Vacuum equipment

Nominal pumping speed: 71 m³/h Pumping speed (at 2 mbar): ≥ 50 m³/h Ultimate partial pressure withou (more)t gas ballast: ≤ 0,2 mbar Ultimate total pressure with small gas ballast: ≤ 1,0 mbar Water vapour tolerance (with small gas ballast): 10 mbar Water vapour tolerable load (with small gas ballast): 0.41 kg/h Noise level: ≤ 60 dB (A) Leak rate: <1 x 10⁻³ mbar

Pumping speed: 1.6 m3/h No-load speed: 0 – 2200 rpm Ultimate vacuum: 2 mbar Ultimate vacuum with gas (more) ballast: 4 mbar Max permitted outlet pressure: 1.1 bar

Pure transferring and evacuation Highly compatible with vapours and condensation Chemically-resistan (more)t Therefore suitable for highly aggressive or corrosive gases and vapours Maintenance-free Environmentally friendly Gastight, leakage rate approx. 6 x 10-3 mbar x l/s, not tested in serial production. Delivery:  60 l/min Ultimate vacuum:  4 mbar Operating pressure: 1 bar Connectors for tube: ID 12 mm Permissible gas and ambient temperature: +5…+40 °C Motor protection: IP 54 Weight 14.8 kg Dimensions (d x h x w): 331mm x 279mm x 291mm 230V / 50HZ / 220W

Displacement 50Hz/60Hz: 3.7/4.5 m³/h Speed 50Hz/60Hz: 3.3/3.9 m³/h Ultimate pressure: 2.0 x 10⁻³ mba (more)r Ultimate pressure gas ballast: 3.0 x 10⁻² mbar Max inlet pressure for water vapour: 80 mbar Max water vapour pumping rate: 60 g/h Max allowed outlet pressure: 0.2 bar Max allowed inlet and gas ballast pressure: 0.5 bar Nominal rotation speed 50/60Hz: 1500/1800rpm Weight (without oil): 25 kg Oil capacity min/max: 0.42/0.7 L Inlet flange: NW25 Exhaust flange: NW25 Noise level: 48 dB(A)

Pumping speed: 1.7 m³/h Ultimate vacuum: 9 mbar Ultimate vacuum with gas ballast: 15 mbar Max permis (more)sible outlet pressure: 2 bar Max pressure difference inlet and outlet: 1.1 bar Permissible relative atmospheric moisture (no condensation): 30 to 85%

Capacity (max.): 5.5 l/min Final vacuum (max.): 160 mbar Operating pressure (max.): 2.4 bar Permissi (more)ble medium temperature: 5 – 40 °C Permissible ambient temperature: 5 – 40 °C Weight: 1.9kg

Standard vacuum pump for microplate washers.

Double-headed, chemically resistant, dry-running diaphragm pumps for a wide range of laboratory appl (more)ications. For conveying and evacuating, without affecting the media. • 100% oil-free transfer, so that the media cannot be contaminated during pumping, evacuating or compressing • Very suitable for vapours and condensates • Suitable for slightly aggressive and corrosive gases and vapours • Maintenance-free, environmentally friendly • Flow rate: 34 L/min (at atmospheric pressure) • Working pressure: 1.0 bar • Final pressure (abs): 8 mbar Dimensions (DxHxW): 341 x 226 x 166 mm Weight: 12 kg

Two-headed, chemically resistant, dry-running diaphragm pumps for a wide range of laboratory applica (more)tions. For transporting and evacuating without affecting the media. • 100% oil-free transfer so media cannot be contaminated during pumping, evacuating or compressing • Very suitable for vapors and condensates • Suitable for aggressive and corrosive gases and vapours • Maintenance-free, environmentally friendly • Flow rate: 20 L/min (at atmospheric pressure) • Working pressure: 1.0 bar • Final pressure (abs): 8 mbar • Max. pumping speed 1.2 m3/h

Deliver precise vacuum and offer widely diverse control functions for a huge range of applications i (more)n the laboratory. The intuitive user guidance on the hand terminal ensures ease of operation; the process parameters can be entered over a touchscreen and a rotation knob. Ajustment capabilities: Units of measurement The operating language The operating mode Parameters, such as the setpoint pressure or suction capacity of the system direct over rotation knob. Depending on the selected operating mode, the graphic display of the hand terminal then indicates the respective process variables. The user can intervene in the ongoing process at any time with the hand terminal and its integrated touchscreen and rotating knob. The hand terminal can be located via vacuum pump system (paging); the hand terminal will answer with a signal tone. Four operating modes: Evacuate – The vacuum pump system evacuates a vacuum chamber with adjustable pump capacity. Pressure control – The vacuum pump system controls the system pressure to the set value (constant pressure). Automatic – The vacuum pump system automatically finds the vapour pressure of the sample and adjusts the process pressure accordingly. Individual pressure function – The vacuum pump system controls the process according to a user-defined pressure curve. The setpoint pressure and the opening and closing of the coolant valve (accessory) on the high-performance condenser can be easily entered for a range of set times. A repeat function allows successive repetitions of the programmed pressure curve.At any time during an active process, you can switch to manual process control. Functions for Evacuate and Pressure control will be available simultaneously. Flow rate (at atm. pressure): 1.26 m³/h Flow rate (at atm. pressure): 21 l/min Ultimate vacuum (< 5.0 with gas ballast valve in use): 2.0 mbar abs. Operating pressure (max.): 0.5 bar (rel.) Dimensions (WxHxD): 366 x 423 x 294 mm Weight: 15 kg

Capacity: 5.5 l/min Final vacuum: 160 mbar Operating pressure: 2.4 bar Weight: 1.9kg

Attainable Vacuum: -333 mbar Free Air Displacement: 40 l/min Life Expectancy: 10.000 h Inlet: 15mm O (more).D. hose nipple Outlet: ISO Rc 1/4 female threaded Duty Cycle: Continuous Coil Insulation Class: E or its equivalent (JETL) and B for UL-1450 Dimensions (w x d x h): 175mm x 118mm x 138mm Gross Weight:   3.0 kg 230V / 50-60Hz / 60W

The Pfeiffer Vacuum TPH062 has a wear free permanent magnetic bearing at the high vacuum side and an (more) oil lubricated ceramic bearing at the backing side. Applications: Freeze drying – packaging industry Degassing, casting, dry vacuum smelting (super-pure metals) Incandescent lamp manufacturing Electronic tubes Thin film deposition Space simulation Cryogenic research Electron microscopy Nuclear physics, Plasma physics, High energy physics Particle accelerators – Storage rings Inlet Flange: DN 63 ISO-KF Outlet Flange: DN 16 ISO-KF Final pressure: < 1 x 10-11 mbar Flow Rate (N2): 56 l/s Weight: 3.5 kg

The Pfeiffer Vacuum TMH 064 Turbo Pump is designed for a wide range of applications in the research  (more)industry. Features: The pump of explosive gases or corrosive gases. Can be operating where there is a danger of explosion The pumping of gases and vapours which attack the materials of the pumps. Operations with improper gas modes High vacuum flange: ISO-K High vacuum seal: Viton Final pressure: < 1 x 10-8 mbar Flow Rate (N2): 30 l/s Weight: 3.5 kg
