IKA Ministar 20 Control Overhead Stirrer

IKA Ministar 20 Control Overhead Stirrer

Speed Range 0/50 to 2,000 RPM Viscosity Max. 10,000 mPas Stirring Quantity Max. 15 l

Features

• Hardened glass enclosed, fast response display for maximum visibility and chemical resistance
• State-of-art vibration sensors detect deviations from permissible thresholds and automatically stop the process
• Clear display for all essential information at a glance
• Integrated timer / counter for the control of kinetic sensitive reactions and reminders
• Viscosities up to 10,000 mPas and volumes of up to 15 l
• Continuously adjustable speed between 0/30 – 2,000 rpm
• USB interface, e.g. for documenting parameters using labworldsoft® or installing firmware updates
• Intuitive and simple handling; touch-sensitive surface for long service life
• Temperature reading on display
• Chemical resistant housing
• Key lock function
• Microprocessor-controlled speed governor for constant rotational speed, even with changes in viscosity

The new MINISTAR series by IKA: Developed using the latest cutting-edge technology, these high-tech overhead stirrers with compact designs are ideal for special applications. Combining high performance with particular excellence, they require minimal space and come with a lifetime guarantee. These products offer incredible stirring capabilities and control, making them a great cost-effective option for laboratories. With features like hardened glass enclosed displays, state-of-the-art vibration sensors, and microprocessor-controlled speed governors, the MINISTAR series ensures precision and reliability.Capable of handling a wide range of viscosities and volumes, these stirrers provide continuously adjustable speeds, making them versatile and efficient for various applications. See for yourself: Click Here to View Product Video

INCLUDED: The IKA Ministar 20 Control Overhead Stirrer includes:

• MINISTAR 20 control
• R 300 shaft protector
• Fasten screws for R 300 (2x)
• H 67.60 Temperature sensor, stainless steel
• Chuck Key
• USB Cable - USB A to Micro-B, 2 m
• Power Cord
• Operator's Guide
• Manufacturer's Documentation
• 2 Year Manufacturer Warranty (+ Additional Free 8 Year Warranty Extension with IKA Registration)

IKA Ministar 20 Control Overhead Stirrer Specifications Stirring quantity max. per stirring position (H2O)15 lMotor rating input60 WMotor rating output46 WMotor principleBrushless DCSpeed displayLCDSpeed range0/50 - 2000 rpmViscosity max.10000 mPasOutput max. at stirring shaft42 WPermissible ON time100 %Torque max. at stirring shaft20 Ncm Speed controlTurning knob Setting accuracy speed1 ±rpm Deviation of speed measurement n 300rpm3 ±%Stirring element fasteningchuckConnection for ext. temperature sensorPT1000Temperature displayyesChuck range diameter0.5 - 8.2 mmHollow shaft, inner diameter8.5 mmHollow shaft (push-through - when stopped)yesFastening on standextension armExtension arm diameter13 mmExtension arm length160 mmTorque displayyesSpeed controlelectronicNominal torque0.2 NmTorque measurementtrendDeviation of torque measurement I3 ±NcmTimeryesTimer displayLCDTime setting range0 - 6000 minTemperature measuring range-10 - 350 °CTemperature measurement resolution0.1 KAccuracy of temperature measurement±0.5 + tolerance PT1000 (DIN EN 60751 Class A) KLimit deviation temperature sensor≤ ± (0.15 + 0.002xITI) KHousing materialalu-cast coating / thermoplastic polymerCommunication distance (depend onbuilding) max.150 mDimensions (W x H x D)70 x 193 x 154 mmWeight1.56 kgPermissible ambient temperature5 - 40 °CPermissible relative humidity80 %Protection class according to DIN EN 60529IP 54USB interfaceyesVoltage100 - 240 VFrequency50/60 HzPower input69 WDC Voltage24 VCurrent consumption2900 mAComparison of ModelsSpecificationsMinistar 20 ControlMinistar 20 DigitalMinistar 40 ControlMinistar 40 DigitalMinistar 80 ControlMinistar 80 DigitalStirring Quantity Max. (H2O)15 l15 l25 l25 l50 l50 lMotor Rating Input60 W60 W60 W60 W60 W60 WSpeed DisplayLCDLEDLCDLEDLCDLEDSpeed Range0/50 - 2000 rpm0/50 - 2000 rpm0/30 - 1000 rpm0/50 - 1000 rpm0/30 - 500 rpm0/50 - 500 rpmViscosity Max.10000 mPas10000 mPas30000 mPas30000 mPas60000 mPas60000 mPasTimer DisplayLCDNoneLCDNoneLCDNoneTemperature DisplayYesNoYesNoYesNoDimensions (W x H x D)70 x 193 x 154 mm70 x 193 x 147 mm70 x 193 x 154 mm70 x 193 x 147 mm70 x 193 x 154 mm70 x 193 x 147 mmUSB InterfaceYesYesYesYesYesYesVoltage100 - 240 V100 - 240 V100 - 240 V100 - 240 V100 - 240 V100 - 240 V.comparison-table tr td:nth-child(2) { background-color: #fffacd; }DownloadsTechnical Specification Download Operator's Manual Download
