CMEX DC.5000-C

Digital photo camera Euromex CMEX DC.5000-C. 5 MPx and USB format. 2592 x 1944 pixels. Includes software Image Focus v4 and cable for connection to a PC.

Specifications:

Equipped with a sensor CMOS 10-bit conversion of gray-scale and a performance of 24-bit color. The cameras are equipped with data interface USB-2 and are provided with the software ImageFocus V4

In addition to the capture of images and videos, the software allows for measurements in still images and in vivo and annotating the captured images. Compatible with Windows XP, Vista, 7, 8, and 10, in configurations of 32 and 64-bit.

TECHNICAL SPECIFICATIONS CMEX-5 (DC.5000c)

CMOS Sensor 1/2.5 inch Pixels 2592 x 1944 pixels, 5.0 Mpix Scan type Progressive type blind Pixel size 2.2 µm x 2.2 µm RGB filter C-mount Maximum fps* Superior to 5 frames per second (2592 x 1944 pixels)

Top to 21 frames per second (1280 x 960 pixels)

Above 25 frames per second (1024 x 768 pixels)

Top to 38 frames per second (640 x 480 pixels)

ADC 10-bit

Color depth 24-bit Sensitivity 1.3 V/lux-sec @ 550 nm Exposure Automatic or manual, from 1 ms. up to 800 ms. Automatic white Balance or manual Dynamic range 65 db Signal/noise ratio 42 db Connection USB 2.0 at 480 Mb/sec Temp. of work 0 – 60° C, 45-85 % humidity Temp. storage -20 to 70° C Supplied Lens 0.45 x with C-mount, USB 2.0 cable, adapters to 30 and 30.5 mm for stereo microscopes, pattern calibration 76 x 24 mm with a scale of 1mm. in 100 parts, CD ROM with program ImageFocus V4, cardboard box. Compatible with Windows XP, Vista, Windows7, Windows 8, Windows 10 (configurations of 32 and 64 bit). OSX (only for capture of images and videos).
