Automated liquid handling

Manufacturer: ASYS Hitech GmbH, Austria Model: Flexispense M - Low Volume and High Speed Dispenser T (more)ype: G 013450 S/N: 56040 Description: The optimum solution for 384 & 1536 well dispensing in HTS  applications, either integrated into fully automated systems or for use as  standalone systems. The Flexispense M is the best choice for dispensing in HTS laboratories.  The computer controlled plate centring mechanism makes plate loading for a robot very easy. A wide range of solvents, acids, bases and other aggressive  liquids can be dispensed with confidence since the liquid path is completely inert and the adjustable pump speed allows for a wide viscosity range. The  Flexispense M is also very fast, filling a 1536 well plate within 23 seconds with 5µl per well. The pressure-free ceramic piston pump system allows to switch  between different reagents using an external valve. The Flexispense M is featuring a 16 channel manifold with disposable tips for 384 and 1536 well. Features: Height adjustable 16 channel manifold for standard-well and low profile  microplates with 384 and 1536 wells Low dead volume and pump-back capability to save expensive reagents Flexible volume range from 2µl - 2.5ml per well, selectable in 0.5µl steps Long life piston pump: High precision over life time and no running cost Flexible dispensing patterns: Start and stop position as well as skipping  columns can be programmed Easy integration into robotics systems Footprint and computer interface compatible to existing, already integrated  instruments from other manufacturers: allows easy swap to Flexispense for immediate availablity of the advantages of this system Computer controlled plate centering system, Active-X controls available Complete inert liquid path: only PTFE, ceramic, PVDF and glass in contact with  liquid High dispensing speed: 22 seconds for a 384 well plate (50µl / well) 23 seconds for a 1536 well plate (5µl / well) Detachable display / keyboard unit to save valuable space for system  integration Items delivered: Asys Flexispense M Low Volume and High Speed Dispenser Power Cord Manual for Flexispense 2 & 6 available as PDF via E-Mail The device is in very good cosmetic condition and 100% functional tested.  Ready for your use!     Hersteller: ASYS Hitech GmbH, Austria Modell: Flexispense M - Low Volume and High Speed Dispenser Typ: G 013450 S/N: 56040 Beschreibung: Die optimale Lösung für das Dispensieren in 384 & 1536 Well Platten in HTS  Applikationen, entweder integriert in vollautomatischen Systemen oder zur Verwendung als standalone System. Der Flexispense M ist die beste Lösung für Dispensier ? Aufgaben in HTS Labors.  Der computergesteuerte Platten-Zentrier-Mechanismus ist für das unkomplizierte Beladen durch Robotersysteme optimiert. Da der  Flüssigkeitspfad völlig inert ist, können verschiedenste Lösungen, Basen, Säuren  und andere aggressive Flüssigkeiten ohne Bedenken dispensiert werden, die  einstellbare Pumpengeschwindigkeit schafft weitgehende Unabhängigkeit von der  Viskosität der zu dispensierenden Flüssigkeit. Mit 23 Sek. für eine 1536 Well Platte (5µl / Well) ist der Flexispense M sehr  schnell. Die druckfreie Keramik Kolbenpumpe in Verbindung mit einem externen  Ventil ermöglicht die parallele Anbindung von mehreren Reagenzien. Der  Flexispense M ist mit einem 16 Kanal Dispensierkamm mit auswechselbaren Spitzen,  für 384 und 1536 Well Platten ausgestattet. Kernmerkmale: Höhenverstellbarer 16 Kanal Dispensierkamm für Standard-Well und Low Profile  Mikroplatten mit 384 und 1536 Wells Niedriges Totvolumen und Rückpump - Funktion zur optimalen Ausnutzung des  vorhandenen Reagenzvolumens Flexibler Volumensbereich von 2µl ? 2.5ml pro Well, wählbar in 0.5µl Schritten Long Life Keramik-Kolbenpumpe: Maximale Präzision über die gesamte Lebensdauer  und dadurch keine laufenden Kosten Flexible Dispensiermuster: Start und Stop Position kann ebenso definiert  werden wie etwa das Auslassen von Reihen Leichte Integration in automatisierte Systeme Standfläche und Computerinterface kompatibel zu existierenden, bereits  integrierten Geräten anderer Hersteller: Leichter Umstieg um die Vorteile des  Flexispense M schnell zu übernehmen ist möglich. Computergesteuerter Platten-Zentrier-Mechanismus, Active-X Controls sind  verfügbar Flüssigkeitspfad völlig inert: nur PTFE, Keramik, PVDF? und Glas kommen mit  Flüssigkeit in Kontakt Hohe Dispensiergeschwindigkeit: 22 Sekunden für eine 384 Well Platte (50µl / Well) 23 Sekunden für eine 1536 Well Platte (5µl / Well) Abnehmbare Display / Tastatureinheit um wertvollen Platz für die Integration  zu sparen Lieferumfang: Asys Flexispense M Low Volume and High Speed Dispenser Stromkabel Bedienungsanleitung für Flexispense 2 & 6 verfügbar as PDF via E-Mail Der Dispenser ist in einem sehr guten Zustand und 100% auf Funkion geprüft.Bereit für Ihren Einsatz!

Manufacturer: Perkin Elmer Model: FlexDrop IV Precision Reagent Dispenser (Low Volume Systems) P/N:  (more)BSQLV41 S/N: S60101 (Jan. 2006) Description: The FlexDrop Precision Reagent Dispenser is a liquid handling system designed  for rapid dispensing of reagents, buffers, solvents and cells for high throughput assay preparation and compound  storage. Intended for use in pharmaceutical, biotech, research and clinical applications, FlexDrop systems  perform direct, non-contact dispensing into 96-, 384-, and 1536-well shallow and deepwell microplates. This small footprint  instrument easily fits into a laboratory biosafety or fume hood to ensure sterile containment and safe dispensing of  volatile reagents and solvents. Specifications: Model: FlexDrop IVReagent Capacity: 1 - 4Dispense Volume Range: 200 nL - 2 mLMicroplate Compatibility: 96-, 384- and 1536-wellDispense Head Configuration: 4 x 8 precision valvesDimensions: 9.5 in. (241.3 mm)including tubing: 12 in. (304.8 mm)Width: including side mounted bottles 21 in. (533.4 mm)Depth: including bottles 20 in (508 mm)Weight (approximate): 35 lb (15.9 kg)Electrical requirements: 110, 220, 240 Vac ±10%; 50/60 Hz; 350 VA Items delivered: - Perkin Elmer FlexDrop IV- including Bottles- Power Cord The Dispenser is in good cosmetic condition and fully working tested.Ready for your application.     Hersteller: Perkin Elmer Modell: FlexDrop IV Precision Reagent Dispenser (Low Volume Systems) P/N: BSQLV41 S/N: S60101 (Jan. 2006) Beschreibung: Der Perkin Elmer Flexdrop Präziosions Reagenz Dispenser (Abfüller) ist ein  Liquid-Handling-System für die schnelle Abfüllung entwickelt von Reagenzien, Puffer, Lösungsmittel und Zellen für die Assay mit hohem Durchsatz Vorbereitung und  Verbindung Lagerung. Vorgesehen für den Einsatz in pharmazeutischen, biotechnologischen, Forschung und klinische Anwendungen, funktionieren Flexdrop  -Systeme direkt, berührungslos in 96-, 384- und 1536-Well Mikroplatten.Dieses platzsparende Instrument passt problemlos in einem Labor oder  Labor-Dunstabzug um die sichere Abfüllung von flüchtigen Reagenzien und  Lösungsmittel zu gewährleisten. Technische Daten: Modell: IV FlexdropReagenzkapazität: 1 - 4Abfüll Volumen Bereich: 200 nL - 2 mlMikrotiter-Kompatibilität: 96-, 384- und 1536-WellDosierkopf Konfiguration: 4 x 8 PräzisionsventileMaße: 9,5 in (241,3 mm)einschließlich Schlauch: 12 (304,8 mm).Breite: einschließlich seitlich montierten Flaschen: 21 in (533,4 mm).Tiefe: einschließlich Flaschen 20 in (508 mm)Gewicht (ca.): 35 lb (15,9 kg)Elektrische Anforderungen: 110, 220, 240 V AC ± 10%; 50/60 Hz; 350 VA Lieferumfang: - Perkin Elmer FlexDrop IV Dispenser- inklusive Flaschen- Stromkabel Der Dispenser befindet sich in sehr guten Zustand und ist 100% auf Funktion  geprüft.

Manufacturer: Tecan Model: Power Washer 384 S/N: 510000011 P/N: 16029900 Description: The Power Wash (more)er 384 is ideal for enzyme immunoassays and cell-based assays, in  either 96- or 384-well microplate formats. It has advanced wash-heads for simultaneous processing of all wells in either format, reducing the overall  plate processing time to just a couple of seconds and enabling maximum  throughput. Additionally, the PW384 is fitted with an aerosol shield to protect the user  from potentially infectious aerosols, and productivity is further increased by automated switching between up to three different buffers. Wash parameters such as dispense and aspiration speed, vertical aspiration  position and vacuum level can be fine-tuned to ensure the best results for your application using the simple WinWash plus package, and up to 20 different  washing programs can be stored. The Power Washer 384 is fully compatible with Tecan’s Freedom EVO® liquid  handling workstations and the Connect™ microplate stacker system. Alternatively, the washer can be operated as a stand-alone instrument and is straight forward  to program using the integrated keypad. The instrument is easy to maintain and comes with fully automated cleaning  procedures, ensuring high reliability. To further improve walkaway time and  process security, the instrument can be fitted with options including large volume  bottles and liquid level control for both buffer and waste bottles Product hightlights include: • High performance washer for 96- and 384-well microplates• 2-in-1 solution combining two applications and two• microplate formats in one compact instrument• Easy, user-exchangeable wash heads guarantee optimum• throughput in both 96- and 384-well formats• Simultaneous processing of all wells also in the 384-well format - no  time-consuming indexing of wash head required• Tunable wash parameters for best results with both cell-based and ELISA assays  for research use• Handling of up to 3 wash buffers for maximum application flexibility• Easy programming via integrated keypad or via WinWash™ plus software• Reliable operation and easy maintenance via predefined cleaning protocols• Aerosol cover around wash head for maximum user safety• Optional large volume bottle set and liquid level control for process  monitoring of wash buffer and waste bottles• Full compatibility with Freedom EVO®, TRAC™ and Connect™ system Specifications: Applications: EIA and Cell based assaysMicroplate formats: 96- and 384-wellsMode of plate processing: all wells simultaneouslyManifold channels: 96, 384Wash-liquid channels: Up to 3Wash program storage: Up to 20Dispense volume range: 50-3000 µl in 96 format10-1000 µl in 384 formatDispensing accuracy: CV = 2% over 96-well plateCV = 3% over 384-well plateResidual volume: = 2 µl across 96-well plate= 2 µl across 384-well plate Items delivered: - Tecan Powerwasher 384 (for 384- & 96-Well)- Power Cord- Instruction Manual as PDF via E-Mail The instrument is fully functional tested - Used but good cosmetic condition.

Manufacturer: Brandel, USA Model: PXR-96-MS Programmable Plate Dispensing System Description: Brande (more)l's Micro Dispensing Systems offer high efficiency, repeatable accuracy  and maximum flexibility – at a cost far below most dispensers currently on the  market.MicroDispensers consist of a Dispensing Unit and a separate,  Pump/Controller with keypad. Dispensers can also be operated by  remote computer using the Controller's built-in RS232 port. PXR - For dispensing viscous solutions such as scintillation cocktail Specifications/Features: Delivers user defined volumes between 10 and 999 µl ±5% relation to calibration with ±3% repeatability Configuration for 96-well plates Operations are menu driven. Simply enter the volume you wish to deliver and  set pump dial to dispense. Critical components are made of Teflon, stainless steel or Teflon-coated  aluminum to resist corrosion. MicroDispenser and Pump/Controller occupy less than 18 x 18. in. of bench  space Dispensing manifolds can be easily interchanged. Liquids of similar viscosity can be used in the same MicroDispenser. Reversible pump clears the system and saves solution. Dispenser can be operated remotely, through an RS232 port, or from controller  keypad. Self-priming delivery manifold, Teflon delivery tubing Digital speed control Power Supply 220V MicroDispensers include one-year warranty and full factory support. Custom configurations for 6, 12, 24, 48-well plates and others upon request. Items delivered: - Pump Control Unit- PXR-96 MS Dispensing Unit- Power Cord- Underlay base for liquid safety (not pictured) The System is in very good cosmetic condition (just 1-2 scratches on top) and  all tubes are very clean (as it's to see on the photos).It's 100% functional tested!Ready for your use!

The offered instrument / system is fully functional tested and ready to use. FURTHER DETAILS TO FOLL (more)OW

Manufacturer: CTC Analytics Model: MN 01-00 PAL Power Supply Description: CTC Analytics MN 01 - 00  (more)PAL power supply. Specifications: - Electrical requirements: 100-240V, 120W, 50/60Hz - Environment: 4°C - 40°C constant temperature, < 80% humidity (noncondensing) - Weight: 10 kg Items delivered: - CTC Analytics MN 01-00 PAL power supply- Conection Cable- Power cord Condition: The power supply is in very good cosmetic condition. It is 100% functional tested and ready to be applied.
