ABB ACH580 Series 75 HP HVAC Variable Frequency Drive with Electronic Bypass

UsedABBIndustrial motorsUnited States

Price on request

In stock

Can't find what you're looking for?

Description
The ABB ACH580-3BCR-096A-4+F267 HVAC Drive operates at 480 volts, 3-phase, with a frequency of 60 Hz. It has a full load amperage rating of 96.3 A and a power rating of 75 HP. The unit is equipped with an electronic bypass and includes integrated cooling fans for thermal management. The drive is housed in a Type 1, 3R, 12 enclosure. Fuse ratings are specified for various components, including 100 A for the main fuse. The unit is UL listed as an enclosed industrial control panel. The drive includes two operator control panels: a standard keypad and an HVAC-specific keypad. Voltage: 480 V. Frequency: 60 Hz. Phase: 3. Fuse rating: 100 A main fuse. Software version: N/A. Manufacturing year: 2020 (visible on label dated 10 JUN 20).
Technical Data
Model: ACH580-3BCR-096A-4+F267 Serial Number: 22021002E0E Voltage: 480 V Frequency: 60 Hz Power Consumption: N/A Fuse Rating: 100 A (main fuse) Software Version: N/A Configuration: Electronic bypass, integrated cooling fans, Type 1, 3R, 12 enclosure, dual operator control panels (standard and HVAC keypad) Manufacturing Year: 2020
Voltage
480 V
Frequency
60 Hz
Power Consumption
N/A
All 14 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 14

Brands
ABB
New/Used
Used
Description
The ABB ACH580-3BCR-096A-4+F267 HVAC Drive operates at 480 volts, 3-phase, with a frequency of 60 Hz. It has a full load amperage rating of 96.3 A and a power rating of 75 HP. The unit is equipped with an electronic bypass and includes integrated cooling fans for thermal management. The drive is housed in a Type 1, 3R, 12 enclosure. Fuse ratings are specified for various components, including 100 A for the main fuse. The unit is UL listed as an enclosed industrial control panel. The drive includes two operator control panels: a standard keypad and an HVAC-specific keypad. Voltage: 480 V. Frequency: 60 Hz. Phase: 3. Fuse rating: 100 A main fuse. Software version: N/A. Manufacturing year: 2020 (visible on label dated 10 JUN 20).
Technical Data
Model: ACH580-3BCR-096A-4+F267 Serial Number: 22021002E0E Voltage: 480 V Frequency: 60 Hz Power Consumption: N/A Fuse Rating: 100 A (main fuse) Software Version: N/A Configuration: Electronic bypass, integrated cooling fans, Type 1, 3R, 12 enclosure, dual operator control panels (standard and HVAC keypad) Manufacturing Year: 2020
Voltage
480 V
Frequency
60 Hz
Power Consumption
N/A
Fuse Rating
100 A (main fuse)
Software Version
N/A
Configuration
Electronic bypass, integrated cooling fans, Type 1, 3R, 12 enclosure, dual operator control panels (standard and HVAC keypad)
Manufacturing Year
2020
Accessories
Electronic bypass module, Dual operator control panels, Integrated cooling fans, Enclosed industrial control panel, Installation and operation manuals
Dimensions
N/A
Weight
N/A

Product description

Robust 75 HP ABB ACH580 HVAC variable frequency drive with electronic bypass, 480 V, 96 A, enclosed control panel.

The ABB ACH580 Series HVAC Drive is an advanced variable frequency drive (VFD) engineered for precise control of HVAC motors, critical in bioprocessing facilities, molecular diagnostics labs, and biomanufacturing plants requiring energy-efficient and reliable environmental control. This model supports a 75 HP motor capacity, operates at 480 V, and delivers a rated current of 96 A.

Key features include:

  • Electronic bypass functionality for seamless switching and operational continuity during maintenance or fault conditions.
  • Housed within a UL listed enclosed industrial control panel designed for rigorous laboratory and industrial environments.
  • Integrated cooling fans to maintain optimal thermal performance, ensuring stable operation in demanding biotechnological and clinical diagnostic settings.

This drive is widely used to regulate air handling units, chillers, and pumps in HVAC systems essential for maintaining controlled environments in biomedical engineering applications and live-cell imaging facilities. Its precision variable frequency control helps optimize energy consumption and system reliability, making it a critical component in modern biopharmaceutical production pipelines and synthetic biology research laboratories.
