Greenheck CUBE-120 Belt-Drive Rooftop Centrifugal Exhaust Fan for Fume Hood (1000 CFM)

Price on request

In stock

Can't find what you're looking for?

MPN
CUBE-120-5-1-19-X
Condition Description
IN VERY GOOD CONDITION
Electrical Requirements
115/208-230V, 60hZ, 1 phase
Electrical Certification / Approval
CUL
Weight (lbs)
70
All 9 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 9

Brands
Greenheck
New/Used
Used
MPN
CUBE-120-5-1-19-X
Condition Description
IN VERY GOOD CONDITION
Electrical Requirements
115/208-230V, 60hZ, 1 phase
Electrical Certification / Approval
CUL
Dimensions
25" diam x 28.5"H
Weight (lbs)
70
Country/region of manufacture
Canada

Product description

Belt-drive rooftop centrifugal exhaust fan with 1000 CFM airflow, max 400°F temp, 1 in w.g. static pressure.

  • Belt-drive, spun aluminum centrifugal exhaust fan designed for rooftop or wall-mounted applications.
  • Suitable for clean or lightly contaminated exhaust air, discharged upward or away from building surfaces.
  • Advanced motor cooling system optimized for performance and reliability.
  • One-piece windband, continuously welded to curb cap, ensures leak-proof construction for the fan’s lifetime.
  • Tested and certified by AMCA for sound, air performance, and fan efficiency (FEI).
  • Extensive life testing to guarantee durability and reliable operation over many years.
  • Maximum continuous operating temperature: 400°F (204°C).
  • Static pressure: 1 inch water gauge (in w.g.).
  • Airflow volume range: 681 to 1,063 CFM.
  • Airstream temperature reference: 70°F.
  • Maximum fan speed: 900 fan RPM (FRPM).
  • Physical dimensions: 19 x 19 inch base with prepunched mounting holes for roof curb attachment; recommended roof opening 15.5 x 15.5 inches.
  • Operating elevation considered: 1,654 ft.
  • Operating power: 0.07 BHP.
  • Ideal for exhaust in fume hood systems requiring reliable rooftop ventilation.
