The 515 HPLC pump is a programmable, free-standing HPLC pump available in isocratic, gradient, and s (more)emi-preparative configurations: Precise stepper motor control (48 steps/µL resolution) of dual reciprocating pistons Non-circular drive gears provide smooth, uniform eluent delivery User-programmable flow rate calibration and compressibility compensation factors ensure straightforward pump operation qualification Tests to retention time variations of less than 0.1% for highly reproducible peak performance Easy-to-read display and keypad for error-free programming Automatic purging and flow calibration

The laminar flow biological safety cabinet, (LFBSC) is a product resulting from the development of t (more)he laminar flow principle and the application of enviromental controls as required in the field of biological research or chemical containment. The LFBSC, when used with proper technique, is an effective laboratory aid in obtaining the optimum control over product quality while reducing the potential for exposure of both product and personnel to airborne biological and particulate chemical agents in low to moderate risk hazard research and drug preparation. Inflow velocity: 0.53 m/s Dimensions (HxWxD): 1600 x 1362 x 835 mm Internal dimensions (HxWxD): 724 x 1178 x 597 mm Weight: 227 kg

Siemens VersaCell sample manager for use with a Siemens Immulite 2000 XPi Immunoassay System. Note:  (more)110 V system!

The Interflow cross flow unit has been developed to protect the object in the workspace of the cross (more) flow unit against external influences and contamination. The operation of the cross flow is based on the principle of the laminar (air) flow technique. This is an air flow which, after flowing through the filters, is virtually dust- and germ-free and flows through the workspace at a specific speed and according to a specific pattern. In this way, dirty air from outside the cross flow unit does not get a chance to enter the workspace. Absolute filter Type: TA2DS14G2F3XNCT Dimension: 610 x 1830 x 70 mm Quantity: 1 Pre-filter Type: V50 Cassette Dimension: 500 x 250 x 50 mm Quantity: 3 Fan Type: DD 9-7 TH ECM2 1/2 Quantity: 2 Relief Fixture: LED strip Type: Linear Flex Ulta Plus Watts: 1640 lm/m Color: 4000K (White) Light intensity: > 800 Lux Dimensions (WxDxH): 1860 x 792 x 1144 mm

The GeneAmp PCR System 9700 is an automated instrument,  specifically designed Instrument for the am (more)plification of nucleic acids using the Polymerase Chain Reaction (PCR) process. The user interface consists of a control panel with a full numeric keypad, soft keys, and a graphical display screen that shows the time and  temperature profile for each run. Equipped with a 96 well block Sample temperature range: 4.0 to 99.9°C The eight pre-coded methods are: AmpliCycle Sequencing AmpliTaq Gold DNA Polymerase BigDye Terminators General PCR LSM2 Time Release PCR Touchdown PCR XL PCR

The Model V15·17 is designed for vertical gels 17 cm x 15 cm (W x L) for separation of up to 20 samp (more)les on a 0.8 mm, 1.5 mm or 3 mm thick gel. The built-in integral clamps allow easy assembly and hold gels of different thickness leak-free in place. The V15·17 is the system of choice for laboratories with low sample throughput but the need of long running distances or large sample volumes (up to 4,000 µl).

Temperature range: Ambient +5°C to 220°C Spatial temperature deviation (at 220°C): ±7 K Time tempera (more)ture deviation (at 220°C): <±1 K Hetaing up time (to 98% of set value): 80 min Heat transfet to the enviroment at 220°C: 500 Wh/h Dimensions (WxDxH): 820 x 588 x 589 mm Internal dimensions (WxDxH): 500 x 380 x 408 mm Capacity: 78 L

The PowerPac Basic power supply is designed to provide constant voltage or current electrophoresis a (more)pplications. The power supply operates at the value specified for the constant parameter, with limits for the other parameters. To prevent damage to the electroferese cell, the PowerPac Basic provides automatic crossover to constant current or constant voltage depending on which set limit is first reached. If the set limit of the non constant parameter is reached, the power supply will switch, making the limiting non constant parameter the new constant. Output specifications: Voltage: Adjustable from 10 to 300 volt, in 1 volt increments Current: Adjustable from 4 to 400 mA, in 1 mA increments Power: 75 W

Analog Dynamic Range: >140 dB (<2Hz) typical Input Signal Range: 18 mV to +1.0 Volt Input Noise: 40  (more)nV RMS typical (Max. 150 nV RMS) 15 Hz Bandwidth Resolution: 24 Bit Common-mode Rejection: 140 dB min., dc to 100Hz Data Acquisition Rate: 0.1 to 100 Hz Monotonicity: 24 Bits, 0.004% FS typical Power: 115/230 VAC 50-60 Hz 135 Watts Dimensions (H x D x W): 104 x 285 x 325 mm

Compact, universal small shaker suitable for shaking tasks with all small vessels. Two operating mod (more)es: Mode A (safe mode with attachment detection) the maximum speed of 3.000 rpm is only reached with the standard attachment in touch mode. When using other attachments the speed is limited to 1.300 rpm. Mode B (without attachment detection) a speed of 3.000 rpm is possible with all attachments. Orbital shaking movement amplitude 4.5 mm Speed 0 – 3000 rpm Dimensions (lxwxh) 148 x 205 x 63 mm Weight 2.9 kg

Compact, universal small shaker suitable for shaking tasks with all small vessels. Two operating mod (more)es: Mode A (safe mode with attachment detection) the maximum speed of 3.000 rpm is only reached with the standard attachment in touch mode. When using other attachments the speed is limited to 1.300 rpm. Mode B (without attachment detection) a speed of 3.000 rpm is possible with all attachments. Orbital shaking movement amplitude 4.5 mm Speed 0 – 3000 rpm Dimensions (lxwxh) 148 x 205 x 63 mm Weight 2.9 kg

Measuring ranges pH: -8…22 mV: ±1200 mV Temperature (Pt 1000): -150…+250°C Temperature (NTC): -5…+25 (more)0°C Resolution pH: 0.001 mV: 0.1 mV Temperature (Pt 1000 or NTC): 0.1°C Measuring accuracy pH: ±0.003 mV: ±0.2 mV Pt 1000: ±0.2 °C (-20…+150 °C) NTC: ±0.6 °C (+10…+40 °C) Without pH electrode.

Maximum temperature: 100°C Temperature stability: ±0.2°C Shaking frequincy: 20 – 200 rpm Shaking str (more)oke: 15 mm Internal dimensions (LxWxD): 300 x 500 x 180 mm Capacity: 22 L Dimensions (LxWxH): 350 x 700 x 260 mm

Collection bottle (PP) capacity: 5L Max pumping speed 50/60Hz: 1.9/2.2 m3/h Ultimate total pressur (more)e (absolute): 100mbar 230V / 50-60Hz / 120W

Separating substances at medium rotational speeds: IKA G-L is the ideal midi centrifuge for all type (more)s of separation processes such as those found in molecular biology. It can be used with standard 1.5/2 ml vessels. The cover opens automatically at the press of a button. Capacity: 12 x 1.5/2.0 ml Permitted density: 1.2 kg/dm3 Centrifugal acceleration: 16500 G Speed range: 800 – 15700 rpm Timer: yes Timer display: 7 segment LED Unbalance sensor: yes Quick stop: yes Cover opening: automatic Dimensions (WxHxD): 200 x 140 x 280 mm Weight: 3.9 kg

The MultiCheck plate and software provide a complete solution for periodic checks for the Infinite 2 (more)00 PRO series, Infinite F500, Infinite M1000 PRO, Spark 10M and Spark 20M series.

Speeds: Choice of 3 options. Standalone interleaved: LV/RV (18 speeds) 8 LV speeds followed by 10 RV (more) speeds Standalone sequential: LV/RV (18 speeds) 8 LV speeds and 10 RV speeds arranged in sequential order from lowest 0.3 rpm to highest 100 rpm. Standalone custom: 54 speeds, user selectable External (PC Control): 0.01 – 200 rpm (0.01 rpm increments from 0.01 to 0.99 rpm, 0.1 rpm increments from 1.0 to 200 rpm) Temperature sensing range: -100˚C to 300˚C Viscosity range: 100 – 40000000 cP Viscosity accuracy: ±1.0% of full scale range Viscosity repeatability: ±0.2% of Full Scale Range Temperature Accuracy: ±1°C (-100°C to +149°C), ±2°C (+150°C to +300°C)

Interfurn Double Door Cabinet Blue 1460x600x630

The DV2T Viscometer features a 5-inch color display to guide users through test creation and data ga (more)thering for fast and easy viscosity measurements. The DV2T also offers powerful new programming capabilities and results analysis including data averaging and QC limits with alarms. 5-inch full color, touch screen display supports multiple languages Displayed info includes: viscosity (cP/mP·s), temperature (°C/°F), shear rate/stress, % torque, spindle/speed, step program status Enhanced security provides customizable user levels and password access. Built-In options include timed tests, data averaging, programmable QC limits/alarms, customizable speed/spindle lists, on screen data comparison Auto range shows maximum viscosity measured with any spindle/speed combination USB PC interface provides optional computer control and automatic data gathering capability Download custom test programs with PG Flash software Front-facing bubble level for convenient viewing Built-in temperature probe Accuracy of ±1.0% of range with displayed test data Repeatability of ±0.2% Viscosity range: 15 – 6.000.000 cP (mPa/s) Spring torque: 673.7 Dyne/cm, 0.0673 mN/m Included LV spindle set consisting of: LV-1: 15 – 20.000 cP LV-2: 50 – 100.000 cP LV-3: 200 – 400.000 cP LV-4: 1.000 – 2.000.000 cP

4-place microplate clamps on aluminum platform Speed Range: 150 – 1000 rpm Speed Accuracy: ±1 rpm Lo (more)ad Bearing Capacity: 5 kg Timer: 0 min to 99 hrs. 59 min Orbit: 2.5 mm Dimensions (DxWxH): 415 x 293 x 143 mm Platform Dimensions (DxW): 320 x 260 mm

Light source: High energy xenon flash lamp Detector: Silicon photodiode Wavelength selection: Single (more) High-Speed Monochromator Wavelength range: 200 – 1000 nm, selectable in 1 nm steps Wavelength accuracy: ≤0.8 nm Wavelength reproducibility: ≤0.5 nm Bandwidth: Fixed, 3.5 nm Measurement range (OD): 0 – 4 OD Measurement time (96-well plate, 1 flash): <14 seconds Measurement time (384-well plate, 1 flash): <30 seconds Fast Scan (200 – 1000 nm, 1 nm steps): <5 seconds OD accuracy (0 – 0.8 OD, 96-well plate): ±0.008 OD OD accuracy (0.8 – 2.5 OD, 96-well plate): <±1.0% OD accuracy (2.5 – 3.0 OD, 96-well plate): <±1.5% OD accuracy (at 260 nm): ≤0.5% OD precision (0 – 1.2 OD, 96-well plate): <±0.006 OD OD precision (1.2 – 3 OD, 96-well plate): ±0.5% OD precision (at 260 nm): ≤0.2% OD linearity (0 – 3 OD, 96-well plate, at 260nm): R-2 > 0.999 OD uniformity (96-well plate, at 1 OD): <3% Sample formats: SBS standard microplates from 1- to 384-wells,NanoQuant low-volume plate Microplate shaking: Linear, orbital and double orbital shaking; variable amplitudes and frequencies Stirring speed regulation: 50 – 1000 rpm Lid lifting system – maximum height of microplate and lid: 24.5 mm Temperature control – heating range: Ambient +4°C up to 42°C Temperature control – uniformity: <0.5°C at 30°C and 37°C at incubation position Dimensions (WxDxH): 494 x 557 x 395 mm Weight: 40 kg Software included

The DYNEX DSX Automated ELISA System is a proven, fully- automated open system with a unique dispens (more)e synchronization that helps eliminate plate drift and achieve consistent results across four independent plate incubators. This helps to manage testing workload with reduced labor and walkaway capability to maximize lab personnel effciency. System: Reader:

Recirculation air volume: 725 m3/hExhaust air volume: 383 m3/hTotal air volume: 1348 m3/hIn flow: 0. (more)45 m/sStandard lighting : 2x 36 WInternal dimensions (WxDxH): 1190 x 600 x 655 mmDimensions (WxDxH): 1280 x 790 x 2180 mmWeight: 240 kgEquipped with:Adjustable ellectric base stand (225 mm range)UV light

Speeds: Choice of 3 options, Instrument has “Interleaved” speeds when manufactured. Interleaved: LV/ (more)RV (18 speeds) 8 LV speeds followed by 10 RV speeds Sequential: LV/RV (18 speeds) 8 LV speeds and 10 RV speeds arranged in sequential order from lowest 0.3 rpm to highest 100 rpm. Custom: 54 speeds, user selectable External (PC Control): 0.01 – 200 rpm, 0.01 rpm increments from 0.01 to 0.99 rpm, 0.1 rpm increments from 1.0 to 200 rpm Temperature Sensing Range: -100˚C to 300˚C Temperature Accuracy: ±1°C (-100°C to 149°C), ±2°C (150°C to 300°C) Viscosity Range: 15 to 6000000 cP Viscosity Accuracy: ±1.0% of full scale range. Viscosity Repeatability: ±0.2% of Full Scale Range Weight: 9 kg Including spindles: LV – 1 LV – 3 LV – 4 LV – 62 Excluding temperature probe!

Compact, universal small shaker suitable for shaking tasks with all small vessels. Two operating mod (more)es: Mode A (safe mode with attachment detection) the maximum speed of 3.000 rpm is only reached with the standard attachment in touch mode. When using other attachments the speed is limited to 1.300 rpm. Mode B (without attachment detection) a speed of 3.000 rpm is possible with all attachments. Orbital shaking movement amplitude 4.5 mm Speed 0 – 3000 rpm Dimensions (lxwxh) 148 x 205 x 63 mm Weight 2.9 kg

Increase your lab’s efficiency with the variable speed Thermo Scientific Tube Revolver / Rotator. A  (more)small footprint, flexible design and simple display help increase flexibility and effectiveness. Speed Range: 10 to 40 rpm Capacity combination of 4 paddles of: 7 x 10 to 15 mL tubes 7 x 5 to 7 mL tubes 15 x 1.5 to 2 mL tubes 21 x 0.5 to 0.8 mL tubes One paddle of 6 x 50 mL tubes Dimensions (LxWxH): 154 x 225 x 195 mm Weight: 1.2 kg Includes: Two 10/15 mL paddles Two 5/7 mL paddles Two 1.5/2 mL paddles Two 0.5/0.8 mL paddles One 50mL paddle
