Jasco J-815

Name: Jasco J-815
Brand: Jasco
SKU: 69710
Availability: PreOrder

UsedJascoOptical detectorsNetherlands

Procurable

Not in stock, available to order through our sourcing team

Not in stock, but we can get it for you

We source this model through our supplier network. Request a quote and we'll come back within one hour.

Request a quote
We confirm price and lead time
You approve, we ship to you

Wavelength range: 163–900 nm
Wavelength accuracy: ±0.2 nm (163–180 nm); ±0.1 nm (180–250 nm); ±0.3 nm (250–500 nm); ±0.8 nm (500–800 nm); ±2.0 nm (800–1100 nm)
Wavelength repeatability: ±0.05 nm (163–250 nm); ±0.1 nm (250–500 nm); ±0.2 nm (500–1100 nm)
Spectral bandwidth: 0.01–15 nm
Slit width: 1–3000 µm
Availability: Procurable
Lead time: Confirmed with your quote

All 31 specifications

Ships to NL
Response within 1 hour
Warranty available. Buy without worry
Support from a scientist

Specifications 31

Brands: Jasco
New/Used: Used
Wavelength range: 163–900 nm
Wavelength accuracy: ±0.2 nm (163–180 nm); ±0.1 nm (180–250 nm); ±0.3 nm (250–500 nm); ±0.8 nm (500–800 nm); ±2.0 nm (800–1100 nm)
Wavelength repeatability: ±0.05 nm (163–250 nm); ±0.1 nm (250–500 nm); ±0.2 nm (500–1100 nm)
Spectral bandwidth: 0.01–15 nm
Slit width: 1–3000 µm
Digital integration time: 0.5 ms–32 s
Scanning speeds: 1–10000 nm/min (continuous scan)
Data interval: 0.025–10 nm (continuous scan); 0.1–100 nm (step scan); 0.5 ms–60 min (time course)
CD full scale: ±10, 200, 2000 mdeg
CD resolution: 0.0005 mdeg (at ±10 mdeg full scale); 0.01 mdeg (at ±200 mdeg full scale); 0.1 mdeg (at ±2000 mdeg full scale)
Stray light: <0.0003% (200 nm)
Light source: 150 W air-cooled xenon lamp
Power supply: AC 100 V ±10 V, 200 VA
Voltage: 100 V

Current: Not specified
Measurement modes: Circular dichroism, UV/Vis absorbance, linear dichroism, fluorescence
Acquisition modes: Wavelength scan (3 modes), Time scan (slow and fast kinetics), Temperature scan
Detection limits: Not specified
Measurement range: 163–1100 nm
Temperature control range: 5–95°C
Stopped-flow accessory: Yes
Sample volume: 100–700 µL
Compatible materials: Proteins, nucleic acids, optically active substances
Dimensions: 1115 x 576 x 410 mm
Weight: 87 kg
Connectivity: USB, LAN
Data output: PC connection
Availability: Procurable
Lead time: Confirmed with your quote

Product description

Circular dichroism spectropolarimeter with 163–900 nm range, Peltier temp control 5–95°C, multimode measurement, stopped-flow accessory.

The Jasco J-815 is a state-of-the-art circular dichroism (CD) spectropolarimeter designed to analyse the chiroptical properties of biomolecules, providing critical insights into their secondary and tertiary structures. This instrument is essential for researchers aiming to understand protein folding, conformational changes, and interactions, particularly within the biotechnology sector.

Key features include:

Wavelength range: 163–900 nm, accommodating a broad spectrum of analyses.
Light source: 150 W air-cooled xenon lamp, ensuring stable and intense illumination.
Measurement modes: Circular dichroism, UV/Vis absorbance, linear dichroism, and fluorescence, offering versatile analytical capabilities.
Temperature control: Peltier element enabling precise thermal studies from 5°C to 95°C, crucial for thermal denaturation experiments.
Stopped-flow accessory: Facilitates rapid kinetics measurements, essential for studying fast biochemical reactions.

The J-815 is widely utilised in fields such as molecular biology, biochemistry, and pharmaceutical research. Its applications are particularly relevant in biotechnology, where understanding protein structures and interactions is vital for advancements in drug development, enzyme engineering, and synthetic biology.

Commonly found in university laboratories, biomedical research centres, and biopharmaceutical companies, the J-815 supports a range of studies, including:

Determining protein folding and conformational stability.
Characterising secondary structures like α-helices and β-sheets.
Investigating protein-ligand interactions and their effects on structure.
Assessing the impact of environmental factors such as pH, temperature, and denaturants on protein stability.

Introduced in 2006, the J-815 remains a cornerstone in chiroptical spectroscopy, reflecting Jasco's commitment to innovation and excellence in scientific instrumentation.
