Tucsen MIchrome 20 20MP USB3.0 CMOS Microscope Camera

UsedTUCSENMicroscopesUnited States

From€1,333.38excl. VAT

In stock

Can't find what you're looking for?

Brands
TUCSEN
New/Used
Used
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Product description

20MP CMOS microscope camera with USB 3.0, live stitching, EDF, and global shutter for fluorescence imaging.

  • Sensor: CMOS, Sony IMX183CQJ-J, color
  • Resolution: 20MP (5472 x 3648 pixels)
  • Pixel Size: 2.4 μm x 2.4 μm
  • Sensor Size: 1-inch diagonal (15.86 mm), effective area 13.1 mm x 8.8 mm
  • Shutter Mode: Rolling shutter
  • Frame Rate: 15 fps at full resolution
  • Exposure Time: 18 μs to 15 s
  • Binning: 2x2, 3x3, 4x4 supported
  • Color Temperature Range: 2000–15000 K
  • Optical Interface: Standard C-mount
  • Bit Depth: 8 or 16 bit
  • Data Interface: USB 3.0, supports stable high-speed transmission
  • Software: Mosaic V2, SDK supports C/C++, C#, Directshow/Twain, supports up to 4 cameras simultaneously
  • Operating Systems: Windows 7/10 (32 & 64 bit), Mac OS
  • Camera Dimensions: 68 mm x 68 mm x 46 mm
  • Key Features:
  • Real-time depth-of-field fusion for extended focus imaging
  • Advanced ISP color-interpolation algorithm for true-to-life color correction
  • Suitable for brightfield, fluorescence, and polarized imaging
  • Global shutter technology offers undistorted capture of fast-moving samples
  • Efficient workflow for image acquisition, editing, measurement, and reporting
  • PC Requirements: Intel Core i5 quad-core or better, 8GB RAM or more
