Laboratory pumps

Edwards nXR120i NW25 Multi Stage Roots Dry Pump Ultimate Vacuum 0.03 mbar (0.022 Torr) Inlet Connect (more)ion NW40 Displacement 120 m 3h-1 Features - Reaches an ultimate vacuum of 0.03 mbar (0.022 Torr) for precise applications - Equipped with NW40 inlet and NW25 outlet flanges for flexible system integration - Maintains a leak tightness of < 1x10⁻⁶ mbar l/s for reliable vacuum integrity - Designed to fit under benchtops, optimizing laboratory space - Ensures a clean, oil-free operation, reducing contamination risks - Keeps the vacuum chamber free from dust, maintaining a clean environment - Seamlessly integrates into existing vacuum systems, ideal for OEMs - Offers design flexibility for R&D and industrial applications - Provides reliable vacuum performance over long periods, ensuring operational stability Edwards has revolutionised the vacuum pump market with the new nXRi high performance, compact dry pump. It delivers unrivalled pumping speeds in the most compact package, with pumping speeds of 30 to 120 m3h-1. The nXRi's lower input power and zero maintenance create real performance improvements and cost benefits across a range of applications.Analytical Instrument OEMs benefit from the ease of integration into most vacuum systems for a ready to go vacuum solution, perfect for mass spectrometry, electron microscopy and leak detection. R&D and Industrial customers will enjoy the design flexibility, oil-free and low maintenance features.Click Here to View Product Video INCLUDED: The Edwards nXR120i NW25 Multi Stage Roots Dry Pump includes: - Operator's Manual - 1 Year Manufacturer's Warranty

Edwards nXDS6iR Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases an (more)d bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally. Unlike the standard nXDS6i, the Edwards nXDS6iR is designedfor specialist applications such as gas recirculation, rare gas pumping andrecovery or other applications where the dilution of the pumped gas isundesirable, or where sealing is integral to minimizing potential gas loss. Click Here to View Product Video INCLUDED: The Edwards nXDS6iR Dry Scroll Pump includes: - 1 Year Full Parts and Labor Warranty - Power Cord - Manufacturer's Documentation - Operator's Manual Edwards nXDS6iR Dry Scroll Pump Technical SpecificationsNominal rotational speed1800 rpmDisplacement6.2 m3h-1 / 3.6 ft3min-1Peak pumping speed6.2 m3h-1 / 3.6 ft3min-1Ultimate vacuum (total pressure)0.020 mbar / 0.015 TorrMinimum standby rotational speed1200 rpmSpeed control resolution (percentage of full rotation speed)1%Pumping speed at minimum rotational speed4.1Maximum continuous inlet pressure200 mbarMotor power 1-ph260 WPower connector 1-phIEC EN60320 C13Recommended fuse10A, 250Vac rmsWeight26.2 kg / 58 lbInlet flangeNW25Exhaust flangeNW25Noise level52 dB(A)Vibration at inlet flange< 4.5 mms-1 (rms)Leak tightness (static)< 1x10-6 mbar ls-1Operating temperature range10 to 40 °C / 41 to 104 °FElectrical Supply115/230VComparison of ModelsSpecificationEdwards nXDS6iREdwards nXDS10iREdwards nXDS15iREdwards nXDS20iRNominal rotational speed (rpm)1800180018001800Displacement (m³h⁻¹ / ft³min⁻¹)6.2 / 3.612.7 / 7.517.1 / 10.128.0 / 16.5Peak pumping speed (m³h⁻¹ / ft³min⁻¹)6.2 / 3.611.4 / 6.715.1 / 8.922.0 / 13.0Ultimate vacuum (total pressure) (mbar / Torr)0.020 / 0.0150.007 / 0.0050.007 / 0.0050.030 / 0.022Weight (kg / lb)26.2 / 5825.8 / 5725.2 / 5625.6 / 56Inlet flangeNW25NW25NW25NW25Noise level (dB(A))52525252Operating temperature range (°C / °F)10 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 104Electrical Supply115/230V115/230V115/230V115/230V.comparison-table tr td:nth-child(2) { background-color: #fffacd; }

Edwards nXDS6iC Dry Scroll Pump Features - Bearing shield ensures separation between process gases a (more)nd bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally. The Edwards nXDS6iC features Chemraz internal valves and stainlesssteel fittings for extra protection from the pumped media. The ‘C’ series isbetter designed for more aggressive applications as opposed to the standardseries. Click Here to View Product Video INCLUDED: The Edwards nXDS6iC Dry Scroll Pump includes: - Power Cord - Manufacturer's Documentation - Operator's Manual - 1 Year Manufacturer's Warranty

Edwards nXDS6i Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases and (more) bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally.Click Here to View Product Video INCLUDED: The Edwards nXDS6i Dry Scroll Pump includes: - Power Cord - Manufacturer's Documentation - Operator's Manual - 1 Year Manufacturer's Warranty

Edwards nXDS20iR Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases a (more)nd bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally. Unlike the standard nXDS20i, the Edwards nXDS20iR isdesigned for specialist applications such as gas recirculation, rare gaspumping and recovery or other applications where the dilution of the pumped gasis undesirable, or where sealing is integral to minimizing potential gas loss. Click Here to View Product Video INCLUDED: The Edwards nXDS20iR Dry Scroll Pump includes: - 1 Year Full Parts and Labor Warranty - Power Cord - Manufacturer's Documentation - Operator's Manual Edwards nXDS20iR Dry Scroll Pump Technical SpecificationsNominal rotational speed1800 rpmDisplacement28.0 m3h-1 / 16.5 ft3min-1Peak pumping speed22.0 m3h-1 / 13.0 ft3min-1Ultimate vacuum (total pressure)0.030 mbar / 0.022 TorrMinimum standby rotational speed1200 rpmSpeed control resolution (percentage of full rotation speed)1%Pumping speed at minimum rotational speed10Maximum continuous inlet pressure50 mbarMotor power 1-ph260 WPower connector 1-phIEC EN60320 C13Recommended fuse10A, 250Vac rmsWeight25.6 kg / 56 lbInlet flangeNW25Exhaust flangeNW25Noise level52 dB(A)Vibration at inlet flange< 4.5 mms-1 (rms)Leak tightness (static)< 1x10-6 mbar ls-1Operating temperature range10 to 40 °C / 41 to 104 °FElectrical Supply115/230VComparison of ModelsSpecificationEdwards nXDS6iREdwards nXDS10iREdwards nXDS15iREdwards nXDS20iRNominal rotational speed (rpm)1800180018001800Displacement (m³h⁻¹ / ft³min⁻¹)6.2 / 3.612.7 / 7.517.1 / 10.128.0 / 16.5Peak pumping speed (m³h⁻¹ / ft³min⁻¹)6.2 / 3.611.4 / 6.715.1 / 8.922.0 / 13.0Ultimate vacuum (total pressure) (mbar / Torr)0.020 / 0.0150.007 / 0.0050.007 / 0.0050.030 / 0.022Weight (kg / lb)26.2 / 5825.8 / 5725.2 / 5625.6 / 56Inlet flangeNW25NW25NW25NW25Noise level (dB(A))52525252Operating temperature range (°C / °F)10 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 104Electrical Supply115/230V115/230V115/230V115/230V.comparison-table tr td:nth-child(5) { background-color: #fffacd; }

Edwards nXDS20iC Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases a (more)nd bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally. The Edwards nXDS20iC features Chemraz internal valves and stainlesssteel fittings for extra protection from the pumped media. The ‘C’ series isbetter designed for more aggressive applications as opposed to the standardseries. Click Here to View Product Video INCLUDED: The Edwards nXDS20iC Dry Scroll Pump includes: - 1 Year Full Parts and Labor Warranty - Power Cord - Manufacturer's Documentation - Operator's Manual Edwards nXDS20iC Dry Scroll Pump Technical SpecificationsNominal rotational speed1800 rpmDisplacement28.0 m3h-1 / 16.5 ft3min-1Peak pumping speed22.0 m3h-1 / 13.0 ft3min-1Ultimate vacuum (total pressure)0.030 mbar / 0.022 TorrMinimum standby rotational speed1200 rpmSpeed control resolution (percentage of full rotation speed)1%Pumping speed at minimum rotational speed10Maximum continuous inlet pressure50 mbarMotor power 1-ph260 WPower connector 1-phIEC EN60320 C13Recommended fuse10A, 250Vac rmsWeight25.6 kg / 56 lbInlet flangeNW25Exhaust flangeNW25Noise level52 dB(A)Vibration at inlet flange< 4.5 mms-1 (rms)Leak tightness (static)< 1x10-6 mbar ls-1Operating temperature range10 to 40 °C / 41 to 104 °FElectrical Supply115/230VComparison of ModelsParameterEdwards nXDS6iCEdwards nXDS10iCEdwards nXDS15iCEdwards nXDS20iCNominal rotational speed (rpm)1800180018001800Displacement (m³h⁻¹ / ft³min⁻¹)6.2 / 3.612.7 / 7.517.1 / 10.128.0 / 16.5Peak pumping speed (m³h⁻¹ / ft³min⁻¹)6.2 / 3.611.4 / 6.715.1 / 8.922.0 / 13.0Ultimate vacuum (total pressure) (mbar / Torr)0.020 / 0.0150.007 / 0.0050.007 / 0.0050.030 / 0.022Weight (kg / lb)26.2 / 5825.8 / 5725.2 / 5625.6 / 56Inlet flangeNW25NW25NW25NW25Noise level (dB(A))52525252Operating temperature range (°C / °F)10 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 104Electrical Supply115/230V115/230V115/230V115/230V.comparison-table tr td:nth-child(5) { background-color: #fffacd; }

Edwards nXDS20i Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases an (more)d bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally. Click Here to View Product Video INCLUDED: The Edwards nXDS20i Dry Scroll Pump includes: - 1 Year Manufacturer's Warranty

Edwards nXDS15iR Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases a (more)nd bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimized pumping performance globally. Unlike the standard nXDS15i, the Edwards nXDS15iR isdesigned for specialist applications such as gas recirculation, rare gaspumping and recovery or other applications where the dilution of the pumped gasis undesirable, or where sealing is integral to minimizing potential gas loss. Click Here to View Product Video INCLUDED: The Edwards nXDS15iR Dry Scroll Pump includes: - Power Cord - Operator’s Manual - Manufacturer's Documentation - 1 Year Manufacturer's Warranty

Edwards nXDS15iC Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases a (more)nd bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally. The Edwards nXDS15iC features Chemraz internal valves and stainlesssteel fittings for extra protection from the pumped media. The ‘C’ series isbetter designed for more aggressive applications as opposed to the standardseries. Click Here to View Product Video INCLUDED: The Edwards nXDS15iC Dry Scroll Pump includes: - 1 Year Full Parts and Labor Warranty - Power Cord - Manufacturer's Documentation - Operator's Manual Edwards nXDS15iC Dry Scroll Pump Technical SpecificationsNominal rotational speed1800 rpmDisplacement17.1 m3h-1 / 10.1 ft3min-1Peak pumping speed15.1 m3h-1 / 8.9 ft3min-1Ultimate vacuum (total pressure)0.007 mbar / 0.005 TorrMinimum standby rotational speed1200 rpmSpeed control resolution (percentage of full rotation speed)1%Pumping speed at minimum rotational speed9.9Maximum continuous inlet pressure200 mbarMotor power 1-ph300 WPower connector 1-phIEC EN60320 C13Recommended fuse10A, 250Vac rmsWeight25.2 kg / 56 lbInlet flangeNW25Exhaust flangeNW25Noise level52 dB(A)Vibration at inlet flange< 4.5 mms-1 (rms)Leak tightness (static)< 1x10-6 mbar ls-1Operating temperature range10 to 40 °C / 41 to 104 °FElectrical Supply115/230VComparison of ModelsParameterEdwards nXDS6iCEdwards nXDS10iCEdwards nXDS15iCEdwards nXDS20iCNominal rotational speed (rpm)1800180018001800Displacement (m³h⁻¹ / ft³min⁻¹)6.2 / 3.612.7 / 7.517.1 / 10.128.0 / 16.5Peak pumping speed (m³h⁻¹ / ft³min⁻¹)6.2 / 3.611.4 / 6.715.1 / 8.922.0 / 13.0Ultimate vacuum (total pressure) (mbar / Torr)0.020 / 0.0150.007 / 0.0050.007 / 0.0050.030 / 0.022Weight (kg / lb)26.2 / 5825.8 / 5725.2 / 5625.6 / 56Inlet flangeNW25NW25NW25NW25Noise level (dB(A))52525252Operating temperature range (°C / °F)10 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 104Electrical Supply115/230V115/230V115/230V115/230V.comparison-table tr td:nth-child(4) { background-color: #fffacd; }

Edwards nXDS15i Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases an (more)d bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally.Click Here to View Product Video INCLUDED: The Edwards nXDS15i Dry Scroll Pump includes: - 1 Year Full Parts and Labor Warranty - Power Cord - Manufacturer's Documentation - Operator's Manual Edwards nXDS15i Dry Scroll Pump Technical SpecificationsNominal rotational speed1800 rpmDisplacement17.1 m3h-1 / 10.1 ft3min-1Peak pumping speed15.1 m3h-1 / 8.9 ft3min-1Ultimate vacuum (total pressure)0.007 mbar / 0.005 TorrMinimum standby rotational speed1200 rpmSpeed control resolution (percentage of full rotation speed)1%Pumping speed at minimum rotational speed9.9Maximum continuous inlet pressure200 mbarMotor power 1-ph300 WPower connector 1-phIEC EN60320 C13Recommended fuse10A, 250Vac rmsWeight25.2 kg / 56 lbInlet flangeNW25Exhaust flangeNW25Noise level52 dB(A)Vibration at inlet flange< 4.5 mms-1 (rms)Leak tightness (static)< 1x10-6 mbar ls-1Operating temperature range10 to 40 °C / 41 to 104 °FElectrical Supply115/230VComparison of ModelsSpecificationEdwards nXDS6iEdwards nXDS10iEdwards nXDS15iEdwards nXDS20iNominal rotational speed (rpm)1800180018001800Displacement (m³h⁻¹ / ft³min⁻¹)6.8 / 4.012.7 / 7.517.1 / 10.128.0 / 16.5Peak pumping speed (m³h⁻¹ / ft³min⁻¹)6.2 / 3.611.4 / 6.715.1 / 8.922.0 / 13.0Ultimate vacuum (total pressure) (mbar / Torr)0.020 / 0.0150.007 / 0.0050.007 / 0.0050.030 / 0.022Weight (kg / lb)26.2 / 5825.8 / 5725.2 / 5625.6 / 56Inlet flangeNW25NW25NW25NW25Noise level (dB(A))52525252Operating temperature range (°C / °F)10 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 104Electrical Supply115/230V115/230V115/230V115/230V.comparison-table tr td:nth-child(4) { background-color: #fffacd; }

Edwards nXDS10iR Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases a (more)nd bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally. Unlike the standard nXDS10i, the Edwards nXDS10iR isdesigned for specialist applications such as gas recirculation, rare gaspumping and recovery or other applications where the dilution of the pumped gasis undesirable, or where sealing is integral to minimizing potential gas loss. Click Here to View Product Video INCLUDED: The Edwards nXDS10iR Dry Scroll Pump includes: - 1 Year Full Parts and Labor Warranty - Power Cord - Manufacturer's Documentation - Operator's Manual Edwards nXDS10iR Dry Scroll Pump Technical Specifications Nominal rotational speed1800 rpmDisplacement12.7 m3h-1 / 7.5 ft3min-1Peak pumping speed11.4 m3h-1 / 6.7 ft3min-1Ultimate vacuum (total pressure)0.007 mbar / 0.005 TorrMinimum standby rotational speed1200 rpmSpeed control resolution (percentage of full rotation speed)1%Pumping speed at minimum rotational speed7.5Maximum continuous inlet pressure200 mbarMotor power 1-ph280 WPower connector 1-phIEC EN60320 C13Recommended fuse10A, 250Vac rmsWeight25.8 kg / 57 lbInlet flangeNW25Exhaust flangeNW25Noise level52 dB(A)Vibration at inlet flange< 4.5 mms-1 (rms)Leak tightness (static)< 1x10-6 mbar ls-1Operating temperature range10 to 40 °C / 41 to 104 °FElectrical Supply115/230VComparison of ModelsSpecificationEdwards nXDS6iREdwards nXDS10iREdwards nXDS15iREdwards nXDS20iRNominal rotational speed (rpm)1800180018001800Displacement (m³h⁻¹ / ft³min⁻¹)6.2 / 3.612.7 / 7.517.1 / 10.128.0 / 16.5Peak pumping speed (m³h⁻¹ / ft³min⁻¹)6.2 / 3.611.4 / 6.715.1 / 8.922.0 / 13.0Ultimate vacuum (total pressure) (mbar / Torr)0.020 / 0.0150.007 / 0.0050.007 / 0.0050.030 / 0.022Weight (kg / lb)26.2 / 5825.8 / 5725.2 / 5625.6 / 56Inlet flangeNW25NW25NW25NW25Noise level (dB(A))52525252Operating temperature range (°C / °F)10 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 10410 to 40 / 41 to 104Electrical Supply115/230V115/230V115/230V115/230V.comparison-table tr td:nth-child(3) { background-color: #fffacd; }

Edwards nXDS10iC Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases a (more)nd bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally. The Edwards nXDS10iC features Chemraz internal valves and stainlesssteel fittings for extra protection from the pumped media. The ‘C’ series isbetter designed for more aggressive applications as opposed to the standardseries. Click Here to View Product Video INCLUDED: The Edwards nXDS10iC Dry Scroll Pump includes: - Power Cord - Manufacturer's Documentation - Operator's Manual - 1 Year Manufacturer's Warranty

Edwards nXDS10i Dry Scroll PumpFeatures - Bearing shield ensures separation between process gases an (more)d bearing lubrication to ensure clean vacuum and no possibility of contamination. - Smart motor drive means consistent performance globally, pump overload protection and remote start/stop capability. - High flow gas ballast feature allows pumping of vapours including water vapour at up to 240 gh-1 - Simple single sided scroll design allows maintenance to be done in minutes for low cost of ownership and maximum up-time. - Enhanced versions offer up to 20% lower peak power requirements during initial pump down. The nXDS allows a wide range of control and communication options The nXDS comes as standard with a manual, easy to use, gas ballast port A perfect companion for your turbomolecular pump With exceptional pumping capability, ultimate vacuum performance and state-of-the-art design features Edwards nXDS is the best performing pump in its class.nXDS improves on legacy XDS pumps by offering increased pumping speeds, combined with lower ultimate pressures, lower power consumption and lower noise - up to 20 times quieter than other pumps. Gas ballast allows for pumping of condensable vapours including, water, solvents, dilute acids and bases. nXDS pumps also feature the latest in tip seal technology giving significantly longer life between tip seal changes. Integrated inverter drive with auto sensing voltage input delivers optimised pumping performance globally. Click Here to View Product Video INCLUDED: The Edwards nXDS10i Dry Scroll Pump includes: - Power Cord - Manufacturer's Documentation - Operator's Manual - 1 Year Manufacturer's Warranty

Edwards nEXT930D - ISO-K200 NW25 Turbomolecular Pump Ultimate Vacuum <3.5x10-9 mbar Inlet Connect (more)ion DN 200 ISO-K Pumping Speed Nominal 5549.99 l/min Features - Delivers fast nitrogen pumping speeds, making it suitable for demanding applications - Designed for R&D, coating, heat treatment, furnace applications, and more - Offers variants for specific needs, including standard, high light gas compression, and regenerative stages - Compatible with TAG and TIC controllers for easy system integration - Allows for field replacement of oil cartridges and bearings with minimal tools - Provides powerful performance in a space-efficient design - Operates efficiently in any orientation, offering versatility in installation - Magnetic bearings reduce vibration, ensuring a stable vacuum environment - Optimized for high-speed and high-compression applications nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers. With the nEXT930 turbomolecular pumps Edwards provides a larger pump offering nitrogen pumping speeds of 925 l/s.INCLUDED: The Edwards nEXT930D - ISO-K200 NW25 Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT930D - CF200 NW25 Turbomolecular Pump Ultimate Vacuum <6x10-10 mbar Inlet Connection  (more)DN 200 CF Pumping Speed Nominal 52,200.00 l/min Features - Delivers fast nitrogen pumping speeds, making it suitable for demanding applications - Designed for R&D, coating, heat treatment, furnace applications, and more - Offers variants for specific needs, including standard, high light gas compression, and regenerative stages - Compatible with TAG and TIC controllers for easy system integration - Allows for field replacement of oil cartridges and bearings with minimal tools - Provides powerful performance in a space-efficient design - Operates efficiently in any orientation, offering versatility in installation - Magnetic bearings reduce vibration, ensuring a stable vacuum environment - Optimized for high-speed and high-compression applications nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers.nEXT930With the nEXT930 turbomolecular pumps Edwards provides a larger pump offering nitrogen pumping speeds of 925 l/s.Features and Benefits - Upper magnetic bearing - ensures clean vacuum, low power and low vibration. - Optimised rotor designs - deliver high speeds and high compression. - Range of variants suitable for many applications - D = standard nEXT pump variant, H = optimised rotor design for high light gas compression and T = additional regenerative stage for increased compression and higher backing pressure capability - Integrated controller / electronics - offers direct I/O or serial control or can be connected to one of our TAG or TIC controllers for easy systemisation. - Fully user serviceable - oil cartridge and bearings can be changed in the field with minimal tooling. - Inlet screen - supplied as standard INCLUDED: The Edwards nEXT930D - CF200 NW25 Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT85H NW40 NW16 80W Turbomolecular Vacuum Pump Ultimate Vacuum <5x10-9 mbar Inlet Conne (more)ction NW40 Pumping Speed Nominal 2,820.00 l/min Features - Combines oil-lubricated ceramic and dry permanent magnetic bearings for enhanced durability - Built-in electronics for streamlined operation and easy integration with control systems - Enhances speed and compression efficiency for a wide range of applications - Allows for in-field replacement of oil cartridges and bearings with minimal tools - Offers standard, high light gas compression, and additional regenerative stage options for specific needs - Provides superior compression performance for various gases - Ensures efficient operation with reduced electrical interference - Magnetic bearings reduce noise and vibration, ensuring a stable vacuum environment The nEXT 85H pumps consist of the turbomolecular pump with a permanently attached controller containing drive electronics. The controller controls the electrical supply to the pump with the exception of standby speed control. It has no manual controls and can only be operated through the logic interface. To operate the nEXT-85 H pump you must connect it to your own control equipment and power supply or alternatively use the Edwards TIC Turbo Instrument Controller or TIC Turbo Controller. nEXT 85H pumps are supllied with an inlet-screen fitted into the centering O-ring for ISO version pumps and into envelope for CF version pumps. nEXT85 pumps with an NW 25 interstage-port are supplied with an inlet-strainer that fits into the interstage-port. The inlet-screen and inlet-strainer protect the pump against damage that would be caused by debris entering the pump. The nEXT 85 H pumps have a vent-port for venting the pump and vacuum system to atmospheric pressure. The pump is supplied with a manual vent-vavle fitted; this can be replaced with a TAV5 or TAV6 solenoid-operated vent-valve. The TAV valve can be directly controlled by the on-board controller. The nEXT pumps have a purge-port: an inert purge gas can be introduced protect the bearing and motor from corrosion. An optional vent-port adapter and purge restrictor can be fitted to the purge-port to control the flow rate of the purge gas and to filter the gas supply. Click Here to View Product Video INCLUDED: The Edwards nEXT85H NW40 NW16 80W Turbomolecular Vacuum Pump includes: - Operator's Manual - 1 Year Manufacturer's Warranty

Edwards nEXT85H ISO63 NW16 80W Turbomolecular Vacuum Pump Ultimate Vacuum 5x10-9 mbar Inlet Connecti (more)on ISO63 NW16 Pumping Speed Nominal 503.99 l/min Features - Combines oil-lubricated ceramic and dry permanent magnetic bearings for enhanced durability - Built-in electronics for streamlined operation and easy integration with control systems - Enhances speed and compression efficiency for a wide range of applications - Allows for in-field replacement of oil cartridges and bearings with minimal tools - Offers standard, high light gas compression, and additional regenerative stage options for specific needs - Provides superior compression performance for various gases - Ensures efficient operation with reduced electrical interference - Magnetic bearings reduce noise and vibration, ensuring a stable vacuum environment nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers.With nEXT85 and nEXT55 Edwards offers a small and compact turbomolecular pump platform ideal for Analytical Instruments as well as for the R&D market. INCLUDED: The Edwards nEXT85H ISO63 NW16 80W Turbomolecular Vacuum Pump includes: - Power Cord - Two Year Manufacturer's Warranty

Edwards nEXT85H - CF63 NW16 - 80W Turbomolecular Vacuum Pump nEXT PumpsnEXT turbomolecular pumps are (more) hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers.nEXT85With nEXT85 and nEXT55 Edwards offers a small and compact turbomolecular pump platform ideal for Analytical Instruments as well as for the R&D market.Features and Benefits - Upper magnetic bearing - ensures clean vacuum, low power and low vibration. - Optimised rotor designs - deliver high speeds and high compression. - Range of variants suitable for many applications - D = standard nEXT pump variant, H = optimised rotor design for high light gas compression and T = additional regenerative stage for increased compression and higher backing pressure capability - Integrated controller / electronics - offers direct I/O or serial control or can be connected to one of our TAG or TIC controllers for easy systemisation. - Fully user serviceable - oil cartridge and bearings can be changed in the field with minimal tooling. - Inlet screen - supplied as standard INCLUDED: The Edwards nEXT85H - CF63 NW16 - 80W Turbomolecular Vacuum Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT85D NW40 NW16 - 80W Turbomolecular Vacuum Pump Ultimate Vacuum <5x10-9 mbar Inlet Con (more)nection NW40 Pumping Speed Nominal 0.047 m³/s Features - Combines oil-lubricated ceramic and dry permanent magnetic bearings for enhanced durability - Built-in electronics for streamlined operation and easy integration with control systems - Enhances speed and compression efficiency for a wide range of applications - Allows for in-field replacement of oil cartridges and bearings with minimal tools - Offers standard, high light gas compression, and additional regenerative stage options for specific needs - Provides superior compression performance for various gases - Ensures efficient operation with reduced electrical interference - Magnetic bearings reduce noise and vibration, ensuring a stable vacuum environment nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers.With nEXT85 and nEXT55 Edwards offers a small and compact turbomolecular pump platform ideal for Analytical Instruments as well as for the R&D market.Features and BenefitsUpper magnetic bearing - ensures clean vacuum, low power and low vibration. Optimised rotor designs - deliver high speeds and high compression. Range of variants suitable for many applications - D = standard nEXT pump variant, H = optimised rotor design for high light gas compression and T = additional regenerative stage for increased compression and higher backing pressure capability Integrated controller / electronics - offers direct I/O or serial control or can be connected to one of our TAG or TIC controllers for easy systemisation. Fully user serviceable - oil cartridge and bearings can be changed in the field with minimal tooling. Inlet screen - supplied as standardINCLUDED: The Edwards nEXT85D NW40 NW16 - 80W Turbomolecular Vacuum Pump includes: - Power Cord - One Year Manufacturer's Warranty

nEXT Pumps Ultimate Vacuum <3.5x10-9 mbar Inlet Connection DN 160 ISO-K Pumping Speed Nominal 4,3 (more)79.99 l/min Features - Delivers fast nitrogen pumping speeds, making it suitable for demanding applications - Designed for R&D, coating, heat treatment, furnace applications, and more - Offers variants for specific needs, including standard, high light gas compression, and regenerative stages - Compatible with TAG and TIC controllers for easy system integration - Allows for field replacement of oil cartridges and bearings with minimal tools - Provides powerful performance in a space-efficient design - Operates efficiently in any orientation, offering versatility in installation - Magnetic bearings reduce vibration, ensuring a stable vacuum environment - Optimized for high-speed and high-compression applications Edwards nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers. With the nEXT730 turbomolecular pumps Edwards provides a larger pump offering nitrogen pumping speeds of 730 l/s. INCLUDED: The Edwards nEXT730D - ISO-K160 BP NW25 Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT730D - CF160 BP NW25 Turbomolecular Pump Ultimate Vacuum <6x10-10 mbar Inlet Connecti (more)on DN 160 CF Pumping Speed Nominal 41,400.00 l/min Features - Delivers fast nitrogen pumping speeds, making it suitable for demanding applications - Designed for R&D, coating, heat treatment, furnace applications, and more - Offers variants for specific needs, including standard, high light gas compression, and regenerative stages - Compatible with TAG and TIC controllers for easy system integration - Allows for field replacement of oil cartridges and bearings with minimal tools - Provides powerful performance in a space-efficient design - Operates efficiently in any orientation, offering versatility in installation - Magnetic bearings reduce vibration, ensuring a stable vacuum environment - Optimized for high-speed and high-compression applications nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers.With the nEXT730 turbomolecular pumps Edwards provides a larger pump offering nitrogen pumping speeds of 730 l/s.INCLUDED: The Edwards nEXT730D - CF160 BP NW25 Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT400T HC - ISO160 160W Turbomolecular Pump Ultimate Vacuum 1x10-8 mbar Inlet Connection D (more)NISO160-K Pumping Speed Nominal 2399.99 l/min Features - Combines oil-lubricated ceramic lower bearing with a dry permanent magnetic upper bearing for enhanced performance - Features built-in electronics for easy integration with TAG and TIC controllers - Allows for in-field oil and bearing cartridge changes with minimal tools - Provides high speeds and compression with advanced simulation-derived designs - Features a patented bearing suspension system to minimize noise and vibration - Ensures a clean vacuum with a permanent magnet upper bearing - Suitable for research, high-energy physics, mass spectrometry, and industrial applications - Designed for long-term reliability and minimal maintenance needs nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers.INCLUDED: The Edwards nEXT300T HC - CF100 160W Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT400T HC - CF160 160W Turbomolecular Pump Ultimate Vacuum <1x10-10 mbar Inlet Connecti (more)on DN160CF Pumping Speed Nominal 2399.99 l/min Features - Combines oil-lubricated ceramic lower bearing with a dry permanent magnetic upper bearing for enhanced performance - Features built-in electronics for easy integration with TAG and TIC controllers - Allows for in-field oil and bearing cartridge changes with minimal tools - Provides high speeds and compression with advanced simulation-derived designs - Features a patented bearing suspension system to minimize noise and vibration - Ensures a clean vacuum with a permanent magnet upper bearing - Suitable for research, high-energy physics, mass spectrometry, and industrial applications - Designed for long-term reliability and minimal maintenance needs nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers. INCLUDED: The Edwards nEXT400D - CF160 160W Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT400D - ISO160 160W Turbomolecular Pump Ultimate Vacuum 1x10-8 mbar Inlet Connection DN16 (more)0ISO-K Pumping Speed Nominal 24,000.00 l/min Features - Combines oil-lubricated ceramic lower bearing with a dry permanent magnetic upper bearing for enhanced performance - Features built-in electronics for easy integration with TAG and TIC controllers - Allows for in-field oil and bearing cartridge changes with minimal tools - Provides high speeds and compression with advanced simulation-derived designs - Features a patented bearing suspension system to minimize noise and vibration - Ensures a clean vacuum with a permanent magnet upper bearing - Suitable for research, high-energy physics, mass spectrometry, and industrial applications - Designed for long-term reliability and minimal maintenance needs nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers.Features and Benefits - Upper magnetic bearing - ensures clean vacuum, low power and low vibration. - Optimised rotor designs - deliver high speeds and high compression. - Range of variants suitable for many applications - D = standard nEXT pump variant, H = optimised rotor design for high light gas compression and T = additional regenerative stage for increased compression and higher backing pressure capability - Integrated controller / electronics - offers direct I/O or serial control or can be connected to one of our TAG or TIC controllers for easy systemisation. - Fully user serviceable - oil cartridge and bearings can be changed in the field with minimal tooling. - Inlet screen - supplied as standard INCLUDED: The Edwards nEXT400D - ISO160 160W Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT400D - CF160 160W Turbomolecular Pump Ultimate Vacuum <1x10-10 mbar Inlet Connection  (more)DN160CF Pumping Speed Nominal 24,000.00 l/min Features - Combines oil-lubricated ceramic lower bearing with a dry permanent magnetic upper bearing for enhanced performance - Features built-in electronics for easy integration with TAG and TIC controllers - Allows for in-field oil and bearing cartridge changes with minimal tools - Provides high speeds and compression with advanced simulation-derived designs - Features a patented bearing suspension system to minimize noise and vibration - Ensures a clean vacuum with a permanent magnet upper bearing - Suitable for research, high-energy physics, mass spectrometry, and industrial applications - Designed for long-term reliability and minimal maintenance needs nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers.Features and Benefits - Upper magnetic bearing - ensures clean vacuum, low power and low vibration. - Optimised rotor designs - deliver high speeds and high compression. - Range of variants suitable for many applications - D = standard nEXT pump variant, H = optimised rotor design for high light gas compression and T = additional regenerative stage for increased compression and higher backing pressure capability - Integrated controller / electronics - offers direct I/O or serial control or can be connected to one of our TAG or TIC controllers for easy systemisation. - Fully user serviceable - oil cartridge and bearings can be changed in the field with minimal tooling. - Inlet screen - supplied as standard INCLUDED: The Edwards nEXT400D - CF160 160W Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT300T HC - CF100 160W Turbomolecular Pump Ultimate Vacuum <5x10-10 mbar Inlet Connecti (more)on DN100CF Pumping Speed Nominal 1799.99 l/min Features - Combines oil-lubricated ceramic lower bearing with a dry permanent magnetic upper bearing for enhanced performance - Features built-in electronics for easy integration with TAG and TIC controllers - Allows for in-field oil and bearing cartridge changes with minimal tools - Provides high speeds and compression with advanced simulation-derived designs - Features a patented bearing suspension system to minimize noise and vibration - Ensures a clean vacuum with a permanent magnet upper bearing - Suitable for research, high-energy physics, mass spectrometry, and industrial applications - Designed for long-term reliability and minimal maintenance needs nEXT turbomolecular pumps are hybrid bearing pumps with integrated controllers for pumping speeds from 47 to 1250 ls-1.The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers. INCLUDED: The Edwards nEXT300T HC - CF100 160W Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT300D - ISO100 160W Turbomolecular Pump Ultimate Vacuum <6x10-8 mbar Inlet Connection  (more)DN100ISO-K Pumping Speed Nominal 18,000.00 l/min Features - Combines oil-lubricated ceramic lower bearing with a dry permanent magnetic upper bearing for enhanced performance - Features built-in electronics for easy integration with TAG and TIC controllers - Allows for in-field oil and bearing cartridge changes with minimal tools - Provides high speeds and compression with advanced simulation-derived designs - Features a patented bearing suspension system to minimize noise and vibration - Ensures a clean vacuum with a permanent magnet upper bearing - Suitable for research, high-energy physics, mass spectrometry, and industrial applications - Designed for long-term reliability and minimal maintenance needs The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers. INCLUDED: The Edwards nEXT300D - ISO100 160W Turbomolecular Pump includes: - One Year Manufacturer's Warranty

Edwards nEXT300D - CF100 160W Turbomolecular Pump Ultimate Vacuum <5x10-10 mbar Inlet Connection  (more)DN100CF Pumping Speed Nominal 18,000.00 l/min Features - Combines oil-lubricated ceramic lower bearing with a dry permanent magnetic upper bearing for enhanced performance - Features built-in electronics for easy integration with TAG and TIC controllers - Allows for in-field oil and bearing cartridge changes with minimal tools - Provides high speeds and compression with advanced simulation-derived designs - Features a patented bearing suspension system to minimize noise and vibration - Ensures a clean vacuum with a permanent magnet upper bearing - Suitable for research, high-energy physics, mass spectrometry, and industrial applications - Designed for long-term reliability and minimal maintenance needs The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers. INCLUDED: The Edwards nEXT300D - CF100 160W Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty

Edwards nEXT240T HC - ISO100 160W Turbomolecular Pump Ultimate Vacuum <6x10-8 mbar Inlet Connecti (more)on DN100CF Pumping Speed Nominal 0.240 m³/s Features - Combines oil-lubricated ceramic lower bearing with a dry permanent magnetic upper bearing for improved performance - Offers direct I/O or serial control; compatible with TAG and TIC controllers for system integration - Oil cartridge and bearings can be replaced in the field with minimal tools - Features multiple drag stages for enhanced compression ratios and increased backing pressure tolerance - Suitable for a variety of demanding applications including high-energy physics, electron microscopy and industrial development - Features a patented bearing suspension system to reduce noise and vibration transmission to the vacuum system - Includes a purge port for safe operation with specialized gases - The permanent magnet upper bearing ensures a hydrocarbon-free environment, reducing contamination The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers.INCLUDED: The Edwards nEXT240T HC - ISO100 160W Turbomolecular Pump includes: - One Year Manufacturer's Warranty

Edwards nEXT240T HC - CF100 160W Turbomolecular Pump Ultimate Vacuum <5x10-10 mbar Inlet Connecti (more)on DNISO100-K Pumping Speed Nominal 1439.99 l/min Features - Combines oil-lubricated ceramic lower bearing with a dry permanent magnetic upper bearing for improved performance - Offers direct I/O or serial control; compatible with TAG and TIC controllers for system integration - Oil cartridge and bearings can be replaced in the field with minimal tools - Features multiple drag stages for enhanced compression ratios and increased backing pressure tolerance - Suitable for a variety of demanding applications including high-energy physics, electron microscopy and industrial development - Features a patented bearing suspension system to reduce noise and vibration transmission to the vacuum system - Includes a purge port for safe operation with specialized gases - The permanent magnet upper bearing ensures a hydrocarbon-free environment, reducing contamination The nEXT is a hybrid bearing compound turbomolecular pump. nEXT pumps combine our proven bearing technology (oil lubricated ceramic lower bearing with dry permanent magnetic upper bearing), an improved rotor design with a new molecular drag stage to deliver improved pumping speed and compression ratios, and user serviceability. They feature 24 V to 48 V DC sensorless motors with a built-in drive that is fully compatible with our range of TAG and TIC controllers.INCLUDED: The Edwards nEXT240T HC - CF100 160W Turbomolecular Pump includes: - Power Cord - One Year Manufacturer's Warranty
