Zeiss Axiocam

UsedZeissCamerasNetherlands
Procurable

Not in stock, available to order through our sourcing team

Not in stock, but we can get it for you

We source this model through our supplier network. Request a quote and we'll come back within one hour.

  1. Request a quote
  2. We confirm price and lead time
  3. You approve, we ship to you
Sensor Type
Sony IMX304 Exmor CMOS, global shutter architecture
Gain Settings
1x, 2x, 4x, 8x, 16x
Power Supply
Provided by USB 3.0 and USB 2.0, max. 7 W consumption
Sensor Size
14.1 mm x 10.4 mm
Pixel Count
12 megapixels (4096 x 3008)
Availability
Procurable
Lead time
Confirmed with your quote
All 24 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 24

Brands
Zeiss
New/Used
Used
Sensor Type
Sony IMX304 Exmor CMOS, global shutter architecture
Gain Settings
1x, 2x, 4x, 8x, 16x
Power Supply
Provided by USB 3.0 and USB 2.0, max. 7 W consumption
Sensor Size
14.1 mm x 10.4 mm
Dimensions
108 mm x 78 mm x 43 mm
Weight
580 g
Pixel Count
12 megapixels (4096 x 3008)
Pixel Size
3.45 µm x 3.45 µm
Binning Options
1x1, 2x2, 3x3, 4x4, 5x5 (combined analog and digital binning)
Frame Rate at Full Resolution
20 frames per second
Frame Rate in Live Image Mode
30 frames per second
Dynamic Range in HDR Mode
1:25,000
Spectral Sensitivity
Approx. 400 nm to 720 nm
Exposure Range
0.1 ms to 60 s
Cooling System
Active thermoelectric cooling, regulated sensor temperature 18 °C
Operating Temperature Range
5 °C to 35 °C
Operating Humidity Range
Max. 80% relative air humidity, not condensing
Interface
USB 3.0 (data & power) and USB 2.0 (power only)
Trigger Ports
Trigger-in, trigger-out, status readout
Optical Interface
C-Mount
Availability
Procurable
Lead time
Confirmed with your quote

Product description

12MP cooled color CMOS camera with 17.5 mm sensor, 20 fps, HDR mode for microscopy imaging.

The Zeiss Axiocam 712 color is a 12-megapixel scientific-grade CMOS camera designed for high-resolution microscopy applications. It delivers over 20 frames per second with a 17.5 mm diagonal large field of view, enabling rapid acquisition of large specimen regions without compromising image quality.

Key features:

  • 12-megapixel cooled color CMOS sensor: Ensures high-resolution imaging with precise color rendition.
  • Large sensor with 17.5 mm diagonal: Provides an extended field of view, reducing the need for tiling in large sample imaging.
  • High frame rates: Achieves 20 frames per second at full 12-megapixel resolution and 30 frames per second in live image mode.
  • Exclusive noise inhibition technology: Enhances low-light imaging capabilities.
  • High dynamic range (HDR) mode: Offers a dynamic range of 1:25,000 for capturing detailed images across varying light intensities.

This camera is widely used in fields such as medical imaging, material science research, pathology, and macroscopic imaging. It is commonly employed in university laboratories, biomedical research centres, and clinical environments. The Zeiss Axiocam 712 color was introduced in 2019 and remains a relevant tool in advanced microscopy applications.
