Deep Freezer U 701 B Medical Systems
- Storage capacity (cryobox): 575 - Storage capacity (2ml vials): 57,500 - Bags of plasma: 500 - Pre (more)set temperature: -82°C - Cold/hot temperature alarm limit: -87°C / -77°C Torage capacity (cryobox): 575 Storage capacity (2ml vials): 57,500 Preset temperature: -82°C Adjustable temperature in 0.1°C increments: -86°C to -40°C Cold / hot temperature alarm limit: -87°C / -77°C Withstand over time (from +5°C to +10°C): 1 hour and 18 minutes (from -80°C to -60°C) Climate class (ambient temperature range): +10°C to +43°C Defrost: Manual Type of refrigerant: R290 / R170 External dimensions W x D x H (mm): 992 x 1039 x 1988 Internal dimensions W x D x H (mm): 740 x 713 x 1370 Heat emission (Kcal / h): 426 Compressor running time (%): 50 Ultra low freezers, or deep freezers, are devices intended for storing blood and plasma components, human cells, tissues and other laboratory samples at temperatures as low as -86°C. "U" models reflect the highest and most uncompromising requirements with state-of-the-art technology. The cooling system is optimally designed to allow very low consumption and little heat production. Medical device in accordance with MDR (EU) 2017/745, Class IIa directive THE CONTROL PANEL Extremely easy control of all parameters: - 7" color touchscreen display at eye level - Locking mechanism protected by card reader and password - Audio-visual alarm system with remote transmission in case of unexpected temperature changes and power failure - B Universal connected software for remote monitoring, recording and long-term archiving - USB port for easy data export - Alarm memory and history on the monitor with indication of the type - Ethernet interface for data management, via B software, to a PC - Backup battery (duration of at least 48 hours) - Optionally, the possibility of passing data to a db through the network. - Monitor indication of: time, input Volt, login status (user level) SAFETY AND TRANQUILITY Accurate temperature and 24-hour storage: The safety standards developed by B Medical Systems define unique technical features, ensuring the safe storage of preparations and setting the highest safety standards for the user. - Controlled air cooling system for a uniform and stable temperature distribution - Automatic defrost while maintaining a stable temperature - Rapid temperature recovery even after numerous door openings - Safety thermostat to prevent freezing - Long range in case of power failure - Audible and visual alarms with remote alert via SMS or email - °B Connected universal software for remote archive, report (according to FDA 21 CFR Part 1) More than certified tools - European regulation on medical devices: MDR (EU) 2017/745, Class IIa (models: 220-240 V - 50/60 Hz and 230 V - 50 Hz) - EMC Directive: 2014/30 / EU (models: 220-240 V - 50/60 Hz and 230 V - 50 Hz) - Low voltage directive: 2014/35 / UE (models: 220-240 V - 50/60 Hz and 230 V - 50 Hz) - FDA-Medical Device Regulations: 21CFR Part 864.9700, Class II (models: 115-127 V - 60 Hz and 220 V - 60 Hz) - CCSAus certified: Yes (models: 115-127V - 60Hz and 220V - 60Hz) - GMP - Clean room classification: ISO class 6 / EC GMP B ISO class 5 / EC GMP A The 'PREMIUM' line provides you with the most advanced tool you can find. The maximum of technology that you will be able to receive in your laboratory or research center, as well as for the pharmacy and hospital. These models will not serve you best today, but for decades they will remain advanced and modern tools. Tens of years of experience in the design, construction and use, in all conditions, have allowed B Medical Systems to be able to create some of the best instruments on the market. By purchasing this instrument manufactured in Luxembourg, you will save energy each day on the time used for your applications, without risking losing your precious samples. Optimized design for energy efficiency - Often polypropylene insulation, without corrosion and with perfect thermal insulation, 100% recyclable - Minimized cold air loss - Ecological refrigerant R290 - Ecological footprint reduced to a minimum Improved structure and built for everlasting durability - Anti-corrosion structure guaranteed for life - Constructed by rotational molding, in high quality polypropylene for better insulation and strength - No sharp edges for easier maintenance and cleaning - Ergonomic design for safe use at all times - Double internal door RTMD | DATI SEMPRE ONLINE WANT EVEN MORE CONTROL? As an option, you can connect your B-Medical-Systems devices to the °B CONNECTED online software. Through this software, via PC or smartphone, you will be able to have a complete overview and management of all your B-Medical-Systems instruments. - Real-time data: temperature, set point, component status, compressor data - All recorded data: alarms, temperatures, exceptional events that occurred during refrigeration - Display and settings of all parameters - Graphic display of temperature curves - Easy graphics to monitor all the devices you own - Incredibly interactive - Customizable data printing - Easy setting of specific alarms, via email or SMS alerts - Data export for third party software - Important advantage in terms of costs compared to a traditional circular paper recorder FEATURES OF VALUE EFFICIENCY - High efficiency natural gas compliant with US SNAP and F-GAS - High performance and low consumption compressor - One-piece printed polypropylene chassis guaranteed for life against corrosion and fully recyclable - Superior insulation - Ergonomic handle with special valve to open the instrument with minimum effort. CONVENIENCE AND COMFORT - Easy access to parameters via 7 'touch-screen - Card reader for reserved entrance or with password - Data export via USB or card reader - Anti-bacterial coating for better cleaning - Low noise - Low heat emission - Modular interior equipment - Easy access to the internal drawers-trays - Highest quality stainless steel - Minimal ice formation to allow easy defrosting MULTIFUNCTION ELECTRONICS - Maximum reliability - Audio-visual alarm system with remote transmission in case of unexpected temperature changes and power failure - Compatible with universal '° B Software' connected for remote monitoring, recording and long-term archiving - Electronic temperature recorder - USB port for easy export of recorded data - Data backup battery Versatile and modular - Full compatibility of internal modules and rails - no need to buy new racks, you can keep previously used racks in different U models - Cryo racks optional ... and much more. Download the data sheet for the data of each model, the standard and optional accessories.
Italy
medical equipment other, climate control equipment other
