Inspectis U30s 4K Pro Metrology Gantry System with Motorized Zoom and Industrial Gantry Stand

The Inspectis U30s 4K Pro Metrology Gantry System is an industrial-grade digital microscope platform optimized for precision inspection, metrology, and measurement workflows in biotechnology, clinical diagnostics, and biomanufacturing environments. Featuring an 8.5 MP Ultra HD CMOS sensor (3840×2160) and true 4K video output at 30 fps, the system delivers exceptional resolution essential for advanced molecular diagnostics and synthetic biology research.

Key technical features include:

• Motorized 30:1 zoom lens with autofocus, iris control, and automatic zoom tracking—crucial for detailed cellular and micro-structural imaging.
• Robust XY gantry stand with travel ranges of 100–750 mm (X) and 100–550 mm (Y), plus an optional extended Y-axis up to 800 mm, enabling flexible sample positioning for varied bioprocessing tasks.
• 4-direction tilt attachment allowing ±30° viewing angles to inspect complex 3D sample geometries.
• White LED ring illumination with 8 high-power LEDs (5800 K) and diffuser for uniform, shadow-free lighting—ideal for live-cell imaging and fluorescence analysis setups.
• Integrated HDMI and USB 3.0 capture for full-HD video and image recording, supporting comprehensive documentation and data export critical in molecular cloning workflows and biomanufacturing quality control.
• 27" 4K Ultra HD monitor and workstation delivering ergonomic workflow efficiency during prolonged microscopy sessions common in cell imaging and neuroscience research.
• Inspectis Pro Software offering advanced metrology measurement tools such as overlay scales, circle/angle/curve detection, polygonal measurements, semi-transparent image overlays, and detailed report generation—widely adopted in synthetic biology and biomedical engineering laboratories.

The hermetically sealed camera housing with ESD protection ensures durability in sensitive biotechnological environments. This turnkey solution supports quality control, industrial inspection, and research applications requiring high-precision optical metrology.

Suitable for professionals in molecular diagnostics, bioprocessing, and clinical research, the Inspectis U30s system is integral in workflows demanding quantitative microscopy, precision measurement, and robust documentation.

SKU Variants: U30-PROMET-GTY-STD / U30-PROMET-GTY-LYR / U30-PROMET-GTY-STD-TLT / U30-PROMET-GTY-LYR-TLT

Manufactured in Sweden. Lead time typically 3–4 weeks. Non-returnable item.
