Agilent ACEA xCELLigence RTCA CardioECR Real-Time Cell Analyzer System Unit 2

The Agilent ACEA xCELLigence RTCA CardioECR System is a compact real-time cell analyzer designed for precise and label-free monitoring of cardiomyocyte activity. It integrates multi-parametric data acquisition by simultaneously measuring cellular impedance and field potentials, enabling comprehensive assessment of contractility, viability, and electrophysiology in live cardiac cells.

Key Technical Specifications:

• Analyzer Model: W600
• 48-Station Multiwell Reader Model: 1x48
• Electrical Input: +6 VDC, 1.5 W max
• FP Band-Pass Filter: 1 Hz to 4.5 kHz
• Stimulation Voltage Range: –2.5 to +2.5 V
• Stimulation Time Resolution: 10 μs
• Impedance Measurement Speed: Up to 24 wells in 1 msec; all 48 wells in 2 msec
• Dimensions: 30.0 × 37.5 × 14.0 cm (W × D × H)
• Weight: <10 kg
• Electrical Interface: Single E-Plate CardioECR 48

Functional Highlights:

• Monitors cardiomyocyte behavior non-invasively and label-free, preserving native cell physiology.
• Detects real-time changes in contractility, electrophysiological function, and cell viability critical for cardiac safety pharmacology and drug discovery workflows.
• Combines impedance-based cell analysis with field potential recordings to assess ion channel activity and acute or long-term assay effects (seconds to days).
• High sensitivity and reproducibility suited for molecular diagnostics and biopharmaceutical production screening models.

Applications:

• Cardiotoxicity screening in drug development, modeling changes in cardiomyocyte contractility and viability.
• Electrophysiological assays for ion channel function in cardiac cells.
• Acute and long-term cellular health assessments supporting synthetic biology and gene editing research involving cardiac cell lines.
• Essential tool for biotechnology research in live-cell imaging of cardiac electrophysiology and cell adhesion dynamics.

Included in the System Package:

• xCELLigence RTCA CardioECR Analyzer unit (Model W600)
• 48-station E-Plate Reader (Model 1x48)
• Computer with RTCA CardioECR Trial software
• Power and communication cables

The system has been fully serviced and tested by expert technicians, verified for electronic integrity, software communication, plate recognition, and resistance measurements according to manufacturer specifications. This equipment is widely adopted in biotechnology, biomedical engineering, and molecular biology research requiring high-throughput cardiac safety assessment.

Keywords & Search Phrases: real-time cardiomyocyte analysis, impedance-based cell analyzer, label-free electrophysiology monitoring, cardiotoxicity screening platform, drug safety testing system, cardiac contractility measurement, molecular diagnostics instrument, biotechnology research tool, synthetic biology assays, biopharmaceutical production screening.

This unit is supplied with a 120-day warranty in continental US and 60 days internationally, with options for remote setup, training, and ongoing technical support. Shipping is handled professionally with full insurance and packaging in ISPM15-certified crates where required.
