Grass Technologies PS33-Plus Photic Stimulator
Refurbished Photic Stimulator. 6 months warranty (Lamp not included). Scope of delivery: - Photic St (more)imulator - Photic Arm - Roll Stand - Table clamp - User Manual Features: - Consistent Flash Characteristics: Accurate stimulus parameters - Wide Intensity Range: Extended appplications - Wide Flash Rates: Provides variable stimulus rates - Synchromous inputs/Outputs: Active High/Low TTL inputs/outputs simplify interfacing Technical data: - Flash Mode: Single or repetitive flashes - Flash Intensity: 5 steps with ratios of 1,2,4,8,16. 22 lumen sec/ft2 at intensity 16 maximum energy (1.44 joules). - Flash Rate: 1 to 60 per second, ‡5% accuracy - Flash Duration: 10 uS - Flash Tube: Xenon - Monitors Front panel monitor light, flashes only when flash lamp lights. Two output pulses suitable for low frequency display devices. - Synchronous Inputs: External control of flash rate via TTL level sync pulse. External control of intensity via TTL logic levels. - Synchronous Output: TTL level, 20 us pulse for high frequency devices, signal averager, oscilloscope, etc. - Power: 115 or 230 VAC, 50/60 Hz, 150 VA maximum Physical Size: - 9.75" W x 5.375" H x 8.1875" D (24.8cm x 13.7cm x 20.8cm) - Weight: 12 lbs. (5.4kg) - Flash Lamp: 5.375" diameter (13.7cm), 5" depth (12.7cm) - Handle: 4" long (10.2cm), 1.25" diameter (3.2cm) - Cable Length: 12-foot (3.6m) Environmental Specifications: - Operations: 0 to 40°C, 10 to 90% RH - Non-condensing - Storage: -20 to 60°C - Pressure: 800 to 1,040 hPa Regulatory: - 115VAC: Certified to CAN/CSA C22.2 - No. 1010.1. Conforms to UL3101-1. - 230VAC: CE Mark to IEC-1010-1.G
€1,150.00 ex VAT
Germany
medical pumps, neurology or eeg or emg
