Nikon Eclipse Ti

Name: Nikon Eclipse Ti
Brand: Nikon
SKU: 68771
Availability: PreOrder

UsedNikonMicroscope accessoriesNetherlands

Procurable

Not in stock, available to order through our sourcing team

Not in stock, but we can get it for you

We source this model through our supplier network. Request a quote and we'll come back within one hour.

Request a quote
We confirm price and lead time
You approve, we ship to you

Field Number: 22 with C-mount, 25 with F-mount
Intermediate Magnification Switching: Manual switching of 1.0x/1.5x
Condenser Lens Types: LWD (O.D.=30 mm, NA=0.52), ELWD (O.D.=75 mm, NA=0.29), CLWD (O.D.=13 mm, NA=0.72), HNA dry (O.D.=5 mm, NA=0.85), HNA oil (O.D.=2 mm, NA=1.4), NAMC (O.D.=44 mm, NA=0.4)
Focusing Unit Stroke: 10 mm
Focusing Unit Minimum Increments: 0.01 μm (coarse), 0.02 μm (fine)
Availability: Procurable
Lead time: Confirmed with your quote

All 23 specifications

Ships to NL
Response within 1 hour
Warranty available. Buy without worry
Support from a scientist

Specifications 23

Brands: Nikon
New/Used: Used
Dimensions: 286 x 466 x 542 mm
Weight: 17 kg
Field Number: 22 with C-mount, 25 with F-mount
Intermediate Magnification Switching: Manual switching of 1.0x/1.5x
Condenser Lens Types: LWD (O.D.=30 mm, NA=0.52), ELWD (O.D.=75 mm, NA=0.29), CLWD (O.D.=13 mm, NA=0.72), HNA dry (O.D.=5 mm, NA=0.85), HNA oil (O.D.=2 mm, NA=1.4), NAMC (O.D.=44 mm, NA=0.4)
Focusing Unit Stroke: 10 mm
Focusing Unit Minimum Increments: 0.01 μm (coarse), 0.02 μm (fine)
Condenser Vertical Stroke: 66 mm
Condenser Backward Tilting: Up to 25 degrees
Stage Stroke Range: X: ±57 mm, Y: ±36.5 mm

Stage Maximum Drive Speed: Approximately 25 mm/s
Nosepiece Positions: 6 motorized positions
Epi-Filter Turret Positions: 6 motorized positions
Filter Wheel Positions: 7 motorized positions
Operating Temperature Range: 0°C to 40°C
Operating Humidity Range: Up to 60% RH at 40°C (no condensation)
Power Supply Voltage: 100V-240V
Power Supply Current: Less than 0.65 A
Power Consumption: 30 W
Availability: Procurable
Lead time: Confirmed with your quote

Product description

Advanced inverted microscope with Perfect Focus System, high-speed motorization, and modular fluorescence imaging capabilities.

The Nikon Ti is an advanced inverted research microscope designed to meet the rigorous demands of modern biological and medical research. Introduced in 2007, this system offers exceptional flexibility and precision, making it ideal for a wide range of imaging applications.

Key features include:

Perfect Focus System (PFS): Maintains real-time focus during long-term, time-lapse imaging, eliminating focus drift caused by thermal fluctuations.

High-speed motorization: Enhances component speed and communication, reducing light exposure and phototoxicity during live-cell imaging.

Modular design: Supports diverse imaging techniques such as Total Internal Reflection Fluorescence (TIRF), Fluorescence Recovery After Photobleaching (FRAP), and High Content Analysis (HCA).

NIS-Elements software integration: Provides seamless control over the microscope, cameras, and peripherals for automated image acquisition and analysis.

The Nikon Ti is widely utilized in fields such as cell biology, neuroscience, and pharmaceutical research. It is commonly found in university laboratories, biomedical research centres, and clinical environments. Although succeeded by the ECLIPSE Ti2 in 2016, the Nikon Ti remains a reliable and versatile instrument in many research settings.
