Facilities & equipment

Skalar’ sampler, type 1050 Computer controlled ROZ sampler, series 1050, for up to 140 samples with  (more)separated standard and QC sample positions, separate rinse pump, optional automatic diluter station for automatic pre- and post run dilutions, and automatic standard preparation, with optional dual sample pick up and optional stirrer.

Gas mixer for 3 gases (CO2, N2, H2) with 3 buffer vessels (90 L + 2x 25 L).

Capacity: 5100 g Readability: 0.1 g Repeatability: 0.1 g Linearity: 0.3 g Dimensions (DxWxH): 360 x  (more)216 x 95 mm Diameter weighing pan: 180 mm Weight: 4.7 kg

The FLoid Cell Imaging Station is an affordable, user-friendly imaging solution for the quick detect (more)ion and verification of fluorescently-labeled samples. The FLoid Cell Imaging Station captures transmitted light and three-color fluorescent images of your cells and samples right at your benchtop. You do not need to be specially trained or have dedicated staff to operate it. An uncomplicated user interface, streamlined image acquisition process, and real-time, multicolor display allow even imaging novices to produce high-quality images with a few mouse clicks. Cell Data: 3-Color Detection Color: Green, Red, Blue Data Outputs: JPG Files, PNG Files, BMP Files, TIFF Files Detection Method: Fluorescent Display: Adjustable tilt, 15-inch color Emission Wavelength: 446/33 (Blue), 532/59 (Green), 646/68 (Red) Excitation Wavelength: 390/40 (Blue), 482/18 (Green), 586/15 (Red) Filter Type: FITC, Texas Red, DAPI For Use With: All fluorophores compatible with excitation and emission filters Format: Slide(s), Cell Culture Dish, Cell Culture Plate (Multi-Well), Cell Culture Flask (T75), Petri Dish, Coverslip(s) Laser Features: LED based adjustable intensity (50,000 hour life) Magnification: 460X (optical) to 1840X (with digital zoom) Memory: 2 Gb USB Objectives: Numerical Aperture = 0.45, Fixed 20X Plan Fluorite, Working Distance = 5.9 mm Stage: Open-Stage Platform for Most Cell Vessels Camera Type: 1.3 Megapixels, Monochrome, HAD CCD, 1/3 inch Lighting Type: LED Resolution: Image resolution – 1296 x 964 pixels, Display resolution – 1366 x 768 pixels Dimensions (WxHxD): 400 x 540 x 350 mm Weight: 12.7 kg

The Waters Acquity UPLC Binary Solvent Manager delivers solvent compositions for isocratic and binar (more)y gradient methods at flow rates of 0.01 to 2.0 mL per minute.  The binary solvent manager’s two pump channels permit quick solvent changeovers at a flow rate of 4.0 mL per minute. Low-volume degasser channels (480 µL internal volume), automated solvent-selection valves, and an automated vent valve make the quick changeovers possible.  The pump accommodates up to four chromatographic solvents and one Binary Solvent Manager Seal wash solvent.

Temperature range: Ambient +5°C to 370°C Dimensions (WxDxH): 358 x 358 x 220 mm Hotplate: 360 x 360  (more)mm Weight: 13 kg

Range 1: 60 – 500 rpm Range 2: 240 – 2000 rpm

Temperature range: ambient +5ºC to 150ºC Setting range: 15°C to 150°C Temperature stability (at 37°C (more)): ±0.1ºC Temperature uniformity within the block (at 37°C): ±0.1ºC Temperature uniformity across similar blocks (at 37°C): ±0.2ºC Display resolution: 1ºC Heat-up rate (ambient to max): 40 min Equipped with a heating block for 24 x 1.5 mL Eppendorf tubes. Dimensions (WxDxH): 205 x 180 x 122 mm Weight: 3.6 kg

Temperature range: -28ºC to 200ºC. Dimensions (WxDxH): 390 x 480 x 420 mm Internal dimensions (WxDxH (more)): 130 x 100 x 150 mm

Temperature control range: -5°C to 99°C Usable temperature range: from 30°C below room temperature t (more)o 99°C Temperature accuracy for 0°C: ±1.0°C 37°C: ±0.5°C 90°C: 1.0°C Heating rate: 5°C/min Cooling rate simple temperature operation: 6.0°C/min between 99°C and 25°C 1.5°C/min between 25°C and -5°C Temperature deviation across blocks: Max 0.2°C Dimensions (WxDxH): 220 x 250 x 125 mm Weight: 5 kg Excluding block

Bio-Rad offers a range of mini horizontal electrophoresis chambers to resolve DNA fragments on eithe (more)r handcast agarose gels or ReadyAgarose precast gels. These cells include a buffer tank, safety lid with cables, and leveling bubble. Fast and flexible, the Mini-Sub cell GT cell is our most popular classroom gel box. The Mini-Sub cell GT cell holds either a 7 x 7 cm or a 7 x 10 cm gel tray. A 10 cm agarose gel poured with two 8-well combs easily accommodates two student teams at a time. At 100 V, this cell resolves DNA fragments from 20–20,000 base pairs in just under 30 min. Cell size (WxLxH): 120 x 260 x 65 mm Gel tray sizes (OD) (WxL): 70 x 70 mm ReadyAgarose gels accommodated: Yes, mini format Sample throughput: 8–30 Base buffer volume: ~270 ml Buffer recirculation: No Bromophenol blue migration: 4.5 cm/hr (at 75 V)

Operation: Control ball and measurement key Display: Digital, LCD, 160 x 128 pixels, full graphics M (more)easuring geometry: 0° / 45°, ring lens system Light source: Incandescent lamp, approx. 3000 K (DIN) or approx. 2856 K (ANSI) Receiver: Si photodiode Densitometric standard: DIN 16536: Filter set 47B, ANSI Status T: Filter set 47, DIN 16536 narrow band: Interference filter set, CIE: V (λ) filter, ANSI PH 2.18: Visual filter Measuring range: 0.00 D – 2.50 D Reproducibility: ± 0.01 D, ± 1% for dot area Linearity: ± 0.01 D, ± 1% for dot area Interinstrument agreement: ± 0.02 D, ± 2% for dot area Measuring aperture: ∅ 3.6 mm Polarization filter: 2x linear (tube P) Measuring time: Approx. 0.8 seconds Data interface: RS232C, remote operation of remission densitometer with computer Weight: Approx. 890 g Dimensions: 83 x 80 x 245 mm

Dimensions (HxWxD): 880 x 1325 x 750 mm

Heat Dissipation: Max 2000 W Heat Absorbed: 1,600 W(2,000 W Maximum) Dimensions (HxWxD): 572 x 380 x (more) 514 mm Weight: 41.7 kg

Refrigerator Temperature Range: 1°C to 9°C Freezer temperature range: -16°C to -26°C Dimensions (HxW (more)xD): 1800 x 550 x 629 mm Refrigerator Capacity: 199 L Freezer capacity: 79 L

The G 7883 washer-disinfector is suitable for reusing laboratory glassware for analytical experiment (more)s in, for example, industrial, environmental and research laboratories. This appliance has a large two-tier wash area and can be built-in under a continuous worktop or used free-standing. After an intensive main cleaning phase, disinfection takes place at >90°C and a storage time of 5 minutes. The final rinse is performed with deionized water without rinsing agents. Control/programs: Multitronic Novo Plus control (certain process parameters can be changed), with 10 standard cleaning programs Program operation/display: Operation via one-button program selector, display of program cycles, display of temperature and program duration, display of program end, optical and acoustic signal, indicator lights for service and fault messages Cleaning mechanisms: Rotating: two spray arms on top and bottom of the chamber, third spray arm on top basket. Dosing devices: Valve dispensers for powdered detergent and liquid detergents. Circulation pump: 400 l/min Temperature: Freely adjustable up to 93°C Drain: 1 drain hose Drying capacity: Gravity convection drying system, 10 minutes. Can be turned on or off in any cycle Water connection: 1x hot water, 1x cold water, 1x purified water Dimensions (WxDxH): 600 x 600 x 850 mm Weight: 74 kg

Sample preparation separated from the titration stand Separation of titrations on a single sample Au (more)tomatic combination of titrations on two samples Easy switch between two titration stands (e.g. for aqueous / non-aqueous titrations)

S+B Display Hanging Cabinet White 900x600x310

Eyepieces: DIN HWF plan 10x/22 mm Head: Trinocular 45° inclined tubes with interpupillary distance o (more)f 54 to 75 mm Nosepiece: Quintuple Objectives: LPlan 4x/0.13, Plan Fluor 10x/0.30, Plan Fluor 20x/0.45, Plan Fluor 40x/0.65 Stage: 50 x 230 mm equipped with a coaxial mechanical 120 x 78 mm X-Y stage Condenser: N.A. 0.30 condenser with iris diaphragm. Working distance 72 mm Focusing adjustment: Coaxial 25 mm coarse and fine adjustments, 2 μm precision and with friction adjustment Illumination: Transmitted 5 W LED Intensity adjustable with internal 100-240 V power supply and a reflected 100 W HBO mercury vapor light source with external 100-240 V power supply with UV protection shield. Fluorescence filters: Blue spectrum, OX.9745, Green spectrum, OX.9746, UV spectrum, OX.9747 Camera: sCMEX-20 Number of pixels: 20 MP Sensor size: 1 Inch Pixel size: 2.4 x 2.4 µm Resolutions: 5440 x 3648, 2736 x 1824, 1824 x 1246 Exposure time: 0.264 ~ 15000 ms Maximum frames: 15, 50, 60 p/sec Grayscale conversion: 16 bits Dynamic range: 66.3 db S/N Ratio: 41.74 db Color rendering: 36 bits Sensitivity: 0.21 V/lux-sec

Multisizer 3 Coulter Counter, with Aperture 70 µm and 100 µm. Complete with waste and Isoton plastic (more) reservoir left, original Beckman map and 12 chapter manual. No software available, but can be requested from Beckman.

Pathlength: 1 mm

Maximum heat compensation (at 40°C): 200 W Spatial temperature deviation (at 40°C): ±0.2 K Temperatu (more)re deviation in time: ±0.1 K Temperature range: 0°C to 70°C Recovery time after door opened 30 s (at 25°C and 60% RH): 6 min Recovery time after door opened 30 s (at 40°C and 75% RH): 7 min Spatial temperature deviation (at 25°C and 60% RH): ±0.2 K Spatial temperature deviation (at 40°C and 75% RH): ±0.2 K Temperature deviation over time (at 25°C and 60% RH): ±0.1 K Temperature deviation over time (at 40°C and 75% RH): ±0.1 K Humidity deviation over time (at 25°C and 60% RH): ≤2 ± % RH Humidity deviation over time (at 40°C and 75% RH): ≤2 ± % RH Humidity range: 10 to 80% RH Chamber volume: 102 L Maximum load per shelf: 30 kg Maximum total load: 100 kg Wall distance behind: 100 mm Wall distance sideways: 100 mm Dimensions (WxDxH): 880 x 650 x 1050 mm Internal dimensions (WxDXH): 600 x 351 x 483 mm Weight: 128 kg

0

Bi-directional peristaltic pump with 8-channels for sample transfer in a dissolution system.

Dimensions (WxDxH): 600 x 520 x 630 mm

Maximum speed: 6000 rpm Maximum capacity: 6 x 1.5/2.0 mL Deceleration time: <5 seconds Dimensions: 1 (more)50 x 150 x 117 mm
