Tucsen MIchrome 16MP USB3.0 CMOS Microscope Camera with Live Stitching and EDF

UsedTUCSENCamerasUnited States

From€1,110.4excl. VAT

In stock

Can't find what you're looking for?

Brands
TUCSEN
New/Used
Used
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Product description

16MP color CMOS camera with USB3.0, live stitching, EDF, and 4-camera SDK support for bright-field imaging.

  • Sensor Type: CMOS, Sensor Model: SONY IMX206CQC
  • Resolution: 16MP (4608 x 3456 pixels)
  • Pixel Size: 1.34 μm x 1.34 μm
  • Effective Area: 6.2 mm x 4.6 mm (Array Diagonal 7.77 mm)
  • Shutter Mode: Rolling shutter
  • Frame Rate: 12 fps at full resolution
  • Exposure Time: 22 μs to 26 s
  • Binning: 2x2, 3x3, 4x4 modes available
  • Color Temperature Range: 2000 K to 15000 K
  • Optical Interface: Standard C-Mount
  • Bit Depth: 8-bit and 16-bit selectable
  • Data Interface: USB 3.0 for high-speed, stable transmission
  • Software Compatibility: Supports Windows 7/10 (32/64 bit) and Mac OS
  • SDK Support: C/C++, C#, Directshow/Twain; enables running up to 4 cameras simultaneously
  • Image Output Formats: TIFF, JPG, PNG, DICOM
  • PC Requirements: Intel Core i5 or higher (quad-core or more), 8GB RAM or more

Key Features:

  • Simultaneous operation of four cameras via SDK
  • Tucsen proprietary ISP color-interpolation algorithm for true color correction simulating human eye sensitivity
  • Suitable for brightfield imaging as well as fluorescence and polarized imaging
  • Advanced global shutter technology for distortion-free capture of fast-moving samples
  • Efficient workflow integration including image acquisition, editing, measurement, and report output
  • Supports live stitching and extended depth of field (EDF) imaging functions

This camera is optimized for open-field, high-quality color imaging in microscopy applications requiring accurate color reproduction and fast, high-resolution image acquisition.
