NASA MODIS

Procurable

Not in stock, available to order through our sourcing team

Not in stock, but we can get it for you

We source this model through our supplier network. Request a quote and we'll come back within one hour.

  1. Request a quote
  2. We confirm price and lead time
  3. You approve, we ship to you
Orbit Altitude
705 km
Orbit Type
Sun-synchronous, near-polar, circular
Design Life
6 years
Thermal Operating Range
268 K ±5 K
Scan Rate
20.3 rpm
Availability
Procurable
Lead time
Confirmed with your quote
All 29 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 29

Brands
NASA
New/Used
Used
Orbit Altitude
705 km
Orbit Type
Sun-synchronous, near-polar, circular
Design Life
6 years
Thermal Operating Range
268 K ±5 K
Scan Rate
20.3 rpm
Data Rate
10.6 Mbps (peak daytime); 6.1 Mbps (orbital average)
Quantization
12 bits
Spatial Resolution (Bands 1-2)
250 m
Spatial Resolution (Bands 3-7)
500 m
Spatial Resolution (Bands 8-36)
1000 m
Polarization Sensitivity
2% from 0.43 µm to 2.2 µm and ±45° scan
Geolocation Control
3600 arcsec
Geolocation Knowledge
141 arcsec
Geolocation Stability
28 arcsec/sec
Geolocation Jitter
1031 arcsec/sec (yaw and roll), 47 arcsec/sec (pitch)
Instrument Instantaneous FOV (Bands 1-2)
250 m
Instrument Instantaneous FOV (Bands 3-7)
500 m
Instrument Instantaneous FOV (Bands 8-36)
1000 m
Swath Dimensions
2330 km (cross track) by 10 km (along track at nadir)
Telescope Diameter
17.78 cm
Instrument Dimensions
1000 mm x 1600 mm x 1000 mm
Instrument Weight
228.7 kg
Field of View
110 degrees
Power Consumption
162.5 W (single orbit average)
Spectral Range
0.4 µm to 14.4 µm
Availability
Procurable
Lead time
Confirmed with your quote

Product description

Satellite sensor capturing data across 36 spectral bands (0.4–14.4 µm) with near-daily global coverage.

The Moderate Resolution Imaging Spectroradiometer (MODIS) is a pivotal satellite-based sensor deployed on NASA's Terra and Aqua satellites, launched in 1999 and 2002, respectively. Designed to enhance our understanding of Earth's systems, MODIS captures data across 36 spectral bands, providing comprehensive global coverage every 1 to 2 days.

Key features:

  • Extensive spectral range: Spanning wavelengths from 0.4 µm to 14.4 µm, enabling diverse environmental observations.
  • High temporal resolution: Achieves near-daily global coverage, facilitating the monitoring of dynamic environmental changes.
  • Versatile applications: Supports studies in vegetation health, land cover dynamics, oceanography, sea surface temperature, and atmospheric analysis.
  • Disaster monitoring: Effectively tracks natural hazards such as wildfires, floods, and volcanic eruptions, aiding in timely response efforts.

Applications:

  • Environmental monitoring: Assesses vegetation health, land use changes, and oceanic biological activity.
  • Climate research: Analyzes cloud properties, aerosol distribution, and atmospheric water vapor to understand climate dynamics.
  • Disaster response: Provides critical data for managing and mitigating natural disasters.

Commonly used by:

  • Research institutions: Universities and environmental research centers.
  • Government agencies: Organizations like NASA and NOAA.
  • International bodies: Entities involved in global climate monitoring and environmental protection.

Since its inception, MODIS has been instrumental in advancing Earth system science, offering invaluable data that continues to support a wide array of scientific and environmental applications.
