED Fluorescence can easily be performed. The BA210E exceeds the limits of a basic upright microscope, allowing to use contrast methods for specific application fields even in teaching environments with limited resources. INCLUDED: The Motic BA210E LED Binocular Compound Microscope w/o 100x Objective includes: - Binocular head Siedentopf type 30° inclined, 360 ° rotating - Widefield high eyepoint eyepiece N-WF10X/20mm with diopter adjustment - Reversed quadruple revolving nosepiece - CCIS EC Plan Achromat Objectives EC PL 4x, 10x, 40x S - Built in low position coaxial rackless stage (Right-hand control) - Focusable Abbe condenser N.A. 1.25 with iris diaphragm and slot - 3WLED module - 45mm blue filter, immersion oil (5mL), allen hexagonal key, thumb screw, vinyl dust cover - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic BA210E LED Binocular Compound Microscope Magnification Range 4x to 100x Optical System Colour  (more)Corrected Infinity (CCIS) Illumination 3W LED Features - Optional intermediate Epi-LED S fluorescence module - Quadruple nosepiece - EC Plan achromatic objectives - Compact rackless stage - Upgradable with phase & pol contrast and simple darkfield - Fixed-Koehler illumination, HAL/LED interchangeability - Coaxial coarse and fine focusing system with tension adjustment - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) Motic’s BA210E is dedicated to give an answer on basic demands from educational and biomedical laboratory work. The upgraded EC Plan Achromatic objectives in our CCIS© Infinity Concept deliver a fully corrected intermediate image for crisp and clear results within a 20mm Field of View. The rackless stage enables a safe x/y scanning even for the unexperienced user. The complete series of EC Plan Achromatic objectives, from 4X to 100X magnification, is achieving an improved image contrast both for human eye and digital cameras through the photo port. Especially in Phase contrast, the optional objectives (positive & negative Phase) show a remarkable performance for a wide range of applications. The N-WF eyepieces start with the standard 10X/20 mm Field of View and provide a diopter adjustment (+/-5dpt) for both eyes, ready for the use of optional reticles. Motic's BA210E is designed for a demanding daily usage. The rackless stage allows a safe evaluation of samples without prominent gear rack. The standard eyepiece tubes feature a 30° viewing angle for maximum comfort, whereas the interpupillary distance of 55-75mm can easily be adjusted, following individual conditions. The trinocular tube option with a 100:0 / 20:80 light split allows the adaption of digital camera systems and the presentation of microscopic images to a larger public. The BA210E is an integral part of Motic’s BA microscope concept. An upgrade with Phase contrast (positive & negative), Darkfield, Polarization and even LED Fluorescence can easily be performed. The BA210E exceeds the limits of a basic upright microscope, allowing to use contrast methods for specific application fields even in teaching environments with limited resources. INCLUDED: The Motic BA210E LED Binocular Compound Microscope includes: - Binocular head Siedentopf type 30° inclined, 360 ° rotating - Widefield high eyepoint eyepiece N-WF10X/20mm with diopter adjustment - Reversed quadruple revolving nosepiece - CCIS EC Plan Achromat Objectives EC PL 4x, 10x, 40x S, 100x S-oil - Built in low position coaxial rackless stage (Right-hand control) - Focusable Abbe condenser N.A. 1.25 with iris diaphragm and slot - 3WLED module - 45mm blue filter, immersion oil (5mL), allen hexagonal key, thumb screw, vinyl dust cover - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic BA210 LED Digital Compound Microscope Magnification Range 4x to 100x Optical System Colour Cor (more)rected Infinity (CCIS) Illumination 3W LED Features - Binocular head Siedentopf type, 30º inclined with Built-in digital camera CMOS 1/2” chip - 3MP - 2048x1536 pixels with USB 2.0 output - Widefield high eyepoint eyepieces N-WF10X/20mm with diopter adjustment - Reversed quadruple revolving nosepiece - CCIS EF-N Plan Achromatic objectives EF-N PL 4X, 10X, 40X S, 100X S Oil - Built in low position coaxial mechanical stage (Right-hand control) - Focusable Abbe condenser N.A. 0.90/1.25 with iris diaphragm and slot - Coaxial coarse and fine focusing system with tension adjustment - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) The new Motic BA310 Digital Pro Upright Microscope is designed for the rigors of daily routine work specifically for diverse applications in Hematology and Cytology. The BA310 Digital is a version of the BA310 featuring a built-in 3.0MP sensor. The demands placed on any routine microscope for daily work needs careful focus on every microscope detail. The new BA310 series features a powerful adjustable light source to meet both delicate and detailed lighting requirements for all sample types while the fully featured Koehler illumination helps in highlighting even the weakest-stained specimens. New CCIS EF-N Plan Achromat objectives provide optimal image contrast through newly designed multi-layer lens coatings. INCLUDED: The Motic BA210 LED Digital Compound Microscope includes: - Widefield high eyepoint eyepiece N-WF10X / 20mm with diopter adjustment - Built-in Digital Live Hi-Res Imaging Chip, 2592 x 1944 Resolution USB 2.0 - Reversed quadruple revolving nosepiece - CCIS EC Plan Achromat objectives 4x, 10x, 40x S, 100x S-oil - Built in low position coaxial mechanical stage (Right-hand control) - Focusable Abbe condenser N.A. 1.25 with iris diaphragm and slot - 45mm blue filter, immersion oil (5mL), power cord, allen hexagonal key, vinyl dust cover - Built in illumination 3W LED with intensity control - Motic Images Plus 3.0 for PC and MAC - Calibration Slide - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic B1-253SP LED Binocular Compound Microscope Magnification Range 4x to 100x Optical System Finit (more)e, 160mm Illumination 3W LED Features - For basic work in biology and medicine - View sections, smears, and other transparent samples - Trinocular head - Semi-Planachromatic SP - 3W LED Illumination - Robust and sturdy base - Phase contrast, Dark field, and Polarization accessories optionally available - Coarse focusing system with tension adjustment - Switching power supply for use worldwide (100-240V) Superior in design and in performance, the B1 Series incorporates a wide range of features designed for university and laboratory use. Superb optical clarity and reliable mechanical engineering assures years of top performance. Choose from two grades of objectives: Standard Achromatic lenses deliver excellent clarity and normal flatness of field, while the ASC Achromatic Super Contrast objectives deliver extra contrast to the image. Combined with precision coaxial coarse and fine focusing adjustments, the B1 models are exceptionally high quality microscopes available within a tight budget. The B1 series also comes equipped with a new rack-less stage, which allows the microscope to be used in different current and future tenders. In order to provide enough light to Brightfield, Phase Contrast as well as Darkfield applications, the illumination has been changed to Motic’s powerful true 3W LED keeping the system cool as well as properly illuminated with steady color-temperature. INCLUDED: The Motic B1-253SP LED Binocular Compound Microscope includes: - Trinocular head inclined 45º and 360º rotating - Widefield eyepieces WF10X / 18mm - Quadruple nosepiece - Semi-Plan Achromatic Objectives: 4X, A 10X, 40X S, 100X S-Oil - Built in low position coaxial Rackless mechanical stage - Focusable 1.25 N.A. Abbe condenser - Iris diaphragm with filter holder - LED illumination 3W with intensity control - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic B1-253ASC LED Binocular Compound Microscope Magnification Range 4x to 100x Optical System Fini (more)te, 160mm Illumination 3W LED Features - For basic work in biology and medicine - View sections, smears, and other transparent samples - Trinocular head - Achromatic Super Contrast - 3W LED Illumination - Robust and sturdy base - Phase contrast, Dark field, and Polarization accessories optionally available - Coarse focusing system with tension adjustment - Switching power supply for use worldwide (100-240V) Superior in design and in performance, the B1 Series incorporates a wide range of features designed for university and laboratory use. Superb optical clarity and reliable mechanical engineering assures years of top performance. Choose from two grades of objectives: Standard Achromatic lenses deliver excellent clarity and normal flatness of field, while the ASC Achromatic Super Contrast objectives deliver extra contrast to the image. Combined with precision coaxial coarse and fine focusing adjustments, the B1 models are exceptionally high quality microscopes available within a tight budget. The B1 series also comes equipped with a new rack-less stage, which allows the microscope to be used in different current and future tenders. In order to provide enough light to Brightfield, Phase Contrast as well as Darkfield applications, the illumination has been changed to Motic’s powerful true 3W LED keeping the system cool as well as properly illuminated with steady color-temperature. INCLUDED: The Motic B1-253ASC LED Binocular Compound Microscope includes: - Trinocular head inclined 45º and 360º rotating - Widefield eyepieces WF10X / 18mm - Quadruple nosepiece - Achromatic Super Contrast Objectives: ASC 4X, 10X, 40X S, 100X S-Oil - Built in low position coaxial Rackless mechanical stage - Focusable 1.25 N.A. Abbe condenser - Iris diaphragm with filter holder - LED illumination 3W with intensity control - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic B1-252SP LED Binocular Compound Microscope Magnification Range 4x to 100x Optical System Finit (more)e, 160mm Illumination 3W LED Features - For basic work in biology and medicine - View sections, smears, and other transparent samples - Binocular head - Semi-Planachromatic SP - 3W LED Illumination - Robust and sturdy base - Phase contrast, Dark field, and Polarization accessories optionally available - Coarse focusing system with tension adjustment - Switching power supply for use worldwide (100-240V) Superior in design and in performance, the B1 Series incorporates a wide range of features designed for university and laboratory use. Superb optical clarity and reliable mechanical engineering assures years of top performance. Choose from two grades of objectives: Standard Achromatic lenses deliver excellent clarity and normal flatness of field, while the ASC Achromatic Super Contrast objectives deliver extra contrast to the image. Combined with precision coaxial coarse and fine focusing adjustments, the B1 models are exceptionally high quality microscopes available within a tight budget. The B1 series also comes equipped with a new rack-less stage, which allows the microscope to be used in different current and future tenders. In order to provide enough light to Brightfield, Phase Contrast as well as Darkfield applications, the illumination has been changed to Motic’s powerful true 3W LED keeping the system cool as well as properly illuminated with steady color-temperature. INCLUDED: The Motic B1-252SP LED Binocular Compound Microscope includes: - Binocular head inclined 45° and 360° rotating - Widefield eyepieces WF10X / 18mm - Quadruple nosepiece - Semi plan Achromatic Objectives: 4X, A 10X, 40X S, 100X S-Oil - Built in low position coaxial Rackless mechanical stage - Focusable 1.25 N.A. Abbe condenser - Iris diaphragm with filter holder - LED illumination 3W with intensity control - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic B1-252ASC LED Binocular Compound Microscope Magnification Range 4x to 100x Optical System Fini (more)te, 160mm Illumination 3W LED Features - For basic work in biology and medicine - View sections, smears, and other transparent samples - Binocular head - Achromatic Super Contrast - 3W LED Illumination - Robust and sturdy base - Phase contrast, Dark field, and Polarization accessories optionally available - Coarse focusing system with tension adjustment - Switching power supply for use worldwide (100-240V) Superior in design and in performance, the B1 Series incorporates a wide range of features designed for university and laboratory use. Superb optical clarity and reliable mechanical engineering assures years of top performance. Choose from two grades of objectives: Standard Achromatic lenses deliver excellent clarity and normal flatness of field, while the ASC Achromatic Super Contrast objectives deliver extra contrast to the image. Combined with precision coaxial coarse and fine focusing adjustments, the B1 models are exceptionally high quality microscopes available within a tight budget. The B1 series also comes equipped with a new rack-less stage, which allows the microscope to be used in different current and future tenders. In order to provide enough light to Brightfield, Phase Contrast as well as Darkfield applications, the illumination has been changed to Motic’s powerful true 3W LED keeping the system cool as well as properly illuminated with steady color-temperature. INCLUDED: The Motic B1-252ASC LED Binocular Compound Microscope includes: - Binocular head inclined 45° and 360° rotating - Widefield eyepieces WF10X / 18mm - Quadruple nosepiece - Achromatic Super Contrast Objectives: ASC 4X, 10X, 40X S, 100X S-Oil - Built in low position coaxial Rackless mechanical stage - Focusable 1.25 N.A. Abbe condenser - Iris diaphragm with filter holder - LED illumination 3W with intensity control - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic AE31E LED Trinocular Inverted Microscope Magnification Range 4x to 40x Optical System Colour C (more)orrected Infinity (CCIS) Illumination 3W LED Features - Professional inverted microscope providing the best image quality, ergonomic design, and clever illumination features - Ideal for all types of routine microbiology applications - Upgradable options like fluorescence are available within this microscope series - Light intensity adjustment with memory for each objective position - Fixed stage plate carries a glass or metal insert for quick overview and comfortable change of objectives - Coaxial coarse and fine focusing system with tension adjustment - Fine focus precision of 2 μm - Auto ON-OFF illumination function via built-in IR-sensor - Focusable and centerable swing-out ELWD Condenser - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) The AE31E is a refined inverted microscope with an extended focus on practical aspects and is Motic's new statement for a professional inverted microscope providing the best image quality, ergonomic design, and clever illumination features. This version of the Motic AE31E is an inverted microscope with a trinocular head and 4X, 10X and 20X objectives. The AE31E is the perfect platform for all kind of routine microbiology applications in clinical and pharmaceutical laboratories with the best options for university research environments. In full accordance with Motic’s CCIS Infinity System, the new LWD Plan Achromatic objectives with an intelligent Phase contrast concept deliver a remarkable image quality. Phase contrast is an integral part of all standard packages, while the optional 4X Phase objective is dedicated to fast screening. The AE31E stand carries an encoded 5-fold nosepiece with a light memory function. The illumination intensity for each objective position is memorized and replicated once the respective objective is swung in again. Rich illumination power is given by the 30 Watt Halogen light source in a Full-Koehler configuration, simply interchangeable with 3W LED modules of different color temperatures. All accessories from the BA series such as the C-mounts, additional eyepieces, etc. can be used without restriction on AE31 Elite. Upgradable options like fluorescence are available within this inverted microscope series. INCLUDED: The Motic AE31E LED Trinocular Inverted Microscope includes: - Widefield WF10x Eyepiece N-WF 10X / 22mm - Rubber Eyecups - Side Facing Quintuple Nosepiece - CCIS Plan Achromat PL4x Objective - CCIS Plan Achromat PL Ph10X, LWD PL Ph20X Phase Objectives - Phase Slider Ph0, BF, Ph1 - Centering Telescope & Keys - Plain Stage with Metal & Glass Inserts - 45mm Blue, Ground Glass and Green Interference Filters - ELWD Condenser N.A. 0.30 (WD = 72mm) with Filter Holder - Allen Hexagonal Key and Vinyl Dust Cover - Koehler Illumination 3W LED with Intensity Control - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic AE2000MET Trinocular Inverted Industrial Microscope, 50W Illumination Objectives Optional Opt (more)ical System Colour Corrected Infinity Optical System (CCIS) Illumination Kohler Quartz Halogen 12V/50W Features - Robust manufacturing quality for a long lifetime - New BF/DF objectives for metallurgy (sold separately) - Sufficient power resources - A flexible upgrade for digital results The Motic AE2000MET Trinocular Inverted Industrial Microscope, 50W Illumination is an Inverted Metallurgical microscope designed to inspect polished cross-sections as well as larger, bulky samples within industries such as automotive, machinery, and metal fabrication. Large metal or die cast parts, too large to view under a conventional upright microscope, can easily be examined for failure analysis, material research or quality control. INCLUDED: The Motic AE2000MET Trinocular Inverted Industrial Microscope, 50W Illumination includes: - Widefield N-WF10X/20mm Eyepieces - Dust Cover - Allen Key - Blue Filter - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic PA53MET-BD-T-3D Trinocular Upright Industrial Microscope w/ Analysis Professional Software Sui (more)te Stage Type Mechanical stage with low-position coaxial control and round/oval inserts Optical System Color Corrected Infinity Optical System (CCIS®) Illumination Koehler Quartz halogen 12V/100W with intensity control, External lamphouse Features - Robust manufacturing quality for a long lifetime - New BF/DF objectives for metallurgy - Sufficient power resources - A flexible upgrade for digital results Motic AE2000MET Trinocular Inverted Industrial Microscope, 100W Illumination Motic’s AE2000MET is an Inverted Metallurgical microscope designed to inspect polished cross-sections as well as larger, bulky samples within industries such as automotive, machinery, and metal fabrication. Large metal or die cast parts, too large to view under a conventional upright microscope, can easily be examined for failure analysis, material research or quality control.INCLUDED: The Motic AE2000MET Trinocular Inverted Industrial Microscope, 100W Illumination includes: - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic AE2000 LED Trinocular Inverted Microscope w/ Moticam BMH4000X Microscope Camera Objectives CCI (more)S® Plan Achromatic, DIN 4X, PH10X Fine Focus Precision Color Corrected Infinity Optical System (CCIS®) Transmitted Illumination (FPS) Quartz Halogen 6V/30W with Intensity Control Features - Color Corrected Infinity Optical System (CCIS®) for excellent image quality - Iris diaphragm for precise light control - Sturdy stage with metal and glass inserts for stable sample placement - Supports brightfield and phase contrast with a phase slider - Inverted stand suitable for routine microbiology and cell cultures - 8MP sensor for detailed and clear images - Features auto/manual exposure, white balance, saturation, contrast, and more

Motic AE2000 LED Trinocular Inverted Microscope - Basic Package Magnification Range 4x to 10x Optica (more)l System Colour Corrected Infinity (CCIS) Illumination 3W LED Features - Entry level model of Motic's inverted microscopes - Designed for routine live cell inspection with an easy and flexible set up - Offers superior image quality when viewing cell cultures in microbiology, living organisms, and tissue - Switch from Brightfield to Phase Contrast by a simple push of the phase ring slider - Fixed stage plate carries a glass or metal insert for quick overview and comfortable change of objectives - Coaxial coarse and fine focusing system with tension adjustment - Fine focus precision of 2 μm - Auto ON-OFF illumination function via built-in IR-sensor - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) The AE2000 is a revolutionary design that is packed with features and sets a new benchmark in affordable inverted microscopy. The AE2000 microscopes are Motic’s entry models of inverted microscopes, providing a flexible optical concept to meet best image quality and robust design for a long lifetime under rough lab conditions. This version of the Motic AE2000 is an inverted microscope with a trinocular head as well as 4X and 10X objectives. The AE2000 is the perfect microscope for routine microbiology in clinical and pharmaceutical laboratories, also offering best options for university teaching. In full accordance with Motic’s CCIS Infinity System, the LWD Plan Achromatic objectives with an ingenious Phase contrast concept deliver a remarkable image quality. The AE2000 stand carries a quadruple nosepiece with a precise click stop of objective positions. Rich illumination power is given by the 30 Watt Halogen light source in a Fixed-Koehler setup, simply interchangeable with 3W LED modules of different color temperatures. INCLUDED: Motic AE2000 LED Trinocular Inverted Microscope - Basic Package includes: - Widefield High Eyepoint Eyepiece N-WF 10X / 20mm - Side Facing Quadruple Nosepiece - PL PH 4x and PL PH 10x Objectives - Phase Slider Ph0, BF, Ph1 - Centering Telescope & Keys - Plain Stage with Metal & Glass Inserts - 45mm Blue, Green and Neutral Density Filters - ELWD Condenser N.A. 0.30 (WD = 72mm) with Filter Holder - Allen Hexagonal Key and Vinyl Dust Cover - 3W LED with Intensity Control - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic AE2000 LED Trinocular Inverted Microscope Magnification Range 4x to 20x Optical System Colour  (more)Corrected Infinity (CCIS) Illumination 3W LED Features - Entry level model of Motic's inverted microscopes - Designed for routine live cell inspection with an easy and flexible set up - Offers superior image quality when viewing cell cultures in microbiology, living organisms, and tissue - Switch from Brightfield to Phase Contrast by a simple push of the phase ring slider - Fixed stage plate carries a glass or metal insert for quick overview and comfortable change of objectives - Coaxial coarse and fine focusing system with tension adjustment - Fine focus precision of 2 μm - Auto ON-OFF illumination function via built-in IR-sensor - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) The AE2000 is a revolutionary design that is packed with features and sets a new benchmark in affordable inverted microscopy. The AE2000 microscopes are Motic’s entry models of inverted microscopes, providing a flexible optical concept to meet best image quality and robust design for a long lifetime under rough lab conditions. This version of the Motic AE2000 is an inverted microscope with a trinocular head and 4X, 10X and 20X objectives. The AE2000 is the perfect microscope for routine microbiology in clinical and pharmaceutical laboratories, also offering best options for university teaching. In full accordance with Motic’s CCIS Infinity System, the LWD Plan Achromatic objectives with an ingenious Phase contrast concept deliver a remarkable image quality. 10X and 20X Phase Contrast objectives are an integral part of all standard packages, while the optional 4X Phase objective is dedicated to fast screening. A 40X Phase objective is available too. The AE2000 stand carries a quadruple nosepiece with a precise click stop of objective positions. Rich illumination power is given by the 30 Watt Halogen light source in a Fixed-Koehler setup, simply interchangeable with 3W LED modules of different color temperatures. INCLUDED: The Motic AE2000 LED Trinocular Inverted Microscope includes: - Widefield High Eyepoint Eyepiece N-WF 10X / 20mm - Side Facing Quadruple Nosepiece - PL PH 4x, PL PH 10x, and PL PH 20x Objectives - Phase Slider Ph0, BF, Ph1 - Centering Telescope & Keys - Plain Stage with Metal & Glass Inserts - 45mm Blue, Green and Neutral Density Filters - ELWD Condenser N.A. 0.30 (WD = 72mm) with Filter Holder - Allen Hexagonal Key and Vinyl Dust Cover - 3W LED with Intensity Control - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic AE2000 LED Binocular Inverted Microscope - Basic Package Magnification Range 4x to 10x Optical (more) System Colour Corrected Infinity (CCIS) Illumination 3W LED Features - Entry level model of Motic's inverted microscopes - Designed for routine live cell inspection with an easy and flexible set up - Offers superior image quality when viewing cell cultures in microbiology, living organisms, and tissue - Switch from Brightfield to Phase Contrast by a simple push of the phase ring slider - Fixed stage plate carries a glass or metal insert for quick overview and comfortable change of objectives - Coaxial coarse and fine focusing system with tension adjustment - Fine focus precision of 2 μm - Auto ON-OFF illumination function via built-in IR-sensor - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) The AE2000 is a revolutionary design that is packed with features and sets a new benchmark in affordable inverted microscopy. The AE2000 microscopes are Motic’s entry models of inverted microscopes, providing a flexible optical concept to meet best image quality and robust design for a long lifetime under rough lab conditions. This version of the Motic AE2000 is an inverted microscope with a binocular head as well as 4X and 10X objectives. The AE2000 is the perfect microscope for routine microbiology in clinical and pharmaceutical laboratories, also offering best options for university teaching. In full accordance with Motic’s CCIS Infinity System, the LWD Plan Achromatic objectives with an ingenious Phase contrast concept deliver a remarkable image quality. The AE2000 stand carries a quadruple nosepiece with a precise click stop of objective positions. Rich illumination power is given by the 30 Watt Halogen light source in a Fixed-Koehler setup, simply interchangeable with 3W LED modules of different color temperatures. INCLUDED: The Motic AE2000 LED Binocular Inverted Microscope - Basic Package includes: - Widefield High Eyepoint Eyepiece N-WF 10X / 20mm - Side Facing Quadruple Nosepiece - PL PH 4x and PL PH 10x Objectives - Phase Slider Ph0, BF, Ph1 - Centering Telescope & Keys - Plain Stage with Metal & Glass Inserts - 45mm Blue, Green and Neutral Density Filters - ELWD Condenser N.A. 0.30 (WD = 72mm) with Filter Holder - Allen Hexagonal Key and Vinyl Dust Cover - 3W LED with Intensity Control - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic AE2000 LED Binocular Inverted Microscope Magnification Range 4x to 20x Optical System Colour C (more)orrected Infinity (CCIS) Illumination 3W LED Features - Entry level model of Motic's inverted microscopes - Designed for routine live cell inspection with an easy and flexible set up - Offers superior image quality when viewing cell cultures in microbiology, living organisms, and tissue - Switch from Brightfield to Phase Contrast by a simple push of the phase ring slider - Fixed stage plate carries a glass or metal insert for quick overview and comfortable change of objectives - Coaxial coarse and fine focusing system with tension adjustment - Fine focus precision of 2 μm - Auto ON-OFF illumination function via built-in IR-sensor - Manufactured in accordance with European RoHS Standard to avoid contact with lead - Anti-fungus treatment applied to all parts of the microscope for humidity protection - Switching power supply for use worldwide (100-240V) The AE2000 is a revolutionary design that is packed with features and sets a new benchmark in affordable inverted microscopy. The AE2000 microscopes are Motic’s entry models of inverted microscopes, providing a flexible optical concept to meet best image quality and robust design for a long lifetime under rough lab conditions. This version of the Motic AE2000 is an inverted microscope with a binocular head and 4X, 10X and 20X objectives. The AE2000 is the perfect microscope for routine microbiology in clinical and pharmaceutical laboratories, also offering best options for university teaching. In full accordance with Motic’s CCIS Infinity System, the LWD Plan Achromatic objectives with an ingenious Phase contrast concept deliver a remarkable image quality. 10X and 20X Phase Contrast objectives are an integral part of all standard packages, while the optional 4X Phase objective is dedicated to fast screening. A 40X Phase objective is available too. The AE2000 stand carries a quadruple nosepiece with a precise click stop of objective positions. Rich illumination power is given by the 30 Watt Halogen light source in a Fixed-Koehler setup, simply interchangeable with 3W LED modules of different color temperatures. INCLUDED: The Motic AE2000 LED Binocular Inverted Microscope includes: - Widefield High Eyepoint Eyepiece N-WF 10X / 20mm - Side Facing Quadruple Nosepiece - PL PH 4x, PL PH 10x, and PL PH 20x Objectives - Phase Slider Ph0, BF, Ph1 - Centering Telescope & Keys - Plain Stage with Metal & Glass Inserts - 45mm Blue, Green and Neutral Density Filters - ELWD Condenser N.A. 0.30 (WD = 72mm) with Filter Holder - Allen Hexagonal Key and Vinyl Dust Cover - 3W LED with Intensity Control - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty
