Inspectis Microscope Light BGA Inspection System with 5 MP USB3.0 Camera and Side-View Optics

The Inspectis Microscope Light BGA Inspection System is a specialized optical inspection platform optimized for side-view analysis of BGAs, µBGAs, CSPs, CGAs, Flip-Chips, and SMDs on printed circuit boards (PCBs). It features a 5.0 MP USB 3.0 CMOS digital camera delivering high-resolution imaging of concealed solder joints down to approximately 40 µm stand-off, critical for electronics manufacturing quality control and assembly diagnostics.

Key technical features:

• Optical Probe: 90° side-view BGA lens offering magnification ranges of approximately 25× to 200× (on 24″ monitor) with a working distance from 0.5 to 25 mm, suitable for detailed inspection of small surface-mount devices.
• Illumination: High-power pure white LED light using microprism technology ensures uniform lighting for clear solder joint visualization.
• Camera Capabilities: Supports multiple video formats including 2592×1944 (15 fps) and 1920×1080 (30 fps); camera controls include auto/manual white balance, exposure, contrast, brightness, gamma correction, sharpness, HDR, and image axis flip functionality.
• Software Integration: Comes with Inspectis BGA Basics software providing real-time image viewing, calibrated distance measurement, image capture via device switch, foot pedal, or software, and comprehensive documentation tools—essential in molecular diagnostics workflows requiring PCB quality assurance in biotechnology instrumentation.
• Mechanical Design: The bench-top microscope holder incorporates ESD protection and grounding points, maintaining safety standards in electronics inspection environments. The system mounts using a standard UNC 1/4″-20 thread interface.
• Complete Inspection Setup: Includes a powerful computer with a 27″ UHD/4K monitor (3840×2160 resolution) and an aluminum carrying case for portability and turnkey inspection workflow readiness.

This system is widely adopted in biomedical engineering and biopharmaceutical production pipelines, where precise PCB inspection is critical. The side-view BGA optics and digital imaging capabilities make it well-suited for gene editing instrumentation maintenance, synthetic biology research tools inspection, and molecular cloning workflow diagnostics in biotechnology labs.

Operating conditions support an environment range from −20 °C to +60 °C with 20–95% relative humidity (non-condensing), ensuring versatility across various lab settings. Manufactured in Sweden, this instrument meets stringent quality and durability standards expected in advanced research and clinical diagnostics environments.

Overall, the Inspectis Microscope Light BGA Inspection System represents a robust, high-precision optical solution for detailed solder joint analysis, critical in cell imaging hardware maintenance and live-cell assay instrumentation quality control.
