Spectrophotometers (UV-Vis, Fluor)

The offered instrument / system is fully functional tested and ready to use. FURTHER DETAILS TO FOLL (more)OW

Prevent costly delays with an enhanced understanding of sample quality using the Thermo Scientific N (more)anoDrop One Microvolume UV-Vis Spectrophotometers. Innovative Thermo Scientific Acclaro Sample Intelligence technology is built into every instrument for improved measurement accuracy and contaminant identification. Quantify and qualify DNA, RNA, and protein samples  in seconds with only 1-2 μL, and obtain full-spectral data before you decide to use samples in downstream applications. Wavelength Range: 190 to 850 nm Wavelength Accuracy: ±1 nm Spectral Bandwidth: ≤1.8 nm (FWHM at Hg 254 nm) Measurement Time: 8 seconds Pathlength: 0.030 to 1.0 mm (auto-ranging) Photometric Range: 10 mm equivalent 0–550 A Repeatability Typical: 0.002 A (1.0 mm path) or 1%CV, whichever is greater Photometric Accuracy: 3% at 0.97 A, 302 nm, (Absorbance expressed at Abs/mm at 25°C) Concentration: dsDNA; 27,500 ng/μL, BSA (IgG); 820 (400) mg/mL Detection Range: dsDNA; 2.0 ng/μL, BSA (IgG); 0.06 (0.03) mg/mL Detector Type: 2048-element CMOS Linear Image Sensor Light Source: Xenon Flash Sample Volume: Minimum 1μL Dimensions (LxWxH): 200 x 254 x 323 mm Weight: 3.6 kg

Optical Design: Dual-Beam – Internal Reference Detector Spectral Bandwidth: 1.8 nm Light Source: Xen (more)on Flash Lamp Detectors: Dual Silicon Photodiodes Wavelength Range: 190 – 1100 nm Wavelength Accuracy: ±1.0 nm Wavelength Repeatability: ±0.5 nm Wavelength Slew Speed: 11000 nm/min Wavelength Scan Speed: Up to 3600 nm/min Wavelength Data Interval for Scanning: 0.1, 0.2, 0.5, 1.0, 2.0, 5.0 nm Photometric Linear Range: Up to 3.5 A at 260 nm Photometric Display: -0.1 A; -1.5–125%T; ±9999 C Photometric Accuracy: ±0.005 A at 1.0 A, 0.010 A K2Cr2O7 Photometric Noise: <0.00025 at 0.0 A; <0.00050 at 1.0 A; <0.00080 at 2.0 A; RMS at 260 nm Photometric Drift: <0.0005 A/hr Stray Light: <0.08%T at 220, 340 nm (NaI, NaNO2); <1.0%T 198–200 nm (KCl) Connectivity: USB Type A port for USB memory device (front panel), USB Type B port for optional computer connectivity (rear panel), USB Type A port for external printer (rear panel) Dimensions (WxDxH): 300 x 400 x 250 mm Weight: 8.6 kg

Dimensions (W x D x H): 260 × 390 × 100 mm

The UV5Nano UV/Vis spectrophotometer enables concentration and purity determination of nucleic acids (more) and protein samples down to 1 μL. Optional automation and 21 CFR part 11 compliance meet the needs of life science and biopharma labs. Pre-programmed applications for Nucleic Acids (DNA, RNA, mRNA, Oligos, etc.) with QC Ratios (260/280 and 260/230), protein assays, and cell density. Full-spectrum micro volume and cuvette measurements combined in one instrument to support both OD600 and protein assay applications. Wavelength Range: 190 – 1100 nm Photometric accuracy (K2Cr2O7): ±0.006 A Wavelength accuracy: ±0.9 nm Resolution (Toluene in hexane): >1.7 Stray light (KCl, 198nm): >1.7 Compatibility with LabX Software: Yes Shortcuts per user: 12 Max. number of methods: 50 Pharmacopeia compliant: No User Identification: Yes Minimal Scan time: 2 s Cuvette Changer: No Optics: Array Light Source: Xenon flash lamp Connectivity USB Interface: Yes Path length: 0.1mm, 1.0mm, 10 mm Dimensions (HxWxD): 217 x 208 x 255 mm Weight: 7.2 kg

Wavelength Range: 190 – 1100 nm Wavelength Accuracy: ± 0.5nm across wavelength range Wavelength Repr (more)oducibility: ± 0.1 nm Lamp Source: Xenon Beam: Double Beam Optical System: Czerny-Turner Monochromator Bandwidth: 2 nm Detector: Dual Solid State Silicon photodiode Photometric Range: -4.000 A to 4.000 A Stray Light: < 0.050%T at 220 nm (NaI), < 0.050%T at 340 nm (NaNO2) Zero Stability: ± 0.001A/hr at 500 nm Baseline Flatness: ± 0.002 A 220 to 900 nm Noise: <0.002 A peak to peak, 0.0008 A RMS near 2 A at 500 nm. <0.00020 A RMS at 0 A at 500 nm over 20 measurements Photometric Accuracy: ± 0.002 A at 0.5 A, ± 0.004 A at 1 A, ± 0.006 A at 2 A at 440 nm, 456 nm, 546.1 nm, 590 nm, 635 nm ± 0.005 A using 60 mg/L K2Cr2O7 Photometric Reproducibility: ± 0.002 A at 1 A Spectral Scanning: Yes (up to 1100 nm) Measurement Type: Fixed Wavelength, Abs/%T, Abs ratio, Abs difference, concentration (standard curve), concentration (factor), multiwavelength, kinetics, Life Science Methods, user log-on, Equation editor Cell Holder: Dual (sample and reference) Method Storage: Up to 90 on-board, unlimited via USB Display: Colour Touchscreen Data Interface: USB Dimensions (WxDxH): 535 x 440 x 335 mm Weight: 17.5 kg

Dual beam, Czerny-Turner monochromator, 190–1100 nm wavelength range, approximately 1.5 nm fixed spe (more)ctral bandwidth, full spectrum Xe pulse lamp single source with exceptionally long life, dual Si diode detectors, quartz overcoated optics, scan rates up to 24000 nm/min, 80 data points per s maximum measurement rate, non-measurement phase stepping wavelength drive, room light immunity, central control by PC with Microsoft Windows operating system.

Pathlength: 1 mm

The UV-1800 is an advanced high-resolution spectrophotometer utilizing a precision Czerny-Turner opt (more)ical system. Operation can be either as a stand-alone instrument or as a PC-controlled instrument with the included UV Probe software. USB memory can be connected directly to the UV-1800 for simple data transfer and printing is possible with the optional screen-copy printer or printers that support PCL control codes. Photometric Mode measures the absorbance or transmittance at a single wavelength or at multiple (up to eight) wavelengths. In multiple-wavelength measurement, calculations can be performed on the data obtained for up to four wavelengths, including the calculation of the difference between, or ratio of, the measurements obtained for two wavelengths. Spectrum Mode obtains sample spectra using wavelength scanning. Changes in the sample can be tracked using repeated scans. Data processing operations, such as the enlargement or reduction of the spectra obtained, peak detection, and area calculations, are also possible. Quantitation Mode generates a calibration curve from standard samples, and uses it to calculate the concentrations of unknown samples. Various combinations of wavelengths (1 to 3 wavelengths and derivatives) and calibration curves (K-factor and first-to-third order regression calibration curves) are possible. Kinetics Mode measures the change in absorbance as a function of time, and calculates enzymatic activity values. You can select either the kinetics measurement method or the rate measurement method. Time-Scan Mode measures the change in absorbance, transmittance, or energy as a function of time. Multi-Component Quantitation Mode separately quantitates up to eight components mixed in a single sample. Pure components or mixtures of components can be used as standard samples. Biomethod Mode is capable of analyzing DNA and proteins using the several common quantitation methods including quantitation of DNA or protein using the absorbance at 260/230 nm or 260/280 nm and protein quantitation via the Lowry method, BCA method, CBB method, Biuret method, and UV absorption method (direct measurement at 280 nm). Security and validation functionality are also preprogrammed. Security functions allow you to restrict functions according to three user levels: administrator, developer, and operator. Automatic or semiautomatic validation functions include wavelength accuracy, wavelength repeatability, resolution, stray light, photometric accuracy, photometric repeatability, baseline flatness, baseline stability, and noise level. The operating time of the lamps can be recorded and displayed so that you can anticipate replacement and avoid downtime. Stray Light: <0.02%T at 340 nm, 400 nm; <1.0%T at 198 nm Source Lamp: Deuterium; Tungsten-Halogen Beam Type: Double Bandwidth: 1.0 nm Min Wavelength: 190 nm Max Wavelength: 1100 nm Wavelength Accuracy: ±0.1 nm Wavelength Reproducibility: ±0.1 nm Min Photometric – Transmittance: 0%T Max Photometric – Transmittance: 400%T Min Photometric – Absorbance: -4 A Max Photometric – Absorbance: 4 A Photometric Drift: <0.0003 A/hr Detector: Silicon photodiode Including UV Probe software

Equipped with a 4 cuvette holder Wavelength: 325 – 1000 nm Absorbance range 1: 0 – 1.0 Absorbance ra (more)nge 1: 0.1 steps Absorbance range 2: 0 – 1.0 Absorbance range 2: 0.2 steps Transmittance: 0 – 100%

Dimensions (W x D x H): 260 × 390 × 100 mm

Lot of 100 plastic cells 10x10 mm for spectrophotometer Number of optical faces: 2 Maximum filling v (more)olume (in ml): 4 Quantity available: 10 boxes
