Vacuum pumps

Laboport SD N 860.3 FT.40.18 is a two-stage pump with an integrated “self-drying” system for automat (more)ic condensate drain. The “SD” series is widely used in laboratories, especially when the vapors are humid and a clean and ecological vacuum is required. Typical applications are: vacuum ovens (for drying chemicals, drying biological samples, heat treatments), autoclaves for sterilizing instruments, containers, filters and textiles. Thanks to the use of anti-corrosion materials, it is possible to vacuum even corrosive products. The heart of the pump is the diaphragm with differentiated structure in PTFE, optimized to guarantee high performance with reduced dimensions and at the same time, long life even in heavy applications. When the humid gases are sucked in, it can happen that condensation forms in the pump head: consequently the performance decreases, considerably increasing the emptying time. To eliminate condensation, the 'drying system' then opens a solenoid valve that allows ambient air to enter the heads. Once the condensation has been eliminated, the solenoid valve closes and the pump sucks from the stove in full capacity. Over time, condensation could form again and then the cycle is repeated. The time interval between one cycle and the next can be adjusted as desired, as well as the duration of the air injection. Technical features Flow rate (max.) 60 l / min Final vacuum (max.) 4 mbar (abs.) Pressure (max.) 1 bar (rel.) Fluid temperature allowed at 5-40°C FFPM valve material PTFE coated diaphragm material Pump head material PTFE Applications Rotary evaporation Centrifugal concentration Distillation Vacuum oven Qualitative characteristics Clean operation, 100% oil-free Corrosion resistant PTFE / FFPM flow path Ideal for extremely aggressive / corrosive gases and vapors Compact, silent and reliable The self-drying system removes condensation without altering the vacuum level Maintenance free Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Technical features Flow rate (max.) 21 l / min Ultimate vacuum (max.) 2 mbar (abs.) Operating pressu (more)re (max.) 0.5 bar (rel.) Permitted fluid temperature 5-40°C FFPM valve material Membrane material PTFE coating PPS pump head material Applications Rotary evaporators Distillation Centrifugal concentrators Aspiration of fluids Qualitative characteristics Clean operation, 100% oil free High suction speed, especially in the low vacuum range Adjustable speed control Exceptionally quiet Corrosion resistant Maintenance free INCLUDED: The KNF N920KT.29.18G diaphragm pump includes: - Power cord - Operator's guide - Manufacturer's documentation - 1 year manufacturer's warranty Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Technical features Flow rate (max.) 5.5 l / min Final vacuum (max.) 160 mbar (abs.) Pressure (max.)  (more)2.4 bar (rel.) Permissible fluid temperature 5-40°C Valve material: FFPM Diaphragm material PTFE coated Pump head material: PPS Applications Filtration Aspiration of liquids Solid phase extraction Qualitative characteristics Clean operation, 100% oil-free Corrosion resistant Compact, silent and reliable Small footprint Maintenance free Download the data sheet for further information and accessories NOT SURE WHICH VACUUM PUMPS YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Technical features Flow rate (max.) 34 l / min Final vacuum (max.) 2 mbar (abs.) Pressure (max.) 1 b (more)ar (rel.) Permissible fluid temperature 5-40°C Valve material: FFPM Diaphragm material PTFE coated Pump head material: PTFE Applications Drying Rotary evaporation Centrifugal concentration Distillation Vacuum oven Qualitative characteristics Clean operation, 100% oil-free Chemically resistant PTFE / FFPM flow path Ideal for extremely aggressive / corrosive gases and vapors Compact, silent and reliable Maintenance free Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Labor port N 840 G KNF Diaphragm vacuum pump resistant to chemical and corrosive liquids, compact an (more)d oil-free. The pump capacity is manually adjustable with a simple knob. Laboport is equipped with gas ballast, PTFE/TFM heads, PTFE lined diaphragms and FFPM valves. It is suitable for a wide range of laboratory applications, including extremely aggressive/corrosive gases and vapours. - Flow rate (max.): 34 l/min - Final vacuum (max.): 6 mbar (abs.) - Adjustable speed control - ATEX compliant only for internal atmosphere (Ex) II 2/-G IIB+H2 T3 - Ideal for extremely aggressive/corrosive gases and vapours - Clean operation, 100% oil-free Technical features - Flow rate (max.): 34 l/min - Final vacuum (max.): 6 mbar (abs.) - Pressure (max.): 0.1 bar (rel.) - Permissible fluid temperature between 5 and 40°C - Valve material: FFPM - Diaphragm material: PTFE coated - Pump head material: PTFE Applications - Centrifugal concentration - Degassing - Drying - Distillation - Drying of the gel - Rotary evaporation - Solid phase extraction Qualitative characteristics - Adjustable speed control - ATEX compliant only for internal atmosphere (Ex) II 2 / -G IIB + H2 T3 - Ideal for extremely aggressive / corrosive gases and vapors - Chemically resistant PTFE / FFPM flow path - Clean operation, 100% oil-free - Compact, silent and reliable - Maintenance free - Small footprint to optimize workspace Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMPS YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION Presentations of the Laboport line directly from the specialists who created it. English subtitles. Presentation of the new Laborports and SMART KNF control.

Technical features Flow rate (max.) 34 l / min Final vacuum (max.) 8 mbar (abs.) Pressure (max.) 1 b (more)ar (rel.) Permissible fluid temperature 5-40°C Valve material: FFPM Diaphragm material PTFE coated Pump head material: PTFE Applications Rotary evaporation Degassing Drying of the gel Vacuum oven Qualitative characteristics Clean operation, 100% oil-free Chemically resistant PTFE / FFPM flow path Ideal for extremely aggressive / corrosive gases and vapors Compact, silent and reliable Maintenance free ATEX compliant only for internal atmosphere (Ex) II 2 / -G IIB + H2 T3 Download the data sheet for further information and accessories NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Labor port N 96 KNF Compact and portable diaphragm vacuum pump, resistant to chemicals and corrosive (more)s, oil-free. The pump capacity is manually adjustable with a simple knob. Laboport is equipped with gas ballast, PTFE/TFM heads, PTFE lined diaphragms and FFPM valves. It is suitable for a wide range of laboratory applications, including extremely aggressive/corrosive gases and vapours. Technical features - Flow rate (max.) 7 l / min - Final vacuum (max.) 130 mbar (abs.) - Pressure (max.) 2.5 bar (rel.) - Permissible fluid temperature 5-40 °C - Valve material: FKM - Diaphragm material: PTFE coated - Pump head material: PPS Applications - Filtration - Fluid suction - Solid phase extraction Qualitative characteristics - 100% oil-free transfer: transfer, evacuation and compression of gases in a clean and safe way - Extremely small footprint - The PTFE coated diaphragm is ideal for aggressive agents / gases and corrosive vapors - Integrated control of the rotation speed - Ecological Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMPS YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION Presentations of the Laboport line directly from the specialists who created it. English subtitles. Presentation of the new Laborports and SMART KNF control.

Technical features Flow rate (max.) 6 l / min Final vacuum (max.) 100 mbar (abs.) Pressure (max.) 2. (more)4 bar (rel.) Permissible fluid temperature 5-40 ° C Valve material: FFPM Diaphragm material PTFE coated Pump head material: PPS Applications Filtration Aspiration of liquids Solid phase extraction Qualitative characteristics Clean operation, 100% oil-free Corrosion resistant Compact, silent and reliable Ecological Maintenance free Download the data sheet for further information and accessories NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

The N 840.3 FT.40.18 is a two-stage pump with an integrated “self-drying” system for automatic conde (more)nsate drain. The “SD” series is widely used in laboratories, especially when the vapors are humid and a clean and ecological vacuum is required. Typical applications are: vacuum ovens (for drying chemicals, drying biological samples, heat treatments), autoclaves for sterilizing instruments, containers, filters and textiles. Thanks to the use of anti-corrosion materials, it is possible to vacuum even corrosive products. The heart of the pump is the diaphragm with differentiated structure in PTFE, optimized to guarantee high performance with reduced dimensions and at the same time, long life even in heavy applications. When the humid gases are sucked in, it can happen that condensation forms in the pump head: consequently the performance decreases, considerably increasing the emptying time. To eliminate condensation, the 'drying system' then opens a solenoid valve that allows ambient air to enter the heads. Once the condensation has been eliminated, the solenoid valve closes and the pump sucks from the stove in full capacity. Over time, condensation could form again and then the cycle is repeated. The time interval between one cycle and the next can be adjusted as desired, as well as the duration of the air injection. Technical features Flow Rate (max.) 34 l / min Ultimate Vacuum (max.) 10 mbar (abs.) Pressure (max.) 1 bar (rel.) Permissible Medium Temperature 5-40°C Valve Material FFPM Diaphragm Material PTFE coated Pump Head Material PTFE Applications Rotary evaporation Vacuum oven Qualitative characteristics Clean operation, 100% oil-free Corrosion resistant PTFE / FFPM flow path Ideal for extremely aggressive / corrosive gases and vapors Compact, silent and reliable The self-drying system removes condensation without altering the vacuum level Maintenance free Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMPS YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

This Edwards ECB8 Rotary Vane Vacuum Pump was removed from a university lab where it was surplus to  (more)requirements. The unit powers up and has been fully tested by a service engineer. It is in full working order and did not require a service. It is in good cosmetic condition with minor marks.

This Edwards 8 E2M8 Two Stage Rotary Vane Vacuum Pump was removed from a university lab where it was (more) surplus to requirements. The unit has been professionally serviced and is in full working order. It performs to 3.5 x 10 - 3. It is in good cosmetic condition with minor marks.

Leybold Vakuum GMBH Trivac 016B Pump This item was removed from a university lab where it was surplu (more)s to requirement. It is in good cosmetic condition and powers on, we are unable to conduct further testing at our facility.

JEOL JEM-100CX II Electron Microscope Vacuum Pump This was removed from a university lab where it w (more)as surplus to requirements. The unit is untested but in reasonable cosmetic condition. It requires a connection to the main system, which we do not have.

PFEIFFER Turbomolecular TMP Vacuum Pump TMH 260 This was removed from a university lab where I was s (more)urplus to requirements. The unit has not been tested but is in good cosmetic condition with marks from use. The turbo fan blade moves freely and are in good cosmetic condition. DN 100 ISO--K, 2PMod - Nr PM P02 13019 pin DIN MALE connector port is in good cosmetic condition. Please note that we have multiples of this unit in stock. You may not receive the one in the photos but will receive one in near-identical working and cosmetic condition. If you would like to see photos of the exact unit you are receiving upon purchase before it is shipped, we would be happy to provide this.

Leybold Trivac Vacuum Pump Type-D65BCS fitted w/ Exhaust filter with lubricant return ARS 40-65 Lab  (more)This item was removed from a university where it was surplus to requirement. It is in reasonably good cosmetic condition and powers on, but it frequently stalled during testing. We believe this could be sorted with a service. Therefore, it is listed as Spares/Repair. A 4 Pin 3 Phase plug was fitted for the purpose of testing, it was removed prior to being stocked. it is not included. This item is fitted with the following:- Leybold Exhaust filter with lubricant return ARS 40-65

Agilent Technologies IDP3 Dry Scroll Vacuum Pump This was removed from a university lab where it was (more) surplus to requirements. The unit powers up and draws suction. It is in good cosmetic condition with minor marks. Model - IDP-3Model no. IDP3A01SN - MY17190036Hours - 218.4

Edwards nXDS6i Dry Scroll Vacuum Pump This system was removed from a university lab where it was sur (more)plus to requirements. The unit is in very good cosmetic condition and is in good working order. Specifications:- Serial No.: 190064172 - Part No.: A73501983 - Speed: 1800 rpm - Displacement: 6.3 cuM/hr - Ultimate Vacuum: 0.020 mBar - Inlet/Outlet Flange: NW25 - Electric Supply: 100 or 240V, 50/60Hz - 2 x Data Ports for remote operation

BOC Edwards Scroll Vacuum Pump XDS5 A724-01-903 This system was removed from a university lab where  (more)it was surplus to requirements. The unit is in very good, clean condition and is in working order. Specifications:- Model: XDS5 A724-01-903 - Serial No.: 056314619

Edwards XDS5 Dry Scroll Vacuum Pump This system was removed from a university lab where it was surpl (more)us to requirements. The unit is in very good cosmetic condition and in working order. Specifications:- Serial No.: 46050723 - Code: A72401903XS - Running Hours: 29,726

Edwards iQDP80 Dry Vacuum Pump This item was removed from a university where it was surplus to requi (more)rement. It is in good cosmetic condition, and we have been advised by the previous owner that it is in good working order. Serial No.: M109880Model: 3XIQDP80Manufacturing Date: 21.11.00 Power supply cable & control module not included.

Edwards iQDP80 Dry Vacuum Pump Lab This item was removed from a university where it was surplus to r (more)equirement. It is in good cosmetic condition, and we have been advised by the previous owner that it is in good working order. Edwards iQDP80 Dry Vacuum PumpSerial No6397149Code No. IQ2100103 XS Power supply cable & control module not included.

Leybold Sogevac SV200 Single Stage Rotary Vane Vacuum Pump Lab This was removed from a university la (more)b where it was surplus to requirements. The unit has been professionally serviced and is in full working order at 2 x 10 m/bar. It is in excellent cosmetic condition.

This Leybold Sogevac SV200 Single-Stage Rotary Vane Vacuum Pump was removed from a university lab wh (more)ere it was surplus to requirements. The unit is in good cosmetic condition but has some stains. The unit has been professionally serviced with new oil and mist filters fitted. It was tested at 1.5 x 10 m/bar.
