Edwards nXDS15i Dry Scroll Pump

Edwards nXDS15i Dry Scroll PumpFeatures

• Bearing shield ensures separation between process gases and bearing lubrication to ensure clean vacuum and no possibility of contamination.
• Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability.
• High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1
• Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time.
• Enhanced versions offer up to 20% lower peak power requirements during initial pump down.

The nXDS allows a wide range of control and communication options

The nXDS comes as standard with a manual, easy to use, gas ballast port

A perfect companion for your turbomolecular pump

With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally.Click Here to View Product Video

INCLUDED: The Edwards nXDS15i Dry Scroll Pump includes:

• 1 Year Full Parts and Labor Warranty
• Power Cord
• Manufacturer's Documentation
• Operator's Manual

Edwards nXDS15i Dry Scroll Pump Technical SpecificationsNominal rotational speed1800 rpmDisplacement17.1 m3h-1 / 10.1 ft3min-1Peak pumping speed15.1 m3h-1 / 8.9 ft3min-1Ultimate vacuum (total pressure)0.007 mbar / 0.005 TorrMinimum standby rotational speed1200 rpmSpeed control resolution (percentage of full rotation speed)1%Pumping speed at minimum rotational speed9.9Maximum continuous inlet pressure200 mbarMotor power 1-ph300 WPower connector 1-phIEC EN60320 C13Recommended fuse10A, 250Vac rmsWeight25.2 kg / 56 lbInlet flangeNW25Exhaust flangeNW25Noise level52 dB(A)Vibration at inlet flange< 4.5 mms-1 (rms)Leak tightness (static)< 1x10-6 mbar ls-1Operating temperature range10 to 40 °C / 41 to 104 °FElectrical Supply115/230VComparison of ModelsSpecificationEdwards nXDS6iEdwards nXDS10iEdwards nXDS15iEdwards nXDS20iNominal rotational speed (rpm)1800180018001800Displacement (m³h⁻¹ / ft³min⁻¹)6.8 / 4.012.7 / 7.517.1 / 10.128.0 / 16.5Peak pumping speed (m³h⁻¹ / ft³min⁻¹)6.2 / 3.611.4 / 6.715.1 / 8.922.0 / 13.0Ultimate vacuum (total pressure) (mbar / Torr)0.020 / 0.0150.007 / 0.0050.007 / 0.0050.030 / 0.022Weight (kg / lb)26.2 / 5825.8 / 5725.2 / 5625.6 / 56Inlet flangeNW25NW25NW25NW25Noise level (dB(A))52525252Operating temperature range (°C / °F)10 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 104Electrical Supply115/230V115/230V115/230V115/230V.comparison-table tr td:nth-child(4) { background-color: #fffacd; }
