IKA DB 5.2 Vial Dry Block (15 mm)

IKA DB 5.1 Vial Dry Block (12 mm)

IKA DB 4.9 Round Bottom Tubes Dry Block (17/18 mm)

IKA DB 4.8 Round Bottom Tubes Dry Block (35 mm)

IKA DB 4.7 Round Bottom Tubes Dry Block (25 mm)

IKA DB 4.6 Round Bottom Tubes Dry Block (20 mm)

IKA DB 4.5 Round Bottom Tubes Dry Block (15/16 mm)

IKA DB 4.4 Round Bottom Tubes Dry Block (12/13 mm)

IKA DB 4.3 Round Bottom Tubes Dry Block (12/13 mm)

IKA DB 4.2 Round Bottom Tubes Dry Block (10 mm)

IKA DB 4.1 Round Bottom Tubes Dry Block (6 mm)

IKA DB 3.3 Test Tube Combination Dry Block (0.5 ml / 1.5 ml / 2.0 ml)

IKA DB 3.2 Test Tube Combination Dry Block (1.5 ml / 15 ml / 50 ml)

IKA DB 3.1 Test Tube Combination Dry Block (6 mm/ 12/13 mm / 25 mm)

IKA DB 2.2 Conical Tube Dry Block (50 ml)

IKA DB 2.1 Conical Tube Dry Block (15 ml)

IKA DB 1.5 Corning Microtube Dry Block (2.0 ml)

IKA DB 1.4 VWR/Eppendorf Microtube Dry Block (2.0 ml)

IKA DB 1.3 VWR Microtube Dry Block

IKA DB 1.2 Eppendorf Microtube Dry Block

IKA DB 1.1 PCR Tube Dry Block

IKA color squid white Speed Range 50 to 1,700 rpm Stirring quantity max. per stirring position (H2O) (more) 1L Setting accuracy speed 10 rpm Features - Compact design to ensure portability. - Digital speed display (LED) for easy monitoring. - Wide speed range of 0 to 2,500 RPM for compatibility with a variety of applications. - Outstanding chemical resistance with glass top and synthetic bottom made of TPC-ET. - Protection class of IP 54 for moderate protection against solid objects and water ingress. Small magnetic stirrer with glass surface.INCLUDED: The IKA color squid white includes: - IKA color squid white - Manufacturer's Documentation - 2 Year Manufacturer's Warranty

IKA CBC ROTAVISC SBS me-vi Viscometer Package Viscosity Measuring Range 40,000,000 mPas Speed Range (more) 0.01 to 200 rpm Working Temperature -100 to 300°C Features - A second beaker (600 ml) can be pre-tempered during the measurement - Optimized water flow management in the insulated bath for fast and precise temperature control - Equipped with the environmentally friendly natural refrigerant R290 - CBC VISC lite can also be used for heating standard vessels according to DIN for absolute viscosity definition with ELVAS spindles or double-walled beakers - The easily removable and cleanable air filter guarantees optimum performance - ROTAVISC and CBC VISC lite are compatible with the labworldsoft® laboratory software, enabling easy automation, control and documentation of measurement results The viscosity of most liquids depends on the temperature. To obtain reliable measurement results, accurate temperature control is crucial. The CBC ROTAVISC SBS me-vi Package is the perfect solution for precise viscosity measurement of temperature-dependent samples in the laboratory. The ready-to-connect package combines the ROTAVISC SBS me-vi rotational viscometer with the CBC VISC lite heating and cooling bath circulator. The sample is measured directly in the heating bath under controlled conditions. ROTAVISC SBS me-vi is a high-performance rotational viscometer for applications in a measuring range from 100 to 40,000,000 mPas. Equipped with advanced ball bearing technology (SBS - steel ball bearing, suspended), it offers exceptional reliability, even in demanding applications with high sample throughput, frequent spindle or location changes or under rather harsh environmental conditions.The CBC VISC lite heating and cooling bath circulator was specially developed for use with IKA viscometers. It covers a temperature range from -25 °C to 125 °C and offers space for two standard beakers (600 ml). This allows a second sample to be pre-tempered during the measurement. Equipped with natural refrigerant R290, the CBC VISC lite is a sustainable and environmentally friendly alternative.INCLUDED: The IKA CBC ROTAVISC SBS me-vi Viscometer Package includes: - ROTAVISC SBS me-vi control - ROTASTAND - CBC VISC lite - SP set-2 - PT 100.8 - Power Cord - Operator's Guide - Two Year Manufacturer's Warranty

IKA CBC ROTAVISC me-vi Viscometer Package Viscosity Measuring Range 40,000,000 mPas Speed Range 0.0 (more)1 to 200 rpm Working Temperature -100 to 300°C Features - A second beaker (600 ml) can be pre-tempered during the measurement - Optimized water flow management in the insulated bath for fast and precise temperature control - Equipped with the environmentally friendly natural refrigerant R290 - CBC VISC lite can also be used for heating standard vessels according to DIN for absolute viscosity definition with ELVAS spindles or double-walled beakers - The easily removable and cleanable air filter guarantees optimum performance - ROTAVISC and CBC VISC lite are compatible with the labworldsoft® laboratory software, enabling easy automation, control and documentation of measurement results The viscosity of most liquids depends on the temperature. To obtain reliable measurement results, accurate temperature control is crucial. The CBC IKA CBC ROTAVISC me-vi Viscometer Package is the perfect solution for precise viscosity measurement of temperature-dependent samples in the laboratory. The ready-to-connect package combines the IKA CBC ROTAVISC me-vi Viscometer Package rotational viscometer with the CBC VISC lite heating and cooling bath circulator. The sample is measured directly in the heating bath under controlled conditions. IKA CBC ROTAVISC me-vi Viscometer Package is a high-performance rotational viscometer for applications in a measuring range from 100 - 40,000,000 mPas. The CBC VISC lite heating and cooling bath circulator was specially developed for use with IKA viscometers. It covers a temperature range from -25 °C to 125 °C and offers space for two standard beakers (600 ml). This allows a second sample to be pre-tempered during the measurement. Equipped with natural refrigerant R290, the CBC VISC lite is a sustainable and environmentally friendly alternative.INCLUDED: The IKA CBC ROTAVISC me-vi Viscometer Package includes: - ROTAVISC me-vi control S000 - ROTASTAND - CBC VISC lite - SP set-1 - PT 100.8 - Power Cord - Operator's Guide - Two Year Manufacturer's Warranty

IKA CBC ROTAVISC lo-vi Viscometer Package Viscosity Measuring Range 6,000,000 mPas Speed Range 0.01 (more) to 200 rpm Working Temperature -100 to 300°C Features - A second beaker (600 ml) can be pre-tempered during the measurement - Optimized water flow management in the insulated bath for fast and precise temperature control - Equipped with the environmentally friendly natural refrigerant R290 - CBC VISC lite can also be used for heating standard vessels according to DIN for absolute viscosity definition with ELVAS spindles or double-walled beakers - The easily removable and cleanable air filter guarantees optimum performance - ROTAVISC and CBC VISC lite are compatible with the labworldsoft® laboratory software, enabling easy automation, control and documentation of measurement results The viscosity of most liquids depends on the temperature. To obtain reliable measurement results, accurate temperature control is crucial. The CBC ROTAVISC lo-vi Package is the perfect solution for precise viscosity measurement of temperature-dependent samples in the laboratory. The ready-to-connect package combines the ROTAVISC lo-vi rotational viscometer with the CBC VISC lite heating and cooling bath circulator. The sample is measured directly in the heating bath under controlled conditions. ROTAVISC lo-vi is a high-performance rotational viscometer for applications in a measuring range from 1 - 6,000,000 mPas. The CBC VISC lite heating and cooling bath circulator was specially developed for use with IKA viscometers. It covers a temperature range from -25 °C to 125 °C and offers space for two standard beakers (600 ml). This allows a second sample to be pre-tempered during the measurement. Equipped with natural refrigerant R290, the CBC VISC lite is a sustainable and environmentally friendly alternative.INCLUDED: The IKA CBC ROTAVISC lo-vi Viscometer Package includes: - ROTAVISC lo-vi control S000 - ROTASTAND - CBC VISC lite - SP set-1 - PT 100.8 - Power Cord - Operator's Guide - Two Year Manufacturer's Warranty

IKA C-Mag MS 7 Magnetic Stirrer Speed Range 100 to 1,500 RPM Stirring Quantity Max. 10 l Set-up Pl (more)ate Material Ceramic Features - Powerful motor for stirring quantities of up to 10 l (H2O) - Elevated control panel for protection against leaking liquids - Speed range: 100 - 1500 rpm - Simple controls ensure ease of use an integration within lab space - Small footprint for efficient usage of benchtop space The IKA C-Mag MS 7 Magnetic Stirrer is designed for stirring tasks without heating, featuring a ceramic set-up plate that provides excellent chemical resistance. It is equipped with a powerful motor capable of stirring quantities up to 10 liters (H2O) at speeds ranging from 100 to 1500 rpm. The elevated control panel protects against leaking liquids, ensuring safe and reliable operation. The stirrer has one stirring position, with a motor rating output of 1.5 W and a left direction of rotation. The device offers speed control via a scale from 0 to 6, and can accommodate stirring bars up to 80 mm in length. The compact design measures 220 x 105 x 335 mm and weighs 5 kg, making it ideal for various laboratory environments. It operates within a permissible ambient temperature range of 5 to 40 °C and a relative humidity of up to 80%.

IKA C-Mag MS 4 Magnetic Stirrer Speed Range 100 to 1,500 RPM Stirring Quantity Max. 5 l Set-up Pla (more)te Material Ceramic Features - Powerful motor for stirring quantities of up to 5 l (H2O) - Elevated control panel for protection against leaking liquids - Speed range: 100 - 1500 rpm - Simple dial based operation ensures ease of use across a variety of laboratory functions - Ceramic Plate material provides durability and resistance against some corrosive sampels The IKA C-Mag MS 4 Magnetic Stirrer is a robust magnetic stirrer designed for stirring quantities up to 5 liters (H2O) without heating. It features a powerful motor with a speed range of 100 - 1500 rpm and a ceramic set-up plate that offers excellent chemical resistance. The elevated control panel protects against leaking liquids, ensuring safe operation. This stirrer has a single stirring position, with a motor rating output of 1.5 W and a left direction of rotation. The compact design, with dimensions of 150 x 105 x 260 mm and a weight of 3 kg, makes it suitable for various laboratory environments. It operates within a permissible ambient temperature range of 5 - 40 °C and a relative humidity of up to 80%.

IKA C-Mag MS 10 Magnetic Stirrer Speed Range 100 to 1,500 RPM Stirring Quantity Max. 15 l Set-up  (more)Plate Material Ceramic Features - Powerful motor for stirring quantities of up to 15 l (H2O) - Elevated control panel for protection against leaking liquids - Speed range: 100 - 1500 rpm - Simple controls ensure ease of use an integration in a lab space - Small footprint for optimization of benchtop space usage The IKA C-Mag MS 10 Magnetic Stirrer is a powerful and versatile laboratory tool designed for stirring quantities up to 15 liters (H2O) without heating. Featuring a durable ceramic set-up plate, it offers excellent chemical resistance, making it suitable for a wide range of applications. The stirrer operates within a speed range of 100 to 1500 rpm, controlled via a scale from 0 to 6, and can accommodate stirring bars up to 80 mm in length. The elevated control panel protects against leaking liquids, ensuring safe and reliable operation. With dimensions of 300 x 105 x 415 mm and a weight of 6 kg, the IKA C-Mag MS 10 is compact and easy to integrate into any laboratory setting. It operates efficiently within an ambient temperature range of 5 to 40 °C and relative humidity up to 80%, with a motor rating output of 1.5 W and a power input of 30 W.

IKA C-MAG HS 7 Magnetic Hotplate Stirrer Package Magnetic stirrer with ceramic heating plate. Bush (more)ing according to DIN 12878 for connecting a contact thermometer, e.g. ETS-D5. Click Here to View Product Video INCLUDED: The IKA C-MAG HS 7 Magnetic Hotplate Stirrer Package includes: - C-MAG HS 7 - ETS-D5 - H 16 V Support rod - H 44 Boss head clamp - H 38 Holding rod - Power Cord - Operator's Guide - Manufacturer's Documentation - 2 Year Manufacturer Warranty ( + Additional Free 1 Year Warranty Extension with IKA Registration) IKA C-MAG HS 7 Magnetic Hotplate Stirrer Package Specifications Number of stirring positions1Stirring quantity max. per stirring position (H2O)10 lMotor rating output1.5 WDirection of rotationleftSpeed controlscale 0 - 6Speed range100 - 1500 rpmStirring bar length max.80 mmSelf-heating of the set-up plate by max. stirring (RT:22°C/duration:1h)1 +KHeat output1000 WTemperature display set-valueLEDTemperature display actual-valueLEDHeating temperature range50 - 500 °CHeat control Turning knobHeating rate heating plate 5 K/minTemperature setting resolution of heating plate 5 KConnection for ext. temperature sensorETS-D5Fixed safety circuit550 °CSet-up plate materialceramicSet-up plate dimensions180 x 180 mmDimensions (W x H x D)220 x 105 x 335 mmWeight5 kgPermissible ambient temperature5 - 40 °CPermissible relative humidity80 %Protection class according to DIN EN 60529IP 21Voltage230 / 120 / 100 VFrequency50/60 HzPower input1020 WComparison of ModelsSpecificationsC-MAG HS 10 DigitalC-MAG HS 10C-MAG HS 4 DigitalC-MAG HS 4C-MAG HS 7 ControlC-MAG HS 7 Control PackageC-MAG HS 7 DigitalC-MAG HS 7C-MAG HS 7 PackageTemperature Range (°C)50 to 50050 to 50050 to 50050 to 500Ambient to 500Ambient to 50050 to 50050 to 50050 to 500Speed Range (RPM)100 to 1,500100 to 1,500100 to 1,500100 to 1,50050 to 1,50050 to 1,500100 to 1,500100 to 1,500100 to 1,500Heat Output (W)1500150025025010001000100010001000Platform Dimensions (mm)260 x 260260 x 260100 x 100100 x 100180 x 180180 x 180180 x 180180 x 180180 x 180Dimensions (W x H x D) (mm)300 x 105 x 415300 x 105 x 415150 x 105 x 260150 x 105 x 260220 x 88 x 354220 x 88 x 354215 x 105 x 330220 x 105 x 335220 x 105 x 335.comparison-table tr td:nth-child(10) { background-color: #fffacd; }

IKA C-Mag HS 7 Magnetic Hotplate Stirrer Speed Range 100 to 1,500 RPM Heating Temp. Range 50 to 50 (more)0°C Stirring Quantity Max. 10 l Features - Powerful motor for stirring quantities of up to 10 l (H2O) - Fixed safety circuit of 550 °C - Hot Top indicator >hot surface warning to prevent burns! - Exact temperature setting via digital display (LED) - Bushing according to DIN 12878 for connecting a contact thermometer, e.g. ETS-D5, enables precise temperature control - Digital error code display - Elevated control panel for protection against leaking liquids The IKA C-Mag HS 7 Magnetic Hotplate Stirrer features one stirring position with a maximum stirring quantity of 10 liters (H2O). It is equipped with a powerful motor with an output of 1.5 W and a speed range of 100 - 1500 rpm. The heat output is 1000 W, and it offers a heating temperature range from 50 to 500 °C. The set-up plate, made of chemical-resistant ceramic, measures 180 x 180 mm. The stirrer includes an LED temperature display for both set and actual values, a turning knob for heat control, and a fixed safety circuit of 550 °C. Additionally, it has a Hot Top indicator for safety and a bushing for connecting an external temperature sensor (ETS-D5). The dimensions are 220 x 105 x 335 mm, and it weighs 5 kg.
