Buchi F-105 Recirculating Chiller for Rotary Evaporators with Digital Temperature Control

The Buchi F-105 recirculating chiller is engineered specifically for rotary evaporator cooling applications, offering a precise temperature range from *-10°C to 25°C* with ±1°C accuracy and digital control featuring 0.1°C resolution.

Key technical specifications include:

• Cooling capacity: 400 W at 10°C
• Flow rate: 2.5 L/min, suitable for continuous operation supporting bioprocessing temperature stability
• Reservoir volume: 3 liters, enabling extended run times without frequent refills
• Dimensional footprint: 280 × 500 × 420 mm, compact for demanding laboratory environments
• Weight: 30 kg, facilitating stability and minimal vibration transfer to sensitive equipment
• Connection tubing diameter: 8 mm, compatible with standard rotary evaporator tubing

The unit integrates seamlessly with Buchi vacuum controllers V-850 and V-855, displaying both set and actual temperatures via its digital interface. This feature supports precise control essential for molecular diagnostics, synthetic biology workflows, and biomanufacturing processes requiring reliable cooling for solvent evaporation.

Widely adopted in biotechnology laboratories, the Buchi F-105 recirculating chiller ensures stable temperature management critical in biochemical extraction and analytical chemistry protocols. Its robust design and precise thermal regulation make it essential in applications like live-cell imaging preparation and pharmaceutical research requiring solvent recovery via rotary evaporation.
