Microplate equipment

MicroFill is an economical, compact, and reliable dispenser for 24-, 96-, and 384-well microplates.  (more)An autoclavable fluid path is ideal for applications that require sterility. The dispense flow rates are easily selected to accommodate sensitive cell-based assays or vigorous dispensing for ELISA. Accurate and precise dispensing are guaranteed, without the time-consuming recalibration, cassette replacement, and maintenance commonly associated with other dispensers. Intuitive, on-board software is easy to use and saves time in instrument setup. Microplate Types: 24-, and 96-well, Low-profile, standard, and deep-well formats Manifold Type: One 8-tube (1 x 8) manifold−316 stainless steel tubes Dispense Speed: 96 wells, 10 µL/well, 1 x 8: 8 s Volume Range 5−6,000 µL/well, Minimum prime volume: 10 mL Flow Rates: User-programmable rates from high to low Dispense Accuracy: ± 1 µL at 5 µL, ± 1 µL at 20 µL, ± 1% at 100 µL Dispense Precision: ≤ 5% CV at 5 µL, ≤ 2.5% CV at 20 µL, ≤ 1% CV at 100 µL Dimensions (DxWxH): 460 x 380 x 180 mm Weight: 8.9 kg

Wavelength range excitation: 250 – 850 nm Wavelength range emission: 360 – 850 nm Wavelength bandwid (more)th: 9 nm Dynamic range: 6 decades Sensitivity top read: 3 fmol/well FITC Detector: Photomultiplier tube Read types: endpoint, kinetic, spectrum scan, well scan Wavelength selection: Monochromator tunable in 1-nm increments Light source: Xenon flash lamp Read time: 15 seconds Dimensions (HxWxD): 340 x 420 x 420 mm Excluding software As-is

The Biochrom Expert 96 is a PC- controlled modern design multi-channel microplate reader, for fast p (more)late reading of standard ANSI SBS footprint 96 well, flat, round and v-bottomed plates. The Biochrom Expert 96 has four shaking modes for mixing of solutions and the ability to perform readings at timed intervals ideal for kinetic assays.

The SkanWasher 300 is an automatic 96-well microplate washer designed to give reliable, reproducible (more) results, with no cross-contamination between wells, and no carryover from plate to plate. The washer incorporates flexible software, and can handle most requirements for kit manufacturers, and research and clinical scientists. The SkanWasher 300 has eight user-defined programs, two inlets for buffer and rinse, and a special rinse program. The fluid pressure can be adjusted individually for each program, making it suitable for very gentle washing, as well as tougher, more turbulent washing. Washes all 96 wells simultaneously 8 user defined programs with 16 steps per program. Wash steps set by either time or volume (100 – 1000 ml) Versatile dispense-only function provides < 4% CV dispense accuracy and precision across the plate Easy to maintian: preset factory rinse program and removable wash head Wash head & manifold combined in one module, thereby reducing risk of contaminant growth Unique double probe washing system provides maximum washing efficiency with minimal reagent consumption Aspirate from top of liquids to avoid cross-contamination of wells Easily-accessible wash head channels for easy cleaning Motorized plate carriage, adjustable for flat & round bottomed plates Quick-disconnect fittings to avoid spills Capacity: 96-well Microplates Soak Time: Programmable to 3 Minutes Dimensions (WxDxH): 660 x 330 x 610 mm

Light source: High energy xenon flash lamp Detector: Silicon photodiode Wavelength selection: Single (more) High-Speed Monochromator Wavelength range: 200 – 1000 nm, selectable in 1 nm steps Wavelength accuracy: ≤0.8 nm Wavelength reproducibility: ≤0.5 nm Bandwidth: Fixed, 3.5 nm Measurement range (OD): 0 – 4 OD Measurement time (96-well plate, 1 flash): <14 seconds Measurement time (384-well plate, 1 flash): <30 seconds Fast Scan (200 – 1000 nm, 1 nm steps): <5 seconds OD accuracy (0 – 0.8 OD, 96-well plate): ±0.008 OD OD accuracy (0.8 – 2.5 OD, 96-well plate): <±1.0% OD accuracy (2.5 – 3.0 OD, 96-well plate): <±1.5% OD accuracy (at 260 nm): ≤0.5% OD precision (0 – 1.2 OD, 96-well plate): <±0.006 OD OD precision (1.2 – 3 OD, 96-well plate): ±0.5% OD precision (at 260 nm): ≤0.2% OD linearity (0 – 3 OD, 96-well plate, at 260nm): R-2 > 0.999 OD uniformity (96-well plate, at 1 OD): <3% Sample formats: SBS standard microplates from 1- to 384-wells,NanoQuant low-volume plate Microplate shaking: Linear, orbital and double orbital shaking; variable amplitudes and frequencies Stirring speed regulation: 50 – 1000 rpm Lid lifting system – maximum height of microplate and lid: 24.5 mm Temperature control – heating range: Ambient +4°C up to 42°C Temperature control – uniformity: <0.5°C at 30°C and 37°C at incubation position Dimensions (WxDxH): 494 x 557 x 395 mm Weight: 40 kg Software included

Caliper Life Sciences Twister II is more than a super-fast, high capacity plate stacker. It’s real p (more)lug-and-play desktop automation. The Twister II Microplate Handler was designed to address the need for a microplate handler with multiple instrument capability, increased speed and capacity, and amazingly simple software. Add a liquid handler and a washer or reader, and you’ve got a system that can handle almost any manual assay step. Twister II can serve as the hub for a new breed of ‘Mini-Systems’. This low-cost microplate handler provides a time saving alternative to stackers and a money saving alternative to larger, more complex integrated systems. Minimum Reach: 305 mm Arm Travel: 216 mm Horizontal, 559 mm Vertical Wrist Rotation: ±135° (270° total) Protrusion Beyond Rotation Point: 38 mm (flush with plate edge) Turret Rotation: 340° with 20° Hard Stop Turret Diameter: 178 mm Turret Height: 996 mm Base Dimensions: 254 mm Diameter Min. Reach Height: 165 mm Max. Reach Height: 711 mm

Apply consistent, secure, tight seals around individual wells, eliminating sample loss through evapo (more)ration and cross contamination between wells. The Thermo Scientific ALPS 50 V Microplate Heat Sealer is designed to provide sealing consistency in low to medium throughput labs. Heat sealing offers superior sample protection of storage and reaction plates in applications including compound storage, sample archiving and PCR. Choose from a wide range of heat seals (including pierceable, optically clear and permanent) for any application. Sealing Temperature Range: 125° to 200°C Dimensions (HxWxD): 425 x 220 x 325 mm Weight: 7.2kg

The BTX HT-200 plate handler allows for the Highthroughput System HT 25 or HT 96 for advanced molecu (more)lar delivery. The HT 96 (96-well) plates or the HT 25 (25-well) plates can be electroporated using a BTX generator (models: ECM 830 and ECM 630) with a plate handler. The Model HT-200 automatically switches columns in a Multi-well plate during electroporation using the Auto-track sensing featute. The Auto-track sensing allows rapid electroporation of an entire plate by setting up all columns and pressing one button. Voltage Range: 0 to 3000V DC Pulse Length Range: 10 µsec to 10 sec Pulse Number Range: 1 to 99 Dimensions (WxDxH): 230 x 215 x 140 mm Weight: 4.8 kg Including: 1x 96-Well Disposable Electroporation Plates, 4 mm, 250 µl, pkg. of 1 1x 96-Well Disposable Electroporation Plates, 2 mm, 125 µl, pkg. of 1 1x HT 25-Well Adapter for Plate Handler

2x Plate washer uWasher DG-34 Grifols (One in good condition, 1 for parts)
