Meiji EMZ-5/BLACK Zoom Stereo Microscope with PK/BLACK Ergonomic Stand

• Microscope Head (EMZ-5/BLACK):
• Zoom ratio: 6.5:1, zoom range 0.7x–4.5x, magnification 7x–45x (using 10x eyepieces)
• Dual graduated bilateral zoom controls with markings from 0.7 to 4.5
• Greenough optics design for improved image flatness, contrast, and brightness across the field of view
• Objective lens constructed with brass
• Field of view: 32mm to 5.1mm
• Working distance: 93mm standard; extended working distances from 34mm to 251mm with auxiliary lenses
• Eyetube inclination: 45° binocular, rotatable 360°
• Interpupillary distance adjustable from 54mm to 75mm
• Dioptric adjustment: dual, ±5 diopters
• Optional eyepieces: 5x, 7.5x, 10x, 12.5x, 15x, 20x, 30x
• Auxiliary lenses available: 0.3x (252mm WD), 0.44x (181mm WD), 0.5x (150mm WD), 0.75x (97mm WD), 1.5x (49mm WD), and 2x (34mm WD)
• Extended magnification range with accessories: 2.1x to 270x
• Mounts into 84.5mm diameter focus holders
• Construction: cast aluminum alloy with black chemical resistant finish
• Manufactured in Japan with limited lifetime warranty

• Eyepieces (MA502):
• Super Widefield 10x eyepieces (pair)
• 25mm reticle mount, field number 23.0
• Eye relief: 16.0 mm
• Focal length: 25.0 mm

• Stand (PK/BLACK):
• Ergonomic black wide plain pole stand made from cast aluminum alloy
• Integral F focusing holder with 84.5mm diameter opening
• Low profile design accommodates up to three standard petri dishes on the top surface
• Includes one reversible black and white stage plate (94.5mm diameter, MA568) and two stainless steel stage clips (MA593)
• Compatible with EMZ, EMT (turret), and EMF (fixed) series microscope bodies
• Optional 5” extension pillar (MA551) for taller specimen accommodation
• Chemical resistant finish for durability

• Modular Flexibility:
• Compatible with a wide range of auxiliary lenses, eyepieces, stands, illuminators, camera adapters, and accessories for customized system configuration.

• Optical Performance:
• Multi-coated optical components reduce chromatic and spherical aberrations
• Provides erect, unreversed stereoscopic images with excellent depth of field and flat image rendition

• Durability and Ergonomics:
• All-metal cast aluminum alloy components ensure rugged dependability and stability
• Compact, lightweight body with ergonomic adjustments for interpupillary distance and diopters
• Available observation tube inclinations: 45°, 60°, 90° for fatigue-free viewing

• Applications:
• Suitable for high-precision inspection in semiconductor manufacturing, medical devices, biological research, industrial quality control, educational use, and various scientific disciplines

This microscope system offers a precise, modular optical solution with extensive customization and an ergonomic stand tailored for laboratory and industrial applications.
