Ohaus e-G52ST07C Digital Heated Magnetic Stirrer with Ceramic Plate and RS232 Communication

The Ohaus e-G52ST07C is a precision digital heated magnetic stirrer designed for laboratory applications requiring controlled stirring and heating, essential in biotechnology workflows such as gene editing, molecular diagnostics, and media preparation. Featuring a 7 in x 7 in (18 cm x 18 cm) ceramic square top plate, the unit supports stirring volumes up to 20 liters, with a stirring speed range from 50 to 1,800 rpm and a speed stability of ±2%, ensuring reliable and consistent agitation.

Key features include:

• Backlit high-contrast LCD display with integrated status indicators and a prominent thermal warning, enhancing usability in temperature-sensitive experimental setups.
• Heating control with temperature stability of ±1% on the plate below 100°C and ±0.5% via probe, maintaining precise thermal conditions required for endothermic reactions, solution sterilization, and sample preparation.
• Robust full metal housing with either a ceramic square top plate or optional ceramic-coated aluminum round top plate, resistant to chemical corrosion and suitable for demanding bioprocessing environments.
• Communication options include RS232 standard with Ethernet and USB accessories available, facilitating data logging and remote control integration in automated biomanufacturing or synthetic biology research setups.
• Designed with an ergonomic large dip-angle front panel and smooth enclosure surfaces for easy operation and cleaning in sterile environments.
• Additional features such as an audible alarm, IP32 splash protection, and an optional rapid-install splash shield enhance laboratory safety during sensitive protocols like heat fixation and denaturing of organic material.
• Timer functionality supports intervals between 1 min to 5,999 min, accommodating both short and extended stirring processes.

Operating within a temperature range of 5°C to 40°C and up to 80% relative humidity (non-condensing), the stirrer is certified to CE and TUV safety standards. Its compact footprint (329 mm x 116 mm x 221 mm) and lightweight design (4.5 kg) make it suitable for benchtop use in clinical diagnostics, cell culture labs, and research institutions focused on biotechnology and molecular biology.

The Ohaus e-G52ST07C excels as a reliable tool for live-cell imaging preparations, buffer and reagent dissolution, and preparing media for cell culture, supporting critical molecular biology and synthetic biology experiments with precise stirring and heating control.
