SUSS MicroTec PA 200 SemiAutomatic Wafer Prober for Precise Semiconductor Testing

The SUSS MicroTec PA 200 SemiAutomatic Wafer Prober is a specialized laboratory instrument designed for precise semiconductor wafer testing and electrical measurement in research and production environments. Manufactured in the United States, this equipment features:

• SemiAutomatic operation enabling efficient and reproducible probing cycles
• High-precision probe positioning technology tailored for detailed semiconductor analysis
• Robust construction to withstand routine laboratory and cleanroom conditions, ensuring repeated operational reliability
• Dimensions of 54 x 32 x 32 inches with a weight of approximately 163.29 kg, suitable for bench or floor installation
• Optimal for applications in biotechnology, molecular diagnostics, and biomanufacturing settings where semiconductor components are integral to instrumentation
• Supports critical workflows in bioprocessing instrumentation development and synthetic biology device testing where wafer-level analysis is essential

This prober is widely used in microelectronics research labs, biomedical engineering facilities, and industries requiring detailed wafer-level electrical testing and quality control. Note: the unit is sold without software, cables, or peripheral components, and currently shows operational functionality with minor cosmetic wear.

Ideal for laboratories focused on molecular diagnostics instrumentation, biotech device prototyping, and semiconductor device validation, the PA 200 delivers precision essential for high-throughput wafer testing in advanced biopharmaceutical production pipelines and gene editing platform development.
