Icalis DXi-80 8-Channel Syringe Pump Diluter Dispenser for Automated Liquid Handling

The Icalis DXi-80 is an advanced 8-channel syringe pump designed for high-precision automated liquid handling within the 10 µL to 5 mL volume range. Engineered for parallel liquid processing, this unit supports critical applications in molecular diagnostics, synthetic biology, and bioprocessing where repetitive pipetting tasks such as sample transfer, dilution, reagent addition, mixing, and plate reformatting are essential.

Key features include:

• Multichannel operation: Equipped with six 2.5 mL syringes by default, compatible with syringe sizes of 100 µL, 250 µL, 500 µL, 1 mL, 2.5 mL, and 5 mL for flexible volume handling.
• Robust mechanical design: PTFE-coated leadscrew coupled with an anti-backlash nut driven by a stepper motor ensures precision and durability; 60 mm plunger travel length with quadrature encoder enables accurate step loss detection.
• Communication interfaces: Supports bidirectional communication via RS232, RS485, or CAN bus; allows multimodule networking with up to 15 modules on a single bus, facilitating integration into complex automation systems.
• Synchronization capabilities: Includes two digital inputs and three TTL outputs to coordinate actions with external laboratory instruments.

Compact and low-maintenance, the DXi-80 enhances workflow efficiency in biomedical engineering, cell imaging sample prep, and biopharmaceutical production pipelines, making it a vital instrument for research laboratories focused on biotechnology and molecular cloning workflows. Its reliable performance and customizable syringe options ensure adaptability to diverse liquid handling protocols critical in gene editing and synthetic biology research environments.

For detailed technical specifications and syringe options, please refer to the manufacturer's datasheet or contact the supplier.
