Motic PSM-1000 Trinocular Upright Industrial Microscope, Head Only Objectives Optional Optical Syste (more)m Specialized lenses design, covers the spectrums ranging from the NUV to visible to NIR Illumination Port for fiber-optic coaxial illumination Features - Specialized head design for inspection and laser work. - Can be utilized within semiconductor analysis. - A wide range of objectives available, allowing users to configure the PSM 1000 based on their application's requirements. - Changeover turret for 355nm to 532nm, 532nm to 1064nm spectrums, additionally configured with a 2XVIS magnifier. The PSM1000 Head is an OEM component for the best image results of flat, reflective specimens. Samples from metallurgy and the semiconductor field are treated by the optional ELWD Plan Apochromatic objectives with a stupendous resolution power. The large FOV24 with an erect, true sided image allows fast orientation and manipulation work. INCLUDED: The Motic PSM-1000 Trinocular Upright Industrial Microscope, Head Only includes: - 3 Lens Changeover Turret - Adjustable Nosepiece - One fixed and three adjustable positions - Laser safety kit - Trinocular head - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (5x, 10x, 20x) PA Objectiv (more)es APO 5X, 10X, 20X Parfocality Adjustable Optical System Specialized Lenses Design For NUV to Visible NIR Illumination Port for Fiber-Optic Coaxial Illumination Features - Ergonomic Design: The design of the PSM-1000 encourages the optimal amount of usability without sacrificing comfort. - Laser Work: The PSM-1000 is standard equipped for laser work covering the spectrums ranging from 355nm [UV] to 532nm [Green] to 1064nm [IR]. - Focusing Block: Rated for load weights up to 45lbs., image focal planes can be adjusted at 1μm resolutions within the total 50mm stroke. - Adjustable Nosepiece: Forward facing and equipped for four M26 x 1/36" (0.706) type objectives, the PSM-1000's nosepiece is dovetail mounted for moulding to different types of research and usage. The PSM1000 is an OEM-ready instrument for the best images of flat, reflective specimens. Samples from metallurgy and the semiconductor field are treated by ELWD Plan Apochromatic objectives with a stupendous resolution power. The large FOV24 with an erect, true sided image allows fast orientation and manipulation work. INCLUDED: The Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (5x, 10x, 20x) PA includes: - APO 5X, 10X, 20X Parfocality Adjustable Objectives - Adjustable Nosepiece - Widefield WF10X/24mm Eyepiece - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (5x, 10x, 20x) Objectives  (more) APO 5X, 10X, 20X Optical System Specialized Lenses Design For NUV to Visible NIR Illumination Port for Fiber-Optic Coaxial Illumination Features - Ergonomic Design: The design of the PSM-1000 encourages the optimal amount of usability without sacrificing comfort. - Laser Work: The PSM-1000 is standard equipped for laser work covering the spectrums ranging from 355nm [UV] to 532nm [Green] to 1064nm [IR]. - Focusing Block: Rated for load weights up to 45lbs., image focal planes can be adjusted at 1μm resolutions within the total 50mm stroke. - Adjustable Nosepiece: Forward facing and equipped for four M26 x 1/36" (0.706) type objectives, the PSM-1000's nosepiece is dovetail mounted for moulding to different types of research and usage. The PSM1000 is an OEM-ready instrument for the best images of flat, reflective specimens. Samples from metallurgy and the semiconductor field are treated by ELWD Plan Apochromatic objectives with a stupendous resolution power. The large FOV24 with an erect, true sided image allows fast orientation and manipulation work. INCLUDED: The Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (5x, 10x, 20x) includes: - APO 5X, 10X, 20X Objectives - Adjustable Nosepiece - Widefield WF10X/24mm Eyepiece - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (2x, 10x, 20x) PA Objectiv (more)es APO 2X, 10X, 20X Parfocality Adjustable Optical System Specialized Lenses Design For NUV to Visible NIR Illumination Port for Fiber-Optic Coaxial Illumination Features - Ergonomic Design: The design of the PSM-1000 encourages the optimal amount of usability without sacrificing comfort. - Laser Work: The PSM-1000 is standard equipped for laser work covering the spectrums ranging from 355nm [UV] to 532nm [Green] to 1064nm [IR]. - Focusing Block: Rated for load weights up to 45lbs., image focal planes can be adjusted at 1μm resolutions within the total 50mm stroke. - Adjustable Nosepiece: Forward facing and equipped for four M26 x 1/36" (0.706) type objectives, the PSM-1000's nosepiece is dovetail mounted for molding to different types of research and usage. The PSM1000 is an OEM-ready instrument for the best images of flat, reflective specimens. Samples from metallurgy and the semiconductor field are treated by ELWD Plan Apochromatic objectives with a stupendous resolution power. The large FOV24 with an erect, true sided image allows fast orientation and manipulation work. INCLUDED: The Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (2x, 10x, 20x) PA includes: - APO 2X, 10X, 20X Parfocality Adjustable Objectives - Adjustable Nosepiece - Widefield WF10X/24mm Eyepiece - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (2x, 10x, 20x) Objectives  (more) APO 2X, 10X, 20X Optical System Specialized Lenses Design For NUV to Visible NIR Illumination Port for Fiber-Optic Coaxial Illumination Features - Ergonomic Design: The design of the PSM-1000 encourages the optimal amount of usability without sacrificing comfort. - Laser Work: The PSM-1000 is standard equipped for laser work covering the spectrums ranging from 355nm [UV] to 532nm [Green] to 1064nm [IR]. - Focusing Block: Rated for load weights up to 45lbs., image focal planes can be adjusted at 1μm resolutions within the total 50mm stroke. - Adjustable Nosepiece: Forward facing and equipped for four M26 x 1/36" (0.706) type objectives, the PSM-1000's nosepiece is dovetail mounted for moulding to different types of research and usage. The PSM1000 is an OEM-ready instrument for the best images of flat, reflective specimens. Samples from metallurgy and the semiconductor field are treated by ELWD Plan Apochromatic objectives with a stupendous resolution power. The large FOV24 with an erect, true sided image allows fast orientation and manipulation work. INCLUDED: The Motic PSM-1000 Trinocular Upright Industrial Microscope w/ APO Objectives (2x, 10x, 20x) includes: - APO 2X, 10X, 20X Objectives - Adjustable Nosepiece - Widefield WF10X/24mm Eyepiece - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Panthera TEC-BF/RL/TL Trinocular Upright Industrial Microscope, 6x4 Stage Objectives 5X, 10X,  (more)20X, S-APO 50X Optical System Color Corrected Infinity Optical System (CCIS) Illumination 3W Led & Integrated TL 0.06Wx39 LEDs Features - Utilizes a Color Corrected Infinity Optical System (CCIS) for sharp, clear imaging with minimal optical aberrations. - Features a trinocular Siedentopf head that swivels 360° and is 25° inclined, with a fixed 50:50 light split for simultaneous viewing and camera attachment. - Equipped with Widefield UC-WF10X/22mm eyepieces with diopter adjustments, providing a wide field of view and sharp focus across the entire viewing field. - Includes a selection of CCIS LD Plan Achromatic and S-Apo objectives for superior image clarity and precision, suitable for detailed examination of various materials. - Comes with a hard-coated mechanical stage, providing a smooth and stable platform for sample manipulation, featuring low position coaxial stage controls for precise movements. - Includes a dust cover, power cord, Allen key, and screws for metal extension support, ensuring you have all necessary components. - Integrated condenser concept for transmitted light, enhancing the examination of compound materials. The Panthera TEC MAT BF: a cutting-edge trinocular microscope tailored for material sciences. This sophisticated instrument is designed to handle opaque samples in industries and natural sciences with precision and ease. Featuring Long-Distance Plan Achromatic and Semi-Apo objectives, the Panthera TEC MAT BF delivers ultra-contrast images from reflective surfaces, making it perfect for detailed metallurgical analysis and other scientific applications. Equipped with UC eyepieces boasting a 22mm field of view, this microscope ensures broad and clear visibility. The advanced 3W LED ring illumination system, adjustable in color temperature, allows for segmental illumination, ideal for examining rough or uneven surfaces. With the innovative Motic LightTracer system, users benefit from a memory function that recalls optimal lighting settings, combined with a built-in Low-Energy mode and an LED feedback indicator to streamline workflow and enhance efficiency. INCLUDED: The Motic Panthera TEC-BF/RL/TL Trinocular Upright Industrial Microscope, 6x4 Stage includes: - Dust Cover - Allen Key - Screws for Metal Extension - Integrated 3W Led Illumination System - 6x4 in. Stage - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Panthera TEC-BF/RL/TL Trinocular Upright Industrial Microscope, 3x2 Stage Objectives 5X, 10X,  (more)20X, S-APO 50X Optical System Color Corrected Infinity Optical System (CCIS) Illumination 3W Led & Integrated TL 0.06Wx39 LEDs Features - Utilizes a Color Corrected Infinity Optical System (CCIS) for sharp, clear imaging with minimal optical aberrations. - Features a trinocular Siedentopf head that swivels 360° and is 25° inclined, with a fixed 50:50 light split for simultaneous viewing and camera attachment. - Equipped with Widefield UC-WF10X/22mm eyepieces with diopter adjustments, providing a wide field of view and sharp focus across the entire viewing field. - Includes a selection of CCIS LD Plan Achromatic and S-Apo objectives for superior image clarity and precision, suitable for detailed examination of various materials. - Comes with a hard-coated mechanical stage, providing a smooth and stable platform for sample manipulation, featuring low position coaxial stage controls for precise movements. - Includes a dust cover, power cord, Allen key, and screws for metal extension support, ensuring you have all necessary components. - Integrated condenser concept for transmitted light, enhancing the examination of compound materials. The Panthera TEC MAT BF: a cutting-edge trinocular microscope tailored for material sciences. This sophisticated instrument is designed to handle opaque samples in industries and natural sciences with precision and ease. Featuring Long-Distance Plan Achromatic and Semi-Apo objectives, the Panthera TEC MAT BF delivers ultra-contrast images from reflective surfaces, making it perfect for detailed metallurgical analysis and other scientific applications. Equipped with UC eyepieces boasting a 22mm field of view, this microscope ensures broad and clear visibility. The advanced 3W LED ring illumination system, adjustable in color temperature, allows for segmental illumination, ideal for examining rough or uneven surfaces. With the innovative Motic LightTracer system, users benefit from a memory function that recalls optimal lighting settings, combined with a built-in Low-Energy mode and an LED feedback indicator to streamline workflow and enhance efficiency. INCLUDED: The Motic Panthera TEC-BF/RL/TL Trinocular Upright Industrial Microscope, 3x2 Stage includes: - Dust Cover - Allen Key - Screws for Metal Extension - Integrated 3W Led Illumination System - 3x2 in. Stage - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Panthera TEC-BF/RL Trinocular Upright Industrial Microscope, 6x4 Stage Objectives 5X, 10X, 20X (more), S-APO 50X Optical System Color Corrected Infinity Optical System (CCIS) Illumination 3W Led W/ Integrated Field and Aperture Diaphragms Features - Utilizes a Color Corrected Infinity Optical System (CCIS) for sharp, clear imaging with minimal optical aberrations. - Features a trinocular Siedentopf head that swivels 360° and is 25° inclined, with a fixed 50:50 light split for simultaneous viewing and camera attachment. - Equipped with Widefield UC-WF10X/22mm eyepieces with diopter adjustments, providing a wide field of view and sharp focus across the entire viewing field. - Includes a selection of CCIS LD Plan Achromatic and S-Apo objectives for superior image clarity and precision, suitable for detailed examination of various materials. - Comes with a hard-coated mechanical stage, providing a smooth and stable platform for sample manipulation, featuring low position coaxial stage controls for precise movements. - Includes a dust cover, power cord, Allen key, and screws for metal extension support, ensuring you have all necessary components. The Panthera TEC MAT BF: a cutting-edge trinocular microscope tailored for material sciences. This sophisticated instrument is designed to handle opaque samples in industries and natural sciences with precision and ease. Featuring Long-Distance Plan Achromatic and Semi-Apo objectives, the Panthera TEC MAT BF delivers ultra-contrast images from reflective surfaces, making it perfect for detailed metallurgical analysis and other scientific applications. Equipped with UC eyepieces boasting a 22mm field of view, this microscope ensures broad and clear visibility. The advanced 3W LED ring illumination system, adjustable in color temperature, allows for segmental illumination, ideal for examining rough or uneven surfaces. With the innovative Motic LightTracer system, users benefit from a memory function that recalls optimal lighting settings, combined with a built-in Low-Energy mode and an LED feedback indicator to streamline workflow and enhance efficiency. INCLUDED: The Motic Panthera TEC-BF/RL Trinocular Upright Industrial Microscope, 6x4 Stage includes: - Dust Cover - Allen Key - Screws for Metal Extension - Integrated 3W Led Illumination System - 6x4 in. Stage - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Panthera TEC-BF/RL Trinocular Upright Industrial Microscope, 3x2 Stage Objectives 5X, 10X, 20X (more), S-APO 50X Optical System Color Corrected Infinity Optical System (CCIS) Illumination 3W Led W/ Integrated Field and Aperture Diaphragms Features - Utilizes a Color Corrected Infinity Optical System (CCIS) for sharp, clear imaging with minimal optical aberrations. - Features a trinocular Siedentopf head that swivels 360° and is 25° inclined, with a fixed 50:50 light split for simultaneous viewing and camera attachment. - Equipped with Widefield UC-WF10X/22mm eyepieces with diopter adjustments, providing a wide field of view and sharp focus across the entire viewing field. - Includes a selection of CCIS LD Plan Achromatic and S-Apo objectives for superior image clarity and precision, suitable for detailed examination of various materials. - Comes with a hard-coated mechanical stage, providing a smooth and stable platform for sample manipulation, featuring low position coaxial stage controls for precise movements. - Includes a dust cover, power cord, Allen key, and screws for metal extension support, ensuring you have all necessary components. The Panthera TEC MAT BF: a cutting-edge trinocular microscope tailored for material sciences. This sophisticated instrument is designed to handle opaque samples in industries and natural sciences with precision and ease. Featuring Long-Distance Plan Achromatic and Semi-Apo objectives, the Panthera TEC MAT BF delivers ultra-contrast images from reflective surfaces, making it perfect for detailed metallurgical analysis and other scientific applications. Equipped with UC eyepieces boasting a 22mm field of view, this microscope ensures broad and clear visibility. The advanced 3W LED ring illumination system, adjustable in color temperature, allows for segmental illumination, ideal for examining rough or uneven surfaces. With the innovative Motic LightTracer system, users benefit from a memory function that recalls optimal lighting settings, combined with a built-in Low-Energy mode and an LED feedback indicator to streamline workflow and enhance efficiency. INCLUDED: The Motic Panthera TEC-BF/RL Trinocular Upright Industrial Microscope, 3x2 Stage includes: - Dust Cover - Allen Key - Screws for Metal Extension - Integrated 3W Led Illumination System - 3x2 in. stage - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Panthera TEC-BD/DF/RL/TL Trinocular Upright Industrial Microscope, 6x4 Stage Objectives 5X, 10 (more)X, 20X, 50X CCIS BD Plan Achromatic & S-Apo (Pb free) DIN (for Brightfield and Darkfield) Optical System Colour Corrected Infinity Optical System (CCIS) Illumination 3W LED Epi-Illumination Kohler Illumination 0.06W LED Features - Panthera TEC models include brilliant optics and smart functionality for extended ease of use. - Features Smart Darkfield with 5 Segment illumination mode. - New LD Plan Achromatic and S-Apochromatic BD objectives & 22mm FOV eyepieces. - Pure incident or incident/ transmitted microscope stands available. - 3W LED of selectable color temperature for incident illumination. - Motic LightTracer: Coded nosepiece & Digital light intensity knob. The Panthera TEC offers high value for the inspection of semiconductors and compound materials, especially in industrial quality control and technical education. Brightfield, Darkfield and Cross Polarization contrast are combined with a new, unique-to-Motic segmental illumination that all contribute to the versatility of this model. This concept allows an oblique incident illumination, perfect for the detection of scratches or other defects on flat and reflecting surfaces without a need to move the sample. BD models feature LD Plan BD objectives with a superb imaging performance, mounted on a 5-fold nosepiece. The light intensity for each objective position is automatically memorized and will be repeated once the objective is swung in again. The compact Epi illuminator carries a slot for polarizer and analyzer, ready for Polarization contrast and to reduce internal reflections. The illuminator also includes the controls for varying the incident light in terms of mode (BF or DF) and illumination angle.INCLUDED: The Motic Panthera TEC-BD/DF/RL/TL Trinocular Upright Industrial Microscope, 6x4 Stage includes: - 5X/0.13 (WD 17.3mm) - 10X/0.25 (WD 16.3mm) - 20X/0.40 (WD 7.3mm) - S-Apo 50X/0.80 (WD 1mm) - Dust Cover - Allen Key - Screws for Metal Extension Support - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Panthera TEC-BD/DF/RL/TL Trinocular Upright Industrial Microscope, 3x2 Stage Objectives 5X, 10 (more)X, 20X BD, 50X S-APO BD CCIS BD Plan Achromatic & S-Apo (Pb free) DIN (for Brightfield and Darkfield) Optical System Colour Corrected Infinity Optical System (CCIS) Illumination 3W LED Epi-Illumination Kohler Illumination 0.06W LED Features - Panthera TEC models include brilliant optics and smart functionality for extended ease of use. - Features Smart Darkfield with 5 Segment illumination mode. - New LD Plan Achromatic and S-Apochromatic BD objectives & 22mm FOV eyepieces. - Pure incident or incident/ transmitted microscope stands available. - 3W LED of selectable color temperature for incident illumination. - Motic LightTracer: Coded nosepiece & Digital light intensity knob. The Panthera TEC offers high value for the inspection of semiconductors and compound materials, especially in industrial quality control and technical education. Brightfield, Darkfield and Cross Polarization contrast are combined with a new, unique-to-Motic segmental illumination that all contribute to the versatility of this model. This concept allows an oblique incident illumination, perfect for the detection of scratches or other defects on flat and reflecting surfaces without a need to move the sample. BD models feature LD Plan BD objectives with a superb imaging performance, mounted on a 5-fold nosepiece. The light intensity for each objective position is automatically memorized and will be repeated once the objective is swung in again. The compact Epi illuminator carries a slot for polarizer and analyzer, ready for Polarization contrast and to reduce internal reflections. The illuminator also includes the controls for varying the incident light in terms of mode (BF or DF) and illumination angle.INCLUDED: The Motic Panthera TEC-BD/DF/RL/TL Trinocular Upright Industrial Microscope, 3x2 Stage includes: - 5X/0.13 (WD 17.3mm) - 10X/0.25 (WD 16.3mm) - 20X/0.40 (WD 7.3mm) - S-Apo 50X/0.80 (WD 1mm), - Dust Cover - Allen Key - Screws for Metal Extension Support - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Panthera TEC-BD/DF/RL/TL Trinocular Upright Industrial Microscope, 6x4 Stage Objectives 5X, 10 (more)X, 20X, 50X CCIS BD Plan Achromatic & S-Apo (Pb free) DIN (for Brightfield and Darkfield) Optical System Colour Corrected Infinity Optical System (CCIS) Illumination 3W LED Epi-Illumination Features - Panthera TEC models include brilliant optics and smart functionality for extended ease of use. - Features Smart Darkfield with 5 Segment illumination mode. - New LD Plan Achromatic and S-Apochromatic BD objectives & 22mm FOV eyepieces. - Pure incident or incident/ transmitted microscope stands available. - 3W LED of selectable color temperature for incident illumination. - Motic LightTracer: Coded nosepiece & Digital light intensity knob. The Panthera TEC offers high value for the inspection of semiconductors and compound materials, especially in industrial quality control and technical education. Brightfield, Darkfield and Cross Polarization contrast are combined with a new, unique-to-Motic segmental illumination that all contribute to the versatility of this model. This concept allows an oblique incident illumination, perfect for the detection of scratches or other defects on flat and reflecting surfaces without a need to move the sample. BD models feature LD Plan BD objectives with a superb imaging performance, mounted on a 5-fold nosepiece. The light intensity for each objective position is automatically memorized and will be repeated once the objective is swung in again. The compact Epi illuminator carries a slot for polarizer and analyzer, ready for Polarization contrast and to reduce internal reflections. The illuminator also includes the controls for varying the incident light in terms of mode (BF or DF) and illumination angle.INCLUDED: The Motic Panthera TEC-BD/DF/RL Trinocular Upright Industrial Microscope, 6x4 Stage includes: - 5X/0.13 (WD 17.3mm) - 10X/0.25 (WD 16.3mm) - 20X/0.40 (WD 7.3mm) - S-Apo 50X/0.80 (WD 1mm) - Dust Cover - Allen Key - Screws for Metal Extension Support - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Panthera TEC-BD/DF/RL Trinocular Upright Industrial Microscope, 3x2 Stage Objectives 5X, 10X,  (more)20X BD 50X S-APO BD CCIS BD Plan Achromatic & S-Apo (Pb free) DIN (for Brightfield and Darkfield) Optical System Colour Corrected Infinity Optical System (CCIS) Illumination 3W LED Epi-Illumination Features - Panthera TEC models include brilliant optics and smart functionality for extended ease of use. - Features Smart Darkfield with 5 Segment illumination mode. - New LD Plan Achromatic and S-Apochromatic BD objectives & 22mm FOV eyepieces. - Pure incident or incident/ transmitted microscope stands available. - 3W LED of selectable color temperature for incident illumination. - Motic LightTracer: Coded nosepiece & Digital light intensity knob. The Panthera TEC offers high value for the inspection of semiconductors and compound materials, especially in industrial quality control and technical education. Brightfield, Darkfield and Cross Polarization contrast are combined with a new, unique-to-Motic segmental illumination that all contribute to the versatility of this model. This concept allows an oblique incident illumination, perfect for the detection of scratches or other defects on flat and reflecting surfaces without a need to move the sample. BD models feature LD Plan BD objectives with a superb imaging performance, mounted on a 5-fold nosepiece. The light intensity for each objective position is automatically memorized and will be repeated once the objective is swung in again. The compact Epi illuminator carries a slot for polarizer and analyzer, ready for Polarization contrast and to reduce internal reflections. The illuminator also includes the controls for varying the incident light in terms of mode (BF or DF) and illumination angle.INCLUDED: The Motic Panthera TEC-BD/DF/RL Trinocular Upright Industrial Microscope, 3x2 Stage includes: - 5X/0.13 (WD 17.3mm) - 10X/0.25 (WD 16.3mm) - 20X/0.40 (WD 7.3mm) - S-Apo 50X/0.80 (WD 1mm) - Dust Cover - Allen Key - Screws for Metal Extension Support - Power Cord - Operator's Manual - Manufacturer's Documentation - 5 Year Manufacturer's Warranty

Motic Panthera TEC POL EPI (Trinocular) Features - UC Plan Achromat objectives (strain-free) for FOV (more) 22mm - Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL EPI series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL EPI (Trinocular) includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL EPI (Trinocular) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf typeSensor type-Sensor size-Capture resolution-Live display mode (through Wi-Fi)-Live display mode (through ethernet)-Live display mode (through HDMI)-Inclination25º inclinedTrinocular light splitFixed 50:50Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjective classificationPlan Achromatic objectives & CCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight10.4kgComparison of ModelsSpecificationPanthera TEC POL EPI (Binocular)Panthera TEC POL EPI (Digital)Panthera TEC POL EPI (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeInterpupillary distance48-75mm48-75mm48-75mmEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(4) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera TEC POL EPI (Digital) Features - UC Plan Achromat objectives (strain-free) for FOV 22 (more)mm - Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL EPI series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL EPI (Digital) includes: - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL EPI (Digital) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeBinocular head, Siedentopf type with built-in digital cameraSensor typeCMOSSensor size1/2.5"Capture resolution5MP (2592x1944)Live display mode (through Wi-Fi)1920x1080 (Full HD)Live display mode (through ethernet)1280x720, 1920x1080 (Full HD)Live display mode (through HDMI)1280x720, 1920x1080 (Full HD)Inclination25º inclinedTrinocular light split-Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjective classificationPlan Achromatic objectives & CCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight9.9kgComparison of ModelsSpecificationPanthera TEC POL EPI (Binocular)Panthera TEC POL EPI (Digital)Panthera TEC POL EPI (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeInterpupillary distance48-75mm48-75mm48-75mmEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(3) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera TEC POL EPI (Binocular) Features - UC Plan Achromat objectives (strain-free) for FOV  (more)22mm - Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL EPI series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL EPI (Binocular) includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL EPI (Binocular) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeBinocular head, Siedentopf typeSensor type-Sensor size-Capture resolution-Live display mode (through Wi-Fi)-Live display mode (through ethernet)-Live display mode (through HDMI)-Inclination25º inclinedTrinocular light split-Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjective classificationPlan Achromatic objectives & CCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight10.4kgComparison of ModelsSpecificationPanthera TEC POL EPI (Binocular)Panthera TEC POL EPI (Digital)Panthera TEC POL EPI (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeInterpupillary distance48-75mm48-75mm48-75mmEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentIntermediate BodyEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsEpi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensatorsObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(2) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera TEC POL (Trinocular) Features - UC Plan Achromat objectives (strain-free) for FOV 22m (more)m - Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL (Trinocular) includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL (Trinocular) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf typeSensor type-Sensor size-Capture resolution-Live display mode (through Wi-Fi)-Live display mode (through ethernet)-Live display mode (through HDMI)-Inclination25º inclinedTrinocular light splitFixed 50:50Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyRotatable analyzer 360º, Bertrand lens and slot for compensatorsObjective classificationCCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmTravel range X&Y1º increments, 0.1º vernier scaleCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight9.8kgComparison of ModelsSpecificationPanthera TEC POL (Binocular)Panthera TEC POL (Digital)Panthera TEC POL (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmTravel range X&Y1º increments, 0.1º vernier scale1º increments, 0.1º vernier scale1º increments, 0.1º vernier scaleFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(4) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera TEC POL (Digital) Features - UC Plan Achromat objectives (strain-free) for FOV 22mm - (more) Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL (Digital) includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL (Digital) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeBinocular head, Siedentopf type with built-in digital cameraSensor typeCMOSSensor size1/2.5"Capture resolution5MP (2592x1944)Live display mode (through Wi-Fi)1920x1080 (Full HD)Live display mode (through ethernet)1280x720, 1920x1080 (Full HD)Live display mode (through HDMI)1280x720, 1920x1080 (Full HD)Inclination25º inclinedTrinocular light split-Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyRotatable analyzer 360º, Bertrand lens and slot for compensatorsObjective classificationCCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmTravel range X&Y1º increments, 0.1º vernier scaleCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight9.9kgComparison of ModelsSpecificationPanthera TEC POL (Binocular)Panthera TEC POL (Digital)Panthera TEC POL (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmTravel range X&Y1º increments, 0.1º vernier scale1º increments, 0.1º vernier scale1º increments, 0.1º vernier scaleFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(3) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera TEC POL (Binocular) Features - UC Plan Achromat objectives (strain-free) for FOV 22mm (more) - Transmitted and transmitted/ incident stand options - Transmitted light: LED/HAL light source interchangeable - Integrated focusable/ centerable Bertrand lens - Motic LightTracer: Coded nosepiece & Digital light intensity knob The Panthera TEC POL series fills a last gap in the Panthera family: Polarization microscopes for all material sciences, ready to handle transparent samples like fibers and foils with their inherent birefringence. The Incident light models for opaque materials work out the specific reflectivity (bireflection) of flat surfaces. To extend the application fields, all microscopes carry an intermediate tube with Bertrand lens to analyze the crystal structure and interference figures of gems, precious stones and minerals.INCLUDED: The Motic Panthera TEC POL (Binocular) includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 60X/0.8/S (WD 0.35mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Blue Filter - Halogen Bulb - Adjustable Key for Nosepiece - Interference Color Chart - Screws for Metal Extension Support - Operator's Guide Motic Panthera TEC POL (Binocular) SpecificationsOptical systemColour Corrected Infinity Optical System (CCIS®)Observation tubeBinocular head, Siedentopf typeSensor type-Sensor size-Capture resolution-Live display mode (through Wi-Fi)-Live display mode (through ethernet)-Live display mode (through HDMI)-Inclination25º inclinedTrinocular light split-Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentNosepieceReversed quintuple, coded with single centering holesIntermediate BodyRotatable analyzer 360º, Bertrand lens and slot for compensatorsObjective classificationCCIS® UC Plan Achromatic (strain-free), DINObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)Objective mounting threadW 4/5"x1/36" (RMS standard)StageCircular rotating 360º, lockableStage sizeØ160mmTravel range X&Y1º increments, 0.1º vernier scaleCondenserFocusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizerDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2µmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminator with fixing capTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorTransformerInternalPower supply110-240V (CE)Other featuresUSB 2.0 for external camera powerDimensions LxWxH410x300x395mmNet weight10.4kgComparison of ModelsSpecificationPanthera TEC POL (Binocular)Panthera TEC POL (Digital)Panthera TEC POL (Trinocular)Optical systemCCISCCISCCISObservation tubeBinocular head, Siedentopf typeBinocular head, Siedentopf type with built-in digital cameraTrinocular head, Siedentopf typeEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentWidefield UC-WF10X/22mm with diopter adjustmentObjectives4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)4X/0.1 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 60X/0.8/S (WD 0.35mm)StageCircular rotating 360º, lockableCircular rotating 360º, lockableCircular rotating 360º, lockableStage sizeØ160mmØ160mmØ160mmTravel range X&Y1º increments, 0.1º vernier scale1º increments, 0.1º vernier scale1º increments, 0.1º vernier scaleFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentCoaxial coarse and fine focusing system with tension adjustmentTransmitted illuminationKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity controlKoehler Quartz halogen 6V/30W with intensity control.comparison-table tr td:nth-child(2) { background-color: #fffacd; }DownloadsTechnical Specification Download

Motic Panthera E2 Trinocular Compound Microscope w/o 100x Objective Manufactured to Withstand the Ti (more)me With the new microscope Series Panthera E2, your decision is distinct. This microscope series allows to experience Life Sciences in a new way, with the best possible learning effect. From now on, you achieve your teaching goals in the easiest way, with the highest precision and accuracy that meet all your intentions in mind. Even in a small lab with a small budget, these new technologies from Motic will convince you.Panthera E2 microscopes combine high-quality materials and precise engineering to a persistent and resilient construction. The smooth operation of the mechanics is self-evident for fast and reliable results, responsible for shifting your daily work in the classroom and lab to a higher level of quality. User-friendly design, robust for tough environments, and unique features grants the best performance. Models of this series convince positively in smooth operation and haptic.Robust Functionality for Demanding Environments Panthera E2 was developed by listening to your objectives in mind. Features like a reversed 4-fold nosepiece, a rackless X/Y-stage with a standard slide holder and an upper limit stop fulfill users' demands. The standard eyepiece tubes can be adjusted to accommodate different physiques. In addition, all tubes are rotatable. Together with a small footprint and compact design worries about small working places or storage problems are obsolete.Strong Optical Performance with Ultra Contrast Optics The Panthera E2 series is equipped with new Ultra Contrast (UC) Plan Achromatic objectives in a range from 4X to 40X magnification. These objectives together with neutral eyepieces guarantee the best performance in terms of color fidelity and contrast. A fully corrected intermediate image for digital access is granted. The optional 100X/0.8 "Dry objective" is especially favorable in environments where the time-consuming immersion procedure is considered too difficult and complicated.Efficiency and Energy Saving LED Illumination Setup The low consumption LED light source in a Fixed Koehler setup stands for a "cool" illumination with a long lifetime. An unbeatable key feature for outdoor activities: A USB port in the stand grants the functionality of the microscope independent from the mains by a power bank.Close to your Individual Applications Panthera E2 microscopes can be upgraded for different contrast methods: Phase contrast for unstained samples from botany, zoology, and medicine is a classic, Darkfield for impressive images from protozoa is on the verge of extinction, POL contrast for birefringent structures is an underrated method for biology and medicine. For plastics and foils from the industrial lab, this method is standard.Click Here to View Product Video INCLUDED: The Motic Panthera E2 Trinocular Compound Microscope w/o 100x Objective includes: - 4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm) Objectives - Dust Cover - Power Cord - Allen Key - Immersion Oil (5ml) - 5 Year Manufacturer's Warranty

Motic Panthera E2 Trinocular Compound Microscope w/ Moticam BMH4000X Microscope Camera Objectives UC (more) Plan Achromatic (Pb free) 4X, 10X, 40X, 100X Optical System Color Corrected Infinity Optical System (CCIS®) Transmitted Illumination (FPS) Fixed Koehler LED Features - Mechanical stage with built-in low position rackless coaxial stage control and sample holder for smoother x/y movement - Fixed Koehler LED 1W with intensity control and nosepiece LED light intensity indicator - Coaxial coarse and fine focusing with 2μm precision and adjustable upper limit stop - Ideal for environments where immersion procedures are considered difficult or complicated - 11.6" LCD screen with native 1920x1080 pixels for real-time viewing - 8MP capture resolution with outputs via HDMI, USB, and WIFI

Motic Panthera E2 Trinocular Compound Microscope Manufactured to Withstand the Time With the new mic (more)roscope Series Panthera E2, your decision is distinct. This microscope series allows to experience Life Sciences in a new way, with the best possible learning effect. From now on, you achieve your teaching goals in the easiest way, with the highest precision and accuracy that meet all your intentions in mind. Even in a small lab with a small budget, these new technologies from Motic will convince you.Panthera E2 microscopes combine high-quality materials and precise engineering to a persistent and resilient construction. The smooth operation of the mechanics is self-evident for fast and reliable results, responsible for shifting your daily work in the classroom and lab to a higher level of quality. User-friendly design, robust for tough environments, and unique features grants the best performance. Models of this series convince positively in smooth operation and haptic.Robust Functionality for Demanding Environments Panthera E2 was developed by listening to your objectives in mind. Features like a reversed 4-fold nosepiece, a rackless X/Y-stage with a standard slide holder and an upper limit stop fulfill users' demands. The standard eyepiece tubes can be adjusted to accommodate different physiques. In addition, all tubes are rotatable. Together with a small footprint and compact design worries about small working places or storage problems are obsolete.Strong Optical Performance with Ultra Contrast Optics The Panthera E2 series is equipped with new Ultra Contrast (UC) Plan Achromatic objectives in a range from 4X to 100X magnification. These objectives together with neutral eyepieces guarantee the best performance in terms of color fidelity and contrast. A fully corrected intermediate image for digital access is granted. The optional 100X/0.8 "Dry objective" is especially favorable in environments where the time-consuming immersion procedure is considered too difficult and complicated.Efficiency and Energy Saving LED Illumination Setup The low consumption LED light source in a Fixed Koehler setup stands for a "cool" illumination with a long lifetime. An unbeatable key feature for outdoor activities: A USB port in the stand grants the functionality of the microscope independent from the mains by a power bank.Close to your Individual Applications Panthera E2 microscopes can be upgraded for different contrast methods: Phase contrast for unstained samples from botany, zoology, and medicine is a classic, Darkfield for impressive images from protozoa is on the verge of extinction, POL contrast for birefringent structures is an underrated method for biology and medicine. For plastics and foils from the industrial lab, this method is standard.Click Here to View Product Video INCLUDED: The Motic Panthera E2 Trinocular Compound Microscope includes: - 4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm) Objectives - Dust Cover - Power Cord - Allen Key - Immersion Oil (5ml) - 5 Year Manufacturer's Warranty

Motic Panthera E2 Trinocular + BTI10 Camera Bundle Panthera E2 microscopes combine high quality mate (more)rials and precise engineering to a persistent and resilient construction. Smooth operation of the mechanics is self-evident for fast and reliable results, responsible for shifting your daily work in classroom and lab to a higher level of quality. User-friendly design, robust for tough environments and unique features grants the best performance. The Moticam BTI10 combines a space-saving camera hardware with new Wi-Fi technology. The 4MP Wi-Fi camera comes together with an 10” Android tablet to deliver fast live images (up to 30 fps) on any microscope with a vertical photo tube.INCLUDED: The Motic Panthera E2 Trinocular + BTI10 Camera Bundle includes: - 4X/0.10 (WD 30.5mm ) Objective - 10X/0.25 (WD 17.4mm ) Objective - 40X/0.65/S (WD 0.6mm ) Objective - 100X/1.25/S-Oil (WD 0.16mm ) Objective - Dust Cover - Power Cord - Allen Key - UC-WF eyepieces 10X/20mm - Moticam BTI10 - 0.35X C-Mount camera adapter - Manufacturer’s Documentation - 5 Year Manufacturer’s Warranty Motic Panthera E2 Trinocular + BTI10 Camera Bundle SpecificationsPanthera E32 Trinocular SpecificationsOptical systemColor Corrected Infinity Optical System (CCIS®)Observation tubeTrinocular head, Siedentopf type, 360° swivelingInclination25° inclined, 360° rotating (storage saving), 360° swivellingTrinocular light splitFixed 50:50Interpupillary distance48-75mmDiopter adjustmentOn both eyepieces, +/- 5 diopterEyepiecesWidefield UC-WF10X/20mm with diopter adjustmentNosepieceReversed quadrupleObjective classificationCCIS® UC Plan Achromatic (Pb free)Objectives4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)Objective mounting threadW 4/5"x1/36" (RMS standard)Stand typeUprightStageMechanical stage with built-in low position rackless coaxial stage control and sample holderStage size140x135mmTravel range X&Y75x40mmCondenserFocusable and centerable Abbe condenser N.A. 0.90/1.25 with slot for contrast slidersDiaphragmIris diaphragmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFine focus precision2μmFocusing stroke25mmUpper limit stopUpper limit stop preset but adjustableFilter holderOn top of the illuminatorTransmitted illuminationFixed Koehler LED 1W with intensity controlIllumination featuresNosepiece LED light intensity indicatorTransformerInternalPower supply110-240V (CE), USB 2.0 for battery packOther featuresUSB 2.0 for external camera powerDimensions LxWxH282x210x396mmNet weight7.5kg BTI10 Camera SpecificationsSensor TypeCMOSSensor Size1/3"Imaging Area5.44x3.07mmCapture Resolution Info4MP (2592x1520 pixels)Live display mode through Wi-Fi1280x720, 1920x1080 pixels (Full HD)Live display mode through Ethernet1280x720, 1920x1080 pixels (Full HD)Pixel size2.0x2.0μmScan modeProgressiveData transferWi-Fi (2.4 & 5 GHz), EthernetMax. frames per second (fps)1920x1080 @ 30 fps, 1280x960 @ 30 fps (depending on Wi-Fi strength)Exposure time0.03 msec to 0.03 secOperating temperatureFrom 0 to +60 Degrees Celsius non condensingMax. signal to noise ratio38.3dBDynamic range64.6dBSensitivity1.9V/Lux-sec (550nm)ButtonsOn/OffSupport deviceUniversal Web browser (HTML5)Supported OSWindows XP/Vista/7/8/10, MAC OSX, Android 4,0 or higher, iOS7 or higherMinimum computer requirements2GHz dualcore - RAM memory 2GB - Video memory min. 512 MBLens mountC-MountScreen10" IPS TabletSoftwareMotiConnect App for iOS and Android (pre-installed)FunctionsStill image and video capture, live and still image measurement, image adjustments, white balance, automatic & manual exposure, individual objective calibration system.Power supply12V (External Power supply)Tablet bracket holderFor tablets from 7” to 10”Package includesUSB cable, Motic 4-dot calibration slide, universal power supply 100V-240V (CE)Tablet SpecificationsSize (mm)218x136x10mmSystemAndroid 10Pre-installed AppMotiConnectLanguageMulti-LanguageCPU2.0GHz 8-coreRAM6GB DDR3NAND Flash128GBDisplay10" (IPS) 16:10 RatioDisplay resolutions1920x1200Touch PanelCapacitive Multi-Touch ScreenGPUMALI-G720 MP3PortsMicroSD/MMC/TF Card (Support up 64 GB), 3.5mm Audio, USB-C (USB OTG and Charging)Speaker8Ω/0.7Wx2MicMIC (Internal)Wi-Fi802.11b/g/nBluetooth4.0CameraFront (5M Pixels) + Rear (8M Pixels)Support display formatMPEG-1/2 (DAT, MPG, VOB, TS), MPEG-4, H.263 (3GP, MOV, MP4), H.264 (AVI, MKV, MP4, MOV, 3GP), RM, RMVB, FLV, WEBMSupport audio formatMP3, WMA, MP2, OGG, AAC, M4A, OGA, FLAC, APE, MP1, WAVPicture formatJPG, JPEG, GIF, BMP, PNGBattery3.7V/3500mAh Rechargeable BatteryPower supply tabletInput：AC100-240V. 50-60HZ - Output: DC5V 2A (Support USB port charging）CertificationsFCC CEColorWhiteComparison of ModelsSpecificationPanthera E2 BinocularPanthera E2 Binocular (w/o 100x)Panthera E2 Trinocular + BMH4000 Camera BundlePanthera E2 Trinocular + BTI10 Camera BundlePanthera E2 TrinocularPanthera E2 Trinocular (w/o 100x)Optical SystemColor Corrected Infinity Optical System (CCIS®)Color Corrected Infinity Optical System (CCIS®)Color Corrected Infinity Optical System (CCIS®)Color Corrected Infinity Optical System (CCIS®)Color Corrected Infinity Optical System (CCIS®)Color Corrected Infinity Optical System (CCIS®)Observation TubeBinocular head, Siedentopf type, 360° swivelingBinocular head, Siedentopf type, 360° swivelingTrinocular head, Siedentopf type, 360° swivelingTrinocular head, Siedentopf type, 360° swivelingTrinocular head, Siedentopf type, 360° swivelingTrinocular head, Siedentopf type, 360° swivelingTrinocular Light SplitN/AN/AFixed 50:50Fixed 50:50Fixed 50:50Fixed 50:50EyepiecesWidefield UC-WF10X/20mm with diopter adjustmentWidefield UC-WF10X/20mm with diopter adjustmentWidefield UC-WF10X/20mm with diopter adjustmentWidefield UC-WF10X/20mm with diopter adjustmentWidefield UC-WF10X/20mm with diopter adjustmentWidefield UC-WF10X/20mm with diopter adjustmentObjectives4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm)4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)Stage Size140x135mm140x135mm140x135mm140x135mm140x135mm140x135mmIlluminationLEDLEDLEDLEDLEDLED.comparison-table tr td:nth-child(5) { background-color: #fffacd; }

Motic Panthera E2 Binocular Compound Microscope w/o 100x Objective Manufactured to Withstand the Tim (more)e With the new microscope Series Panthera E2, your decision is distinct. This microscope series allows to experience Life Sciences in a new way, with the best possible learning effect. From now on, you achieve your teaching goals in the easiest way, with the highest precision and accuracy that meet all your intentions in mind. Even in a small lab with a small budget, these new technologies from Motic will convince you.Panthera E2 microscopes combine high-quality materials and precise engineering to a persistent and resilient construction. The smooth operation of the mechanics is self-evident for fast and reliable results, responsible for shifting your daily work in the classroom and lab to a higher level of quality. User-friendly design, robust for tough environments, and unique features grant the best performance. Models of this series convince positively in smooth operation and haptic.Robust Functionality for Demanding Environments Panthera E2 was developed by listening to your objectives in mind. Features like a reversed 4-fold nosepiece, a rackless X/Y-stage with a standard slide holder and an upper limit stop fulfill users' demands. The standard eyepiece tubes can be adjusted to accommodate different physiques. In addition, all tubes are rotatable. Together with a small footprint and compact design worries about small working places or storage problems are obsolete.Strong Optical Performance with Ultra Contrast Optics The Panthera E2 series is equipped with new Ultra Contrast (UC) Plan Achromatic objectives in a range from 4X to 100X magnification. These objectives together with neutral eyepieces guarantee the best performance in terms of color fidelity and contrast. A fully corrected intermediate image for digital access is granted. The optional 100X/0.8 "Dry objective" is especially favorable in environments where the time-consuming immersion procedure is considered too difficult and complicated.Efficiency and Energy Saving LED Illumination Setup The low consumption LED light source in a Fixed Koehler setup stands for a "cool" illumination with a long lifetime. An unbeatable key feature for outdoor activities: A USB port in the stand grants the functionality of the microscope independent from the mains by a power bank.Close to your Individual Applications Panthera E2 microscopes can be upgraded for different contrast methods: Phase contrast for unstained samples from botany, zoology, and medicine is a classic, Darkfield for impressive images from protozoa is on the verge of extinction, POL contrast for birefringent structures is an underrated method for biology and medicine. For plastics and foils from the industrial lab, this method is standard.Click Here to View Product Video INCLUDED: The Motic Panthera E2 Binocular Compound Microscope w/o 100x Objective includes: - 4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm) Objectives - Dust Cover - Power Cord - Allen Key - Immersion Oil (5ml) - 5 Year Manufacturer's Warranty

Motic Panthera E2 Binocular Compound Microscope Manufactured to Withstand the Time With the new micr (more)oscope Series Panthera E2, your decision is distinct. This microscope series allows to experience Life Sciences in a new way, with the best possible learning effect. From now on, you achieve your teaching goals in the easiest way, with the highest precision and accuracy that meet all your intentions in mind. Even in a small lab with a small budget, these new technologies from Motic will convince you.Panthera E2 microscopes combine high-quality materials and precise engineering to a persistent and resilient construction. The smooth operation of the mechanics is self-evident for fast and reliable results, responsible for shifting your daily work in the classroom and lab to a higher level of quality. User-friendly design, robust for tough environments, and unique features grant the best performance. Models of this series convince positively in smooth operation and haptic.Robust Functionality for Demanding Environments Panthera E2 was developed by listening to your objectives in mind. Features like a reversed 4-fold nosepiece, a rackless X/Y-stage with a standard slide holder and an upper limit stop fulfill users' demands. The standard eyepiece tubes can be adjusted to accommodate different physiques. In addition, all tubes are rotatable. Together with a small footprint and compact design worries about small working places or storage problems are obsolete.Strong Optical Performance with Ultra Contrast Optics The Panthera E2 series is equipped with new Ultra Contrast (UC) Plan Achromatic objectives in a range from 4X to 100X magnification. These objectives together with neutral eyepieces guarantee the best performance in terms of color fidelity and contrast. A fully corrected intermediate image for digital access is granted. The optional 100X/0.8 "Dry objective" is especially favorable in environments where the time-consuming immersion procedure is considered too difficult and complicated.Efficiency and Energy Saving LED Illumination Setup The low consumption LED light source in a Fixed Koehler setup stands for a "cool" illumination with a long lifetime. An unbeatable key feature for outdoor activities: A USB port in the stand grants the functionality of the microscope independent from the mains by a power bank.Close to your Individual Applications Panthera E2 microscopes can be upgraded for different contrast methods: Phase contrast for unstained samples from botany, zoology, and medicine is a classic, Darkfield for impressive images from protozoa is on the verge of extinction, POL contrast for birefringent structures is an underrated method for biology and medicine. For plastics and foils from the industrial lab, this method is standard.Click Here to View Product Video INCLUDED: The Motic Panthera E2 Binocular Compound Microscope includes: - 4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm) Objectives< - Dust Cover - Power Cord - Allen Key - Immersion Oil (5ml) - 5 Year Manufacturer's Warranty

Motic Panthera Cloud Features - Built-in Smart CAM digital head 8.0 MP - ImagingOnDevice system (Pan (more)thera App embeded software) - HDMI (1080i - FullHD) - USB 2.0 for external devices (2x) - RJ-45 (1 GB LAN) - Wi-Fi - Unique Cloud Storage Function - 10 GB Internal Memory - Sleep mode (auto on-off function) The Panthera Cloud has been designed to streamline workflow! The Smart CAM digital head and its ImagingOnDevice System allows you to instantly capture what you are viewing with the tip of your finger. Work in FullHD through the HDMI port directly on a screen with the help of a mouse, or work with your Tablet and the Panthera App. Thanks to the QRlink system, you can send your live image to your tablet or smartphone by simply scanning the QR-code on the top of the Tubehead cover. The LAN port offers users the option to work through DigiClass or remote sharing.INCLUDED: The Motic Panthera Cloud includes: - 4X/0.1 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 100X/1.25/S (WD 0.16mm) Objective - Widefield UC-WF10X/22mm with Diopter Adjustment - Dust Cover - Power Cord - Allen Key - Immersion Oil (5mL) - Blue Filter - Halogen Bulb - LED Module - HDMI Cable - Wi-Fi USB Dongle - Calibration Slide - Operator's Guide Motic Panthera Cloud SpecificationsObservation tubeBinocular head, Siedentopf type 25°, 360° swivelingOptical systemColour Corrected Infinity Optical System (CCIS®)Sensor TypeCMOSSensor Size1/2.5"Capture Resolution Info8MPCondenserFocusable and centerable Abbe condenser N.A. 0.90/1.25 with slot for contrast slidersDarkfieldOptional slider/turretData transferWi-Fi, HDMI, EthernetDiaphragmIris diaphragmDiopter adjustmentOn both eyepieces, +/- 4 diopterEyepiecesWidefield UC-WF10X/22mm with diopter adjustmentFilter holderOn top of the illuminator with fixing capFine focus precision2µmFocus mechanismCoaxial coarse and fine focusing system with tension adjustmentFocusing stroke25mmIllumination featuresMotic LightTracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicatorIllumination interchangeabilityHalogen/LED and LED color temperature interchangeabilityInclination25° inclined, 360° swivelingInterpupillary distance48-75mmLive display mode through Ethernet1280x720, 1920x1080 pixels (Full HD)Live display mode through HDMI1920x1080 (Full HD)Live display mode through Wi-Fi1920x1080 (Full HD)NosepieceReversed quintuple, codedObjective classificationCCIS® UC Plan Achromatic (Pb free), DINObjective mounting threadW 4/5"x1/36" (RMS standard)Objectives4X/0.10 (WD 30.5mm), 10X/0.25 (WD 17.4mm), 40X/0.65/S (WD 0.6mm), 100X/1.25/S-Oil (WD 0.16mm)Other featuresUSB 2.0 for external Devices (x2)Phase contrastOptional slider/turretPolarizationOptional add-onStageCompact mechanical stage with built-in low position rackless coaxial stage control and sample holderStage size185x145mmStand typeUprightStandard contrast techniqueBrightfieldTransmitted illuminationKoehler LED 3W & Quartz halogen 6V/30W with intensity controlTravel range X&Y75x50mmUpper limit stopUpper limit stop preset but adjustableSoftwareImagingOnDevice System (Panthera App embedded)TransformerInternalPower supply110-240V (CE)Dimensions LxWxH282x210x394mmWeight Net8.8kgDownloadsTechnical Specification Download Operator's Manual Download Request a Formal Quote

Motic Panthera C2 Trinocular Compound Microscope w/ Moticam BMH4000X Microscope Camera Objectives UC (more) Plan Achromatic (Pb free) 4X, 10X, 40X, 100X Fine Focus Precision Color Corrected Infinity Optical System (CCIS®) Transmitted Illumination (FPS) Koehler LED 3W and Quartz Halogen 6V/30W Features - Mechanical stage with built-in low position rackless coaxial stage control and sample holder for smoother x/y movement - Includes light memory, sleep mode (auto on-off), and nosepiece LED light intensity indicator - Coaxial coarse and fine focusing with 2μm precision and adjustable upper limit stop - Compatible with separate accessories for phase contrast, polarization and dark field to ensure compatibility with a variety of applications - 11.6" LCD screen with native 1920x1080 pixels for real-time viewing - 8MP capture resolution with outputs via HDMI, USB, and WIFI

Motic Panthera C2 Trinocular Compound Microscope Your Personal Lab Solution If it is about stained s (more)ections with cover glass protection, about native smears, fine needle biopsies, blood smears that wanted to be treated with or without cover glass: Panthera C2 with its selection of specified optics is your solution. The new Ultra Contrast (UC) objectives with additional glass elements to reach a 22mm Field of View, working perfectly together with neutral eyepieces (thanks to CCIS a fully corrected intermediate image for digital access is granted) guarantee the best performance in terms of color fidelity and contrast. Microscope hardware, illumination, handling: Simply convincing. Functionality is Always Related to the Sample Bright Field is the standard, Phase Contrast, Pol Contrast, objectives with/without cover glass correction, optional LED Fluorescence modules with variable filter combinations: Within Panthera C2 module kit everything is possible for your lab, for your application. The microscope hardware suits to almost any physics of the user, no need to talk about interpupillary distance, viewing angle, or seating position. New UC Optics for New Insights No doubt. The new Plan UC Achromatic objectives, from 2X to 100X magnification range, show significantly improved image contrast. For your individual application: The new 100X/0.8 "Dry objective" is especially favorable in environments where the time-consuming immersion procedure may be considered too complicated. Test it, you are easily convinced. A Field of View of 22mm indicates one more step closer to the High-End level of overview: Your horizon will be enlarged. Flexibility in Illumination The Panthera C2 offers flexibility in light sources. A 30W Halogen bulb can be replaced by a 3W LED of different color temperatures. A Full-Koehler setup for transmitted light is self-evident. Seamless Integration into your Workflow For maximum use of accessories, the Panthera C2 is deeply integrated into Motic's Upright microscope system. The universal turret condenser with all Phase rings and a Darkfield stop, the combination of Polarizer/Analyzer for birefringent samples, LED Fluorescence modules for Epi-Fluorescence: design your workplace according to your demands. We will help you. Click Here to View Product Video INCLUDED: The Motic Panthera C2 Trinocular Compound Microscope includes: - Widefield UC-WF10x/20 Eye Piece - 4X/0.10 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 100X/1.25/S-Oil (WD 0.16mm) Objective - Dust Cover - Power Cord - Allen Key - Immersion Oil (5ml) - Blue Filter - Halogen Bulb - LED Module - 5 Year Manufacturer's Warranty

Motic Panthera C2 Trinocular 50:50 Simple Phase Compound Microscope Package Your Personal Lab Soluti (more)on If it is about stained sections with cover glass protection, about native smears, fine needle biopsies, blood smears that wanted to be treated with or without cover glass: Panthera C2 with its selection of specified optics is your solution. The new Ultra Contrast (UC) objectives with additional glass elements to reach a 22mm Field of View, working perfectly together with neutral eyepieces (thanks to CCIS a fully corrected intermediate image for digital access is granted) guarantee the best performance in terms of color fidelity and contrast. Microscope hardware, illumination, handling: Simply convincing.Functionality is Always Related to the Sample Bright Field is the standard, Phase Contrast, Pol Contrast, objectives with/without cover glass correction, optional LED Fluorescence modules with variable filter combinations: Within Panthera C2 module kit everything is possible for your lab, for your application. The microscope hardware suits to almost any physics of the user, no need to talk about interpupillary distance, viewing angle, or seating position.New UC Optics for New Insights No doubt. The new Plan UC Achromatic objectives, from 2X to 100X magnification range, show significantly improved image contrast. For your individual application: The new 100X/0.8 "Dry objective" is especially favorable in environments where the time-consuming immersion procedure may be considered too complicated. Test it, you are easily convinced. A Field of View of 22mm indicates one more step closer to the High-End level of overview: Your horizon will be enlarged.Flexibility in Illumination The Panthera C2 offers flexibility in light sources. A 30W Halogen bulb can be replaced by a 3W LED of different color temperatures. A Full-Koehler setup for transmitted light is self-evident.Seamless Integration into your Workflow For maximum use of accessories, the Panthera C2 is deeply integrated into Motic's Upright microscope system. The universal turret condenser with all Phase rings and a Darkfield stop, the combination of Polarizer/Analyzer for birefringent samples, LED Fluorescence modules for Epi-Fluorescence: design your workplace according to your demands. We will help you.Click Here to View Product Video INCLUDED: The Motic Panthera C2 Trinocular 50:50 Simple Phase Compound Microscope Package includes: - Widefield UC-WF10x/20 Eye Piece - 4X/0.10 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 100X/1.25/S-Oil (WD 0.16mm) Objective - Dust Cover - Power Cord - Allen Key - Immersion Oil (5ml) - Blue Filter - Halogen Bulb - LED Module - 5 Year Manufacturer's Warranty

Motic Panthera C2 Trinocular 50:50 Phase Compound Microscope Package Your Personal Lab Solution If i (more)t is about stained sections with cover glass protection, about native smears, fine needle biopsies, blood smears that wanted to be treated with or without cover glass: Panthera C2 with its selection of specified optics is your solution. The new Ultra Contrast (UC) objectives with additional glass elements to reach a 22mm Field of View, working perfectly together with neutral eyepieces (thanks to CCIS a fully corrected intermediate image for digital access is granted) guarantee the best performance in terms of color fidelity and contrast. Microscope hardware, illumination, handling: Simply convincing.Functionality is Always Related to the Sample Bright Field is the standard, Phase Contrast, Pol Contrast, objectives with/without cover glass correction, optional LED Fluorescence modules with variable filter combinations: Within Panthera C2 module kit everything is possible for your lab, for your application. The microscope hardware suits to almost any physics of the user, no need to talk about interpupillary distance, viewing angle, or seating position.New UC Optics for New Insights No doubt. The new Plan UC Achromatic objectives, from 2X to 100X magnification range, show significantly improved image contrast. For your individual application: The new 100X/0.8 "Dry objective" is especially favorable in environments where the time-consuming immersion procedure may be considered too complicated. Test it, you are easily convinced. A Field of View of 22mm indicates one more step closer to the High-End level of overview: Your horizon will be enlarged.Flexibility in Illumination The Panthera C2 offers flexibility in light sources. A 30W Halogen bulb can be replaced by a 3W LED of different color temperatures. A Full-Koehler setup for transmitted light is self-evident.Seamless Integration into your Workflow For maximum use of accessories, the Panthera C2 is deeply integrated into Motic's Upright microscope system. The universal turret condenser with all Phase rings and a Darkfield stop, the combination of Polarizer/Analyzer for birefringent samples, LED Fluorescence modules for Epi-Fluorescence: design your workplace according to your demands. We will help you.Click Here to View Product Video INCLUDED: The Motic Panthera C2 Trinocular 50:50 Phase Compound Microscope Package includes: - Widefield UC-WF10x/20 Eye Piece - 4X/0.10 (WD 30.5mm) Objective - 10X/0.25 (WD 17.4mm) Objective - 40X/0.65/S (WD 0.6mm) Objective - 100X/1.25/S-Oil (WD 0.16mm) Objective - Dust Cover - Power Cord - Allen Key - Immersion Oil (5ml) - Blue Filter - Halogen Bulb - LED Module - 5 Year Manufacturer's Warranty
