Analytical instruments

RFM 340 refractometer Scale Refractive Index (RI): 1.33 – 1.54 Scale Sugar °Brix: 0 – 95 Resolution  (more)RI: 0.0001/0.00001 Resolution Sugar °Brix: 0.1/0.01 Accuracy RI: ±0.00003 Accuracy Sugar °Brix: 0.02 Lab circulating refrigerated water bath Temperature range: -20 to 200°C Temperature stability: ±0.03°C Pump capacity: 16 L/min Capacity: 7 litres

The RE40D refractometers is used to easily determine the refractive index of liquids. The measuremen (more)ts are carried out using the total reflection method. With this method, even dark samples can be measured easily. Thanks to the latest technology – no moving parts, durable LED light source and resistant sapphire prism, the RE refractometers are virtually maintenance-free Measure liquids with a refractive index in a range from 1.32000 to 1.7000 Require a minimal amount of sample (approx. 0.4 milliliters) for the measurement Keep the temperature of the samples to be measured between  15.00 and 70.00°C thanks to a built-in Peltier thermostat (no water bath required) Calculate the refractive index of the samples for any reference temperatures based on user-defined temperature functions Show the refractive index of the samples directly in Brix degrees Able to convert the measured values into any units (e.g. Zeiss number) and display them directly in these units Suitable for concentration determinations. Concentrations are due to custom formulas or concentration tables are automatically calculated from the measured refractive index. Deliver statistical evaluations (mean value, standard deviation, relative standard deviation) of the results. Entry of 10 measurement methods. One of these methods is reserved for adjusting the device. Can be easily checked with the built-in check function. This function allows a regular checking of the measurement accuracy without changing the device settings Three serial ports for connecting a printer, a barcode reader and a computer and a connection for controlling an automation unit Including RS-P42 printer

The Epsilon 1 is a fully integrated energy dispersive XRF analyzer consisting of a spectrometer, bui (more)lt-in computer, touch screen and analysis software. Powered by the latest advances in excitation and detection technology the Epsilon 1 is a star performer in the low-cost benchtop instrument class. Epsilon 1 produces fast, cost-effective, precise and accurate data with minimal operator dependence and sample preparation. The total running cost is therefore much lower than other analytical techniques such as AAS, ICP and wet chemical methods that are costly and also require a dedicated skilled operator. Sample Handling- Sample Type: Liquids, solids, slurries, loose powders, filters Sample Handling- Sample Positioning: Highly repeatable sample positioning Sample Handling- Spillage Protection: Spillage protection against powders and liquids X-Ray Tube- Window Type: High-stability ceramic side window X-Ray Tube- Window Size: 50 µm thin window (Be) for higher intensities X-Ray Tube- Max Voltage: Max voltage of 50 kV, ideal for analyzing heavier elements Detector- Resolution: High-resolution, typical 135 eV Detector- Window Size: 8 µm thin window (Be) for higher intensities Detector- Count Rate: High count rate detector capacity for faster analysis

The UV-1800 is an advanced high-resolution spectrophotometer utilizing a precision Czerny-Turner opt (more)ical system. Operation can be either as a stand-alone instrument or as a PC-controlled instrument with the included UV Probe software. USB memory can be connected directly to the UV-1800 for simple data transfer and printing is possible with the optional screen-copy printer or printers that support PCL control codes. Photometric Mode measures the absorbance or transmittance at a single wavelength or at multiple (up to eight) wavelengths. In multiple-wavelength measurement, calculations can be performed on the data obtained for up to four wavelengths, including the calculation of the difference between, or ratio of, the measurements obtained for two wavelengths. Spectrum Mode obtains sample spectra using wavelength scanning. Changes in the sample can be tracked using repeated scans. Data processing operations, such as the enlargement or reduction of the spectra obtained, peak detection, and area calculations, are also possible. Quantitation Mode generates a calibration curve from standard samples, and uses it to calculate the concentrations of unknown samples. Various combinations of wavelengths (1 to 3 wavelengths and derivatives) and calibration curves (K-factor and first-to-third order regression calibration curves) are possible. Kinetics Mode measures the change in absorbance as a function of time, and calculates enzymatic activity values. You can select either the kinetics measurement method or the rate measurement method. Time-Scan Mode measures the change in absorbance, transmittance, or energy as a function of time. Multi-Component Quantitation Mode separately quantitates up to eight components mixed in a single sample. Pure components or mixtures of components can be used as standard samples. Biomethod Mode is capable of analyzing DNA and proteins using the several common quantitation methods including quantitation of DNA or protein using the absorbance at 260/230 nm or 260/280 nm and protein quantitation via the Lowry method, BCA method, CBB method, Biuret method, and UV absorption method (direct measurement at 280 nm). Security and validation functionality are also preprogrammed. Security functions allow you to restrict functions according to three user levels: administrator, developer, and operator. Automatic or semiautomatic validation functions include wavelength accuracy, wavelength repeatability, resolution, stray light, photometric accuracy, photometric repeatability, baseline flatness, baseline stability, and noise level. The operating time of the lamps can be recorded and displayed so that you can anticipate replacement and avoid downtime. Stray Light: <0.02%T at 340 nm, 400 nm; <1.0%T at 198 nm Source Lamp: Deuterium; Tungsten-Halogen Beam Type: Double Bandwidth: 1.0 nm Min Wavelength: 190 nm Max Wavelength: 1100 nm Wavelength Accuracy: ±0.1 nm Wavelength Reproducibility: ±0.1 nm Min Photometric – Transmittance: 0%T Max Photometric – Transmittance: 400%T Min Photometric – Absorbance: -4 A Max Photometric – Absorbance: 4 A Photometric Drift: <0.0003 A/hr Detector: Silicon photodiode Including UV Probe software

Capacity: 3200 g Readability (0 – 600 g): 0.1 g Readability (600 – 3200 g): 0.1 g Repeatability: 0.0 (more)1 g Linearity: 0.02 g Stabilization time: 1.5 s Weighing pan: 170 mm Dimensions (LxWxH): 315 x 195 x 85 mm Weight: 5.5 kg

Can be operated with one hand Internal Buffer Detection Automatic/Manual Temperature Compensation In (more) Autolock mode, stable readings are held on the display mV – accuracy: ±0.1% ±1 digit mV – resolution: 1 pH – calibration: 1, 2 or 3 points pH – Accuracy: ±0.1% ±2 Digit Temperature Accuracy (°C): ±0.3 ±2 digits Temperature resolution (°C): 0.1 Memory – Logging Function: No

Equipped with a 4 cuvette holder Wavelength: 325 – 1000 nm Absorbance range 1: 0 – 1.0 Absorbance ra (more)nge 1: 0.1 steps Absorbance range 2: 0 – 1.0 Absorbance range 2: 0.2 steps Transmittance: 0 – 100%

test

ElectraSyn 2.0 essentially combines three products in one and will facilitate the mass adoption of e (more)lectrochemistry for preparative organic synthesis: a potentiostat, an analytical device and a stir plate. It is a compact, user friendly and cost effective platform for organic chemists to explore electrochemistry. The ElectraSyn 2.0 Ready-To-Go package includes all that is required to for your first experiment. including a single 10 ml vial, vial holder and a set of graphite electrodes. Voltage output (electrode): 30/10 V Current output (electrode): 100 mA Speed range: 50 – 1500 rpm Setting accuracy speed: 10 rpm Stirring quantity max.(H2O): 0.1 l Speed control: Turning knob Output current resolution: 0.1 mA Output voltage resolution: 0.01 V Current measuring resolution: 0.1 mA Voltage measuring resolution: 0.1 V Current measuring accuracy: 0.1 ±mA Voltage measuring accuracy: 0.01 ±V Dimensions (WxHxD): 130 x 150 x 250 mm Weight: 3.72 kg

pH electrode

No electrode included

Capacity: 3600 g Readability (0 – 600 g): 0.01 g Readability (600 – 3200 g): 0.1 g Repeatability: 0. (more)01 g Linearity: 0.02 g Stabilization time: 1.5 s Weighing pan: 170 mm Dimensions (LxWxH): 315 x 195 x 85 mm Weight: 5.5 kg

Weighing range: 0 to 3100 g Readability: 0.1 g Reproducibility: 0.05 g Linearity: ± 0.1 g Weighing p (more)latform: 182 x 228 mm Dimensions (WxDxH): 196 x 310 x 67 mm Weight: 4.1 kg

The award winning MATRIX-F is a dedicated Fourier Transform Near Infrared (FT-NIR) process spectrome (more)ter. It is the first industry hardened FT-NIR system that can directly withstand harsh environments. The MATRIX-F is an ideal process instrument, which can also be installed in the laboratory as a stand-alone system for method development and then move directly into your process application. The MATRIX-F is available as a free-standing unit with NEMA 4/IP66 (splashproof) housing. It can also be mounted in a standard 19 inch rack in a temperature controlled cabinet. The MATRIX-F can be equipped with a 6 port fiber optic multiplexer.

You can start a measurement or calibration with just one push of a button. The menu settings are int (more)uitive and consist of complete sentences in 12 languages. Read all relevant data at a glance, thanks to the 4.3″ color display with large numbers and clear icons. Increase the productivity of your instrument by connecting peripherals such as a printer, PC, USB stick and barcode reader. Parameter: pH, Ion, ORP Channel: Single Channel Measuring range pH: -2 to 20 Resolution pH: 0.001, 0.01, 0.1 Accuracy pH: ±0.002 Ion concentration measuring range: 1.00E-9 to 9.99E+9 Ion Concentration Resolution: 3 or 4 Digits (Auto) Ion concentration accuracy: ±0.5% Measuring range mV: -2,000,000 to 2,000,000 Resolution mV: 0.1, 1 Accuracy mV: ±0.1 Temperature range: -30°C to 130°C Temperature resolution: 0.1°C Temperature Accuracy: ±0.1°C Security & Compliance: Password Protection, GLP, User Management Memory size: 1,000 measurements Data transfer: PC, Printer, USB stick Flexibility and modularity: Stirrer, Barcode Scanner Compatible with Intelligent Sensor Management (ISM): Yes

System contains: Solvent tray Vacuum degasser: G1322A Vacuum degasser: The Agilent 1100 HPLC Degasse (more)r features a 4-channel vacuum container, including four tubular plastic membranes, and a vacuum pump. This degasser has a maximum flow rate of 0-10ml/min flow rate per channel and 5-10ml/min at reduced degassing performance. Quaternary pump: Hydraulic system: Dual plunger in series pump with proprietary servo-controlled variable stroke drive, floating plungers and active inlet valve Setable flow range: 0.001 – 10 ml/min, in 0.001 ml/min increments Flow range: 0.2 – 10.0 ml/min Flow precision: < 0.07% RSD, or < 0.02 min SD whatever is greater, based on retention time at constant room temperature Flow accuracy: ± 1% or 10 µl/min whatever is greater Pressure: Operating range 0 – 400 bar up to 5 ml/min, 0 – 200 bar up to 10 ml/min Pressure pulsation: < 2 % amplitude (typically < 1 %), at 1 ml/min isopropanol, at all pressures > 10 bar Compressibility compensation: User-selectable, based on mobile phase compressibility Recommended pH range: 1.0 – 12.5, solvents with pH < 2.3 should not contain acids which attack stainless steel Gradient formation: Low pressure quaternary mixing/gradient capability using proprietary high-speed proportioning valve Delay volume 800 – 1100 µl, dependent on back pressure Composition Range: 0 – 95 % or 5 – 100 %, user selectable Composition Precision: < 0.2 % RSD, at 0.2 and 1 ml/min Autosampler thermostat: Temperature range: setable from 4°C to 40°C in 1°C increments Temperature accuracy (at ambient temperatures < 25 °C and humidity < 50%): – 1°C to + 4°C at a setpoint of 4°C Temperature accuracy (at ambient temperatures > 25 °C and/or humidity > 50%): – 1°C to + 5°C at a setpoint of 4°C Standard autosampler: Pressure: Operating range 0 – 400 bar GLP features: Early maintenance feedback (EMF), electronic records of maintenance and errors Safety features: Leak detection and safe leak handling, low voltages in maintenance areas, error detection and display Injection range: 0.1 – 100 µl in 0.1 µl increments Replicate injections: 1 – 99 from one vial Precision: <0.25% RSD from 5 – 100 µl, <1% RSD 1 – 5 µl Minimum sample volume: 1 µl from 5 µl sample in 100 µl microvial, or 1 µl from 10 µl sample in 300 µl microvial Carryover: Typically <0.1% Sample viscosity range: 0.2 – 50 cp Replicate injections per vial: 1 – 99 Sample capacity 100 x 2 ml vials in 1 tray Injection cycle time: Typically 50 s depending on draw speed and injection volume Thermostatted colomn compartment: Temperature range: 10 degrees below ambient to 80 °C, up to 80 °C: flow rates up to 5 ml/min Temperature stability: ± 0.15 °C Temperature accuracy: ± 0.8 °C (± 0.5 °C With calibration) Column capacity: Three 30 cm Warm-up/cool-down time: 5 minutes from ambient to 40 °C, 10 minutes from 40 – 20 °C Dead volume: 3 µl Communications: Controller-area network (CAN), GPIB, RS-232C, APG Remote: ready, start, stop and shut-down signals, LAN via other series module Safety and maintenance: Extensive diagnostics, error detection and display (through control module and Agilent ChemStation), leak detection, safe leak handling, leak output signal for shutdown of pumping system. Low voltages in major maintenance areas. Diode array detector: Detection type: 1024-element photodiode array Light source: Deuterium and tungsten lamps Wavelength range: 190 – 950 nm Short term noise (ASTM) Single and Multi-Wavelengt: ± 1 × 10-5 AU at 254 and 750 nm Drift: 2 × 10-3 AU/hr at 254 nm Linear absorbance range: > 2 AU (upper limit) Wavelength accuracy: ± 1 nm Self-calibration with deuterium lines, verification with holmium oxide filter Wavelength bunching: 1 – 400 nm Programmable in steps of 1 nm Slit width: 1, 2, 4 , 8, 16 nm Programmable slit Diode width: < 1 nm Flow cells: 13 µl volume, 10 mm cell path length and 120 bar (1760 psi) pressure maximum Control and data evaluation: Agilent ChemStation for LC Analog outputs: Recorder/integrator: 100 mV or 1 V, output range 0.001 – 2 AU, two outputs Communications: Controller-area network (CAN), GPIB, RS-232C, APG Remote: ready, start, stop and shut-down signals, LAN optional Safety and maintenance: Extensive diagnostics, error detection and display through control module and ChemStation), leak detection, safe leak handling, leak output signal for shutdown of pumping system. Low voltages in major maintenance areas. GLP features: Early maintenance feedback (EMF) for continuous tracking of instrument usage in terms of lamp burn time with user-settable limits and feedback messages. Electronic records of maintenance and errors. Verification of wavelength accuracy with built-in holmium oxide filter.

The 515 HPLC pump is a programmable, free-standing HPLC pump available in isocratic, gradient, and s (more)emi-preparative configurations: Precise stepper motor control (48 steps/µL resolution) of dual reciprocating pistons Non-circular drive gears provide smooth, uniform eluent delivery User-programmable flow rate calibration and compressibility compensation factors ensure straightforward pump operation qualification Tests to retention time variations of less than 0.1% for highly reproducible peak performance Easy-to-read display and keypad for error-free programming Automatic purging and flow calibration

Measuring ranges pH: -8…22 mV: ±1200 mV Temperature (Pt 1000): -150…+250°C Temperature (NTC): -5…+25 (more)0°C Resolution pH: 0.001 mV: 0.1 mV Temperature (Pt 1000 or NTC): 0.1°C Measuring accuracy pH: ±0.003 mV: ±0.2 mV Pt 1000: ±0.2 °C (-20…+150 °C) NTC: ±0.6 °C (+10…+40 °C) Without pH electrode.

Speeds: Choice of 3 options. Standalone interleaved: LV/RV (18 speeds) 8 LV speeds followed by 10 RV (more) speeds Standalone sequential: LV/RV (18 speeds) 8 LV speeds and 10 RV speeds arranged in sequential order from lowest 0.3 rpm to highest 100 rpm. Standalone custom: 54 speeds, user selectable External (PC Control): 0.01 – 200 rpm (0.01 rpm increments from 0.01 to 0.99 rpm, 0.1 rpm increments from 1.0 to 200 rpm) Temperature sensing range: -100˚C to 300˚C Viscosity range: 100 – 40000000 cP Viscosity accuracy: ±1.0% of full scale range Viscosity repeatability: ±0.2% of Full Scale Range Temperature Accuracy: ±1°C (-100°C to +149°C), ±2°C (+150°C to +300°C)

The DV2T Viscometer features a 5-inch color display to guide users through test creation and data ga (more)thering for fast and easy viscosity measurements. The DV2T also offers powerful new programming capabilities and results analysis including data averaging and QC limits with alarms. 5-inch full color, touch screen display supports multiple languages Displayed info includes: viscosity (cP/mP·s), temperature (°C/°F), shear rate/stress, % torque, spindle/speed, step program status Enhanced security provides customizable user levels and password access. Built-In options include timed tests, data averaging, programmable QC limits/alarms, customizable speed/spindle lists, on screen data comparison Auto range shows maximum viscosity measured with any spindle/speed combination USB PC interface provides optional computer control and automatic data gathering capability Download custom test programs with PG Flash software Front-facing bubble level for convenient viewing Built-in temperature probe Accuracy of ±1.0% of range with displayed test data Repeatability of ±0.2% Viscosity range: 15 – 6.000.000 cP (mPa/s) Spring torque: 673.7 Dyne/cm, 0.0673 mN/m Included LV spindle set consisting of: LV-1: 15 – 20.000 cP LV-2: 50 – 100.000 cP LV-3: 200 – 400.000 cP LV-4: 1.000 – 2.000.000 cP

Speeds: Choice of 3 options, Instrument has “Interleaved” speeds when manufactured. Interleaved: LV/ (more)RV (18 speeds) 8 LV speeds followed by 10 RV speeds Sequential: LV/RV (18 speeds) 8 LV speeds and 10 RV speeds arranged in sequential order from lowest 0.3 rpm to highest 100 rpm. Custom: 54 speeds, user selectable External (PC Control): 0.01 – 200 rpm, 0.01 rpm increments from 0.01 to 0.99 rpm, 0.1 rpm increments from 1.0 to 200 rpm Temperature Sensing Range: -100˚C to 300˚C Temperature Accuracy: ±1°C (-100°C to 149°C), ±2°C (150°C to 300°C) Viscosity Range: 15 to 6000000 cP Viscosity Accuracy: ±1.0% of full scale range. Viscosity Repeatability: ±0.2% of Full Scale Range Weight: 9 kg Including spindles: LV – 1 LV – 3 LV – 4 LV – 62 Excluding temperature probe!

Capacity: 4100 g Readability: 0.01 g Repeatability: 0.008 g Linearity: 0.02 g Stabilization time: 1. (more)2 s Weighing pan: 170 x 205 mm Dimensions (LxWxH): 367 x 195 x 97 mm Weight: 6.9 kg

Weighing range: 0 to 610 g Readability: 0.01 g Reproducibility: 0.005 g Linearity: ± 0.01 g Weighing (more) platform: 150 mm Dimensions (WxDxH): 194 x 316 x 68 mm Weight: 3.8 kg
