Biotech and life sciences

The PCR Cabinet is designed for the production of PCR and other sterile samples without contaminatio (more)n. The work area has a HEPA filtered air down flow to provide minimum of CLASS 100 Air at a laminar velocity of approx. 0.4 m/sec. The cabinet is fitted with a timer controlled U.V. light for sterilising the cabinet work-surface and equipment. A safety door is supplied to cover the work area whilst cabinet is being sterilised. The work surface is manufactured from 316 grade stainless steel for ease of cleaning. Laminar flow velocity: >0.4m/sec UV lighting 254 nm at 15 watts Dimensions (WxDxH): 63 x 55 x 90 cm Work area size: 610 x 550 mm Weight: 60 kg

Temperature range: 0°C to 50°C Dimensions (HxWxD): 1110 x 830 x 750 mm Internal dimensions (HxWxD):  (more)610 x 600 x 535 mm

Workstation body: Acrylic/FR ABS Work surface: Acid resistant Formica Closure doors: Acrylic Glass s (more)creen: Tempered safety glass/Aluminium Dimensions: 1370 x 760 x 760 mm

Temperature range: Ambient + 5°C to 80°C Temperatuur accuracy (at 37°C): ±0.1°C Indication: 0.1°C in (more)crements Alarm signal with temperature deviation: ±1°C Speed setting: 25 – 500 rpm Speed accuracy: ±1 rpm Stroke: 25 mm Indication: 1 rpm increments Alarm signal with speed deviation: ±5 rpm Dimensions (WxDxH): 559 x 762 x 610 mm Platform size: 460 x 460 mm Weight: 79.4 kg

Temperature range: 0°C to 50°C Dimensions (HxWxD): 1110 x 830 x 750 mm Internal dimensions (HxWxD):  (more)610 x 600 x 535 mm

7” colorfull touch screen, graphicallydisplay. Effortlessly interchangeable modules, swapped in seco (more)nds without tools. Durable premium peltier element, ensure long life and high quality. Large storage of 10,000 programs on board, enhancing friendly operation. Update software through USB flash drive. Outstanding uniformity, producing best PCR result. Block: 96 wells x 0.2ml Block Temperature Range: 0°C – 100°C Max. Heating Rate: 5°C/s Max. Cooling Rate: 4°C/s Ramping Rate Adjustable: Yes Temperature Uniformity: ≤ ±0.2°C（at 95°C） Temperature Accuracy: ≤ ±0.2°C（35°C – 100°C）

The all-in-one Invitrogen E-Gel Power Snap Electrophoresis System is designed for fast and convenien (more)t E-Gel agarose gel electrophoresis, from DNA sample loading to gel image. With dry precast E-Gel agarose gel technology, you can run DNA samples in as little as 10 minutes and observe sample separation in real time. It is the only benchtop system that seamlessly integrates DNA sample separation and gel imaging into one workflow. Features of the E-Gel Power Snap Electrophoresis system include: Streamline electrophoresis and image capture with an all-in-one system Separate DNA in as little as 10 minutes with dry precast E-Gel agarose gels View and capture DNA samples in real time Designed for efficient and convenient benchtop use Small, fast, and powerful The all-in-one E-Gel Power Snap Electrophoresis System provides everything you need for DNA gel electrophoresis and gel imaging in a small lightweight benchtop system. The electrophoresis device includes a power supply, blue-light transilluminator, and amber filter. This enables gel separation and real-time sample tracking on E-Gel agarose gels pre-stained with SYBR Safe or SYBR Gold II DNA stains. The electrophoresis device arrives with pre-programmed protocols for each type of available E-Gel agarose gel. Instant image capture Capture high-resolution E-Gel agarose gel images on the go with the included easy-to-use E Gel Power Snap Camera. The camera is directly docked to the electrophoresis device, requiring no external power supply or connection to a desktop computer. This enables the freedom to capture images on the spot without leaving the bench. Made for convenience The E-Gel Power Snap Camera touch screen and on-board software provides an intuitive interface for quick gel image capture and editing. Store images using the Power Snap internal memory storage through months of camera use or easily transfer the images to an external USB memory device. Unsurpassed convenience of dry precast E-Gel agarose gels Run DNA samples in as little as 10 minutes with dry, precast, pre-stained E-Gel agarose gels. The E-Gel dry pre-cast agarose gel technology provides speed and convenience by eliminating any need for gel preparation or staining. E-Gel agarose gels are available in a variety of gel percentages and with a choice of two DNA stains. The E-Gel Power Snap Electrophoresis System is compatible with all low-throughput E-Gel precast agarose gels, including E-Gel EX, E-Gel SYBR Safe, E-Gel Go!, E-Gel CloneWell II, and E-Gel SizeSelect II gels. Ideal for cloning workflow The blue light emitted by the E-Gel Power Snap Electrophoresis Device transilluminator ensures maximum possible safety to the user, and results in improved cloning efficiency over ethidium bromide/UV when used with E-Gel CloneWell II Agarose gels.

All-in-one PCR plate centrifuge/vortex mixer that allows for the simultaneous sample preparation of  (more)multiple samples at one time. Versatile through being able to hold non, semi and fully skirted PCR plates with no additional accessories required. The CVP-2 offers three devices in one. • Centrifuge with vortex mixing • PCR plate centrifuge • PCR plate mixer Dimensions (hxdxw): 190 x 350 x 285 mm Centrifuge mixing speed control range: 300 to 1500 rpm Vortex mixing speed control range: 300 to 1200 rpm Speed control increment: 100 rpm G-force/RCF: 245 Centrifuge timer with sound alarm: 0 to 30 minutes Vortex timer with sound alarm: 0 to 60 seconds Centrifuge/vortex cycles: 1 to 999 Capacity: 2 non-, semi or fully skirted microplates External power supply: Input AC 120-230V, 50/60Hz, Output DC 24V Power consumption 18 W (0.75A) Input voltage: 24V DC Weight: 6.15 kg

The GeneAmp PCR System 9700 is an automated instrument,  specifically designed Instrument for the am (more)plification of nucleic acids using the Polymerase Chain Reaction (PCR) process. The user interface consists of a control panel with a full numeric keypad, soft keys, and a graphical display screen that shows the time and  temperature profile for each run. Equipped with a 96 well block Sample temperature range: 4.0 to 99.9°C The eight pre-coded methods are: AmpliCycle Sequencing AmpliTaq Gold DNA Polymerase BigDye Terminators General PCR LSM2 Time Release PCR Touchdown PCR XL PCR

The Model V15·17 is designed for vertical gels 17 cm x 15 cm (W x L) for separation of up to 20 samp (more)les on a 0.8 mm, 1.5 mm or 3 mm thick gel. The built-in integral clamps allow easy assembly and hold gels of different thickness leak-free in place. The V15·17 is the system of choice for laboratories with low sample throughput but the need of long running distances or large sample volumes (up to 4,000 µl).

Light source: High energy xenon flash lamp Detector: Silicon photodiode Wavelength selection: Single (more) High-Speed Monochromator Wavelength range: 200 – 1000 nm, selectable in 1 nm steps Wavelength accuracy: ≤0.8 nm Wavelength reproducibility: ≤0.5 nm Bandwidth: Fixed, 3.5 nm Measurement range (OD): 0 – 4 OD Measurement time (96-well plate, 1 flash): <14 seconds Measurement time (384-well plate, 1 flash): <30 seconds Fast Scan (200 – 1000 nm, 1 nm steps): <5 seconds OD accuracy (0 – 0.8 OD, 96-well plate): ±0.008 OD OD accuracy (0.8 – 2.5 OD, 96-well plate): <±1.0% OD accuracy (2.5 – 3.0 OD, 96-well plate): <±1.5% OD accuracy (at 260 nm): ≤0.5% OD precision (0 – 1.2 OD, 96-well plate): <±0.006 OD OD precision (1.2 – 3 OD, 96-well plate): ±0.5% OD precision (at 260 nm): ≤0.2% OD linearity (0 – 3 OD, 96-well plate, at 260nm): R-2 > 0.999 OD uniformity (96-well plate, at 1 OD): <3% Sample formats: SBS standard microplates from 1- to 384-wells,NanoQuant low-volume plate Microplate shaking: Linear, orbital and double orbital shaking; variable amplitudes and frequencies Stirring speed regulation: 50 – 1000 rpm Lid lifting system – maximum height of microplate and lid: 24.5 mm Temperature control – heating range: Ambient +4°C up to 42°C Temperature control – uniformity: <0.5°C at 30°C and 37°C at incubation position Dimensions (WxDxH): 494 x 557 x 395 mm Weight: 40 kg Software included

The redesigned Sub-Cell GT Electrophoresis Cell offers updated features that make electrophoresis ev (more)en easier. The Sub-Cell GT Cell is the most versatile submerged horizontal electrophoresis cell in the Sub-Cell family. Because the Sub-Cell GT cell offers the greatest choice of gel lengths, sample combs, and separation modes, it is ideal for Southern and northern blotting protocols. Up to 30 samples can be resolved over a distance of 25 cm. Using four rows of combs, the cell will run up to 120 analytical samples. Cell size (WxLxH): 18 x 40.5 x 9.4 cm Gel tray sizes (OD) (WxL): 15 x 20 cm ReadyAgarose gels accommodated: No Sample throughput: 1–120 Base buffer volume: ~1 L Buffer recirculation: No Bromophenol blue migration: ~3.0 cm/hr (at 75 V)

Progressive scan type 2/3″ CCD, super-high-resolution with 1.4 million pixels (1280×1024) 5.1 cm pol (more)ysilicone TFT display for frame and focus adjustment in preview mode Camera control with handswitch, avoids vibrations of camera head and guarantees sharp images Photometric system with integral (30%) and spot (1%) metering possibility Automatic exposure adjustment with auto-exposure lock +/- 3 step compensation JPEG image format with three resolution modes 3.3 V SmartMedia (SSFDC) with 8 MB intermediate image storage without PC Direct printing to Olympus P-330E high resolution dye-sublimation printer (306 dpi) Camera control with personal computer via serial interface

Temperature control range: Ambient +5°C to 60°C Temperature fluctuation: ± 0.5°C Temperature variati (more)on: ± 1°C Capacity: 93 L Timer: Electronic timer with delay timer Dimensions (WxDxH): 580 x 595 x 820 mm Internal dimensions (WxDxH): 450 x 460 x 450 mm Weight: 44 kg

qPCR Laboratory Workstation consisting of: Myra Liquid Handling System Mic qPCR Cycler Myra Liquid H (more)andling System: Position control: Closed loop, 100 μm resolution Calibration: High precision camera Pipetting volume range: 1 – 50 μL Liquid level detection: Pressure sensing Tips per rack: 384 Dispense modes: Single Precision: 1 μL; < 10% CV, 5 – 50 μL; < 1% CV Accuracy: 1 μL; < 10%, 5 – 50 μL; < 1% Tip disposal type: Internal enclosed waste container HEPA filter: 99.98% at 0.3 μm UV lamp: High intensity 70 mW 280 nm UV LED Dimensions (HxWxL): 310 x 350 x 460 mm Weight: 9kg Mic qPCR Cycler: Temperature Accuracy: ±0.25°C Temperature Uniformity: ±0.10°C Ramp Rates: Heating 5°C/s, Cooling 4°C/s Temperature Input Range: 35 to 99°C Detectors: Photodiode per channel Channels: 2 Excitation Sources: High power LED for each channel Channels: Green – Ex 465nm – Em 510nm, Yellow – Ex 540nm – Em 570nm, Orange – Ex 585nm – Em 618nm, Red – Ex 635nm – Em 675nm Samples per Instrument: 48 Reaction Volume Range: 5 to 30 µL Acquisition Time: 1 second Dimensions (WxDxH): 150 x 150 x 130 mm Weight: 2 kg

Temperature range: Ambient + 5°C to 50°C Digital Temperature Control Dimensions (WxDxH): 765 x 800 x (more) 2150 mm Internal dimensions (WxDxH): 530 x 630 x 1450 mm

Temperature range: Ambient up to 60°C  Temperature precision: ±0.2°C Air circulation: 110 m3/h Speed (more): 0 – 400 rpm Dimensions (WxDxH): 800 x 674 x 732 mm Chamber dimensions (WxDxH): 555 x 495 x 410 mm Chamber capacity: 113 L Tray size: 480 x 420 mm Weight: 90 kg

Temperature control range: Ambient +5°C to 60°C Temperature fluctuation: ± 0.5°C Temperature variati (more)on: ± 1°C Capacity: 93 L Timer: Electronic timer with delay timer Dimensions (WxDxH): 580 x 595 x 820 mm Internal dimensions (WxDxH): 450 x 460 x 450 mm Weight: 44 kg

Caliper Life Sciences Twister II is more than a super-fast, high capacity plate stacker. It’s real p (more)lug-and-play desktop automation. The Twister II Microplate Handler was designed to address the need for a microplate handler with multiple instrument capability, increased speed and capacity, and amazingly simple software. Add a liquid handler and a washer or reader, and you’ve got a system that can handle almost any manual assay step. Twister II can serve as the hub for a new breed of ‘Mini-Systems’. This low-cost microplate handler provides a time saving alternative to stackers and a money saving alternative to larger, more complex integrated systems. Minimum Reach: 305 mm Arm Travel: 216 mm Horizontal, 559 mm Vertical Wrist Rotation: ±135° (270° total) Protrusion Beyond Rotation Point: 38 mm (flush with plate edge) Turret Rotation: 340° with 20° Hard Stop Turret Diameter: 178 mm Turret Height: 996 mm Base Dimensions: 254 mm Diameter Min. Reach Height: 165 mm Max. Reach Height: 711 mm

Temperature range: 4°C to 50°C Digitally adjustable and digitally readable per 0.1°C Equipped with w (more)eek clock Dimensions (WxDxH): 760 x 820 x 2030 mm Internal dimensions (WxDxH): 530 x 650 x 1450 mm

Apply consistent, secure, tight seals around individual wells, eliminating sample loss through evapo (more)ration and cross contamination between wells. The Thermo Scientific ALPS 50 V Microplate Heat Sealer is designed to provide sealing consistency in low to medium throughput labs. Heat sealing offers superior sample protection of storage and reaction plates in applications including compound storage, sample archiving and PCR. Choose from a wide range of heat seals (including pierceable, optically clear and permanent) for any application. Sealing Temperature Range: 125° to 200°C Dimensions (HxWxD): 425 x 220 x 325 mm Weight: 7.2kg

Temperature range: 0 – 70°C Capacity: 151 L Temperature alarm for high/low value. Glass inner door 2 (more) shelves Dimensions (HxWxD): 1270 x 850 x 620 mm

QIAgility Automated PCR setup in all formats Pre-optimized experiment setup Standardized results and (more) increased productivity Elimination of manual pipetting steps The QIAgility is a compact benchtop instrument that enables rapid, high-precision setup of PCR experiments with ready-to-use software for ease and convenience. The software provides step-by-step guidance for worktable setup and automatic calculation of all mixes, eliminating the need to program pipetting steps. Just select the kit and cycler, define your targets and start the run.
