American BioTech Supply 2.5 Cu Ft Vaccine Refrigerator PH-ABT-NSF-UCFS-0204G

UsedAmerican BioTech SupplyMedical equipment - otherUnited States

From€2,453.59excl. VAT

In stock

Can't find what you're looking for?

OPERATIONAL ENVIRONMENT
INDOOR USE ONLY. OPTIMAL OPERATING RANGE: +18°C TO +26°C (+65°F TO +78°F), <70% RH
STORAGE CAPACITY
2.5 CU. FT. GROSS VOLUME
DOOR
ONE SWING GLASS DOOR, SELF-CLOSING, RIGHT HINGED, NON-REVERSIBLE, MAGNETIC SEALED GASKET, KEYED LOCK
SHELVES
FOUR SHELVES (THREE ADJUSTABLE/ONE FIXED) WITH GUARD RAIL ON BACK
MOUNTING AND INSTALLATION
LEVELING LEGS. NOTE: 4" OF CLEARANCE ON ALL SIDES MUST BE MAINTAINED FOR ADEQUATE VENTILATION
All 21 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 21

Brands
American BioTech Supply
New/Used
Used
OPERATIONAL ENVIRONMENT
INDOOR USE ONLY. OPTIMAL OPERATING RANGE: +18°C TO +26°C (+65°F TO +78°F), <70% RH
STORAGE CAPACITY
2.5 CU. FT. GROSS VOLUME
DOOR
ONE SWING GLASS DOOR, SELF-CLOSING, RIGHT HINGED, NON-REVERSIBLE, MAGNETIC SEALED GASKET, KEYED LOCK
SHELVES
FOUR SHELVES (THREE ADJUSTABLE/ONE FIXED) WITH GUARD RAIL ON BACK
MOUNTING AND INSTALLATION
LEVELING LEGS. NOTE: 4" OF CLEARANCE ON ALL SIDES MUST BE MAINTAINED FOR ADEQUATE VENTILATION
INTERIOR LIGHTING
SHIELDED, SWITCHED LED LIGHTING, FULL COVERAGE, BALANCED SPECTRUM
AIRFLOW MANAGEMENT
FORCED AIR TECHNOLOGY, PATENT PENDING
EXTERNAL PROBE ACCESS
REAR WALL PORT (3/8") DIA.
INSULATION
CABINET IS FOAMED-IN-PLACE WITH EPA COMPLIANT HIGH DENSITY URETHANE FOAM
EXTERIOR MATERIALS
WHITE POWDER COATED STEEL
ACCESS CONTROL
PYXIS®, OMNICELL® AND ACUDOSE RX® COMPATIBLE
GENERAL WARRANTY
TWO (2) YEARS PARTS AND LABOR WARRANTY, EXCLUDING DISPLAY PROBE CALIBRATION
COMPRESSOR WARRANTY
FIVE (5) YEARS COMPRESSOR WARRANTY
PRODUCT WEIGHT
71 LBS.
SHIPPING WEIGHT
100 LBS.
RATED AMPERAGE
0.9 A MAX
POWER PLUG/POWER CORD
NEMA 5-15 PLUG, 8 TO 10 FT TYPICAL, CONFORMS TO UL471 REQUIREMENTS, VACCINE STORAGE POWER CORD WARNING LABEL
FACILITY ELECTRICAL REQUIREMENT
110-120V AC: 15 A (MINIMUM)
AGENCY LISTING AND CERTIFICATION
CERTIFIED IN ACCORDANCE WITH THE NSF/ANSI 456 STANDARD FOR VACCINE STORAGE. UL, C-UL, ETL, C-ETL LISTED (EITHER SINGLE OR DUAL AGENCY LISTINGS) AND CERTIFIED TO UL471 STANDARD, HYDROCARBON REFRIGERANT SAFETY.

Product description

2.5 cu ft NSF-compliant vaccine refrigerator with microprocessor control, alarms, LED lighting, and HFC-free refrigerant.

American BioTech Supply's 2.5 Cu Ft Vaccine Refrigerator model PH-ABT-NSF-UCFS-0204G is designed to meet NSF/ANSI 456 standards for vaccine storage. This undercounter unit maintains vaccines within 2°C to 8°C (36°F to 46°F) using forced air technology and microprocessor temperature control.

Key Features:

  • Capacity: 2.5 cubic feet gross volume
  • Door: One right-hinged, self-closing swing glass door with magnetic seal, keyed lock, non-reversible
  • Shelving: Four shelves (three adjustable, one fixed) with rear guard rails
  • Interior Lighting: Shielded, switched LED with full coverage and balanced spectrum
  • Airflow: Forced air technology (patent pending) ensuring uniform temperature distribution
  • Temperature Control: Parametric microprocessor controller with LED display, 0.1°C resolution, calibrated stainless steel display probe, temperature setpoint range 1°C to 10°C (factory preset for compliance)
  • Temperature Alarm System: High/low alarms compliant with NSF/ANSI 456; visual and audible alarms with remote alarm contacts
  • Probe Access: Rear wall 3/8" diameter port with included probes in buffered solution for accurate temperature measurement
  • Insulation: EPA-compliant high density foam-in-place urethane
  • Exterior: White powder-coated steel
  • Compatibility: Compatible with Pyxis®, Omnicell®, and Acudose Rx® access control systems
  • Power: 110-120V AC, 0.9A max, NEMA 5-15 plug, UL471 compliant
  • Noise Level: 34 dBA or less when installed
  • Energy Consumption: 0.58 kWh/day; heat rejection 1.00 kWh/day (142 BTU/h)
  • Performance: Temperature uniformity ±1.1°C; stability ±0.7°C; variation ±1.2°C; rapid recovery after door openings
  • Warranty: 2 years parts and labor (excluding display probe calibration), 5 years compressor warranty
  • Weight: Product weight 71 lbs; shipping weight 100 lbs
  • Certification: NSF/ANSI 456, UL, C-UL, ETL, C-ETL listings, Hydrocarbon refrigerant safety certified
  • Environmental: Utilizes HFC-free refrigerant for energy efficiency and environmental health

Operational Environment:

  • Indoor use only
  • Optimal ambient temperature +18°C to +26°C (+65°F to +78°F), relative humidity <70%
  • Requires 4 inches clearance on all sides for ventilation

Includes:

  • Temperature Monitor Device (TMD) compliant with CDC guidelines, 3-year calibration certification, min/max memory, field installable

This refrigerator is intended for secure pharmaceutical storage with precise temperature control and alarm functions, suitable for clinical and laboratory vaccine storage applications.
