HEKA EPC 10

UsedHEKAData acquisitionNetherlands
Procurable

Not in stock, available to order through our sourcing team

Not in stock, but we can get it for you

We source this model through our supplier network. Request a quote and we'll come back within one hour.

  1. Request a quote
  2. We confirm price and lead time
  3. You approve, we ship to you
Number of Amplifiers/Headstages
1
Dimensions (Main Unit)
Depth: 311 mm, Width: 483 mm, Height: 145 mm
Weight (Main Unit)
11.4 kg
Headstage Dimensions
Diameter: 90 mm, Width: 17 mm, Height: 14.5 mm
Power Supply
125 W, 90-120 V or 210-250 V, 50/60 Hz
Availability
Procurable
Lead time
Confirmed with your quote
All 19 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 19

Brands
HEKA
New/Used
Used
Number of Amplifiers/Headstages
1
Dimensions (Main Unit)
Depth: 311 mm, Width: 483 mm, Height: 145 mm
Weight (Main Unit)
11.4 kg
Headstage Dimensions
Diameter: 90 mm, Width: 17 mm, Height: 14.5 mm
Power Supply
125 W, 90-120 V or 210-250 V, 50/60 Hz
Current Gain Settings (Low Gain Range)
0.005, 0.01, 0.02, 0.05, 0.1, 0.2 mV/pA
Current Gain Settings (Medium Gain Range)
0.5, 1, 2, 5, 10, 20 mV/pA
Current Gain Settings (High Gain Range)
50, 100, 200, 500, 1000, 2000 mV/pA
Input Capacitance
< 1 pF
Noise Performance (Medium Gain Range)
Up to 1 kHz: ~180 fA rms, Up to 3 kHz: ~320 fA rms, Up to 10 kHz: ~580 fA rms
Noise Performance (High Gain Range)
Up to 1 kHz: ~31 fA rms, Up to 3 kHz: ~72 fA rms, Up to 10 kHz: ~350 fA rms
Bandwidth (Low and Medium Gain Range)
100 kHz
Bandwidth (High Gain Range)
> 60 kHz
Holding Potential
Software controlled within a ±2000 mV range
External Stimulus Input (VC)
Via a BNC connector at the front panel, allows scaling of the external stimulus with a factor in the range of ±1.0
Availability
Procurable
Lead time
Confirmed with your quote

Product description

Fully software-controlled patch clamp amplifier with integrated AD/DA, low-noise, multi-channel configurations.

The HEKA EPC-10 is a fully computer-controlled patch clamp amplifier designed for precise electrophysiological measurements. Integrated with HEKA's LIH 8+8 AD/DA interface, this system offers low-noise recordings essential for studying ion channel activity and cellular electrophysiology.

Key features include:

  • Full software control: Allows direct access to all amplifier settings, enabling automation of experimental protocols.
  • Integrated data acquisition: Combines amplifier and data acquisition in a single unit, reducing setup complexity and potential compatibility issues.
  • Low-noise performance: Optimised headstage design ensures minimal recording noise, crucial for detecting subtle electrophysiological signals.
  • Versatile configurations: Available in single, double, triple, and quadruple amplifier versions to accommodate various experimental needs.
  • Automatic compensation: Features automatic capacitance neutralisation and leak subtraction for enhanced recording accuracy.

The EPC-10 is widely used in fields such as neuroscience, molecular biology, and biotechnology, facilitating research in areas like ion channel function, synaptic transmission, and cellular excitability. Its applications are particularly relevant in biotechnology, where understanding cellular electrical properties is vital for developing novel therapeutics and diagnostic tools.

Commonly employed in university laboratories, biomedical research centres, and pharmaceutical companies, the EPC-10 has been a trusted instrument since its release in 2002 and continues to be relevant in contemporary research settings.
