Lumenera INFINITY 5-5M Microscope Camera with Sony Pregius CMOS Sensor

UsedLumeneraMicroscope accessoriesUnited States

From€3,591.64excl. VAT

In stock

Can't find what you're looking for?

Image Sensor
SONY IMX250; CMOS format, monochrome, diagonal 11.1mm array
Effective Pixels
2464×2056, 3.45μm square pixels
Frame Rate
1080P60 (~75 fps at full resolution) in 8-bit
Signal/Noise
>72dB
Digital Output
8 or 12-bit
All 23 specifications
  • Ships to NL
  • Response within 1 hour
  • Warranty available. Buy without worry
  • Support from a scientist

Specifications 23

Brands
Lumenera
New/Used
Used
Image Sensor
SONY IMX250; CMOS format, monochrome, diagonal 11.1mm array
Effective Pixels
2464×2056, 3.45μm square pixels
Frame Rate
1080P60 (~75 fps at full resolution) in 8-bit
Signal/Noise
>72dB
Digital Output
8 or 12-bit
Read Noise
~ 2.30 e-
Mass
330g
Power Requirement
External 5VDC – 1.2A, power supply (included)
Power Consumption
~4Watts
Operating Temperature
0° C to 50° C
Operating Humidity
5%-95%, Non-condensing
Integration Time
42μs to 59.5m (snapshot); 14μs to 14s (video)
Shutter
Global Shutter
ROI
Full Frame
Exposure Mode
Automatic / Manual
White Balance
Automatic / Manual
Gain
~1 to 16x; manual and automatic
Interface Connector
USB 3.0 connector, HDMI output
Dimensions (L x W x H)
3.85 x 2.75 x 2.25 inches
Lens Mount
C-Mount lens adapter
Binning Options
2 x 2

Product description

5MP microscope camera with Sony Pregius CMOS sensor, global shutter, 75fps at 2464x2056, USB 3.0 and HDMI outputs.

  • Utilizes Sony IMX252 Pregius global shutter CMOS sensor with 2/3” optical format
  • Resolution of 2464 x 2056 pixels with 3.45 x 3.45 μm pixel size
  • Supports fast frame rates of approximately 75 fps at full resolution (8-bit)
  • Dual digital output: USB 3.0 (high-speed USB 3.1 Gen 1) and HDMI compatible monitor output
  • Selectable 8-bit or 12-bit pixel data output
  • Low read noise of approximately 2.30 electrons and signal-to-noise ratio >72 dB
  • Controls include manual and automatic exposure, gain (1-16x), white balance, and ROI full frame
  • Integration times range from 42 μs to 59.5 msec (snapshot) and 14 μs to 14 sec (video)
  • Camera weight: 330 g; Dimensions: 3.85 x 2.75 x 2.25 inches
  • Power requirements: 5 V DC, 1.2 A external supply included; typical power consumption ~4 W
  • Operating temperature: 0°C to 50°C; Operating humidity: 5%-95%, non-condensing
  • Interface connectors: USB 3.0 and HDMI output; lens mount: C-Mount adapter
  • Includes 2 x 2 binning options
  • Compatible with Windows 7/8.1/10, Mac OS X 10.13, 32- and 64-bit systems
  • Software support: Lumenera INFINITY Capture, third-party software MetaMorph, Micro-Manager, MatLab, LabView, TWAIN, and DirectShow interfaces
  • Package includes: INFINITY5-5 camera, USB 3m cable, HDMI 3m cable, power supply, and software DVD
  • Backed by a 4-year full warranty
