Mitutoyo 5x M Plan Apochromatic Microscope Objective

€737.59excl. VAT

In stock

Can't find what you're looking for?

Type:
Infinity Corrected Brightfield
Wavelength:
Visible
Magnification:
5x
N.A.:
0.14
Working Distance:
34.0mm
All 14 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 14

Brands
Mitutoyo
New/Used
Used
Type:
Infinity Corrected Brightfield
Wavelength:
Visible
Magnification:
5x
N.A.:
0.14
Working Distance:
34.0mm
Focal Length:
40mm
Resolving Power:
2.0µm
Focal Depth:
14µm
Field of View with Ø24 Eyepiece
Ø4.8
Real Field of View with 1/2" Chip Camera
0.96 x 1.28
Thread Size:
M26
Part Number:
378-802-6

Product description

5x magnification apochromatic objective with 0.14 NA, 34mm working distance for brightfield microscopy.

  • Type: Infinity Corrected Brightfield Objective
  • Magnification: 5x
  • Numerical Aperture (N.A.): 0.14
  • Working Distance: 34.0 mm
  • Focal Length: 40 mm
  • Resolving Power: 2.0 µm
  • Focal Depth: 14 µm
  • Field of View (Ø24 Eyepiece): Ø4.8 mm
  • Real Field of View (1/2" Chip Camera): 0.96 x 1.28 mm
  • Wavelength Range: Visible spectrum
  • Thread Size: M26
  • Part Number: Originally 378-802-6, new assignment 378-802-12
  • Optical Design: Apochromatic design providing flat, chromatic-aberration-free imaging ideal for true-color metallurgical observation.
