Vacuum pumps

Laboport SD N 860.3 FT.40.18 is a two-stage pump with an integrated “self-drying” system for automat (more)ic condensate drain. The “SD” series is widely used in laboratories, especially when the vapors are humid and a clean and ecological vacuum is required. Typical applications are: vacuum ovens (for drying chemicals, drying biological samples, heat treatments), autoclaves for sterilizing instruments, containers, filters and textiles. Thanks to the use of anti-corrosion materials, it is possible to vacuum even corrosive products. The heart of the pump is the diaphragm with differentiated structure in PTFE, optimized to guarantee high performance with reduced dimensions and at the same time, long life even in heavy applications. When the humid gases are sucked in, it can happen that condensation forms in the pump head: consequently the performance decreases, considerably increasing the emptying time. To eliminate condensation, the 'drying system' then opens a solenoid valve that allows ambient air to enter the heads. Once the condensation has been eliminated, the solenoid valve closes and the pump sucks from the stove in full capacity. Over time, condensation could form again and then the cycle is repeated. The time interval between one cycle and the next can be adjusted as desired, as well as the duration of the air injection. Technical features Flow rate (max.) 60 l / min Final vacuum (max.) 4 mbar (abs.) Pressure (max.) 1 bar (rel.) Fluid temperature allowed at 5-40°C FFPM valve material PTFE coated diaphragm material Pump head material PTFE Applications Rotary evaporation Centrifugal concentration Distillation Vacuum oven Qualitative characteristics Clean operation, 100% oil-free Corrosion resistant PTFE / FFPM flow path Ideal for extremely aggressive / corrosive gases and vapors Compact, silent and reliable The self-drying system removes condensation without altering the vacuum level Maintenance free Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Technical features Flow rate (max.) 21 l / min Ultimate vacuum (max.) 2 mbar (abs.) Operating pressu (more)re (max.) 0.5 bar (rel.) Permitted fluid temperature 5-40°C FFPM valve material Membrane material PTFE coating PPS pump head material Applications Rotary evaporators Distillation Centrifugal concentrators Aspiration of fluids Qualitative characteristics Clean operation, 100% oil free High suction speed, especially in the low vacuum range Adjustable speed control Exceptionally quiet Corrosion resistant Maintenance free INCLUDED: The KNF N920KT.29.18G diaphragm pump includes: - Power cord - Operator's guide - Manufacturer's documentation - 1 year manufacturer's warranty Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Technical features Flow rate (max.) 5.5 l / min Final vacuum (max.) 160 mbar (abs.) Pressure (max.)  (more)2.4 bar (rel.) Permissible fluid temperature 5-40°C Valve material: FFPM Diaphragm material PTFE coated Pump head material: PPS Applications Filtration Aspiration of liquids Solid phase extraction Qualitative characteristics Clean operation, 100% oil-free Corrosion resistant Compact, silent and reliable Small footprint Maintenance free Download the data sheet for further information and accessories NOT SURE WHICH VACUUM PUMPS YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Technical features Flow rate (max.) 34 l / min Final vacuum (max.) 2 mbar (abs.) Pressure (max.) 1 b (more)ar (rel.) Permissible fluid temperature 5-40°C Valve material: FFPM Diaphragm material PTFE coated Pump head material: PTFE Applications Drying Rotary evaporation Centrifugal concentration Distillation Vacuum oven Qualitative characteristics Clean operation, 100% oil-free Chemically resistant PTFE / FFPM flow path Ideal for extremely aggressive / corrosive gases and vapors Compact, silent and reliable Maintenance free Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Labor port N 840 G KNF Diaphragm vacuum pump resistant to chemical and corrosive liquids, compact an (more)d oil-free. The pump capacity is manually adjustable with a simple knob. Laboport is equipped with gas ballast, PTFE/TFM heads, PTFE lined diaphragms and FFPM valves. It is suitable for a wide range of laboratory applications, including extremely aggressive/corrosive gases and vapours. - Flow rate (max.): 34 l/min - Final vacuum (max.): 6 mbar (abs.) - Adjustable speed control - ATEX compliant only for internal atmosphere (Ex) II 2/-G IIB+H2 T3 - Ideal for extremely aggressive/corrosive gases and vapours - Clean operation, 100% oil-free Technical features - Flow rate (max.): 34 l/min - Final vacuum (max.): 6 mbar (abs.) - Pressure (max.): 0.1 bar (rel.) - Permissible fluid temperature between 5 and 40°C - Valve material: FFPM - Diaphragm material: PTFE coated - Pump head material: PTFE Applications - Centrifugal concentration - Degassing - Drying - Distillation - Drying of the gel - Rotary evaporation - Solid phase extraction Qualitative characteristics - Adjustable speed control - ATEX compliant only for internal atmosphere (Ex) II 2 / -G IIB + H2 T3 - Ideal for extremely aggressive / corrosive gases and vapors - Chemically resistant PTFE / FFPM flow path - Clean operation, 100% oil-free - Compact, silent and reliable - Maintenance free - Small footprint to optimize workspace Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMPS YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION Presentations of the Laboport line directly from the specialists who created it. English subtitles. Presentation of the new Laborports and SMART KNF control.

Technical features Flow rate (max.) 34 l / min Final vacuum (max.) 8 mbar (abs.) Pressure (max.) 1 b (more)ar (rel.) Permissible fluid temperature 5-40°C Valve material: FFPM Diaphragm material PTFE coated Pump head material: PTFE Applications Rotary evaporation Degassing Drying of the gel Vacuum oven Qualitative characteristics Clean operation, 100% oil-free Chemically resistant PTFE / FFPM flow path Ideal for extremely aggressive / corrosive gases and vapors Compact, silent and reliable Maintenance free ATEX compliant only for internal atmosphere (Ex) II 2 / -G IIB + H2 T3 Download the data sheet for further information and accessories NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Labor port N 96 KNF Compact and portable diaphragm vacuum pump, resistant to chemicals and corrosive (more)s, oil-free. The pump capacity is manually adjustable with a simple knob. Laboport is equipped with gas ballast, PTFE/TFM heads, PTFE lined diaphragms and FFPM valves. It is suitable for a wide range of laboratory applications, including extremely aggressive/corrosive gases and vapours. Technical features - Flow rate (max.) 7 l / min - Final vacuum (max.) 130 mbar (abs.) - Pressure (max.) 2.5 bar (rel.) - Permissible fluid temperature 5-40 °C - Valve material: FKM - Diaphragm material: PTFE coated - Pump head material: PPS Applications - Filtration - Fluid suction - Solid phase extraction Qualitative characteristics - 100% oil-free transfer: transfer, evacuation and compression of gases in a clean and safe way - Extremely small footprint - The PTFE coated diaphragm is ideal for aggressive agents / gases and corrosive vapors - Integrated control of the rotation speed - Ecological Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMPS YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION Presentations of the Laboport line directly from the specialists who created it. English subtitles. Presentation of the new Laborports and SMART KNF control.

Technical features Flow rate (max.) 6 l / min Final vacuum (max.) 100 mbar (abs.) Pressure (max.) 2. (more)4 bar (rel.) Permissible fluid temperature 5-40 ° C Valve material: FFPM Diaphragm material PTFE coated Pump head material: PPS Applications Filtration Aspiration of liquids Solid phase extraction Qualitative characteristics Clean operation, 100% oil-free Corrosion resistant Compact, silent and reliable Ecological Maintenance free Download the data sheet for further information and accessories NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

The N 840.3 FT.40.18 is a two-stage pump with an integrated “self-drying” system for automatic conde (more)nsate drain. The “SD” series is widely used in laboratories, especially when the vapors are humid and a clean and ecological vacuum is required. Typical applications are: vacuum ovens (for drying chemicals, drying biological samples, heat treatments), autoclaves for sterilizing instruments, containers, filters and textiles. Thanks to the use of anti-corrosion materials, it is possible to vacuum even corrosive products. The heart of the pump is the diaphragm with differentiated structure in PTFE, optimized to guarantee high performance with reduced dimensions and at the same time, long life even in heavy applications. When the humid gases are sucked in, it can happen that condensation forms in the pump head: consequently the performance decreases, considerably increasing the emptying time. To eliminate condensation, the 'drying system' then opens a solenoid valve that allows ambient air to enter the heads. Once the condensation has been eliminated, the solenoid valve closes and the pump sucks from the stove in full capacity. Over time, condensation could form again and then the cycle is repeated. The time interval between one cycle and the next can be adjusted as desired, as well as the duration of the air injection. Technical features Flow Rate (max.) 34 l / min Ultimate Vacuum (max.) 10 mbar (abs.) Pressure (max.) 1 bar (rel.) Permissible Medium Temperature 5-40°C Valve Material FFPM Diaphragm Material PTFE coated Pump Head Material PTFE Applications Rotary evaporation Vacuum oven Qualitative characteristics Clean operation, 100% oil-free Corrosion resistant PTFE / FFPM flow path Ideal for extremely aggressive / corrosive gases and vapors Compact, silent and reliable The self-drying system removes condensation without altering the vacuum level Maintenance free Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMPS YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Edwards RV3 Vacuum PumpFeatures - The RV is a truly versatile pump for operation throughout for your (more) operations, perfect for wet applications, dusty applications and clean dry applications. - The RV series of pumps has the highest vapour handling capacity of any rotary vane pump. This is ideally suited for your wet pumping applications such as freeze drying, extraction, filtration and gel drying. - The best-in-class anti-suck back protection prevents dust or oil mist from entering your system. The fast-acting automatic inlet valve acts within 0.4 seconds. - The universal motor in the pump covers the widest possible voltage and frequency range from a single motor. - You can service and replace parts without dismantling the pump mechanism. All parts self-align, eliminating the need for special assembly. Pump valve has "controlled" opening on power startup so that the system vacuum will never see a pressure surge on startup The RV uses a high-quality "universal" motor to cover the widest possible voltage and frequency range. A one-size Allen key is used to dismantle all parts of the RV pump. All rotor and stator parts are completely interchangeable The RV series of small oil sealed rotary vane pumps deliver excellent ultimate vacuum pressure, high pumping speeds and superior vapour handling capabilities with quiet operation. With over 300,000 units produced, these pumps offer proven performance that sets the industry standard for R&D and scientific pumping applications. All RV pumps are approved to UL and CSA standards by an external test house and feature our unique mode selector switch, meaning one model is suitable for both high vacuum or high throughput applications. Click Here to View Product Video INCLUDED: The Edwards RV3 Rotary Vane Vacuum Pump includes: - 1 Liter of Edwards Ultragrade 19 Oil - Power Cord - Manufacturer's Documentation - Operator's Manual - 1 Year Manufacturer's Warranty

Deliver precise vacuum and offer widely diverse control functions for a huge range of applications i (more)n the laboratory. The intuitive user guidance on the hand terminal ensures ease of operation; the process parameters can be entered over a touchscreen and a rotation knob. Ajustment capabilities: Units of measurement The operating language The operating mode Parameters, such as the setpoint pressure or suction capacity of the system direct over rotation knob. Depending on the selected operating mode, the graphic display of the hand terminal then indicates the respective process variables. The user can intervene in the ongoing process at any time with the hand terminal and its integrated touchscreen and rotating knob. The hand terminal can be located via vacuum pump system (paging); the hand terminal will answer with a signal tone. Four operating modes: Evacuate – The vacuum pump system evacuates a vacuum chamber with adjustable pump capacity. Pressure control – The vacuum pump system controls the system pressure to the set value (constant pressure). Automatic – The vacuum pump system automatically finds the vapour pressure of the sample and adjusts the process pressure accordingly. Individual pressure function – The vacuum pump system controls the process according to a user-defined pressure curve. The setpoint pressure and the opening and closing of the coolant valve (accessory) on the high-performance condenser can be easily entered for a range of set times. A repeat function allows successive repetitions of the programmed pressure curve.At any time during an active process, you can switch to manual process control. Functions for Evacuate and Pressure control will be available simultaneously. Flow rate (at atm. pressure): 1.26 m³/h Flow rate (at atm. pressure): 21 l/min Ultimate vacuum (< 5.0 with gas ballast valve in use): 2.0 mbar abs. Operating pressure (max.): 0.5 bar (rel.) Dimensions (WxHxD): 366 x 423 x 294 mm Weight: 15 kg

BUCHI Syncore Q-101 platform + KNF vacuum pump + V-850 vacuum controller Model: Büchi Analyst Q-101  (more)Vibration frequency: 0 - 300 min⁻¹ Heating power: 1500 W Temperature Range: Up to 100°C W×D: 480×487 mm Included: Rack R-12 Polyvap (120ml) A condensation unit and bottle A KNF vacuum pump A Buchi V-850 vacuum controller Traces of rust in the bottom of the heating element Equipment tested

Portable suction system, vacuum pump ROCKER BIOVAC 240 New equipment (never used) Max. vacuum : 720  (more)mmHg Max. flow rate : 38 l//min Hose barb : 3/16 inch Pump type: Piston Dimension (LxWxH) : 53x24x35cm Suction bottle：PC (3000ml)

KNF Mini diaphragm vacuum pump LABOPORT N 86 KT.18 Model: N86KT.18 100% oil-free pumping, so media c (more)annot be contaminated when pumping and evacuating Maintenance-free, quiet running Flow rate: 5.5 l/min Weight [kg] : 1.9 Dimensions W x H x D [mm] : 90 x 141 x 164 Ultimate vacuum (max.): 403mbar (abs.) found following our proper functioning test (see photo) Year of manufacture: 2007 Signs of wear and peeling paint in places

Portable suction system, vacuum pump ROCKER BIOVAC 240 New equipment (never used) Max. vacuum : 720  (more)mmHg Max. flow rate : 38 l//min Hose barb : 3/16 inch Pump type: Piston Dimension (LxWxH) : 53x24x35cm Suction bottle：PC (3000ml)

VARIAN DS 102 vacuum pump DS102 model Code: SQ 396 1725/1425 rpm 230 V 50/60 Hz 1/2 HP Vacuum limit: (more) 11.0 x 10-3 mbar (0.011 mbar) External dimensions (D)x(H)x(W): 42 x 14 x 24 cm Weight: 24Kg Without filter

VARIAN DS 102 vacuum pump DS102 model Code: SQ 396 1725/1425 rpm 230 V 50/60 Hz 1/2 HP Vacuum limit: (more) 11.0 x 10-3 mbar (0.011 mbar) External dimensions (D)x(H)x(W): 42 x 14 x 24 cm Weight: 24Kg Without filter

The offered instrument / system is fully functional tested and ready to use. FURTHER DETAILS TO FOLL (more)OW

The offered instrument / system is fully functional tested and ready to use. FURTHER DETAILS TO FOLL (more)OW

Chemical resistant vacuum pump consisting of N 840 G diaphragm vacuum pump, base plate and two separ (more)ator bottles on the suction and pressure side. Thanks to the high compatibility of steam and condensate, the system is perfectly suited for extremely aggressive/corrosive gases and vapours. Technical features Flow rate (max.): 20 l / min Final vacuum (max.): 6 mbar (abs.) Pressure (max.): 0.1 bar (rel.) Flow rate (m³/h) at atm. pressure: 2,04 Permissible fluid temperature between 5°C and 40°C Valve material: FFPM Diaphragm material: PTFE coated Pump head material: TFM ™ PTFE Applications Filtration Degassing Vacuum oven Centrifugal concentration Qualitative characteristics Ideal for extremely aggressive / corrosive gases and vapors High compatibility with steam and condensate Integrated gas ballast valve Integrated control of the rotation speed 3-color status display for running / stand-by / error Compact, silent and reliable Chemically resistant compound vacuum system diaphragm vacuum pump, base plate and two separating bottles on the suction and pressure sides Modular; expandable 100% oil-free transfer - then pure transfer, evacuation and compression of gases High compatibility with steam and condensate Ecological Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

The N 820.3 FT.40.18 is a two-stage pump with an integrated “self-drying” system for automatic conde (more)nsate drain. The “SD” series is widely used in laboratories, especially when the vapors are humid and a clean and ecological vacuum is required. Typical applications are: vacuum ovens (for drying chemicals, drying biological samples, heat treatments), autoclaves for sterilizing instruments, containers, filters and textiles. Thanks to the use of anti-corrosion materials, it is possible to vacuum even corrosive products.  The heart of the pump is the diaphragm with differentiated structure in PTFE, optimized to guarantee high performance with reduced dimensions and at the same time, long life even in heavy applications.  When the humid gases are sucked in, condensation may form in the pump head: consequently the performance decreases, considerably increasing the emptying time. To eliminate condensation, the 'drying system' then opens a solenoid valve that allows ambient air to enter the heads. Once the condensation has been eliminated, the solenoid valve closes and the pump sucks from the stove in full capacity. Over time, condensation could form again and then the cycle is repeated. The time interval between one cycle and the next can be adjusted as desired, as well as the duration of the air injection. Technical features Flow rate (max.) 20 l / min Final vacuum (max.) 10 mbar (abs.) Pressure (max.) 1 bar (rel.) Fluid temperature allowed at 5-40°C FFPM valve material PTFE coated diaphragm material Pump head material PTFE Applications Rotary evaporation Vacuum oven Qualitative characteristics Clean operation, 100% oil-free Corrosion resistant PTFE / FFPM flow path Ideal for extremely aggressive / corrosive gases and vapors Compact, silent and reliable The self-drying system removes condensation without altering the vacuum level Maintenance free Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMPS YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION

Chemical-resistant vacuum pump consisting of N 820 G diaphragm vacuum pump, base plate, separator on (more) the suction side and high-performance condenser on the pressure side. Thanks to the high compatibility of steam and condensate, the system is perfectly suited for extremely aggressive/corrosive gases and vapours. Technical features Flow rate (max.): 20 l / min Final vacuum (max.): 6 mbar (abs.) Pressure (max.): 0.1 bar (rel.) Flow rate (m³/h) at atm. pressure: 1,2 Permissible fluid temperature between 5 and 40°C Valve material: FFPM Diaphragm material: PTFE coated Pump head material: TFM ™ PTFE Applications Distillation Rotary evaporation Multi-user vacuum systems Qualitative characteristics Vacuum system comprising chemically resistant diaphragm vacuum pump, base plate, separator on suction side and high performance condenser on pressure side Modular expandable 100% oil-free transfer Thereby pure transferring, evacuation and compression of gases High level of vapor and condensate compatibility Ideal for extremely aggressive / corrosive gases and vapors Integrated gas ballast valve 3-color status display for in operation / stand-by / error Integrated rotational speed control Environmentally friendly Start against ultimate vacuum of the pump Download the data sheet for further information and accessories. NOT SURE WHICH VACUUM PUMP YOU NEED? Try following our guide to KNF pumps: VACUUM PUMPS FOR THE LABORATORY Or download the KNF guide: THE IDEAL DIAPHRAGM PUMP FOR EVERY APPLICATION
