Shimadzu SPD-10A VP UV-Visible Detector for VP Series HPLC Systems

The Shimadzu SPD-10A VP UV-visible detector functions as a system controller for the Shimadzu VP Series HPLC system, enabling centralized control of all VP Series modules connected via fiber optic interfaces for plug-and-play setup. It is backward compatible with previous Shimadzu systems and features user-friendly single-point control through an easy-to-read, menu-driven display. The detector offers high sensitivity and low noise for reliable peak detection across a wide wavelength range.

Specifications:

• Ambient Temperature Range: 4–35ºC
• Light Source: Deuterium (D2) lamp and Tungsten (W) lamp
• Signal-To-Noise (S/N) Ratio: ±0.35 × 10⁻⁵ AU
• Wavelength Repeatability: 0.1 nm
• Wavelength Range: 190–900 nm
• Wavelength Accuracy: ±1 nm
• Wavelength Reproducibility: ±0.1 nm
• Spectral Bandwidth: 8 nm
• Drift: Max. 2 × 10⁻⁴ AU/hour at constant room temperature (10AVP: 250 nm)
• Wavelength Scanning: Steps of 1–5 nm in 5 steps (2–5 nm with W lamp)
• Scan Speed: 10–50 nm/sec in 5 steps
• Time Program: Controlled by detector or system controller; includes wavelength (2 wavelengths), auto zero, range, marker, response, wavelength scan, event, polarity, lamp ON/OFF, loop
• Output Recorder: 10 mV
• Integrator Settings: 0.5, 1, 2, 4, 1.25, 2.5 AU/V in 6 steps
