Yamato FO-110CR 1.5L Muffle Furnace with Communication Port, 220V

UsedYamato ScientificHeating & coolingUnited States

From€2,934.32excl. VAT

In stock

Can't find what you're looking for?

Operating Temp. Range
100~1150°C
Temp. Control Accuracy
±2°C (at 1150 ° C)
Max. Temp. Reaching Time
~60min.
Exterior Material
Cold rolled steel plate with baked-on melamine resin finish
Internal Material
Ceramic fiber
All 23 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 23

Brands
Yamato Scientific
New/Used
Used
Operating Temp. Range
100~1150°C
Temp. Control Accuracy
±2°C (at 1150 ° C)
Max. Temp. Reaching Time
~60min.
Exterior Material
Cold rolled steel plate with baked-on melamine resin finish
Internal Material
Ceramic fiber
Sensor
R-thermocouple
Heater
Iron-chrome wire
Exhaust Port
ø20mm (top)
Cooling Fan Type
Axial fan motor
Temp. Controller
PID controll by microprocessor
Temp. Setting/Display Method
Digital setting by▲/▼ keys / Digital display
Operation Function
Fixed temperature, quick auto stop, auto stop, auto start, program (maximum 6 patterns: 30 steps x 1 pattern, 15 steps x 2 patterns or 10 steps x 3 patterns)
Additional Functions
Calibration off-set, power failure compensation, lock, RS485 communication interface
Timer
1 min. to 99 Hrs. 59 min. and 100 Hrs. to 999 Hrs.
Safe Device
Self diagnostic (memory error, heater disconnection, sensor error, SSR short curcuit), Electric leakage breaker, Overheat prevention device
Internal Dimensions WxDxH
100×150×100 mm
External Dimensions WxDxH
346×405×517 mm
Internal Capacity
1.5L
Power Source (50/60Hz)
AC220V 5A
Weight
~24kg
Accessories
Exhaust port cap 1 pc.

Product description

Microprocessor-controlled 1.5L muffle furnace, 100–1150°C, ±2°C accuracy with RS485 communication port.

The Yamato FO-110CR is a microprocessor-controlled muffle furnace featuring:

  • Operating temperature range: 100 to 1150°C
  • Temperature control accuracy: ±2.0°C at 1150°C
  • Internal capacity: 1.5 liters; internal dimensions 100 × 150 × 100 mm
  • Construction: Exterior of cold-rolled steel with baked-on melamine resin finish; internal chamber made of ceramic fiber
  • Heating element: Iron-chrome wire producing 1 kW power
  • Sensor: Long-life R-type thermocouple
  • Controller: PID control with digital setting/display and operation via ▲/▼ keys
  • Program operation capability: Up to 6 patterns, supporting 30 steps (1 pattern), 15 steps (2 patterns), or 10 steps (3 patterns)
  • Safety features: Self-diagnostic functions (memory error, heater disconnection, sensor error, SSR short circuit), earth leakage breaker, automatic overheat prevention device, calibration offset, lock function, and power failure compensation
  • Additional outputs: RS485 communication interface and selectable options such as exhaust system unit, N₂ gas loading device with flow meter, temperature and alarm output terminals
  • Physical dimensions: External 346 × 405 × 517 mm; weight approximately 24 kg
  • Power supply: AC 220V, 5A, 50/60 Hz
  • Extras: Exhaust port cap included
  • Cooling system: Axial fan motor with an exhaust port diameter of 20 mm (top)

Designed for high-temperature applications including glass fusing, enamel coating, ceramics, soldering, brazing, alloying, annealing, metallurgy, environmental testing, and R&D settings.
