Bresser B-190 Digital Binocular Microscope with 3.1MP Camera and Tablet, 1000x Magnification, PLAN Objectives

The Bresser B-190 Digital Binocular Microscope combines advanced optical and digital imaging technologies tailored for life sciences education, clinical diagnostics, and biotechnology research. Featuring a 1000x magnification capability through four high-quality N-PLAN objectives (4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25 Oil/Water immersion with anti-fungus treatment), it delivers precise, flat-field images ideal for *brightfield microscopy applications*.

Key technical specifications include:

• Binocular head: 30° inclined, 360° rotatable with interpupillary distance adjustment (48–75 mm) and dioptric correction on left eyepiece for ergonomic observation.
• Eyepieces: Widefield WF 10x/18 mm secured by screws, enabling high-resolution viewing.
• Imaging: Integrated built-in 3.1 MP CMOS camera connected to a detachable Windows tablet PC with a vivid 10.1" touchscreen, powered by an Intel processor, facilitating real-time image capture, analysis, and remote control, enhancing workflows in molecular diagnostics and bioprocessing documentation.
• Mechanical stage: Double-layer sliding with X-Y movement range of 70x30 mm and vernier scales offering 0.1 mm positional precision for sample navigation critical in cell imaging and synthetic biology experiments.
• Focusing system: Coaxial coarse and fine focusing with adjustable tension and limit stop to prevent objective-slide damage during sensitive biotechnology assays.
• Illumination: Energy-efficient, uniform X-LED² illumination system with 3 W white LED at a color temperature of 6300 K, controlled for intensity modulation—ideal for consistent sample illumination in fluorescence-related, histology, and biomedical engineering applications.
• Condenser: Pre-centered Abbe condenser with numerical aperture 1.25 and iris diaphragm, adjustable height to optimize contrast and resolution in live-cell imaging and molecular cloning workflows.

This digital binocular microscope with integrated camera and versatile tablet control is widely adopted in synthetic biology research, clinical diagnostics, and biopharmaceutical production pipelines, facilitating detailed observation and documentation in laboratory environments requiring precision and flexibility.
