Applikon ez2-Control Bioreactor System Controller Model Z310110012

The Applikon ez2-Control Bioreactor System Controller (Model Z310110012) is designed for precise bioprocess management with features including:

• Brushless motor to reduce maintenance needs
• Supports integration of up to 6 Mass Flow Controllers to minimize shear stress in cultures
• Remote operation capability via web browsers and wireless devices
• Autotuning adaptive PID control for enhanced process stability
• Compatible with up to 8 analog/digital I/O connections
• Supports up to 4 external variable speed pumps

Technical Specifications:

• pH measurement range: 0–14, accuracy ±0.01 pH
• Dissolved Oxygen (DO) range: 0–100% saturation, accuracy ±0.1%
• Redox potential range: ±2000 mV, accuracy ±1 mV
• Temperature range: 0–150 °C, accuracy ±0.1 °C
• Stirring speed: 0–2000 rpm with feedback control, accuracy 0.1% full scale
• Certifications: CE, GAMP compliant, 21 CFR part 11 compliant

Physical Attributes:

• Weight: 65.32 kg (144 lbs)
• Shipping dimensions: 48.77 cm x 45.72 cm x 85.34 cm (19.2 in x 18.0 in x 33.6 in)

Compliance and Use:

• Harmonized Code: 841989 – machinery related to chemical and bioprocess industries for microbial and cell culture applications.

The unit was tested and powers on without errors. Package includes the ez2-Control with stirrer and heating blanket.
