Bioer Quant Gene 9600 Fluorescent Quantitative PCR Detection System

Key Specifications:

• Sample Capacity: 96-well 0.2 mL PCR plates, 12 × 8-strip tubes, or 96 × 0.2 mL single tubes (transparent bottom)
• Reaction Volume: 5–100 µL
• Dynamic Range: 1–10¹⁰ copies/µL
• Detection Channels: 5 or 6 channels (F1–F6)
• Excitation Wavelength: 300–800 nm
• Emission Wavelength: 500–800 nm
• Temperature Range: 4–105°C with 0.1°C increments
• Temperature Control Accuracy: ±0.1°C
• Temperature Uniformity: ≤ ±0.3°C
• Heating and Cooling Rates: Up to 4.0°C/s
• Hot Lid Temperature: Adjustable 30–110°C, default 105°C
• Gradient Temperature Range: 1–36°C
• Scanning Mode: Full-plate and designated line scanning; 5.5 seconds per scan
• Programming: Up to 20 segments per program, 99 cycles maximum
• Operating System Compatibility: Windows 7, 8, 10
• Software Requirements: Microsoft Excel 2000/2002/2003/2007/2012
• Minimum Computer Specifications: RAM 512 MB; HDD 10 GB; CPU Pentium 4; Virtual Memory ≥1000 MB
• Power Supply: 100–240V, 50/60Hz, 600W
• Dimensions: 410 mm (W) × 386 mm (D) × 352 mm (H)
• Weight: Approx. 20 kg
• Certifications: CE, EMC, RoHS 2.0, MET
