Molecular Devices Digidata 1440A

UsedMolecular DevicesData acquisitionNetherlands
Procurable

Not in stock, available to order through our sourcing team

Not in stock, but we can get it for you

We source this model through our supplier network. Request a quote and we'll come back within one hour.

  1. Request a quote
  2. We confirm price and lead time
  3. You approve, we ship to you
Sampling Rate per Channel
250,000 samples per second
Total Data Throughput
4,000,000 samples per second
Input Voltage Range
±10 V
Input Resistance
1 MΩ
Power Supply
100–240 V AC, 50–60 Hz, 115 W (max.)
Availability
Procurable
Lead time
Confirmed with your quote
All 16 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 16

Brands
Molecular Devices
New/Used
Used
Dimensions
483 x 362 x 364 mm
Weight
3.63 kg
Sampling Rate per Channel
250,000 samples per second
Total Data Throughput
4,000,000 samples per second
Input Voltage Range
±10 V
Input Resistance
1 MΩ
Power Supply
100–240 V AC, 50–60 Hz, 115 W (max.)
Analog Input Channels
16 single-ended
Analog Output Channels
4
Digital Input Channels
16 TTL compatible
Digital Output Channels
8 (of 16 supported in software)
USB Interface
USB 2.0
Availability
Procurable
Lead time
Confirmed with your quote

Product description

High-resolution 16-bit data acquisition system with 16 analog inputs, 4 outputs, up to 250 kHz sampling, USB 2.0 connection.

Digidata 1440A is a high-resolution, low-noise 16-bit data acquisition system designed for precise electrophysiological recordings. This digitiser seamlessly interfaces with computers via a USB 2.0 connection, facilitating straightforward installation and immediate data acquisition without the need for programming.

Key features include:

  • 16 analogue input channels and 4 analogue output channels, enabling comprehensive signal recording and stimulation.
  • Sampling rates up to 250 kHz per channel, ensuring accurate capture of rapid physiological events.
  • Low inherent noise and minimal channel crosstalk, with noise levels rated at less than ±1 mV peak-to-peak at 10 kHz within a ±10 V input range.
  • Compatibility with AxoScope and pCLAMP software, providing versatile data acquisition and analysis capabilities.

This system is widely utilised in:

  • Neuroscience research for whole-cell patch-clamp recordings.
  • Cardiac electrophysiology studies, including action potential measurements in cardiomyocytes.
  • Biomedical research requiring precise electrical signal acquisition.

Commonly employed in university laboratories, biomedical research centres, and clinical research facilities, the Digidata 1440A has been a reliable tool since its release. While it has been succeeded by newer models, it remains in use due to its robust performance and ease of integration into existing research setups.
